Fortinet AP433 Installation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Fortinet AP433
Installation Guide
.January 2014
Copyright© 2015 Fortinet, Inc. All rights reserved. Fortinet® and certain other marks are registered trademarks of
Fortinet, Inc., in the U.S. and other jurisdictions, and other Fortinet names herein may also be registered and/or
common law trademarks of Fortinet. All other product or company names may be trademarks of their respective
owners. Performance and other metrics contained herein were attained in internal lab tests under ideal condi-
tions, and actual performance and other results may vary. Network variables, different network environments and
other conditions may affect performance results. Nothing herein represents any binding commitment by Fortinet,
and Fortinet disclaims all warranties, whether express or implied, except to the extent Fortinet enters a binding
written contract, signed by Fortinet's General Counsel, with a purchaser that expressly warrants that the identified
product will perform according to certain expressly-identified performance metrics and, in such event, only the
specific performance metrics expressly identified in such binding written contract shall be binding on Fortinet. For
absolute clarity, any such warranty will be limited to performance in the same ideal conditions as in Fortinet's
internal lab tests. In no event does Fortinet make any commitment related to future deliverables, features or
development, and circumstances may change such that any forward-looking statements herein are not accurate.
Fortinet disclaims in full any covenants, representations, and guarantees pursuant hereto, whether express or
implied. Fortinet reserves the right to change, modify, transfer, or otherwise revise this publication without notice,
and the most current version of the publication shall be applicable.
