Samsung S85 Service Manual

Hide thumbs Also See for S85:
Table of Contents

Advertisement

Quick Links

See also: User Manual

Advertisement

Table of Contents
loading

Related Manuals for Samsung S85

Summary of Contents for Samsung S85

  • Page 2: Table Of Contents

    C O N T E N T S Ⅰ Ⅰ . SPECIFICATION 1. CAMERA SPECIFICATION……………………………………………………………………………………… 4 2. System Requirements …………………………………………………………………………………………… 7 3. LCD monitor indicator …………………………………………………………………………………………… 8 4. CONNECTION DIAGRAM ……………………………………………………………………………………… 11 5. IDENTIFICATION OF FEATURES …………………………………………………………………………… 12 Ⅱ Ⅱ . . EXPLODED VIEW AND PARTS LIST 1.
  • Page 3 Ⅴ Ⅴ . CIRCUIT DIAGRAM ………………………………………………………………………………………… 61 1)MAIN_COACH9S GPIO ………………………………………………………………………………… 62 2) MAIN_COACH9S VOLATGE UI ………………………………………………………………………………………………… 63 3) MAIN_MEMORY …………………………………………………………………………………………………… 64 4) MAIN_USB IF …………………………………………………………………………………………… 65 5) MAIN_LENS DRIVER ……………………………………………………………………………………………………… 66 6) MAIN_LCD ………………………………………………………………………………………… 67 7) MAIN_SYSTEM BLOCK ………………………………………………………………………………………… 68 8) MAIN_POWER BLOCK …………………………………………………………………………………………………...

  • Page 4: Camera Specification

    Ⅰ. SPECIFICATION 1. CAMERA SPECIFICATION Image Sensor - Type : 1/2.5" CCD - Effective Pixel : Approx. 8.2 Mega-pixel - Total Pixel : Approx. 8.3 Mega-pixel Lens - Focal Length : SHD Lens f = 6.3 ~ 31.5mm (35mm film equivalent : 38 ~ 190mm) - F No.
  • Page 5 · Audio : WAV - Image Size 3264x2448 3264x2176 3264x1824 2592x1944 2048x1536 1024x768 - Capacity (256MB MMC) Super Fine Fine Normal * These figures are measured under Samsung’s standard conditions and may vary depending on shooting conditions and camera settings.
  • Page 6 * Included battery may depending on sales region. Dimensions (WxHxD) - 100.3 X 63 X 23.4mm (excluding protrusions) Weight - Approx. 154g (without batteries and card) Operating Temperature - 0 ~ 40° C Operating Humidity - 5 ~ 85% Software - Samsung Master, Adobe Reader...

  • Page 7: System Requirements

    Ⅰ. SPECIFICATION 2. System Requirements For Windows For Macintosh PC with processor better than Pentium II 450MHz Power Mac G3 or later (Pentium 800MHz recommended) Windows 98SE/2000/ME/XP/Vista Mac OS 10.0 ~ 10.4 Minimum 128MB RAM Minimum 64MB RAM (Over 512MB recommended) (Over 256MB recommended) 200MB of available hard disk space 110MB of available hard-disk space...

  • Page 8: Lcd Monitor Indicator

    Ⅰ. SPECIFICATION 3. LCD monitor indicator ■ Recording mode [ Image & Full Status ]...
  • Page 9 Ⅰ. SPECIFICATION Description Icons Recording mode Memory card icon / Internal memory icon Number of available shots remaining Remaining time 00:00:00 Voice Memo Optical / Digital Zoom bar / Digital Zoom rate Battery Image Size Image Quality / Frame Rate Metering Drive mode White Balance...
  • Page 10 Ⅰ. SPECIFICATION ■ Play mode Description Icons Playback mode Memory card indicator Folder name & File name 100-0010 Battery 50 ~ 1600 Aperture value F2.8 ~ F4.6 Shutter speed 15 ~ 1/2000 Flash ON/OFF Image size 3264X2448 ~ 320X240 Recording date 2007/08/01 DPOF Protect...
  • Page 11 Ⅰ. SPECIFICATION 4 4 . . C C O O N N N N E E C C T T I I O O N N D D I I A A G G R R A A M M SD Card Card Reader TV Monitor...

  • Page 12: Identification Of Features

    Ⅰ. SPECIFICATION 5. IDENTIFICATION OF FEATURES Front & Top Mode dial Power button Shutter button Speaker Flash Self-timer lamp / AF sensor USB / AV connection terminal Lens/ Lens cover DC input connection port Microphone Back Camera status lamp Zoom T button (Digital zoom) Zoom W button (Thumbnail) E (Effects) button Strap eyelet...
  • Page 13 Ⅰ. SPECIFICATION Bottom Tripod socket Battery chamber cover Memory card slot Battery chamber 5 Function button Information/ Up button MENU/ OK button Flash/ Self-timer/ Left button Right button Macro/ Down button Play & Pause button...

  • Page 14: Main Assembly

    Ⅱ. EXPLODED VIEW AND PART LIST 1. MAIN ASSEMBLY...

  • Page 15: Frame Assembly

    Ⅱ. EXPLODED VIEW AND PART LIST 2. FRAME ASSEMBLY 2-18 2-24 2-15 2-23 2-25 2-21 2-19 2-23 2-20 2-22 2-16 2-15 2-13 2-14 2-37 2-38 2-39 2-35 2-11 2-10 2-12 2-40 2-33 2-36 2-27 2-32 2-26 2-29 2-30 2-34 2-28 2-31...

  • Page 16: Barrel Assembly

    Ⅱ. EXPLODED VIEW AND PART LIST 3. BARREL ASSEMBLY 3-24 3-56 3-20 3-55 3-19 3-12 3-22 3-11 3-23 3-13 3-16 3-17 3-10 3-21 3-14 3-15 3-54 3-18 3-57 3-43 3-42 3-41 3-40 3-39 3-58 3-60 3-61 3-40 3-40 3-34 3-38 3-35 3-34 3-36...

  • Page 17: Front Cover Assembly

    Ⅱ. EXPLODED VIEW AND PART LIST 4. FRONT COVER ASSEMBLY...

  • Page 18: Middle Cover Assembly

    Ⅱ. EXPLODED VIEW AND PART LIST 5. MIDDLE COVER ASSEMBLY 5-18 5-16 5-12 5-10 5-13 5-11 5-14 5-17 5-15...

  • Page 19: Back Cover Assembly

    Ⅱ. EXPLODED VIEW AND PART LIST 6. BACK COVER ASSEMBLY 6-10 6-11...

  • Page 20: Packing Item

    Ⅱ. EXPLODED VIEW AND PART LIST 7. PACKING ITEM 8-18 7-15 7-16 7-10 7-11 7-13 7-17 7-14 7-12 7-19...
  • Page 21 Fig No Old Code New Code Parts Name Q'ty Supply Remark 1.MAIN ASSEMBLY Q8100023801A AD81-05603A TAPPING_SCREW Q6002026301A AD81-01116A SCREW Q8100097701A AD81-06343A TAPPING_SCREW Q8100025501A AD81-05620A TAPPING_SCREW 2.FRAME ASSEMBLY Q8100098201A AD81-06348A FRAME Q8100098301A AD81-06349A MYLAR_CHASSIS Q8100098401A AD81-06350A SMT_ASSY -STROBE Q6002026301A AD81-01116A SCREW Q8100098501A AD81-06351A SPEAKER Q8100098601A AD81-06352A...
  • Page 22 2-32 Q8100100601A AD81-06372A BATTERY_DOOR_BLK 2-33 Q8100103201A AD81-06398A BTCN_CHASSIS_SID Q8100103301A AD81-06399A BATTERY_COVER_ASSY_SILVER 2-34 Q8100103401A AD81-06400A BATTERY_COVER_ASSY_BLACK 2-35 Q8100104501A AD81-06411A FLASH_TOP_ASSY Q9002170801A AD97-15008A BARREL SILVER 2-36 Q9002170901A AD97-15009A BARREL BLACK 2-37 Q8100104701A AD81-06413A CCD_RUBBER 2-38 Q8100104801A AD81-06414A CCD_IR_CUT 2-39 Q8100100901A AD81-06375A CCD_PCB ASSY 2-40 Q8100104901A AD81-06415A CCD_PLATE...
  • Page 23 3-29 Q7212204401A AD97-14958A ZOOM RING 3-30 Q7411133401A AD66-00579A 1st MOVE PIN 3-31 Q7212204501A AD67-00802A INNER GUIDE PLATE 3-32 Q7212204601A AD67-00803A INNER CAM BARREL 3-33 Q9002163901A AD97-15029A 2nd LENS ASSY 3-34 Q7411133901A AD66-00580A MOVE PIN 3-35 Q9005163801A AD97-15041A SHUTTER ASS'Y 3-36 Q7012096001A AD66-00574A SHUTTER FPCB GUIDER 3-37...
  • Page 24 Q9002170801A AD97-15008A BARREL_ASSY_U5_SILVER 3-64 Q9002170901A AD97-15009A BARREL_ASSY_U5_BLACK 4.FRONT COVER ASSEMBLY Q8100095401A AD81-06320A FRONT_COVER_SILVER Q8100103501A AD81-06401A FRONT_COVER_BLACK Q8100095501A AD81-06321A SAMSUNG-BADGE Q8100095701A AD81-06323A GRIP_S85 Q8100095801A AD81-06324A AF_COVER Q8100095901A AD81-06325A MIC_NONWOVEN Q8100096001A AD81-06326A LENS_RING_DOUBLE_TAPE Q8100096101A AD81-06327A LENS_RING_DECO Q8100103601A AD81-06402A FRONT_COVER_ASSY_SILVER KENOX Q8100103701A AD81-06403A...
  • Page 25 Q8100101101A AD81-06377A LCD_SPONGE Q8100101201A AD81-06378A PLATE_ESD Q8100101301A AD81-06379A FUNCTION_BUTTON Q8100101401A AD81-06380A 4_WAY_BUTTON Q8100101501A AD81-06381A OK_BUTTON Q8100101601A AD81-06382A T/W_BUTTON_SILVER Q8100101701A AD81-06383A SPRING_T/W_BUTTON Q8100101801A AD81-06384A T/W_BUTTON SHAFT 6-10 Q8100101901A AD81-06385A LED_BACK Q8100097601A AD81-06342A REAR_COVER_ASSY_SILVER 6-11 Q8100104301A AD81-06409A REAR_COVER_ASSY_BLACK...
  • Page 26 7.PACKING ITEM QP960210101A 6902-000924 PE BAG (FOR CAMERA) Q6909018201A AD81-02635A PE BAG (FOR ACCESSORY) Q6909019601A 6902-000939 AIR BAG(FOR CAMERA)_L73/L83/S85 Q6901287201A AD69-01328A INNER_PAD_KENOX_S85_KOR_EXP Q6806449701A AD68-01861A QS_MANUAL_KENOX_S85 Q6806449801A AD68-01862A QS_MAN_S85_E_G_F_SP_I_DU_P_7 Q6806449901A AD68-01863A QS_MAN_S85_E_G_FI_SW_DA_RU_6 Q6806450001A AD68-01864A QS_MAN_S85_E_FR_TU_CH_IN_AR_TH_7 1 Q6806450101A AD68-01865A QS_MAN_S85_ENG_SPA_FRA_3 Q6806450201A AD68-01866A...
  • Page 27 7-17 Q3801001001A AD81-00682A AC CODE CABLE_UK-DSC220SE Q3801003701A AD81-00700A AC CODE CABLE_CHI-D1 Q3801003401B 3903-000349 AC CODE CABLE_AUS-D1 7-18 Q4301001801A AD81-00867A ALKALINE (1.5V, AA) 2EA - DURACEL ULTRA Q6809006602A AD68-02008A U_MANUAL_ROHS_CHI 7-19 Q6806448601A AD68-01860A U_MANUAL_S85_CHI_S...

  • Page 28: Firmware

    Ⅲ. ADJUSTMENT 1. FIRMWARE 1) Checking version 1. Remove the memory card from the camera. 2. Connect the AC adapter or a fully charged battery. 3. Turn the camera off. 4. Press and hold the PLAY button for approximately 2 seconds while holding down the TELE button and the OK button simultaneously.
  • Page 29 Ⅲ. ADJUSTMENT 2) Upgrading the Firmware 1. Insert the SD card containing the firmware file into the camera. ※ Updating the firmware will delete all the data in the Flash memory. Be sure to back up all the data onto your PC before updating the firmware.
  • Page 30 Ⅲ. ADJUSTMENT 5. Upgrade is progressed and the Status LED (Green) of the camera blinks during upgrade. When the upgrade is complete, the Power button LED is automatically turned off. 6. Turn the camera on again and run RESET in the SETUP menu.
  • Page 31 Ⅲ. ADJUSTMENT 2. Adjustment Procedures for Each Feature 1) Reading EEPROM You can read data from the EEPROM according to the procedures below. < Requirements > ① Special Cable (USB) ② EEPROM TOOL Program ③ Test Mode Recognition Driver ④ Camera to extract standard data...
  • Page 32 Ⅲ. ADJUSTMENT 1. Remove the memory card from the camera. 2. Connect the AC adapter or a fully charged battery. 3. Turn the camera off. 4. Press and hold the PLAY button for approximately 2 seconds while holding down the TELE button and the MENU button simultaneously.
  • Page 33 Ⅲ. ADJUSTMENT ② Press the MENU button to show the sub menu of the USB MODE. ③ Select OK for the USB MODE using the Left direction button and then press the MENU button.
  • Page 34 Ⅲ. ADJUSTMENT ④ The “MS to PC Mode" message appears on the LCD screen of the camera. 6. Connect the camera with the PC using the Adjustment Jack Board when the camera is in the MS to PC Mode.
  • Page 35 Ⅲ. ADJUSTMENT When Found New Hardware runs. When you connect the camera (USB MODE Disable) to the PC for the first time, make the camera recognized according to the procedures below. After that, the camera will automatically be recognized by the PC when you connect the camera to the same ①...
  • Page 36 Ⅲ. ADJUSTMENT ③ When the camera is recognized, click the "Finish" button. ④ To confirm that the camera is properly recognized, check if the camera is registered as an Imaging Device in the Control Panel – Device Manager window.
  • Page 37 Ⅲ. ADJUSTMENT 7. Download and uncompress the EEPROM TOOL program. (Installation is not necessary.) 8. Run the EEPROM TOOL program. 9. If you click the Read From Camera from the EEPROM TOOL program menu, EEPROM data is loaded and the OK message appears at the bottom.
  • Page 38 Ⅲ. ADJUSTMENT 10. Click the Write File from the EEPROM TOOL program menu to save the EEPROM data into a desired folder.
  • Page 39 Ⅲ. ADJUSTMENT ※ ※ Caution Make sure to set USB MODE to normal (so that USB MODE is marked as OK as shown by the figure below) before shipping the product. Normal State (USB MODE is marked as OK) Abnormal State (USB MODE is marked as NG)
  • Page 40 Ⅲ. ADJUSTMENT 2) Writing onto EEPROM You can write data onto the EEPROM according to the procedures below. < Requirements > ① Specal Cable (USB) ② EEPROM TOOL Program ③ Test Mode Recognition Driver ④ Camera onto which standard EEPROM data will be written...
  • Page 41 Ⅲ. ADJUSTMENT 1. Remove the memory card from the camera. 2. Connect the AC adapter or a fully charged battery. 3. Turn the camera off. 4. Press and hold the PLAY button for approximately 2 seconds while holding down the TELE button and the MENU button simultaneously.
  • Page 42 Ⅲ. ADJUSTMENT ② Press the MENU button to show the sub menu of the USB MODE. ③ Select OK for the USB MODE using the Left direction button and then press the MENU button.
  • Page 43 Ⅲ. ADJUSTMENT ④ The “MS to PC Mode" message appears on the LCD screen of the camera. 6. Connect the camera with the PC using the Adjustment Jack Board when the camera is in the MS to PC Mode.
  • Page 44 Ⅲ. ADJUSTMENT When Found New Hardware runs. When you connect the camera (USB MODE Disable) to the PC for the first time, make the camera recognized according to the procedures below. After that, the camera will automatically be recognized by the PC when you connect the camera to the same ①...
  • Page 45 Ⅲ. ADJUSTMENT ③ When the camera is recognized, click the "Finish" button. ④ To confirm that the camera is properly recognized, check if the camera is registered as an Imaging Device in the Control Panel – Device Manager window.
  • Page 46 Ⅲ. ADJUSTMENT 7. Download and uncompress the EEPROM TOOL program. (Installation is not necessary.) 8. If you click the Read File from the EEPROM TOOL program menu, and open a standard EEPROM data.
  • Page 47 Ⅲ. ADJUSTMENT 9. If you click the Write To Camera from the EEPROM TOOL program menu, the EEPROM data is written onto the camera and the OK message appears at the bottom, after a moment.
  • Page 48 Ⅲ. ADJUSTMENT ※ ※ Caution Make sure to set USB MODE to normal (so that USB MODE is marked as OK as shown by the figure below) before shipping the product. Normal State (USB MODE is marked as OK) Abnormal State (USB MODE is marked as NG)

  • Page 49: Parts Arrangement For Each Pcb Ass'y

    Ⅳ. PATTERN DIAGRAM 1. PARTS ARRANGEMENT FOR EACH PCB ASS’Y 1) MAIN_TOP...

  • Page 50: Main_Bottom

    Ⅳ. PATTERN DIAGRAM 2) MAIN_BOTTOM...

  • Page 51: Ccd_Top

    Ⅳ. PATTERN DIAGRAM 3) CCD_TOP...

  • Page 52: Ccd_Bottom

    Ⅳ. PATTERN DIAGRAM 4) CCD_BOTTOM...

  • Page 53: Strobe_Top

    Ⅳ. PATTERN DIAGRAM 5) STROBE_TOP...

  • Page 54: Strobe_Bottom

    Ⅳ. PATTERN DIAGRAM 6) STROBE_BOTTOM...

  • Page 55: Main_Coach9S Gpio

    Ⅴ. CIRCUIT DIAGRAM 1) MAIN_COACH9S GPIO...

  • Page 56: Main_Coach9S Volatge Ui

    Ⅴ. CIRCUIT DIAGRAM 2) MAIN_COACH9S VOLATGE UI...

  • Page 57: Main_Memory

    Ⅴ. CIRCUIT DIAGRAM 3) MAIN_MEMORY...

  • Page 58: Main_Usb If

    Ⅴ. CIRCUIT DIAGRAM 4) MAIN_USB IF...

  • Page 59: Main_Lens Driver

    Ⅴ. CIRCUIT DIAGRAM 5) MAIN_LENS DRIVER...

  • Page 60: Main_Lcd

    Ⅴ. CIRCUIT DIAGRAM 6) MAIN_LCD...

  • Page 61: Main_System Block

    Ⅴ. CIRCUIT DIAGRAM 7) MAIN_SYSTEM BLOCK...

  • Page 62: Main_Power Block

    Ⅴ. CIRCUIT DIAGRAM 8) MAIN_POWER BLOCK...

  • Page 63: Main_Power

    Ⅴ. CIRCUIT DIAGRAM 9) MAIN_POWER...

  • Page 64: Main_Ad9920

    Ⅴ. CIRCUIT DIAGRAM 10) MAIN_AD9920...

  • Page 65: Ccd

    Ⅴ. CIRCUIT DIAGRAM 11) CCD...

  • Page 66: Ccd Pin Define

    Ⅴ. CIRCUIT DIAGRAM 12) CCD Pin Define...

  • Page 67: Mode Dial

    Ⅴ. CIRCUIT DIAGRAM 13) MODE DIAL...

  • Page 68: Strobe

    Ⅴ. CIRCUIT DIAGRAM 14) STROBE...

  • Page 69: Service Information

    Ⅵ. SERVICE INFORMATION 1. The order of disassembly and assembly ■ ■ Caution 1. Do the disassembling and assembling camera where the blocking static electricity mat is on the table. 2. When handling the major PCBs of camera, please wearing the band which cuts off the electric current on the wrist.
  • Page 70 Ⅵ. SERVICE INFORMATION ■ ■ Disassembling the Camera 1. Remove the 2 screws. 2. Remove the 2 screws.
  • Page 71 Ⅵ. SERVICE INFORMATION 3. Remove the 4 screws. 4. Separate the Back Cover.
  • Page 72 Ⅵ. SERVICE INFORMATION 5. Separate the PCB from the connector. 6. Remove the 3 screws from the inside of the Front Cover.
  • Page 73 Ⅵ. SERVICE INFORMATION 7. Separate the Front Cover. 8. Detach the sticker at the microphone part.
  • Page 74 Ⅵ. SERVICE INFORMATION 9. Remove the 2 screws. 10. Separate the PCB from the connector.
  • Page 75 Ⅵ. SERVICE INFORMATION 11. Separate the LCD Assy. 12. Unsolder the contact points of the Top PCB and unsolder 2 wires from the PCB.
  • Page 76 Ⅵ. SERVICE INFORMATION 13. Remove the 2 screws. 14. Unsolder the battery terminals.
  • Page 77 Ⅵ. SERVICE INFORMATION 15. Separate the PCB from the connector. 16. Remove the 4 screws.
  • Page 78 Ⅵ. SERVICE INFORMATION 17. Separate the Main PCB. Bottom of the Main PCB (CCD is installed)
  • Page 79 Ⅵ. SERVICE INFORMATION Main PCB 18. Remove the 2 screws.
  • Page 80 Ⅵ. SERVICE INFORMATION 19. Separate the Flash PCB. 20. Remove the 3 screws.
  • Page 81 Ⅵ. SERVICE INFORMATION 21. Separate the barrel Assy.
  • Page 82 Ⅵ. SERVICE INFORMATION ■ ■ Disassembling the Barrel 1. Unsolder the wires from Shutter PCB and remove the 3 screws. 2. Separate the Lens Base Assy.
  • Page 83 Ⅵ. SERVICE INFORMATION 3. Remove the fixing pin from the Shutter PCB. 4. Remove the fixing pin from the Shutter PCB.
  • Page 84 Ⅵ. SERVICE INFORMATION 5. Separate the Outer Guide Barrel with reference to the part circled in red as shown below. 6. Separate the Outer Guide Barrel with reference to the part circled in red as shown below.
  • Page 85 Ⅵ. SERVICE INFORMATION 7. Separate the Outer Guide Barrel. 8. Separate the Inner Cam Barrel Assy with reference to the part circled in red as shown below.
  • Page 86 Ⅵ. SERVICE INFORMATION 9. Separate the Inner Cam Barrel Assy. 10. Separate the Lens Cap Assy with reference to the part circled in red as shown below.
  • Page 87 Ⅵ. SERVICE INFORMATION 11. Separate the Lens Cap Assy. (Check the reference point circled in blue for reassembly.) 12. Separate the Shutter Assy with reference to the part circled in red as shown below.
  • Page 88 Ⅵ. SERVICE INFORMATION 13. Separate the Shutter Assy. 14. Separate the Front Lens Group Assy with reference to the part circled in red as shown below.
  • Page 89 Ⅵ. SERVICE INFORMATION 15. Separate the Front Lens Group Assy. 16. Separate the Guide Plate as shown below.
  • Page 90 Ⅵ. SERVICE INFORMATION 17. Separate the Guide Plate. Reference for Assembly. Check the reference point circled in red for the assembly.
  • Page 91 Ⅵ. SERVICE INFORMATION Reference for Assembly. Check the point circled in red in relation to the Shutter PCB position for reassembly. Reference for Assembly. Check the position of the photo interrupter in relation to the Shutter PCB position for reassembly.
  • Page 92 Ⅵ. SERVICE INFORMATION Reference for Assembly. Check the position of the photo interrupter in relation to the Shutter PCB position for reassembly.
