OPERATING INSTRUCTIONS ON-OFF SWITCH/VOLUME CONTROL Rotate this knob clockwise to turn the radio on. Continue rota- tion until the desired volume level is obtained. Rotate the knob fully counter-clockwise to turn the unit off. TONE CONTROL (PUSH) Push this knob in and rotate it clockwise to emphasize treble response, counter-clockwise to emphasize bass response.
Page 3
AM/FM BAND SELECTOR (AM/FM) Each time this button is pressed, the radio band is changed. The indication “AM1”, “AM2”, “FM1”, “FM2”, or “FM3” will ap- pear on the display panel according to your selection. MANUAL UP/DOWN TUNING To manually select a radio station frequency, rotate the knob to the right.
Page 4
STATION PRE-SET MEMORIES To set any of the 6 pre-set memory buttons, use the following procedure: 1. Turn the unit on and select the desired band. 2. Select the first station to be pre-set using the Manual Up/Down or Automatic Seek Tuning functions.
TIME/FREQUENCY SELECTOR (T/F) During radio or CD/Auxiliary Input operation, press this button to call the time display on the incorporated quartz clock. Pressing the button again or activating any tuning function (during radio operation) will return to frequency or “Cd” display. During tape operation, the time display will always be shown.
SPECIFICATIONS Size: Operating Voltage: Output Power: Output Wiring: Output Impedance: Tuning Range: Sensitivity: FM Stereo Separation: Tape Frequency Response: Tape S/N Ratio: Wow & Flutter: 7" W 178 mm x 50 mm x 140 mm 12 volts DC, negative ground 14 watts maximum (7 watts x 2 channels) Common-ground type design for 4 speaker use.
CARE AND MAINTENANCE The radio portion of your new sound system does not require any maintenance. We recommend you keep this manual for future reference of the many features found in this unit. As with any cassette player, the cassette section of this sound system does require a minimum of maintenance to keep it in good working condition.
AUDIOVOX CORPORATION (the Company) warrants to the original retail purchaser of this product that should this product or any part thereof, under normal use and conditions, be proven defective in material or workmanship within 12 months from the date of original purchase, such defect(s) will be repaired or replaced with new or reconditioned product (at the Company's option) without charge for parts and repair labor.
