- Page 1 IB831 VIA VX900 5.25-inch Disk Size SBC USER’S MANUAL Version 1.0...
- Page 2 Acknowledgments AMI is a registered trademark of American Megatrends Inc. PS/2 is a trademark of International Business Machines Corporation. Microsoft Windows is a registered trademark of Microsoft Corporation. Winbond is a registered trademark of Winbond Electronics Corporation. All other product names or trademarks are properties of their respective owners.
-
Page 3: Table Of Contents
Table of Contents Introduction .............. 1 Product Description............. 1 Checklist ................2 Specifications ..............3 Board Dimensions ............... 4 Installations .............. 5 Installing the Memory ............6 Setting the Jumpers ............. 7 Connectors on IB831 ............9 Bypass and WDT .............. 15 Block Diagram: .............. - Page 4 This page is intentionally left blank. IB831 User’s Manual...
-
Page 5: Introduction
Currently, the board is available in three models, namely: Model VIA Nano LAN Bypass Watchdog Timer Dual Core CPU IB831 1.2 GHz IB831-NB 1.2 GHz IB831 Features Supports four Realtek 10/100/1000 LAN ports Supports 1.2GHz VIA Nano X2 U4300 processor ... -
Page 6: Checklist
INTRODUCTION Checklist Your IB831 package should include the items listed below. The IB831 VIA Nano X2 motherboard 1 CD containing chipset drivers and flash memory utility Optional cables for VGA, KB/MS, Serial port, Serial ATA IB831 User’s Manual... -
Page 7: Specifications
INTRODUCTION Specifications Form Factor Desktop / Table Top Networking Product VIA Nano X2 U4300 Dual Core @ 1.2 GHz, 13W x86 and x64 (64-bit) capability Bus speeds up to 1066 MHz Hardware Virtualization (VMX) VIA Virtualization (VIA-VT) ... -
Page 8: Board Dimensions
INTRODUCTION Board Dimensions 203 (W) x 146 (D) mm IB831 User’s Manual... -
Page 9: Installations
INSTALLATION Installations This section provides information on how to use the jumpers and connectors on the IB831 in order to set up a workable system. The topics covered are: Installing the Memory ..............6 Setting the Jumpers ..............7 Connectors on IB831 ..............9 Bypass and WDT ................ -
Page 10: Installing The Memory
INSTALLATION Installing the Memory The IB831 board supports one DDR3 memory socket for a maximum total memory of 2GB in DDR3 memory type. Installing and Removing Memory Modules To install the DDR3 modules, locate the memory slot on the board and perform the following steps: 1. -
Page 11: Setting The Jumpers
INSTALLATION Setting the Jumpers Jumpers are used on IB831 to select various settings and features according to your needs and applications. Contact your supplier if you have doubts about the best configuration for your needs. Jumper Locations on IB831 Jumpers on IB831 ................…7 J3: Clear CMOS Setting ................. - Page 12 INSTALLATION J3: Clear CMOS Setting Setting Normal Clear CMOS JP3 & JP4: Bypass LANs & Reboot Setting IB831 User’s Manual...
-
Page 13: Connectors On Ib831
INSTALLATION Connectors on IB831 The connectors on IB831 allow you to connect external devices such as keyboard, floppy disk drives, hard disk drives, printers, etc. The following table lists the connectors on IB831 and their respective functions. FAN1: CPU Fan Power Connector ............10 FAN2: System Fan Power Connector ........... - Page 14 INSTALLATION FAN1: CPU Fan Power Connector FAN1 is a 4-pin header for the CPU fan. The fan must be 12V (Max. 1A). Pin # Signal Name Ground +12V Rotation detection Rotation control FAN2: System Fan Power Connector FAN2 is a 4-pin header for system fans. The fan must be 12V (Max. 1A). Pin # Signal Name Ground...
- Page 15 INSTALLATION CN8: COM1 Serial Port Pin # Signal Name DCD, Data carrier detect RXD, Receive data TXD, Transmit data DTR, Data terminal ready Ground DSR, Data set ready RTS, Request to send CTS, Clear to send RI, Ring indicator SW1: System Reset CN1: Serial ATA Port J4: Parallel Port Signal Name...
- Page 16 INSTALLATION J6: PS/2 Keyboard and PS/2 Mouse Connectors Pin # Signal Name KBDA KBCL Ground +5VSUS J9: AT_12V Connector J9 is a DC-in internal connector supporting +12V. Pin # Signal Name +12V Ground J12: Mini PCI-E Connector (top side) Signal Signal Signal WAKE#...
- Page 17 INSTALLATION JP6: SPI Debug Port Signal Name Pin # Pin # Signal Name MSPISS0 SPIVCC MSPIDI -HOLD MSPICLK MSPIDO JP7: VGA Connector Signal Name Pin # Pin # Signal Name DACR +5VCRT DACG DACB CRT_SPD HSYNC_C +5VCRT VSYNC_C CRT_SPCLK JP8: HDD Power Connector (Output: Max. 2A) Pin # Signal Name Ground...
- Page 18 INSTALLATION CN2: Compact Flash Connector (top side) Signal Signal Signal IOW# INTRQ CSEL# NC/VS2 CS0# IOCS16# RESET# GND/A10 CD2# IORDY ATA_SEL# CD1# NC/NPACK# GND/A09 VCC/REG# GND/A08 DASP# GND/A07 PDIAG# GND/A06 GND/A05 CS1# GND/A04 GND/VS1# GND/A03 IOR# IB831 User’s Manual...
-
Page 19: Bypass And Wdt
INSTALLATION Bypass and WDT The bypass function is used to link (or short) two independent Ethernet ports when user’s application software halts or when power is off. Block Diagram: Bypass Relays Ethemet#1 RJ45 CN11 Ethemet#2 RJ45 CN12 Normal State Relays are "Energized" Relay I/O Command Driver... -
Page 20: Watchdog Timer Configuration
INSTALLATION Watchdog Timer Configuration The WDT is used to generate a variety of output signals after a user programmable count. The WDT is suitable for use in the prevention of system lock-up, such as when software becomes trapped in a deadlock. Under these sort of circumstances, the timer will count to zero and the selected outputs will be driven. - Page 21 INSTALLATION bBuf = Get_W627DHG_Reg(0x2D); bBuf &= (~0x01); Set_W627DHG_Reg(0x2D, bBuf); //Enable WDTO //--------------------------------------------------------------------------- void WDTEnable(unsigned char NewInterval) unsigned char bBuf; Set_W627DHG_LD(0x08); //switch to logic device 8 Set_W627DHG_Reg(0x30, 0x01); //enable timer bBuf = Get_W627DHG_Reg(0xF5); bBuf &= (~0x08); Set_W627DHG_Reg(0xF5, bBuf); //count mode is second Set_W627DHG_Reg(0xF6, NewInterval);...
- Page 22 INSTALLATION Init_Finish: return (result); //--------------------------------------------------------------------------- void Unlock_W627DHG (void) outportb(W627DHG_INDEX_PORT, W627DHG_UNLOCK); outportb(W627DHG_INDEX_PORT, W627DHG_UNLOCK); //--------------------------------------------------------------------------- void Lock_W627DHG (void) outportb(W627DHG_INDEX_PORT, W627DHG_LOCK); //--------------------------------------------------------------------------- void Set_W627DHG_LD( unsigned char LD) Unlock_W627DHG(); outportb(W627DHG_INDEX_PORT, W627DHG_REG_LD); outportb(W627DHG_DATA_PORT, LD); Lock_W627DHG(); //--------------------------------------------------------------------------- void Set_W627DHG_Reg( unsigned char REG, unsigned char DATA) Unlock_W627DHG(); outportb(W627DHG_INDEX_PORT, REG);...
-
Page 23: Gpio Function Definition
INSTALLATION GPIO Function Definition The IB831 has defined some of the GPI function to satisfy various requirements. Here are the definitions for the GPIO function: GPIO # Active Color Status1 GPIO37 Green Status2 GPIO36 Green Alarm GPIO35 IB831 User’s Manual... -
Page 24: Digital I/O Sample Configuration
INSTALLATION Digital I/O Sample Configuration Filename：Main.cpp //--------------------------------------------------------------------------- // THIS CODE AND INFORMATION IS PROVIDED "AS IS" WITHOUT WARRANTY OF ANY // KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE // IMPLIED WARRANTIES OF MERCHANTABILITY AND/OR FITNESS FOR A PARTICULAR // PURPOSE. - Page 25 INSTALLATION void Dio2Initial(void) unsigned char ucBuf; //switch GPIO multi-function pin Set_W627DHG_LD(0x09); //enable the GP2 group ucBuf = Get_W627DHG_Reg(0x30); ucBuf |= 0x01; Set_W627DHG_Reg(0x30, ucBuf); //input detect type Set_W627DHG_Reg(0xE5, 0x00); //--------------------------------------------------------------------------- void Dio2SetOutput(unsigned char NewData) //NewData : 1 for input, 0 for output Set_W627DHG_LD(0x09);...
- Page 26 INSTALLATION Set_W627DHG_LD(0x09); Set_W627DHG_Reg(0xF1, NewData); //--------------------------------------------------------------------------- unsigned char Dio3GetInput(void) unsigned char result; Set_W627DHG_LD(0x09); result = Get_W627DHG_Reg(0xF1); return (result); //--------------------------------------------------------------------------- void Dio3SetDirection(unsigned char NewData) //NewData : 1 for input, 0 for output Set_W627DHG_LD(0x09); Set_W627DHG_Reg(0xF0, NewData); //--------------------------------------------------------------------------- unsigned char Dio3GetDirection(void) unsigned char result; Set_W627DHG_LD(0x09);...
- Page 27 INSTALLATION W627DHG_BASE = 0x00; result = W627DHG_BASE; Init_Finish: return (result); //--------------------------------------------------------------------------- void Unlock_W627DHG (void) outportb(W627DHG_INDEX_PORT, W627DHG_UNLOCK); outportb(W627DHG_INDEX_PORT, W627DHG_UNLOCK); //--------------------------------------------------------------------------- void Lock_W627DHG (void) outportb(W627DHG_INDEX_PORT, W627DHG_LOCK); //--------------------------------------------------------------------------- void Set_W627DHG_LD( unsigned char LD) Unlock_W627DHG(); outportb(W627DHG_INDEX_PORT, W627DHG_REG_LD); outportb(W627DHG_DATA_PORT, LD); Lock_W627DHG(); //--------------------------------------------------------------------------- void Set_W627DHG_Reg( unsigned char REG, unsigned char DATA) Unlock_W627DHG();...
- Page 28 INSTALLATION //=========================================================================== void Set_W697HF_Reg( unsigned char REG, unsigned char DATA) Unlock_W697HF(); outportb(W697HF_INDEX_PORT, REG); outportb(W697HF_DATA_PORT, DATA); Lock_W697HF(); //=========================================================================== unsigned char Get_W697HF_Reg(unsigned char REG) unsigned char Result; Unlock_W697HF(); outportb(W697HF_INDEX_PORT, REG); Result = inportb(W697HF_DATA_PORT); Lock_W697HF(); return Result; //=========================================================================== Filename：W627DHG.h //--------------------------------------------------------------------------- // THIS CODE AND INFORMATION IS PROVIDED "AS IS" WITHOUT WARRANTY OF ANY // KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE // IMPLIED WARRANTIES OF MERCHANTABILITY AND/OR FITNESS FOR A PARTICULAR // PURPOSE.
-
Page 29: Bios Setup
BIOS SETUP BIOS Setup This chapter describes the different settings available in the AMI BIOS that comes with the board. The topics covered in this chapter are as follows: BIOS Introduction ..................26 BIOS Setup ....................26 Main BIOS Setup .................. -
Page 30: Bios Introduction
BIOS SETUP BIOS Introduction The BIOS (Basic Input / Output System) installed in your computer system’s ROM supports Intel processors. The BIOS provides critical low-level support for a standard device such as disk drives, serial ports and parallel ports. It also adds virus and password protection as well as special support for detailed fine-tuning of the chipset controlling the entire system. -
Page 31: Main Bios Setup
BIOS SETUP Main BIOS Setup This setup allows you to view processor configuration used in your computer system and set the system time and date. BIOS SETUP UTILITY Main Advanced PCIPnP Boot Security Chipset Exit Processor Use[ENTER], [TAB] or [SHIFT-TAB] to VIA Nano X2 U4300 @ 1.2 + GHz select a field. -
Page 32: Advanced Settings
BIOS SETUP Advanced Settings BIOS SETUP UTILITY Advanced Main PCIPnP Boot Security Chipset Exit Advanced Settings Configure CPU. WARNING: Setting wrong values in below sections may cause system to malfunction. ► CPU Configurations ► IDE Configuration ► Super IO Configuration ►... - Page 33 BIOS SETUP The CPU Configuration menu shows the following CPU details including the manufacturer, CPU type, its frequency and cache levels. Other options include: CMPXCHG8B instruction support If you want to install Windows NT 4.0 you must disable it. Enable MSR 3A [2] [0] VMX enable Enhanced C-state Disable or Enable...
-
Page 34: Serial Port1 Address
BIOS SETUP Enhanced SATA Power Management Enhance SATA Power Management HIPM Function Port1 SATA HIPM function control VIA SATA Driver Cap Port0 / 1 SATA Port Capability Enabling by VIA SATA driver BIOS SETUP UTILITY Advanced Main PCIPnP Boot Security Chipset Exit Configure Win627DHG Super IO Chipset... - Page 35 BIOS SETUP BIOS SETUP UTILITY Advanced Main PCIPnP Boot Security Chipset Exit Hardware Health Configuration System Temperature :34°C/93°F CPU Temperature :38°C/100°F VX900 Temperature :38°C/100°F SYSFAN Speed :0 RPM CPUFAN Speed :0 RPM :0.984 V Vcore <- Select Screen +12V :12.196 V +1.5VMem :1.568 V ↑↓...
-
Page 36: Acpi Version Features
BIOS SETUP BIOS SETUP UTILITY Advanced Main PCIPnP Boot Security Chipset Exit ACPI Settings Advance ACPI Configuration settings ►Advanced ACPI Configuration Use this section to configure additional ACPI options. <- Select Screen ↑↓ Select Item Change Field Tab Select Field General Help F10 Save and Exit ESC Exit... -
Page 37: Acpi Apic Support
BIOS SETUP ACPI APIC support Include ACPI APIC table pointer to RSDT pointer list. AMI OEMB table Include OEMB table pointer to R (X) SDT pointer lists. Headless mode Enable / Disable Headless operation mode through ACPI. BIOS SETUP UTILITY Advanced Main PCIPnP... - Page 38 BIOS SETUP BIOS SETUP UTILITY Advanced Main PCIPnP Boot Security Chipset Exit PCI Express Configuration Enable/Disable PCI Express Device Relaxed Ordering [Auto] Relaxed Ordering. Maximum Payload Size [Auto] Extended Tag field [Auto] <- Select Screen No Snoop [Auto] ↑↓ Select Item Maximum Read Request Size [Auto] Change Field...
-
Page 39: Usb Configuration
BIOS SETUP USB Configuration This option is used to configure USB mass storage class devices. BIOS SETUP UTILITY Advanced Main PCIPnP Boot Security Chipset Exit USB Configuration Enables support for legacy USB. AUTO Module Version – 2.24.5-13.4 option disables legacy support if USB Devices Enabled: no USB devices are 1 Keyboard... -
Page 40: Redirection After Bios Post
BIOS SETUP BIOS SETUP UTILITY Advanced Main PCIPnP Boot Security Chipset Exit Configure Remote Access type and parameters Select Remote Access type. Remote Access [Enabled] Serial port number [COM1] Base Address, IRQ [3F8h, 4] <- Select Screen Serial Port Mode [115200 8,n,1] ↑↓... -
Page 41: Pcipnp Settings
BIOS SETUP PCIPnP Settings BIOS SETUP UTILITY PCIPnP Main Advanced Boot Security Chipset Exit Advanced PCI/PnP Settings Clear NVRAM during System Boot WARNING: Setting wrong values in below sections may cause system to malfunction. Clear NVRAM [No] Plug & Play O/S [No] PCI Latency Timer [64]... - Page 42 BIOS SETUP Allocate IRQ to PCI VGA This assigns IRQ to PCI VGA card if card requests IRQ or doesn't assign IRQ to PCI VGA card even if card requests an IRQ. Palette Snooping This informs the PCI devices that an ISA graphics device is installed in the system so the card will function correctly.
-
Page 43: Boot Settings
BIOS SETUP Boot Settings This option configures the settings during system boot including boot device priority and HDD/CD/DVD drives. BIOS SETUP UTILITY Boot Main Advanced PCIPnP Security Chipset Exit Boot Settings Configure Settings during System Boot. ► Boot Settings Configuration ►... -
Page 44: Security Settings
BIOS SETUP Security Settings This setting comes with two options set the system password. Supervisor Password sets a password that will be used to protect the system and Setup utility. User Password sets a password that will be used exclusively on the system. -
Page 45: Advanced Chipset Settings
BIOS SETUP Advanced Chipset Settings This setting configures the north bridge and south bridge. WARNING! Setting the wrong values may cause the system to malfunction. - BIOS SETUP UTILITY Chipset Main Advanced PCIPnP Boot Security Exit Advanced Chipset Settings Configure North Bridge features. - Page 46 BIOS SETUP DDR2 Memory Chip ODT [DDR2/DDR Auto, Disabled, 75 ohm/60 ohm, 150 ohm/120 ohm, 50 ohm/40 ohm, NA/20 ohm, NA/30 ohm. DDR3 Dynamic ODT Auto, Disabled, RZQ/4 or RZQ/2 VGA Share Memory (Frame Buffer) 8, 16, 32, 64, 128, 256 or 512 MB Internal VGA DVO Support Disabled, DVOx8 or DVOx16 support.
- Page 47 BIOS SETUP BIOS SETUP UTILITY Chipset Main Advanced PCIPnP Boot Security Exit South Bridge VIA VX900 Configuration * Show SMBus Device Control [Disabled] * SATA Gen2 Support [Enabled] * ISA Master Support [Not Support] * HPET Support [Enabled] * SMBus Device Switch [New SMBus Device] <- Select Screen...
-
Page 48: Exit Setup
BIOS SETUP Exit Setup The exit setup has the following settings that are: BIOS SETUP UTILITY Exit Main Advanced PCIPnP Boot Security Chipset Exit Options Exit system setup after saving the changes. Save Changes and Exit Discard Changes and Exit Discard Changes <- Select Screen... -
Page 49: Drivers Installation
DRIVERS INSTALLATION Drivers Installation This section describes the installation procedures for software and drivers under the Windows OS. The software and drivers are included with the motherboard. If you find the items missing, please contact the vendor where you made the purchase. The contents of this section include the following: VIA VX900 VGA Driver Installation ......... -
Page 50: Via Vx900 Vga Driver Installation
DRIVERS INSTALLATION VIA VX900 VGA Driver Installation 1. Insert the CD that comes with the board and the screen below would appear. Choose VIA and click VIA VX900 Chipset Driver. The VIA Setup Wizard welcome screen will appear. 2. In the following window, click all the components to be installed, and click Next to continue. - Page 51 DRIVERS INSTALLATION 3. You are now asked to review setting before installing the components, click Yes to continue. 4. The following window shows you the installing status with the result. Click Continue Anyway. IB831 User’s Manual...
- Page 52 DRIVERS INSTALLATION 5. The installation process is now complete. Restart the computer as prompted for changes to take effect. IB831 User’s Manual...
-
Page 53: Realtek Lan Driver Installation
DRIVERS INSTALLATION Realtek LAN Driver Installation 1. Insert the CD that comes with the motherboard and the screen below would appear. Click on LAN Card. On the next screen, click on Realtek LAN Controller Drivers and Realtek RTL8111E LAN Drivers. When the welcome screen appears, click Next to continue. - Page 54 DRIVERS INSTALLATION This page is intentionally left blank. IB831 User’s Manual...
