[Router-luser-network-user1] service-type ppp
[Router-luser-network-user1] quit
# Configure an IPv6 prefix authorized to the user in the ISP domain.
[Router] domain system
[Router-isp-system] authorization-attribute ipv6-prefix 2003:: 64
[Router-isp-system] quit
Verifying the configuration
# Display PPP user information on GigabitEthernet 1/0/1.
[Router] display ppp access-user interface gigabitethernet 1/0/1
Interface
VA0
PPPoE server IPv6 address assignment through DHCPv6
configuration example
Network requirements
As shown in
Figure 16 Network diagram
Configuration procedure
# Create interface Virtual-Template 10.
<Router> system-view
[Router] interface virtual-template 10
# Configure interface Virtual-Template 10 to use PAP to authenticate the peer.
[Router-Virtual-Template10] ppp authentication-mode pap domain system
# Configure an IPv6 address for interface Virtual-Template 10.
[Router-Virtual-Template10] ipv6 address 3001::1 64
# Enable interface Virtual-Template 10 to advertise RA messages.
[Router-Virtual-Template10] undo ipv6 nd ra halt
# Configure the host to use the DHCPv6 protocol to obtain IPv6 addresses.
[Router-Virtual-Template10] ipv6 nd autoconfig managed-address-flag
# Enable the DHCPv6 server feature.
[Router-Virtual-Template10] ipv6 dhcp select server
[Router-Virtual-Template10] quit
# Enable the PPPoE sever on GigabitEthernet 1/0/1, and bind the interface to interface Virtual-Template
10.
[Router] interface gigabitethernet 1/0/1
[Router-GigabitEthernet1/0/1] pppoe-server bind virtual-template 10
Username
user1
Figure 16, configure the PPPoE server to assign an IPv6 address to the host through DHCPv6.
MAC address IP address
0000-5e08-9d00 -
60
IPv6 address
2003::9CBC:3898:0:605
