81170_2.BOOK Page iii Thursday, July 19, 2001 2:36 PM Raystar 120 GPS Receiver Owner’s Handbook SAFETY NOTICES 1. SERVICING There are no user serviceable parts or adjustments in this unit. The operator should never open the unit or attempt to service the equipment.
Warranty To register your Raystar 120 GPS Receiver ownership, please take a few minutes to fill out the Warranty registration card. It is very important that you complete the owner information and return the card to the factory in order to receive full warranty benefits.
Chapter 1: Introduction Chapter 1: Introduction 1.1 Satellite Differential System The Raystar 120 Satellite Differential GPS Receiver utilizes a new satellite differential system to improve the accuracy, integrity and availability of the basic GPS signals, resulting in satellite differential corrections and enhanced positional accuracy over standard GPS receivers.
Geostationary Satellites which broadcast the corrected data on the standard GPS frequency, making it available to the user’s Raystar 120 GPS Receiver. The Raystar 120 GPS Receiver uses the correctional data transmitted by the Geostationary Satellites to refine the GPS positional data for greater accuracy.
EGNOS is currently in the early testing and qualification phases and signal outages may occur at any time. The status of EGNOS and any planned outages are available on-line at Raymarine’s website: http://www.raymarine.com Use of Satellite Differential is currently disabled outside of the WAAS reception area.
The navigational accuracy of equipment using these satellite broadcast SD signals during the testing and qualification phases is not guaranteed by Raymarine Limited, nor is the continuation of the broadcast SD signals the responsibility of Raymarine Limited or Raytheon Corporation.
Raymarine equipment should be serviced only by authorized Raymarine service technicians. They will ensure that service pro- cedures and replacement parts used will not affect performance. There are no user serviceable parts in this Raymarine product. • When powered up, all electrical equipment produces electromag- netic fields.
81170_2.BOOK Page 1 Thursday, July 19, 2001 2:36 PM Chapter 2: Installation Chapter 2: Installation This handbook covers two models of the Raystar 120 NMEA Version - Part # E32026 SeaTalk Version - Part # E32025 2.1 EMC Installation Guidelines...
The more stable the unit, the easier it is to track satellites lower to the horizon. The Raystar 120 can be mounted on a pole. Alternatively, you can use the supplied surface mount kit.
81170_2.BOOK Page 3 Thursday, July 19, 2001 2:36 PM Chapter 2: Installation Surface Mounting Refer to Figure 2-1 : 1. Select a suitable area which allows access to the underside of the mounting surface for fixing and, using the template supplied in this document, carefully drill the two 6mm (0.25in) fixing holes marked.
81170_2.BOOK Page 4 Thursday, July 19, 2001 2:36 PM Raystar 120 GPS Receiver Top view Underside view D4725_1 Figure 2-1: Surface Mounting Arrangement Pole Mounting Refer to Figure 2-2 : 1. Screw the pole mount base to a suitable pole or rail mount bracket, having an industry standard 1in 14TPI thread, until secure.
81170_2.BOOK Page 5 Thursday, July 19, 2001 2:36 PM Chapter 2: Installation D4726-1 Figure 2-2: Pole Mounting Arrangement 2.3 Connections Two versions of this unit are available; SeaTalk and NMEA. NMEA Version The unit is normally connected to an NMEA system via a 33ft (10m) cable terminated with a moulded 6-pin connector.
Figure 2-3 to Figure 2-3 below. Note: As with all onboard marine equipment, the installer should en- sure that the power supply connection to the Raystar 120 is adequate- ly protected by a suitably rated fuse or circuit breaker. This will be provided, typically, by connection via a fused display unit.
D4728-2 Figure 2-4: SeaTalk Cable Connections Using a Connector Block When connecting a Raystar 120 into an existing instrument system or to certain Raymarine chartplotters (eg. Raychart 630) a connector block can be used to connect into the SeaTalk bus.
Page 20
D5188-1 Figure 2-5: NMEA/SeaTalk Wiring Interconnections Note: A SeaTalk Auxiliary Junction Box, which satisfies the above re- quirements, is available from your Raymarine agent or is supplied with certain chartplotter products. NMEA Inputs/Outputs Information transfer between units is determined by various data sentences transferred via NMEA as detailed in Table 2-2 .
81170_2.BOOK Page 1 Thursday, July 19, 2001 2:36 PM Appendix A: Raystar 120 GPS Receiver Mounting Template Appendix A: Raystar 120 GPS Receiver Mounting Template Note: Access to the underside of the mounting surface must be available to allow for se- cure fixing.
Appendix B: Raystar 120 GPS Receiver Application Guide Appendix B: Raystar 120 GPS Receiver Application Guide The Raystar 120 Receiver is available in two versions, Seatalk or NMEA. Each version is easily identified with NMEA or SEATALK printed on the top of the receiver case.
Page 25
81170_2.BOOK Page 1 Thursday, July 19, 2001 2:36 PM This equipment uses certain elements of software supplied to Raytheon by SiRF Tech- nology Inc., to which the following licence agreement applies. Please read it carefully. SiRF LICENSE AGREEMENT IMPORTANT - READ CAREFULLY: This is a legal agreement (the “Agreement”) between SiRF Technology Incorporated, which has offices at 3970 Freedom Circle, Santa Clara, California 95054 (“SiRF”) and you.
