  • Page 1 SIMPLY CLEVER OWNER´S MANUAL OWNER´S MANUAL ŠKODA Rapid Spaceback...
  • Page 2 Documentation of vehicle delivery Date of vehicle delivery   ŠKODA Partner Stamp and signature of the vendor I confirm that I have taken delivery of the specified vehicle in good con- dition, have received information on how to operate it correctly, and have had the terms of the warranty explained to me.
  • Page 3 1 vehicle owner 2 vehicle owner This vehicle with the official registration This vehicle with the official registration number number (filled in by the vendor) belongs to: belongs to: Title, Name / Company: Title, Name / Company: Address: Address: Phone: Phone: ŠKODA Partner ŠKODA Partner...
  • Page 4 Preface You have opted for a ŠKODA – our sincere thanks for your confidence in us. The description of the vehicle operation, important information about safety, vehicle care, maintenance and self-help, as well as technical vehicle data, are given in this Owner's Manual. For vehicles with Infotainment, the operation of some of the functions and vehicle systems is carried out via Infotainment.

  • Page 5: Table Of Contents

    Driving data (Multifunction display) Table of Contents Driving MAXI DOT display Starting-off and Driving Service interval display materials defect liability and ŠKODA warranty Starting and stopping the engine for new cars SmartGate START-STOPsystem On-board literature Unlocking and opening Brakes and parking Unlocking and locking Notes Manual gear changing and pedals...
  • Page 6 Brake fluid Vehicle battery Wheels Wheels and tyres Operating in winter conditions Do-it-yourself Emergency equipment and self-help Emergency equipment Changing a wheel Breakdown kit Jump-starting Towing the vehicle Remote - change battery Emergency unlocking / unlocking of doors Replacing windscreen wiper blades Fuses and light bulbs Fuses Bulbs...

  • Page 7: Materials Defect Liability And Škoda Warranty For New Cars

    If your ŠKODA vehicle was purchased from a ŠKODA Partner in a country of the materials defect liability and ŠKODA warranty for new European Economic Area (i.e. the countries of the European Union, Norway, cars Iceland and Liechtenstein) or in Switzerland, claims arising from the ŠKODA warranty must also be made through a ŠKODA Service Partner in one of these countries.
  • Page 8 ▶ Parts fitted on or in the vehicle, whose use has not been approved by ŠKODA Note AUTO, or modification of the vehicle in a manner not approved by ŠKODA The ŠKODA extended warranty is only available in some countries. AUTO (e.g.

  • Page 9: On-Board Literature

    ŠKODA brand. The Pictures in this Owner's Manual are for illustrative purposes only. The il- http://go.skoda.eu/owners-manuals lustrations can differ in minor details from your vehicle; they are only intended ▶...

  • Page 10: Notes

    Notes Terms used “Specialist garage” - a workshop that carries out specialist service tasks for ŠKODA vehicles. A specialist garage can be a ŠKODA partner, a ŠKODA service partner or an independent workshop. “ŠKODA Service Partner” - A workshop that has been contractually authorised by ŠKODA AUTO or its sales partner to service ŠKODA vehicles and to sell ŠKODA Genuine Parts.

  • Page 11: Structure Of The Owner's Manual And Further Information

    Structure of the Owner's Manual and further information Structure of the manual The operating manual is hierarchically divided into the following areas. Section (e.g. Operating instructions) - the title of the section is shown down ■ in the left-hand corner Main chapter (e.g.

  • Page 12: Abbreviations

    Abbreviation Definition Abbreviations Petrol engine with turbo charging and direct injection Abbreviation Definition Vehicle identification number Engine revolutions per minute Watt, unit of power Anti-lock brake system Wi-Fi wireless data network Automatic gearbox Vehicle battery type Traction control Carbon dioxide Declaration of conformity Automatic double clutch gearbox Electronic differential lock...

  • Page 13: Safety

    ▶ Protect children using a suitable child seat » page 20, Transporting children Safety safely. ▶ Adopt the correct seated position. Tell your passengers to assume the cor- Passive Safety rect seated position » page 11, Correct and safe seated position. General information Driving safety ...
  • Page 14 Adjust the headrest so that the top edge of the headrest is at the same WARNING  level as the upper part of your head (not for seats with integrated headr- The front seats and all head restraints must be adjusted to match the ■...

  • Page 15: Seat Belts

    WARNING Seat belts Never adjust the steering wheel when the vehicle is moving only when ■ the vehicle is stationary! Using seat belts The safety lever must always be locked so that the steering wheel cannot ■ accidentally change position – risk of accident! ...
  • Page 16 WARNING (Continued) Correct routing of seat belt No two persons (also not children) should ever use a single seat belt to- ■ gether. The lock tongue should only be inserted into the lock which is the correct ■ one for your seat. Wrong use of the safety belt will reduce its capacity to protect and the risk of injury increases.

  • Page 17: Inertia Reels And Belt Tensioners

    › Seat belt height adjusters for front seats Insert the lock tongue into the belt buckle for the seat » Fig. 6 -  until it › Push the return pulley upwards in the direction of arrow » Fig. 5 - .

  • Page 18: Airbag System

    If there is a collision of a certain severity, the seat belts are tightened by the Airbag system belt tensioner so that unwanted body motion is prevented. Belt tensioners are not activated in the event of minor collisions, in the case Description of the airbag system of a roll-over and also not in accidents in which no major forces are produced.
  • Page 19 Front airbags - the forward thrust of the driver and of the front passenger is Airbag deployment cushioned when they make contact with the fully-inflated airbag, and the risk of injury to head and chest is thus reduced. The front airbags can be identified by the lettering  featured on the steer- ing wheel and on the dashboard on the passenger side.
  • Page 20 The following airbags will be deployed in the event of a severe side collision. WARNING ▶ Front side airbag. Information about the front airbags ▶ Head airbag. For the driver and front passenger, it is important to maintain a distance ■...

  • Page 21: Airbag Deactivation

    WARNING WARNING Information on the use of the airbag system If an airbag is deactivated at the time of the vehicle being sold, the pur- Any work on the airbag system, including the installation and removal of chaser must be informed! ■...

  • Page 22: Transporting Children Safely

    › Fold the key bit out completely for the radio key » Transporting children safely › Carefully insert the key into the key slot in the key switch as far as the stop. › Use the key to turn the slot of the key switch carefully into the position . Child seat ›...
  • Page 23 WARNING (Continued) Use of a child seat on the front passenger seat Children are exposed to an increased risk of injury in the event of an acci- ■ Does not apply to Taiwan dent if they lean forward or adopt an incorrect seated position when the vehicle is moving.
  • Page 24 Adjust the height of the front passenger seat belt so that the belt does not Child safety and the side airbag “jam” in the return pulley. In the event of an accident, there is the risk of in- jury to the neck of the child carried due to the seat belt! Fig.

  • Page 25: Fastening Systems

     is a system for securing child seats quickly and safely. Front passenger Rear seats Rear seat Group seat External Centre There are two locking eyes between the rear exterior seats for fixing the child in place using the -system »...
  • Page 26 Use of child safety seats with the  system Never use a rear-facing child seat on the front passenger seat if the front passenger airbag is activated. This child safety seat is positioned in the deployment area of the front passenger airbag. The airbag may cause the child severe, or even fatal injuries, in the event of it being deployed. Overview of the usefulness of child seats fastened with the -system on each of the seats in accordance with the ECE-R 16 standard.
  • Page 27 Attachment points of the   -system Fig. 15 Attachment points of the  -system   is a fastening system, which restricts the movement of the upper part of the child seat. The locking eyes for attaching the belt of a child seat with the   sys- tem are located on the rear side of the outer rear seat backrests »...
  • Page 28 Fig. 16 Cockpit example for LHD models Using the system...

  • Page 29: Using The System Cockpit

    Bonnet release lever Using the system Steering wheel locking lever Depending on equipment fitted: Cockpit ▶ Ignition lock ▶ Starter button Overview Storage compartment Electric windows Handbrake lever Door opening lever Depending on equipment fitted: Electric exterior mirror adjustment ▶ Gearshift lever (manual gearbox) ▶...

  • Page 30: Instruments And Warning Lights

    Engine revolutions counter » page 28 Instruments and warning lights ▶ with warning lights » page 29 Display » page 37 Instrument cluster Speedometer  ▶ with warning lights » page 29 Introduction Bar with warning lights » page 29 Operation key: ▶...

  • Page 31: Warning Lights

    If the fuel level reaches the reserve level , the warning light illumi-  Coolant temperature gauge nates in the instrument cluster» page Fig. 19 WARNING Coolant temperature gauge For the vehicle systems to function correctly, and thus for safe driving, there must be sufficient fuel in the tank.

  • Page 32: Warning

    Turn signal system   WARNING Trailer turn signal lights  Ignoring illuminated indicator lights and related messages or instructions ■ Fog lights in the instrument cluster display may lead to serious personal injury or  Speed regulating system / speed limiter damage to the vehicle.

  • Page 33: Power Steering / Steering Lock (Engine Start Push-Button)

    If the seat belt is not fastened by the driver or front passenger during the next Disconnecting the vehicle battery approx. 2 minutes, the warning signal is deactivated and the warning light If the vehicle's battery has been disconnected and reconnected, the warning ...

  • Page 34: Traction Control (Tcs) Deactivated

    Traction control (TCS) deactivated Preheating unit (diesel)     Read and observe on page 30 first. Read and observe on page 30 first. illuminates – the TCS system is disabled. flashes – there is a fault in the engine management system. The system ...

  • Page 35: Tyre Pressure

    ▶ Airbag/ belt tensioner deactivated. Continued driving is possible with appropriate caution. Seek assistance from  a specialist garage immediately. AIRBAG/ BELT TENSIONER OFF  Other incidents WARNING The illumination of the warning light can have the following reasons.  When a fault in the airbag system occurs, there is a risk of the system not ▶...

  • Page 36: Trailer Turn Signal Lights

    illumi- Gearbox over-heated. Continued driving is possible. Trailer turn signal lights     nates GEARBOX OVERHEATED   Read and observe on page 30 first. The gearbox is overheated, which continued driving is possible with appropri- ately cautious style of driving. flashes –...

  • Page 37: Coolant

    ▶ ▶ As the battery discharges while driving, all non-essential electrical loads (e.g. Stop the vehicle, switch off the engine, and check the engine oil level. ▶ Infotainment) should be switched off. Even if the oil level is correct, do not drive any further if the warning light ...

  • Page 38: Lamp Failure

    CAUTION  Lamp failure As long as the warning light  illuminates, one must take into account an ■  Read and observe on page 30 first. increased fuel consumption and a power reduction of the engine. Using diesel fuel with increased sulphur content can significantly reduce the ■...

  • Page 39: Information System

     illuminates – the safe distance to the vehicle in front is below the mini- Information system mum. Information on the Front Assist system» page 105. Driver information system  Introduction  Advance warning / emergency brake (Front Assist) This chapter contains information on the following subjects: ...

  • Page 40: Service Interval Display

    › Door alarm Switch on the ignition. › Service interval display Press and hold the » Fig. 22 button until the time is shown in the display. › Release the button and the system switches to the hour setting function. Outside temperature ›...

  • Page 41: Operation Of The Information System

    As long as the faults are not rectified the messages are always shown. After Buttons/dials on the multifunction steering wheel the message is displayed for the first time, the warning lights (danger) or   Switch on/off voice control  (warning) continue to be displayed.
  • Page 42 The units and the display of some information can be set in Infotainment Adjust the speed limit while the vehicle is stationary › » Owner´s Manual - Infotainment. Select the menu item Warning at at () or  () and confirm. ›...

  • Page 43: Maxi Dot Display

    Long-term () and “2” () Main menu items (depending on vehicle equipment) The memory gathers driving data from any number of individual journeys up to Driving data » page 39 ■ a total of 99 hours and 59 minutes driving time or 9999 kilometres driven. Assist systems »...

  • Page 44: Service Interval Display

    Menu itemTelephone Displaying the distance and days until the next service interval The call list with the following symbols is displayed in the Telephone menu item. Fig. 27 Incoming call  Button in the instrument cluster Outgoing call  Missed call ...

  • Page 45: Smartgate

    SmartGate. We recommend that you do not reset the service interval display yourself. In- correctly setting the service interval display could cause problems to the vehi- http://go.skoda.eu/connectivity-smartgate cle. CAUTION Variable service interval To increase the access security to the transmitted vehicle data, once the ■...
  • Page 46 › Enter the password (vehicle identification number using uppercase let- If you want to connect to SmartGate in a different vehicle, you must make a ters» page 44). new connection in the SmartGate application. With SmartGate, a maximum of four external devices can be connected simul- Disconnection taneously using Wi-Fi.

  • Page 47: Unlocking And Opening

    › Restart SmartGate by tapping on the “Reboot” button. Unlocking and opening Changing the PIN code for the Wi-Fi Direct connection › Unlocking and locking Open the SmartGate web interface » page 44, SmartGate web interface. › In the menu item “WiFi Direct PIN:”, enter the new PIN code (6 digits). ›...

  • Page 48: Unlocking/Locking With The Remote Control Key

    WARNING Unlocking/locking with the remote control key Never leave the key in the vehicle when you exit the vehicle. Unauthor- ■ ised persons (e.g. children) could lock the car, turn on the ignition or start Fig. 30 the engine - danger of injury and accidents! Key with pop-out key bit When leaving the vehicle, never leave persons who are not completely in- ■...

  • Page 49: Unlocking/Locking - Kessy

    If the boot lid is closed after locking the vehicle and the key with which the Unlocking/locking - KESSY vehicle was locked remains in the luggage compartment, the lid is automatical- ly unlatched (partially opened). After automatically unlocking, the turn signal lights will flash four times.

  • Page 50: Safelock

    All doors SafeLock The function allows you to unlock all doors, the boot lid and the fuel filler flap.  Read and observe on page 46 first. Single door The function allows you to unlock only the driver's door and the fuel filler flap SafeLock prevents opening the doors from inside as well as window operation.

  • Page 51: Anti-Theft Alarm System

    › To open from the inside pull the door opening lever and push the door Malfunctions away from you. ›  To the lock from the inside, grab the handle and close the door. Read and observe on page 46 first. WARNING Synchronise remote If the buttons on the remote control key have been depressed several times...

  • Page 52: Luggage Compartment Lid

     Read and observe on page 50 first. CAUTION Before leaving the vehicle, check that all doors and windows are closed in or- The interior monitor detects movements inside the locked vehicle and then der to ensure that the alarm system is fully operational. triggers the alarm.

  • Page 53: Window Operation

    Opening / closing the boot lid Window operation  Introduction This chapter contains information on the following subjects: Mechanical windows Electric window Force limiter Operational faults The window can be operated mechanically by means of the handle attached to the respective door panel. Fig.
  • Page 54 Mechanical windows Fig. 39 Window winder button  Read and observe on page 51 first. Fig. 37 Window operation: left / right The electrical power windows can only be operated when the ignition is switched on.  Read and observe on page 51 first.

  • Page 55: Lights And Visibility

    Force limiter Lights and visibility  Read and observe on page 51 first. Lights If there is an obstacle, the closing process is stopped and the window goes  Introduction down by several centimetres. This chapter contains information on the following subjects: If the obstacle prevents the window from being closed during the next 10 sec- onds, the closing process is interrupted once again and the window goes down Operating the light function...

  • Page 56: Operating The Light Function

    Note Operating the light function If, with a low beam, the ignition is turned off, then the dipped beam will au- ■ tomatically switch off and the parking lights illuminate. The parking lights are Fig. 40 switched off when the ignition key is removed (for vehicles with the KESSY Light switch and control dial for system, after opening the driver's door).

  • Page 57: Turn Signal And Main Beam

    Turn signal and main beam Automatic driving light control Fig. 41 Fig. 42 Operating lever: Turn signal and Light switch: AUTO position main beam operation   Read and observe on page 53 first. Read and observe on page 53 first. Operating lever positions »...

  • Page 58: Fog Lights/Rear Fog Light

    Fog lights/rear fog light Fog lights with the CORNER function  Read and observe on page 53 first. Fig. 43 Light switch – switch on front The CORNER function automatically switches on the fog lights on the respec- and rear fog lights tive side of the vehicle (e.g.

  • Page 59: Interior Lighting

    Switching on the side light on both sides  Hazard warning light system › Switch on the ignition and turn the light switch to position , the parking lights » page 54 are turned on. Fig. 44 › Switch off the ignition and lock the car. Button for hazard warning light After pulling out the ignition key and opening the driver's door, an audible system...
  • Page 60 Front interior light Interior lighting, rear Fig. 45 Operation of the front light: Version 1/version 2 Fig. 46 Interior lights at the rear: Version 1/version 2 Positions of the sliding light switch » Fig. 45 Variant 1: operation (by pressing the switch »...

  • Page 61: Visibility

    The brightness level of lighting with the low beam or parking lights switched Note on can be adjusted in Infotainment » Owner's Manual - Infotainment. If the on-board voltage decreases, the heating switches off automatically ■ » page 133, Automatic shutdown of consumers - vehicle battery discharge protection.

  • Page 62: Windscreen Wipers And Washers

    CAUTION Sun screen of the panoramic roof If the windscreen wipers are in rest position, they cannot be folded out from ■ the windscreen. The wipers must be set to the service position to raise them Fig. 49 off the windscreen »...

  • Page 63: Rear View Mirror

    Slow-speed wiping  Headlight cleaning system High-speed wiping   Read and observe on page 60 first. Single wipe of the windscreen (spring-loaded position)  Spraying and wiping the disc (spring-loaded position) - after releasing the  The headlights are cleaned with every first and after every tenth spraying of operating lever the wipers continue for another 1 to 3 strokes the windscreen under the following conditions.

  • Page 64: Fig

    WARNING Interior mirror dimming The mirrors with automatic dimming contain electrolyte fluid which may ■ leak if the mirror glass is broken - this can irritate skin, eyes and the respi- ratory system. If your eyes or skin come into contact with the electrolytic fluid, immedi- ■...

  • Page 65: Seats And Head Restraints

    Folding in the exterior mirrors Seats and head restraints The mirror can be manually folded in towards the side window. To put it back into its original position, it should be folded back from the side window until it Front seats audibly clicks into place.

  • Page 66: Rear Seats

    Before folding the seat backrests forwards, adapt the position of the front Setting the armrest height seats in such a way that they are not damaged by the folded seat backrests. Folding forward Fig. 55 › Push the headrest into the seat backrest until it clicks into position. Raise armrest ›...

  • Page 67: Headrests

    Adjustment of the head rest heights is the same in the front and rear. Fold down armrest › Grasp the headrest and move upwards in the direction of arrow » Fig. › To move the headrest down, press the securing button in the direction of Fig.

  • Page 68: Front Seat Heating

    › To remove, hold the locking button in the direction of arrow , at the CAUTION same time, using a flat screwdriver (with a max. width of 5 mm), press the The following instructions must be observed to avoid damage to the seats. locking button in the opening in the direction of arrow and remove the...

  • Page 69: Useful Features

    WARNING (Continued) Useful features For safety reasons, lockable storage compartments should be closed ■ while driving - there is a risk of injury from the opened lid or through the Interior fittings loose objects in the compartment.  Make sure no objects protrude from the storage compartments - danger Introduction ■...

  • Page 70: Stowage Compartments In The Doors

     Read and observe on page 67 first. stowage compartments in the doors The non-lockable storage compartment is located in the front centre console and in the rear centre console » Fig. USB and AUX input Fig. 65 USB and AUX inputs Fig.

  • Page 71: Cup Holders

    Cup holders Waste container Fig. 67 Cup holder at the front/rear Fig. 69 Waste container: inserting and moving/opening Fig. 68 Cup holder in rear armrest Fig. 70 Replacing bags  Read and observe on page 67 first. Two beverage containers can be placed into the cup holder. ...

  • Page 72: Cigarette Lighter

    Open/close waste container Note › Lift the lid in the direction of arrow » Fig. The cigarette lighter socket can also be used as a 12 volt socket. Closing takes place in reverse order. Ashtray Replace bags › Remove the waste container from the slot. ›...

  • Page 73: 12-Volt Socket

    CAUTION 12-volt socket The sockets can only be used for the connection of approved electrical ac- ■ cessories with a total power consumption of up to 120 watts - otherwise the electrical system of the vehicle may be damaged. Connecting appliances when the engine is not running will drain the battery ■...

  • Page 74: Storage Compartment In The Front Arm Rest

    CAUTION Storage compartment in the front arm rest Do not put any heat-sensitive objects in the glasses storage box - with high ■ temperatures there is risk of damage. The box must be closed before leaving and locking the vehicle – risk of im- ■...

  • Page 75: Storage Compartment For Umbrella

    WARNING Storage compartment for umbrella Never leave any heavy or sharp-edged objects in the pockets of the items ■ of clothing hung up - danger of injury. Fig. 78 Do not use hangers to hang up the clothes - there is a risk of restricting ■...

  • Page 76: Tablet Holder

    The maximum permissible load of each of the pockets is 150 g. Tablet holder  Introduction This chapter contains information on the following subjects: Install / Remove Handling the holder External devices (e.g. tablet, smartphone, etc.) measuring min. 122 mm and Fig.

  • Page 77: Transport Of Cargo

    Transport of cargo Fig. 85 Adjusting the holder size Luggage compartment and transporting objects  Introduction This chapter contains information on the following subjects: Fastening elements Fixing nets Multifunction pocket  Read and observe on page 74 first. Hooks Luggage compartment cover The holder may be tipped by 30°...

  • Page 78: Fastening Elements

    Overview of the fastening elements » Fig. 86 WARNING Lashing eyes for securing cargo, fastening nets and multifunction pocket Never exceed the maximum permissible load of the respective fasteners, ■ nets, hooks etc. Heavy objects were not secured sufficiently – risk of injury! Fastener for securing fastening nets and multifunction pocket Do not exceed the permissible axle loads and permissible gross weight of ■...

  • Page 79: Multifunction Pocket

    Hooks Fig. 88 Fastening a vertical pocket Fig. 90 Hooks  Read and observe on page 76 first.  Read and observe on page 76 first. Fastening examples for nets » Fig. 87 » Fig. 88 Horizontal pocket One hook for attaching small items of luggage, such as bags etc., is provided Floor net on each side of the luggage compartment »...

  • Page 80: Parking Position" Of The Boot Cover

     Removing Read and observe on page 76 first. › On both sides of the boot lid unhook the straps in direction of arrow The boot cover can be stowed behind the rear seat backrests. » Fig. › › Hold the raised cover and press on the two sides on the underside of the Slide the dismantled cover between bolt and contact surface of the...

  • Page 81: Storage Net Bag

    Storage net bag Fig. 94 Meshed pocket for storage Fig. 96 Remove cargo element: Version 3 / Mounting example of the car- go using the cargo elements  Read and observe on page 76 first.  Read and observe on page 76 first. The meshed pocket for storage is located on the right-hand side of the boot »...

  • Page 82: Variable Loading Floor In The Luggage Compartment (Estate)

    › Proper functioning of the electrical installation is essential for safe vehicle op- To set in the upper position, lift the variable loading floor in the front area eration. It is important to ensure that the electrical installation is not damaged and position on the edge ›...

  • Page 83: Transportation On The Roof Rack

    CAUTION Transportation on the roof rack When removing or inserting the variable loading floor, a distance of 15 cm » Fig. 98 underneath the edge of the cover must be maintained - risk of dam- aging the boot lid seal. Note The variable loading floor cannot be placed in the vehicle when the luggage compartment cover is in the “park position”...

  • Page 84: Heating And Ventilation

    WARNING Heating and ventilation The blower should always be on to prevent the windows from misting. ■ Otherwise there is a risk of accident. Heating, manual air conditioning system, Climatronic Under certain circumstances, air at a temperature of about 5 °C can flow ■...
  • Page 85  Air flow in the footwell Recirculated air mode activated  Air flow to the windows and the footwell Cooling system activated Switch recirculation on/off » page 84  Set blower speed Switch the cooling system on/off  Set the blower speed (the set blower speed is indicated by the corre- sponding number of segments in the display) Information on the cooling system ▶...
  • Page 86 Note WARNING In order to ensure adequate thermal comfort, there may be an increase in en- The recirculation system cannot be switched on for a longer period of time, gine idle speed during operation of the Climatronic in some circumstances. because no fresh air is fed through from the outside.
  • Page 87 The setting of the airflow direction is carried out by moving the adjustment el- ement » Fig. 103 in the desired direction. Open/close › Turn the regulator upwards/downwards » Fig. 103. Depending on the setting for air distribution, the air will flow from the follow- ing air vents.

  • Page 88: Driving

    Note Driving Do not warm up the engine while the vehicle is stationary. If possible, start your journey as soon as the engine has started. Through this, the engine rea- Starting-off and Driving ches its operating temperature faster. Starting and stopping the engine Electronic immobiliser and steering lock ...
  • Page 89 Starting the engine Switch on/off ignition › On vehicles with ignition lock, turn the key to position and the engine starts» Fig. 104 on page 87 . Then release the key, the engine will start au- tomatically. If the engine does not start within 10 seconds, turn the key to position .

  • Page 90: Start-Stopsystem

    The START STOPsystem (hereinafter referred to as the system) reduces Note emissions and harmful emissions, and saves fuel. The engine running noises may be louder at first for a short time after start- ■ ing the cold engine. If the system determine that the engine is not needed when the vehicle stops You should not switch on any major electrical components during the heat- ■...

  • Page 91: Brakes And Parking

    Requirements for the system to function correctly Note The following conditions must be met for the system to function correctly. If the driver's seat belt is removed for more than 30 seconds or the driver's ■ The driver's door is closed. ...
  • Page 92 The wear and tear on the brake pads is dependent on the operating condi- WARNING (Continued) tions and driving style. In difficult conditions (e.g. urban, sporty driving), the Do not depress the brake pedal if there is no requirement to slow down. ■...

  • Page 93: Manual Gear Changing And Pedals

    A warning signal sounds if the vehicle is inadvertently driven off with the Manual gear changing handbrake applied. The handbrake warning is activated if the vehicle is driven at a speed of over 5 km/h for more than 3 seconds. Fig.

  • Page 94: Automatic Gearbox

    Only a floor mat (ex-factory or from the ŠKODA Original Accessories range) Select selector lever position which can be secured to the attachment points should be used in the driver's footwell. Fig. 110 Selector lever/display WARNING There should be no objects in the driver's footwell, otherwise the pedal op- eration can be impeded - risk of accident! Automatic gearbox ...
  • Page 95 Selector lever lock Manual shifting (Tiptronic) Fig. 111 Fig. 112 Shift lock button Selector lever   Read and observe on page 92 first. Read and observe on page 92 first. Tiptronic mode makes it possible to manually shift gears on the selector lever. The selector lever is locked in modes P and N to prevent the forwards travel mode from being selected accidentally and setting the vehicle in motion.

  • Page 96: Running In And Economical Driving

    Starting-off and driving Tips on economical driving  Read and observe on page 92 first. Fuel consumption depends on the driving style, road and weather conditions, and similar such factors. Moving off and pausing temporarily › For an economical driving style, the following instructions must be observed. Firmly depress and hold the brake pedal.

  • Page 97: Avoiding Damage To Your Vehicle

    “Green leaf” Avoiding damage to your vehicle The greener the leaf, the more economic the driving style. With less economi- cal driving, the leaf is presented without any green colouring or it can be com-  Introduction pletely hidden. This chapter contains information on the following subjects: bar graph Driving Tips The higher the green bars, the more economical the driving style.

  • Page 98: Assist Systems

    The following instructions must be observed if vehicle damage is to be avoided Assist systems when driving through water (e.g. flooded roads). › Therefore, always determine the depth of the water before driving through General information water. The water level must not go above the web of the lower beam ...
  • Page 99 WARNING Traction control (TCS) The general information relating to the use of assistance systems must be observed » page 96, in section Introduction. Fig. 115 Button for the TCS system Stability Control (ESC)  Read and observe on page 97 first. The ESC improves vehicle stability when driving at the limit (e.g.
  • Page 100 Electronic Differential Lock (EDL) Multi collision brake (MCB)   Read and observe on page 97 first. Read and observe on page 97 first. EDL prevents the turning of the respective wheel of the driven axle. EDL MCB helps to decrease speed after a collision by means of automatic braking brakes a spinning wheel if required and transfers the drive power force to the interventions and to stabilise the vehicle.

  • Page 101: Parking Assistance (Parkpilot)

    Parking assistance (ParkPilot) Function  Introduction This chapter contains information on the following subjects: Function Display in the Infotainment display Activation / deactivation Automatic system activation when moving forward Park Assist (hereinafter referred to as the system) draws attention via acoustic signals or the Infotainment display when manoeuvring around obstacles in the Fig.
  • Page 102 Approximate range of sensors (in cm)    Depending on the Infotainment type: Switching off park assistant dis- play. Area » Fig. 117 Version 1 Version 2 (3 sensors) (7 sensors)    Switching audible parking signals on/off. Change to rear-view camera display.

  • Page 103: Reversing Camera

    For vehicles with variant 2, the system is automatically deactivated by press- Reversing camera ing the  button or at a speed above 15 km/h (the symbol in the button  goes out).  Introduction Displaying an error This chapter contains information on the following subjects: If a warning signal sounds for 3 seconds after activating the system and there Operation is no obstacle close to your car, this indicates a system fault.
  • Page 104 Operation Guidelines and function keys Fig. 121 Installation location of the camera / scanned area behind the ve- Fig. 122 Infotainment display: orientation lines / function surfaces hicle  Read and observe on page 101 first.  Read and observe on page 101 first.

  • Page 105: Speed Control System

    CAUTION The objects shown in the display can be closer or even further away than they appear. This is especially the case in the following situations. Protruding objects, such as the rear of a truck and the like. ■ When driving from a horizontal surface into a slope or a depression. ■...

  • Page 106: Speed Limiter

    Note Operation description During control, speed can be increased by pressing the accelerator pedal. Re- ■ leasing the accelerator pedal will cause the speed to drop again to the set Fig. 125 speed. Cruise control system controls By pressing the button during the regulation, this is cancelled and the ■...

  • Page 107: Front Assist

    To activate the speed limiter, set the switch to position , then press to operate. Interrupt control (sprung position)  Disable speed limiter (set limit delete)  Take control again / increase speed - press (in increments of 1  km/h), hold (in increments of 10 km/h) Start regulation / reduce speed - press (in increments of 1 km/h), ...
  • Page 108 The Front Assist (hereinafter referred to as the system) warns you of the dan- WARNING ger of a collision with a vehicle or another obstacle in front of the vehicle, and If you suspect that the sensor is damaged, deactivate the system. Have ■...
  • Page 109 Advance warning Distance warning If the system detects a risk of collision, the warning light  » Fig. 131 appears in the display and you will hear an acoustic signal. Fig. 130 The pre-warning display can occur in the following situations. Instrument cluster display: distance warning ▶...

  • Page 110: Fatigue Detection

    If the distance-warning function was deactivated before the ignition was Deactivation/activation switched off, it remains deactivated after the ignition is switched on again. WARNING In the following situations, Front Assist should be switched off for safety reasons. When the vehicle is being towed away. ■...

  • Page 111: Tyre Pressure Monitoring

    If none of these conditions are met or if the driving style is not changed, the WARNING system recommends a driving break again after 15 minutes. The general information relating to the use of assistance systems must ■ be observed »...
  • Page 112  Read and observe on page 109 first. Storing the tyre pressure values and Infotainment display › Inflate all the tyres to the specified pressure. › Fig. 133 Switch on the ignition. › Button for storing the pressure Press the symbol key  »...

  • Page 113: Towing Device And Trailer

    Towing device and trailer Description Hitch  Introduction This chapter contains information on the following subjects: Description Adjusting the ready position Check the setting of the standby position Assembling the tow bar – Step 1 Assembling the tow bar – Step 2 Fig.
  • Page 114 Adjusting the ready position Check the setting of the standby position Fig. 136 Remove cap from the lock / insert key into the lock Fig. 138 Ready position  Read and observe on page 111 first. Correctly adjusted standby position »...
  • Page 115 Assembling the tow bar – Step 1 Assembling the tow bar – Step 2 Fig. 140 Secure the lock and remove key / place cap on lock Fig. 139 Remove cap for receiving shaft / use ball bar   Read and observe on page 111 first.
  • Page 116 Check proper fitting Fig. 143 Unlock lock Fig. 141 Correctly secured ball head  Read and observe on page 111 first.  Read and observe on page 111 first. No trailer or other accessory is connected to the tow bar. We recommend put- ting the protective cover onto the ball head before removing the tow bar.

  • Page 117: Using The Towing Device

    › Remove the tow bar from the mounting recess downwards and in the direc- Distance of the centre of gravity of Permissible total weight of the ac- tion of the arrow . At the same time, the ball rod latches into the ready po- the load from the ball head cessory, including load sition and is therefore ready to be re-fitted.
  • Page 118 Exterior mirrors WARNING (Continued) You should have additional exterior mirrors fitted if you are not able to see the After the electrical connection between the vehicle and trailer (accessory) ■ traffic behind the trailer using the standard rear-view mirrors. the trailer / accessory lights should be checked for function. Never use the securing eye to tow - risk of accident! ■...
  • Page 119 Permissible trailer load, braked (kg) Engine Gearbox Permissible trailer load, unbraked (kg) Gradients of up to 12 % Gradients of up to 8% 1000 1100 1.6 l./81 kW MPI 1000 1100 1000 1100 1.4 l/66 kW TDI CR 1000 1100 1.6 l/85 kW TDI CR 1200 1200...

  • Page 120: General Maintenance

    General Maintenance Vehicle operating under different weather conditions  Read and observe on page 118 first. Care and maintenance If you would like to operate your vehicle in countries other than those with its Service work, adjustments and technical alterations intended weather conditions, you should contact a ŠKODA Partner.
  • Page 121 ŠKODA Original parts Spoiler   Read and observe on page 118 first. Read and observe on page 118 first. We recommend the use of ŠKODA Genuine Parts for your vehicle, as these WARNING parts are approved by ŠKODA AUTO. These parts comply wholly with ŠKODA If your vehicle is equipped with a Genuine Accessories spoiler on the front AUTO regulations and are identical to the parts used in series production.

  • Page 122: Service Intervals

    The following is taken to mean aggravated operating conditions: WARNING ▶ Fuel containing sulphur. No changes may be made to airbag system components, the front bump- ■ ▶ Frequent short trips. er and the bodywork. ▶ Longer periods of engine idling (e.g. taxis). Any work on the airbag system including the installation and removal of ■...
  • Page 123 ▶ Fixed service interval QI4. Note ▶ Variable service interval QI6. For diesel operation with a high sulphur content, the oil must be changed ev- ery 7,500 km. Ask your specialist garage for information on the countries In order to operate a vehicle with a variable service interval, it must only be where diesel fuel has a high sulphur content.

  • Page 124: Cleaning And Care

    ▶ Protection against loss or damage of the entries – you receive a complete re- Car washing cord of the work carried out, if required. ▶  Option to receive the record in electronic form. Read and observe on page 122 first. ▶...
  • Page 125 WARNING Vehicle compo- Circumstances Remedy nents When washing your vehicle in the winter: Water and ice in the braking ■ system can affect the braking efficiency – risk of accident! Chrome clear water, cloth, possibly cleaners Take care when cleaning the underbody or the inside of the wheel wells - ■...
  • Page 126 Product life of the films Reversing camera ■ Environmental influences (e.g. sunlight, humidity, air pollution, rockfall) affect The following instructions must be observed, otherwise there is a risk of the life of the films. Films will age and become brittle – this is entirely normal; camera damage.
  • Page 127 CAUTION Caring for the interior ® Natural leather / leather / Alcantara / material ■  Read and observe on page 122 first. Avoid standing for lengthy periods in bright sunlight, and protect the mate- ■ rials by covering to prevent them from fading. Vehicle compo- Remove fresh stains (e.g.

  • Page 128: Inspecting And Replenishing

    Inspecting and replenishing Petrol and diesel refuelling Fuel  Introduction Fig. 149 Stickers showing the prescribed fuel Fig. 150 Open fuel filler flap / unscrew tank cap / place the tank cap on the fuel filler flap  Read and observe on page 126 first.
  • Page 129 The vehicle can only operate with unleaded petrol that meets standard EN CAUTION , and contains maximum 10% bioethanol (E10). Petrol additives (additives) Unleaded petrol complying with the EN 228 standard meets all the condi- ■ Prescribed fuel 95 / min. 92 and 93 RON / ROZ tions for problem-free engine operation.

  • Page 130: Engine Compartment

    CAUTION WARNING (Continued) The following instructions must be observed, otherwise there is a risk of dam- For vehicles with manual transmission the lever into the neutral position. ■ age to the engine and to the exhaust system. For vehicles with automatic transmission, place the selector lever in the P If a different fuel other than diesel fuel, which complies to the above men- position.
  • Page 131 WARNING Opening and closing the bonnet Never drive with the bonnet lid not properly closed - risk of accident! ■ Make sure that when closing the bonnet, no body parts are crushed - ■ there is danger of injury! Engine compartment overview Fig.

  • Page 132: Engine Oil

    The engine has been filled ex-factory with a high-grade oil that can be used Windscreen washer fluid throughout the year (except in extreme climate zones). We recommend that the oil changes are carried out by a ŠKODA Service Part- Fig. 153 ner.

  • Page 133: Coolant

    › Vehicles with fixed service intervals Pull the dipstick out and wipe with a clean cloth. › Push the dipstick back to the stop and then pull it out again. Petrol engines Specification › Read the oil level and push the dipstick back in. 1.2 l/66, 81 kW TSI The oil level must lie in range »...
  • Page 134 › Place a cloth over the cap of the coolant expansion tank and unscrew the WARNING cap carefully. The following instructions must be followed at all times when working on ■ › Always top up using coolant of the correct specification. the engine compartment »...

  • Page 135: Brake Fluid

    Brake fluid Vehicle battery  Introduction Fig. 156 Brake fluid reservoir This chapter contains information on the following subjects: Check condition Charging Disconnect/reconnect and change The vehicle battery represents a power source for the motor to start and for the supply of electrical consumers in the car. Check the brake fluid under the following conditions.
  • Page 136 WARNING Check condition Battery acid is highly corrosive - it can cause injury, chemical burns or poi- soning! Corrosive vapours in the air irritate and damage the respiratory tract and the eyes. The following guidelines must be observed. Always wear protective gloves, eye and skin protection when handling ■...
  • Page 137 After disconnecting and re-connecting the vehicle battery, the following func- Charging tions or devices are partially or completely inoperative.  Read and observe on page 134 first. Function / device Commissioning Only charge the battery when the ignition and all consumers are switched off. Windows »...

  • Page 138: Wheels

    The specified running direction must be strictly adhered to, otherwise the fol- Wheels lowing tyre characteristics may be degraded. ▶ Driving stability. Wheels and tyres ▶ Traction. ▶ Tyre noise and tyre wear. Advice on tyre/wheel usage WARNING During the first 500 km, new tyres do not offer optimum grip; appropriate care Never use tyres if you do not know anything about their condition and ■...
  • Page 139 The prescribed tyre inflation is on the sticker with pictograms » Fig. 158 (for Tyre wear and wheel change some countries, the pictograms are replaced with a text). Tyre pressure is always to match the load. Inflation pressure for half load Inflation pressure for environmentally friendly operation (slightly lower fuel consumption and emissions) Inflation pressure for full load...

  • Page 140: Operating In Winter Conditions

    Spare wheel Tyre marking The size of the spare wheel is identical to that of the vehicle factory installed Explanation of tyre markings - e.g. 185/60 R 15 84 H wheels. Tyre width in mm After changing the spare wheel, the tyre pressure should be adjusted. Height/width ratio in % In vehicles with tyre pressure monitoring, save the tyre pressure values in the Code letter for the type of tyre –...
  • Page 141 If “winter” tyres are mounted, summer tyres should be fitted again in good WARNING time as they provide better handling properties, a shorter braking distance, Do not use chains on snow and ice-free routes - the handling would be im- less tyre noise and reduced tyre wear on roads which are free of snow and ice paired and there is a risk of damage to the tyres.

  • Page 142: Do-It-Yourself

    WARNING Do-it-yourself Properly secure the first aid kit and the warning triangle - there is a risk of injury in the event of sudden braking or a vehicle collision. Emergency equipment and self-help Emergency equipment Location of reflective vest  Introduction Fig.

  • Page 143: Changing A Wheel

    WARNING WARNING Always properly secure the fire extinguisher - there is a risk of injury in the The factory-supplied lifting jack is only intended for your model of vehicle. ■ event of sudden braking or a vehicle collision. Under no circumstances attempt to lift other vehicles or loads with it – there is a risk of injury.
  • Page 144 › Jack up the vehicle until the wheel that needs changing is clear of the ground WARNING » page 144. Tightening torque which is too high can damage the threads and this can › Unscrew the wheel bolts and place them on a clean surface (cloth, paper, result in permanent deformation of the contact surfaces on the rim.
  • Page 145 › To remove the cap, insert the extraction pliers as far as they will go on the Full wheel trim cap and pulling them out in the direction of arrow » Fig. 165. › Remove trim To install, insert the cap onto the wheel bolt as far as it will go. ›...
  • Page 146 Loosening/tightening wheel bolts Fig. 167 Loosening the wheel bolts Fig. 169 Attach lifting jack › Insert the wheel wrench onto the wheel bolt to the stop. Use the associated Before the vehicle is raised, please take note of the safety instructions »...

  • Page 147: Breakdown Kit

    Breakdown kit Description of the breakdown kit  Introduction This chapter contains information on the following subjects: Description of the breakdown kit Preparing to use the breakdown kit Sealing and inflating tyres Information on driving with repaired tyres The following information applies for the breakdown kit supplied ex-factory. The breakdown kit can be used to seal punctures with a diameter of up to about 4 mm.
  • Page 148 › For vehicles with manual transmission, set the lever in the neutral position. Preparing to use the breakdown kit › On vehicles with automatic transmission, place the selector lever in the P  Read and observe on page 145 first. position.

  • Page 149: Jump-Starting

    If the tyre pressure is 1.3 bar or more Jump-starting using the battery from another vehicle › Set the tyre pressure back to the correct value » page 136. › Continue driving carefully to the nearest specialist garage at a maximum speed of 80 km/h (50 mph).

  • Page 150: Towing The Vehicle

    › Attach clamp to the negative terminal of the power-supplying battery. Towing the vehicle › For vehicles with the START-STOPsystem, attach clamp to the earth point of the engine » Fig. 171. Information about the towing process › For vehicles without the START-STOPsystem, attach clamp to a solid metal part firmly attached to the engine block or directly to the engine block.
  • Page 151 › If it is not possible to start the engine, switch on the ignition so that the Removing/installing the towing eye › steering wheel does not lock and so that the turn signal lights, windscreen To fit, screw in the towing eye by hand in the direction of the arrow wipers and windscreen washer system can be used.

  • Page 152: Remote - Change Battery

    Unlock the boot lid Remote - change battery Selector lever-emergency unlocking Unlocking/locking the driver's door Fig. 177 Handle on the driver's door: open lock cover Fig. 176 Remove cover/take out battery › Pop out the key bit. › The driver's door can be emergency unlocked / emergency locked using the Press off the battery cover »...

  • Page 153: Replacing Windscreen Wiper Blades

    Locking the door without locking cylinders Selector lever-emergency unlocking Fig. 178 Emergency locking: Left/right rear door Fig. 180 Remove / release the selector lever › › Open the corresponding back door remove the trim » Fig. 178. Firmly apply the handbrake. ›...
  • Page 154 Attaching the windscreen wiper blade Replacing the windscreen wiper blades › Slide the windscreen wiper blade in the opposite direction to arrow until it locks into place. Check that the windscreen wiper blade is correctly attached. Fig. 181 › Fold the windscreen wiper arm back to the windscreen. Setting the service position for ›...

  • Page 155: Fuses And Light Bulbs

    Fuses and light bulbs Fuses in the dashboard Fuses Fig. 185 Remove the fuse box cover.  Introduction Fig. 184 Blown fuse  Read and observe on page 153 first. The fuses are located on the bottom of the dash panel behind a cover. Replacing fuses ›...
  • Page 156 Power consumer Fuse arrangement in the dashboard Air conditioning, automatic transmission, diagnostic connector, heat- ed windscreen Instrument cluster, emergency call Anti-theft alarm, horn Not assigned Not assigned Not assigned Not assigned Windscreen and rear window washer system (without KESSY or Fig.
  • Page 157 Power consumer Rear window heater Power windows - front passenger Trailer device - electrical outlet Cigarette lighter, 12-volt socket in the interior, 12-volt socket in the luggage compartment Power windows - rear right Front and rear window washer, operating lever under the steering wheel Fig.

  • Page 158: Bulbs

    Power consumer Fuse arrangement in the engine compartment Lambda probe Fig. 189 Glow plug system, crankcase ventilation heater Fuses Bulbs  Introduction This chapter contains information on the following subjects: Bulb arrangement in the front headlights Replacing the bulb for the side light (Halogen headlights) ...
  • Page 159 WARNING (Continued) Replacing the bulb for the side light (Halogen headlights) H7 and H15 bulbs are pressurised and may burst when changing the bulb - ■ risk of injury! We therefore recommended wearing gloves and safety glasses when changing a bulb. Do not carry out any work on the Xenon gas discharge lamps - risk of ■...
  • Page 160 Changing the bulb for the front turn signal light Fig. 194 Changing the bulb for the front turn signal light Fig. 193 Change the light bulb for the parking light  Read and observe on page 156 first.  Read and observe on page 156 first.
  • Page 161 Refit the headlight and grille Changing light bulbs for fog lights › Replace the fog light by inserting it in the opposite direction of the arrow » Fig. 195 and tightening. › Insert the guard and push it gently until it locks into place. Changing the bulb for the licence plate light Fig.
  • Page 162 › Close the boot lid. Removing/installing taillights CAUTION Ensure that the cable bundle does not become pinched between the body ■ and the lamp when it is being refitted – risk of damage to the electrical instal- lation and risk of water ingress. If you are not sure whether the cable bundle has become pinched, we recom- ■...
  • Page 163 The lamp holder must engage firmly. Fuses and light bulbs...

  • Page 164: Technical Data

    Technical data Vehicle data Technical data Basic vehicle data  Introduction This chapter contains information on the following subjects: Vehicle data Operating weight Payload Fig. 199 Vehicle data sticker/type plate Measurement of fuel consumption and CO emissions according to ECE Vehicle data sticker Regulations and EU Directives The vehicle data sticker...
  • Page 165 Maximum permissible front axle load Operating weight Maximum permissible rear axle load Engine Gearbox Operating weight (kg) Vehicle identification number (VIN) 1160 1.2 l/66 kW TSI The vehicle identification number - VIN (vehicle body number) is stamped into 1194 the engine compartment on the right hand suspension strut dome. This num- 1.2 ltr./81 kW TSI 1180 ber is also located on a sign on the lower left hand edge below the windscreen...
  • Page 166 In the extra-urban driving cycle, the vehicle is accelerated and decelerated in all gears, corresponding to daily routine driving conditions. The driving speed varies between 0 and 120 km/h. The calculation of the combined fuel consumption considers a weighting of about 37 % for the intra-urban cycle and 63 % for the extra-urban cycle.
  • Page 167 Dimensions Fig. 200 Vehicle dimensions Vehicle dimensions for operating weight without driver (in mm) » Fig. 200 Specification Value Height 1459 Basic dimension 1457 Front track Vehicles with the 1.2 l/66 kW TSI and 1.4 l/66 kW TDI CR engine 1463 Width 1706...
  • Page 168 Departure angle Fig. 201 Overhang angle Angle » Fig. 201 Overhang angle, front Overhang angle, rear The overhang angle values indicate the maximum incline of a slope, up which the vehicle can drive at a slow speed without the bumper or underbody mak- ing contact with the slope.

  • Page 169: Vehicle-Specific Details Per Engine Type

    Vehicle-specific details per engine type  Introduction This chapter contains information on the following subjects: 1.6 l/81 kW MPI engine 1.4 l/66 kW TDI CR engine 1.2 ltr. / 66 kW TSI engine 1.6 l/85 kW TDI CR engine 1.2 ltr. / 81 kW TSI engine 1.4 ltr./92 kW TSI engine The specified values have been determined in accordance with rules and under conditions set out by legal or technical requirements for determining operational and technical data for motor vehicles.
  • Page 170 1.4 ltr./92 kW TSI engine Output (kW/rpm) 92/5000 Maximum torque (Nm at rpm) 200 / 1400-4000 Number of cylinders/displacement (cm 4/1395 Transmission Top speed (km/h) Acceleration 0-100 km/h (s) 1.6 l/81 kW MPI engine Output (kW/rpm) 81/5800 Maximum torque (Nm at rpm) 155/3800 Number of cylinders/displacement (cm 4/1598...

  • Page 171: Index

    Armrest Bonnet Index Front Closing Rear Opening Ashtray Boot Cargo element Assembling the Operation Class N1 vehicles tow bar, Step 1 Warning light Hooks tow bar, Step 2 See boot lid Acceptance and recycling of used vehicles Assist systems Storage compartments Accessories Auto Check Control Boot cover...
  • Page 172 Changing wheels Coolant Wheels Checking Camera Refilling Charging a vehicle battery See reversing camera Temperature display Check Warning light Brake fluid See Owner´s Manual -Infotainment CORNER Engine oil Car battery See Fog lights with the CORNER function Fit ball head properly Check condition Oil level Correct routing of seat belt...
  • Page 173 Disposal Unlocking/locking the door Fatigue detection Acceptance and recycling of used vehicles Unlocking / locking the door Films Distance warning Emergency equipment Fire extinguisher Warning light Fire extinguisher First aid kit First aid kit Door Flashing Jack Child safety lock Floor covering in the luggage compartment Reflective vest Emergency locking...
  • Page 174 Gear change Information system Lamps Gear recommendation Auto Check Control Warning light Information on the selected gear Door alarm LEAVING HOME Gear recommendation Gear changing Lever MAXI DOT display Gear stick Cruise control Multifunction display Genuine parts Front Assist Service interval display Operation of the information system Glasses compartment Infotainment...
  • Page 175 Locking Menu item telephone Oil changing Central locking button Operation Engine oil in case of emergency Maximum speed On-board computer KESSY see multifunction display Remote control Operating weight Mechanical window Lock steering lock Open and close Original accessories Low beam Media Overview Low tyre pressure warning...
  • Page 176 Practical features Rev counter Heating Pockets Rear Reversing camera Storage compartment for umbrella Rear armrest Rims Waste container Rear seat backrests Roof Setting Preheating unit Load Seats and head restraint Roof rack Selector lever Running in Selector lever control Radio Brake pads Selector lever lock See Owner´s Manual - Infotainment...
  • Page 177 Sound Stopping the engine Tiptronic See Owner´s Manual -Infotainment Tools Starter button Spare wheel TOP TETHER Removing / stowing Storage Towing Speed control system Storage compartment Towing a trailer Glasses compartment Speed limiter Towing away in the boot Warning light Towing device in the centre console Speed regulating system...
  • Page 178 Tyres Weights 162, 163 damage Wheel bolts Variable loading floor Explanation of the label Anti-theft wheel bolts Vehicle battery Caps Automatic shutdown of consumers Tyre pressure Loosening and tightening charging Wear indicator Wheels Safety instructions Tyre size Full trim Vehicle care Load Index Vehicle cleaning Snow chains...
  • Page 179 Winter tyres Wipers and washer Warning light for windscreen washer fluid level 36 Wiping interval Index...
  • Page 180 Index...
  • Page 181 Reprinting, reproduction, translation, or any other use, either in whole or in Issued by: ŠKODA AUTO a.s. part, is not permitted without the written consent of ŠKODA AUTO a.s. © ŠKODA AUTO a.s. 2016 ŠKODA AUTO a.s. expressly reserves all rights relating to copyright laws. Subject to change.
  • Page 184 Návod k obsluze Rapid Spaceback anglicky 05.2016 S57.5610.06.20 5JJ012720AF  5JJ012720AF...

This manual is also suitable for:

Rapid

Table of Contents
