Panel Description - Icom IC-F5060 SERIES Instruction Manual

1

PANEL DESCRIPTION

TX CODE CHANNEL UP/DOWN KEYS
Push to directly select a TX code channel.
SCRAMBLER/ENCRYPTION KEY
➥ While in the analog mode, push to toggle the voice scram-
bler function ON or OFF.
➥ While in the digital mode, push to toggle the encryption
transmission function ON or OFF.
COMPANDER KEY
Push to toggle the compander function ON or OFF.
The compander function reduces noise components from
the transmitted audio to provide clear communications.
ID-MR SELECT KEY (PMR operation only)
➥ Recalls detected ID codes.
• Push this key, then select the ID code using [CH Up]/
[CH Down].
• Up to 5 ID's are memorized.
➥ Hold down for 1 second to erase the selected ID's.
HOOK SCAN KEY
When the on hook scan function is activated, push this key
to disable the on hook scan function (stop scanning) tempo-
rarily. Push this key again to resume the scanning.
7
USER SET MODE KEY
➥ Hold down for 1 second to enter the user set mode.
• While in the user set mode, push this key to select an item that is
enabled by your dealer, and change the value or condition using
[CH Up]/[CH Down].
➥ Hold down this key for 1 second again to exit the user set
mode.
10Key ENT KEY
Push to enable the connected microphone's 10-keypad oper-
ation.
• The desired memory channel, TX code channel (5-Tone), ID list
number (digital), TX status (MSK/Digital) or Short Data Message
(digital) can be selected. (Depends on the pre-programming.)
OPT 1/2/3 KEYS
Push to control the output signal level from an optional unit.
POWER OFF EMERGENCY
While holding down this key, turn the transceiver's power OFF
to activate the Power OFF Emergency function.
After the specified time period has passed, from the time this
function is activated, the emergency call is transmitted with
no beep sound and no display indication. (p. 14)
