Daewoo RC900M0001 Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
RC900M0001

VACUUM CLEANER

Model : RC-900M
OCT. 2005

Advertisement

Table of Contents
loading

Related Manuals for Daewoo RC900M0001

Summary of Contents for Daewoo RC900M0001

  • Page 1: Vacuum Cleaner

    RC900M0001 VACUUM CLEANER Model : RC-900M OCT. 2005...

  • Page 2: Table Of Contents

    CONTENTS Page 1. SPECIFICATIONS ---------------------------------------------------- 2. EXTERNAL VIEWS --------------------------------------------------- 3. DIAGRAM --------------------------------------- 3-1. WIRING DIAGRAM 3-2. CIRCUIT DIAGRAM 4. TROUBLE SHOOTING GUIDE ------------------------------------ 5. DISASSEMBLING AND TREATMENT 5-1. CLEANER ASSEMBLY ---------------------------------------------- 5-2. BODY ASSEMBLY -------------------------------------------------------- 5-3. MOTOR ASSEMBLY ----------------------------------------------------- 5-4. CORDREEL ASSEMBLY ------------------------------------------------ 10 5-5.

  • Page 3: Specifications

    1. SPECIFICATIONS MODEL RC-900M Rated Voltage AC 230V Rated Frequency 50/60Hz Input Watt 2000W Suction Power 400W Noise Level 78dB(A) Weight (Body) 7.2Kg Dimension (WXHXD) 546 X 250 X 290 mm Cord Length 6.0m Filter HEPA Hose Current 1.6m Pipe Telescopic(Steel) Pedal Crevice Tool...

  • Page 4: External Views

    2. EXTERNAL VIEWS PART NAME RC-900M UNIT FILTER HEPA HOSE ASSEMBLY 2-CURRENT PIPE ASSEMBLY TELESCOPIC (STEEL) BRUSH ASSEMBLY PEDAL...

  • Page 5: Diagram

    3. DIAGRAM 3-1. WIRING DIAGRAM 1) MODEL RC-900M 3-2. CIRCUIT DIAGRAM 1) MODEL RC-900M...

  • Page 6: Trouble Shooting Guide

    4. TROUBLE SHOOTING GUIDE TROUBLE CAUSE COUNTERMEASURE SUCTION POWER FILTER BAG(CLOTH)/DUST BOX IS CHANGE IT WITH NEW ONE (See 5-1) IS WEAK FULL WITH DUST REMOVE THE DUST IN DUST BOX FILTER PRE IS CLOGGY WITH DUST REMOVE THE DUST (See 5-2) CLOGGING OR TEAR IN HOSE REMOVE OBSTACLE OR REPLACE THE HOSE (See 5-6)
  • Page 7 TROUBLE CAUSE COUNTERMEASURE BROKEN REEL SPRING REPLACE IT (See 5-4) OF CORD REEL POWER CORD IS NOT WOUND UP POWER CORD BROKE AWAY REPAIR (See 5-4) FROM THE BOBBIN BE CAREFUL WHEN BREAKING UP THE CORD REEL, THE REELSPRING CAUTION MAY SPRING OUT OF THE SPRING COVER.

  • Page 8: Disassembling And Treatment

    5. DISASSEMBLING AND TREATMENT 5-1. CLEANER ASSEMBLY 1) LIFT THE BUTTON(11), FILTER(12), GRILLE(13) AND UNSCREW THE 6 SCREWS(10) AND THEN LIFT THE COVER ASSEMBLY(9) UP FROM THE BODY ASSEMBLY(1). 2) CHECK CONNECTION BETWEEN THE PCB(8) AND THE WIRES OF EACH ASSEMBLY(2,7,9) 3) LIFT THE MOTOR ASSEMBLY(2), CORDREEL ASSEMBLY(7) FROM THE BODY ASSEMBLY.

  • Page 9: Body Assembly

    5-2. BODY ASSEMBLY 1) CHECK THE FILTER IN (15). 2) CHECK THE SCREW(20) 3) CHECK CONNECTION BETWEEN THE WIRE(21) AND THE MAIN PCB/ CORDREEL ASSEMBLY.

  • Page 10: Motor Assembly

    5-3. MOTOR ASSEMBLY 1) TAKE THE MOTOR OUT OF THE CASE (3, 4). 2) CHECK THE MOTOR(1) (WHETHER THE MOTOR IS BURNT OUT OR NOT). 3) CHECK CONNECTION BETWEEN MOTOR TERMINAL AND THE WIRES. 4) CHECK THE THERMOSTAT(6). 5) CHECK CONNECTION BETWEEN THE THERMOSTAT(6) AND THE WIRE HARNESS(10)

  • Page 11: Cordreel Assembly

    5-4. CORDREEL ASSEMBLY...
  • Page 12 1) TAKE THE CORD REEL ASSEMBLY OUT OF THE BODY ASSEMBLY. 2) UNSCREW THE SCREW(20). 3) SEPARATE THE BOBBIN(6) FROM THE BRACKET(1) AND CHECK CONTACT BETWEEN THE Y TYPE TERMINALS(14,15) AND THE RING TYPE TERMINALS(8,9). 4) CHECK THE LEVER SPRING(4). 5) IF THE ROLLER BRAKE(3) IS WORN OUT AND SEPARATE THE LEVER(2) FROM THE BRACKET THEN REPLACE THE ROLLER BRAKE(3).

  • Page 13: Pcb Assembly

    5-5. PCB ASSEMBLY 1) MODEL RC-900M 1) CHECK THE CONNECTIONS BETWEEN THE WIRES AND PCB BOARD. 2) CHECK THE THERMOSTAT...

  • Page 14: Hose Assembly

    5-6. HOSE ASSEMBLY 1) MODEL RC-900M 1) UNSCREW THE 2 SCREWS(20) AND DISASSEMBLE THE COVER(19) FROM PIPE(13). 2) CHECK CONNECTION BETWEEN THE TERMINALS(15) AND THE SLIDE VOLUME(14). 3) CHECK THE SLIDE VOLUME(14). 4) CHECK CONNECTION BETWEEN WIRES OF THE TERMINAL(15) AND THE HOSE(9).

  • Page 15: Brush Assembly

    5-7. BRUSH ASSEMBLY 1) TO SEPARATE THE PIPE BRUSH(4) FROM THE COVER BRUSH(1), UNSCREW THE 4 SCREWS(15). 2) CHECK OPENING OF THE NECK BRUSH(8) AND THE PIPE BRUSH(5).

  • Page 16: Exploded View And Parts List

    6.EXPLODED VIEW AND PARTS LIST 6-1. CLEANER ASSEMBLY 1) MODEL RC-900M...
  • Page 17 PART NAME PART CODE SPECS. Q'YT BODY AS 3620411610 ASSY(RC-900) MOTOR UNIVERSAL 3962511860 230V 1800W DMI(F) VA122C7130 PACKING MOTOR 3624008300 NR FOAM CASE MOTOR FRONT 3621106200 CASE MOTOR REAR AS 3621106520 ASSY SCREW TAPPING 7121401411 T2S PAN 4X14 MFZN CORD REEL AS 3629508220 ASSY PCB AS...

  • Page 18: Body Assembly

    6-2. BODY ASSEMBLY 1) MODEL RC-900M...
  • Page 19 PART NAME PART CODE SPECS. Q'YT BODY 3620411500 SHAFT CASTER 3624902000 MSWR SCREW TAPPING 7048402012 MACHINE 4X14 WASHER BLACK BRACKET ROLLER 3620602900 PA, RHODIA, TECHNYL 1011HI ROLLER CASTER 3624706400 PVC-S + POM SHAFT ROLLER 3624902100 MSWR HOLDER BRUSH 3623007000 PC(LEXAN121) SCREW TAPPING 7121401411 T2S PAN 4X14 MFZN...

  • Page 20: Cover Body Assembly

    6-3. COVER BODY ASSEMBLY 1) MODEL RC-900M...
  • Page 21 PART NAME PART CODE SPECS. Q'YT COVER BODY 3621434220 ABS+PAINTING ABSORBER VIBRATION 3620102810 NR FOAM FILTER MIDDLE 3621908400 PE+TAPE SWITCH PUSH 3629002000 7A, 250V (SKT) PACKING PCB 3624008600 HARNESS 3622714950 ASSY(TER+WIRE+HOUSING) SCREW TAPPING 7121401411 T2S PAN 4X14 MFZN SUPPORTER STAND 3625300600 SPRING BUTTON 3625110000...

  • Page 22: Cover Dust Assembly

    6-4. COVER DUST ASSEMBLY 1) MODEL RC-900M...
  • Page 23 PART NAME PART CODE SPECS. Q'YT COVER DUST 3621434310 ABS+PAINTING PLATE DUST COVER 3624502400 CASE TERMINAL BOTTOM 3621106400 SOCKET 3629801900 ABS(AF305) CASE TERMINAL 3621101700 HARNESS 3622714950 ASSY CLAMP COVER 3621202900 SPRING CLAMP 3625106400 HSW3 CLAMP NOZZLE 3621203000 BUTTON NC 3626606900 SPRING SWEEPER 3625107900 HSW3...

  • Page 24: Motor Assembly

    6-5. MOTOR ASSEMBLY 1) MODEL RC-900M PART NAME PART CODE SPECS. Q'YT MOTOR UNIVERSAL 3962511860 230V 1800W DMI(F) VA122C7130 PACKING MOTOR 3624008300 NR FOAM CASE MOTOR FRONT 3621106200 CASE MOTOR REAR 3621106300 MOUNT MOTOR 3627901800 THERMOSTAT 3629002100 KI T95 SCREW TAPPING 7121300811 T2S PAN 3X8 MFZN HARNESS...

  • Page 25: Cordreel Assembly

    6-6. CORDREEL ASSEMBLY 1) MODEL RC-900M...
  • Page 26 PART NAME PART CODE SPECS. Q'YT BRACKET CR 3620603000 LEVER CR 3623703200 STOPPER ASSY 3625200200 ASSY SPRING CR LEVER 3625109800 HSW3 SCREW TAPPING 7128401011 T2S WAS 4X10 MFZN BOBBIN 3629200900 HOLDER TERMINAL 4565A36020 PP(5101SW,V-0) TERMINAL 4565A36024 C2600P-1/2H T0.3 TERMINAL 4565A36034 C2600P-1/2H T0.3 10 CORD POWER 3621302500...

  • Page 27: Pcb Assembly

    6-7. PCB ASSEMBLY 1) MODEL RC-900M PART NAME PART CODE SPECS. Q'YT 3624314600 1.6T, FR-1 HARNESS 3622714710 ASSY HEAT SINK 3624302920 20*50.3T RIVET 7523240820 KVEX K1671-00412 CONN WAFER 997920007R MG 640598-1 CONN WAFER 997920007N MG 640598NETURAL C MYLAR CMXV2A224J AC63V(DC100V) 0.22MF J C MYLAR CL 1DB3154K AC 275V 0.15MF K DIAC DIAC...

  • Page 28: Hose Assembly

    6-8. HOSE ASSEMBLY 1) MODEL RC-900M...
  • Page 30 PART NAME PART CODE SPECS. Q'YT PIPE INNER ADAPTER 3624414800 ABS(AF305) FRAME FIRST RING 3622202900 FRAME TERMINAL AS 3622203200 ASSY (ADAPTER, SECOND) PIPE ADAPTER 3624414900 SUPPORTER TERMINAL 3625300700 ABS(AF305) COVER TERMINAL SUPPORTER 3621434600 ABS(AF305) BUTTON HOSE ADAPTER 3626607200 COVER ADAPTER RIGHT 3621434700 COVER ADAPTER LEFT 3621434800...

  • Page 31: Pipe Assembly

    6-9. PIPE ASSEMBLY 1) MODEL RC-900M PART NAME PART CODE SPECS. Q'YT PIPE AS 3624411420 ASSY(SPC. T=0.7 - CR)

  • Page 32: Brush Assembly

    6-10. BRUSH ASSEMBLY 1) MODEL RC-900M...
  • Page 33 PART NAME PART CODE SPECS. Q'YT COVER BRUSH 3621420800 DUCT BRUSH 3629306300 NECK BRUSH 3628002100 PIPE BRUSH 3624408300 PP, CLEAN BR PIPE ROLLER-F BRUSH 3624704310 SHAFT ROLLER 3624900900 ROLLER-B BRUSH 3624704400 BUTTON BRUSH 3626604400 SPRING BUTTON 3625107300 SK-5,T=0.3 SCREW TAPPING 7128400811 T2S WAS 4X8 MFZN SWEEPER BRUSH AS...
