HTC ROSE Service Manual

Qwerty keyboard
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Doc. No.
DOC-00045381
REV.
HTC Corporation
Issued Date
2008/8/12
A02
.
Revised Date
2008/11/13
Page
1 of 94
Doc. Title
ROSE Service Manual
ROSE
Service Manual
HTC Proprietary
U
Confidential Treatment Requested
Rev. A03
HTC Corp.
Engineering Mobility
HTC CONFIDENTIAL
SM-TP001-0812

Advertisement

Table of Contents
loading

Related Manuals for HTC ROSE

Summary of Contents for HTC ROSE

  • Page 1 Doc. No. DOC-00045381 REV. HTC Corporation Issued Date 2008/8/12 Revised Date 2008/11/13 Page 1 of 94 Doc. Title ROSE Service Manual ROSE Service Manual HTC Proprietary Confidential Treatment Requested Rev. A03 HTC Corp. Engineering Mobility HTC CONFIDENTIAL SM-TP001-0812...
  • Page 2 Doc. No. DOC-00045381 REV. HTC Corporation Issued Date 2008/8/12 Revised Date 2008/11/13 Page 2 of 94 Doc. Title ROSE Service Manual REVISION CONTROL TABLE DATE CONTENTS DEPT REVISED STAGE AX01 2008/8/12 Fist Draft Clement_Chen 2008/10/3 First Release Complete SM Clement_Chen Modify Board Level 2.5...

  • Page 3: Table Of Contents

    DOC-00045381 REV. HTC Corporation Issued Date 2008/8/12 Revised Date 2008/11/13 Page 3 of 94 Doc. Title ROSE Service Manual 1. INTRODUCTION ..................................4 1.1 P ............................5 RODUCT EATURES 1.2 P ............................10 RODUCT OVERVIEW 2. DEVICE DISASSEMBLING AND ASSEMBLING PROCEDURE ................17 2.1 T ..............................17...

  • Page 4: Introduction

    Page 4 of 94 Doc. Title ROSE Service Manual 1. Introduction This manual provides the technical information to support the service activities of this product. This document contains highly confidential information, so any or all of this document should not be revealed to any third party.

  • Page 5: Product Features

    Doc. No. DOC-00045381 REV. HTC Corporation Issued Date 2008/8/12 Revised Date 2008/11/13 Page 5 of 94 Doc. Title ROSE Service Manual 1.1 Product Features HTC CONFIDENTIAL SM-TP001-0812...
  • Page 6 Doc. No. DOC-00045381 REV. HTC Corporation Issued Date 2008/8/12 Revised Date 2008/11/13 Page 6 of 94 Doc. Title ROSE Service Manual HTC CONFIDENTIAL SM-TP001-0812...
  • Page 7 Doc. No. DOC-00045381 REV. HTC Corporation Issued Date 2008/8/12 Revised Date 2008/11/13 Page 7 of 94 Doc. Title ROSE Service Manual HTC CONFIDENTIAL SM-TP001-0812...
  • Page 8 Doc. No. DOC-00045381 REV. HTC Corporation Issued Date 2008/8/12 Revised Date 2008/11/13 Page 8 of 94 Doc. Title ROSE Service Manual HTC CONFIDENTIAL SM-TP001-0812...
  • Page 9 Doc. No. DOC-00045381 REV. HTC Corporation Issued Date 2008/8/12 Revised Date 2008/11/13 Page 9 of 94 Doc. Title ROSE Service Manual HTC CONFIDENTIAL SM-TP001-0812...

  • Page 10: Product Overview

    Doc. No. DOC-00045381 REV. HTC Corporation Issued Date 2008/8/12 Revised Date 2008/11/13 Page 10 of 94 Doc. Title ROSE Service Manual 1.2 Product overview HTC CONFIDENTIAL SM-TP001-0812...
  • Page 11 Doc. No. DOC-00045381 REV. HTC Corporation Issued Date 2008/8/12 Revised Date 2008/11/13 Page 11 of 94 Doc. Title ROSE Service Manual HTC CONFIDENTIAL SM-TP001-0812...
  • Page 12 Doc. No. DOC-00045381 REV. HTC Corporation Issued Date 2008/8/12 Revised Date 2008/11/13 Page 12 of 94 Doc. Title ROSE Service Manual HTC CONFIDENTIAL SM-TP001-0812...
  • Page 13 Doc. No. DOC-00045381 REV. HTC Corporation Issued Date 2008/8/12 Revised Date 2008/11/13 Page 13 of 94 Doc. Title ROSE Service Manual Installing the SIM card HTC CONFIDENTIAL SM-TP001-0812...
  • Page 14 Doc. No. DOC-00045381 REV. HTC Corporation Issued Date 2008/8/12 Revised Date 2008/11/13 Page 14 of 94 Doc. Title ROSE Service Manual Installing the SD card HTC CONFIDENTIAL SM-TP001-0812...
  • Page 15 Doc. No. DOC-00045381 REV. HTC Corporation Issued Date 2008/8/12 Revised Date 2008/11/13 Page 15 of 94 Doc. Title ROSE Service Manual To install / remove the battery HTC CONFIDENTIAL SM-TP001-0812...
  • Page 16 Doc. No. DOC-00045381 REV. HTC Corporation Issued Date 2008/8/12 Revised Date 2008/11/13 Page 16 of 94 Doc. Title ROSE Service Manual Charging the battery Using the Strap Holder HTC CONFIDENTIAL SM-TP001-0812...

  • Page 17: Device Disassembling And Assembling Procedure

    HTC Corporation Issued Date 2008/8/12 Revised Date 2008/11/13 Page 17 of 94 Doc. Title ROSE Service Manual 2. Device Disassembling and Assembling Procedure 2.1 Tools list level No. Item Vendor 1 Mini USB DATA interface Cable 2 Earphone Headset 3 AC Adapter 4 WLAN AP Memory Card with Diag.

  • Page 18: Disassembling Procedure

    Doc. No. DOC-00045381 REV. HTC Corporation Issued Date 2008/8/12 Revised Date 2008/11/13 Page 18 of 94 Doc. Title ROSE Service Manual 2.2 Disassembling procedure 1. C LEANING CLOTH 2. ESD GLOVE OR WRIST STRAP 3. P LASTIC TWEEZERS 4. F...
  • Page 19 REV. HTC Corporation Issued Date 2008/8/12 Revised Date 2008/11/13 Page 19 of 94 Doc. Title ROSE Service Manual 1. T AKE OUT THE BATTERY AS SHOWN 2. L OOSEN INDICATED SCREWS FROM THE HOUSING 1. E XTEND THE KEYBOARD BY SLIDING THE DISPLAY UP 2.
  • Page 20 DOC-00045381 REV. HTC Corporation Issued Date 2008/8/12 Revised Date 2008/11/13 Page 20 of 94 Doc. Title ROSE Service Manual 1. U PLASTIC TWEEZER DISCONNECT THE SPEAKER AT THE LOCATION INDICATED AUTION VOID DAMAGE THE SPEAKER 1. U SE THE FLAT PLASTIC STICK...
  • Page 21 Issued Date 2008/8/12 Revised Date 2008/11/13 Page 21 of 94 Doc. Title ROSE Service Manual 1. U SE THE FLAT PLASTIC STICK TO RELEASE THE I/O BOARD FPC CONNECTOR PLASTIC TWEEZER TO REMOVE THE INDICATED I/O BOARD FPC. 1. U...
  • Page 22 Doc. No. DOC-00045381 REV. HTC Corporation Issued Date 2008/8/12 Revised Date 2008/11/13 Page 22 of 94 Doc. Title ROSE Service Manual 1. U SE THE FLAT PLASTIC STICK DISCONNECT INDICATED CONNECTOR 2. R EMOVE CONDUCTIVE FABRIC LOCATION INDICATED. SE THE FLAT PLASTIC STICK...
  • Page 23 Doc. No. DOC-00045381 REV. HTC Corporation Issued Date 2008/8/12 Revised Date 2008/11/13 Page 23 of 94 Doc. Title ROSE Service Manual 1. R EMOVE THE I O BOARD FROM THE C COVER AS SHOWN 1. C AREFULLY REMOVE CONDUCTICE FABRIC FROM...
  • Page 24 REV. HTC Corporation Issued Date 2008/8/12 Revised Date 2008/11/13 Page 24 of 94 Doc. Title ROSE Service Manual 1. D QWERTY ISASSEMBLE THE KEYPDA AND C COVER BY LIFTING THEM UP AS SHOWN 1. L OOSEN INDICATED SCREWS FROM THE B CORVER 2.
  • Page 25 Doc. No. DOC-00045381 REV. HTC Corporation Issued Date 2008/8/12 Revised Date 2008/11/13 Page 25 of 94 Doc. Title ROSE Service Manual 1. R ELEASE THE FPC CONNECTOR AND REMOVE THE FPC INDICADED EMOVE CONDUCTIVE FABRIC LOCATION INDICATED. SE THE PLASTIC TWEEZERS...
  • Page 26 DOC-00045381 REV. HTC Corporation Issued Date 2008/8/12 Revised Date 2008/11/13 Page 26 of 94 Doc. Title ROSE Service Manual 1. R EMOVE CONDUCTIVE FABRIC LOCATION INDICATED 1. U SE THE FLAT PLASTIC STICK TO DISCONNECT THE LCD FPC CONNECTOR INDICATED 2.
  • Page 27 Issued Date 2008/8/12 Revised Date 2008/11/13 Page 27 of 94 Doc. Title ROSE Service Manual 1. U SE THE PLASTIC TWEEZER CAREFULLY TO TEAR DOWN THE INDICATED TWO VOLUME SWITCHS FROM LCD METAL HOLDER AS SHOWN TEAR DOWN THE LCD FPC FROM LCD METAL HOLDER 1.
  • Page 28 REV. HTC Corporation Issued Date 2008/8/12 Revised Date 2008/11/13 Page 28 of 94 Doc. Title ROSE Service Manual OOSEN THE INDICATED SCREWS FROM THE A COVER SE PLASTIC TWEEZER TO DISASSEMBLE DOOR HOLDER AS SHOWN ISASSEMBLE THE KEYPAD FROM A COVER BY LIFTING IT...
  • Page 29 HTC Corporation Issued Date 2008/8/12 Revised Date 2008/11/13 Page 29 of 94 Doc. Title ROSE Service Manual 1. P UT THE PRE ASSY LCD WITH A COVER INTO AN OVEN ABOUT MINUTES DEGREE CELCIUS 2. D ISASSEMBLE THE PRE ASSY...

  • Page 30: Assembling Procedure

    Doc. No. DOC-00045381 REV. HTC Corporation Issued Date 2008/8/12 Revised Date 2008/11/13 Page 30 of 94 Doc. Title ROSE Service Manual 2.3 Assembling procedure 1. U ADHESIVE DOUBLE TAPE TO PASTE ON THE A COVER SHOWEN (ADHESIVE DOUBLE TAPE P/N 76H02971-00M) 1.
  • Page 31 REV. HTC Corporation Issued Date 2008/8/12 Revised Date 2008/11/13 Page 31 of 94 Doc. Title ROSE Service Manual 1. U SE THUMBS TO PRESS INDICATED CORNERS GENTLY SHOWN 2. C HECK THE REAR SIDE OF THE PRE ASSY LCD TO...
  • Page 32 Doc. No. DOC-00045381 REV. HTC Corporation Issued Date 2008/8/12 Revised Date 2008/11/13 Page 32 of 94 Doc. Title ROSE Service Manual 1. F ASTEN THE SCREWS AT THE LOCATIONS INDICATED SCREW 72H02991-00M : 0.5-0.01 ORQUE 2. I NSTALL THE RECEIVER AT THE LOCATION INDICATED 1.
  • Page 33 Doc. No. DOC-00045381 REV. HTC Corporation Issued Date 2008/8/12 Revised Date 2008/11/13 Page 33 of 94 Doc. Title ROSE Service Manual AUTION LEASE BEND THE FPC BETWEEN THE VOLUME SWITCHS INDICATED ARCH SHAPE 1. P LACE THE LCD METAL HOLDER AND LCD FPC ON THE A COVER AS SHOWN 2.
  • Page 34 REV. HTC Corporation Issued Date 2008/8/12 Revised Date 2008/11/13 Page 34 of 94 Doc. Title ROSE Service Manual 1. U SE THE FLAT PLASTIC STICK TO CONNECT THE CONNECTOR INDICATED 2. U PLASTIC TWEEZERS TO INSERT THE LCD FPC INTO THE LOWER...
  • Page 35 REV. HTC Corporation Issued Date 2008/8/12 Revised Date 2008/11/13 Page 35 of 94 Doc. Title ROSE Service Manual 1. U PLASTIC TWEEZERS TO INSERT THE POWER BUTTON INTO THE POWER BUTTON SLOT OF THE A COVER 2. U PLASTIC TWEEZERS TO INSERT THE...
  • Page 36 Doc. No. DOC-00045381 REV. HTC Corporation Issued Date 2008/8/12 Revised Date 2008/11/13 Page 36 of 94 Doc. Title ROSE Service Manual 1. F ASTEN THE SCREWS TO THE B CORVER AT THE LOCATIONS INDICATED SCREW 72H02986-00M : 0.8-0.05 ORQUE 2. F...
  • Page 37 REV. HTC Corporation Issued Date 2008/8/12 Revised Date 2008/11/13 Page 37 of 94 Doc. Title ROSE Service Manual 1. P ASTE CONDUCTIVE FABRIC AT THE LOCATION INDICATED FPC CONDUCTIVE FABRIC 72H02957-00M 1. C ONNECT THE INDICATED M/B FPC CONNECTOR TO...
  • Page 38 REV. HTC Corporation Issued Date 2008/8/12 Revised Date 2008/11/13 Page 38 of 94 Doc. Title ROSE Service Manual 1. U PLASTIC TWEEZERS TO INSERT THE LCD FPC INTO THE LOWER BOARD SLOT SHOWN 2. G ET ALLY THE INDICATED 2...
  • Page 39 DOC-00045381 REV. HTC Corporation Issued Date 2008/8/12 Revised Date 2008/11/13 Page 39 of 94 Doc. Title ROSE Service Manual 1. P ASTE THE KAPTON TAPES LOCATIONS INDICATED KAPTON TAPE 76H01925-00M 1. U SE PLASTIC TWEEZER TO CONNECT THE SPEAKER AS SHOWN 2.
  • Page 40 REV. HTC Corporation Issued Date 2008/8/12 Revised Date 2008/11/13 Page 40 of 94 Doc. Title ROSE Service Manual 1. H OLD THE THUMBS ON THE TOP LEFT AND BOTTOM RIGHT OF THE BATTERY COVER SLIDE DOWNWARDS ASSEMBLY COMPLETE HTC CONFIDENTIAL...

  • Page 41: Rom Re-Flash Procedure

    2008/8/12 Revised Date 2008/11/13 Page 41 of 94 Doc. Title ROSE Service Manual 3. ROM Re-flash Procedure 3.1 ROM upgrade thru RUU (Re-flash Upgrade Utility) Connect device to PC 1. Setting and allow USB connections in Microsoft ActiveSync. 2. Connect your device and desktop/ or laptop via USB cable.
  • Page 42 2008/8/12 Revised Date 2008/11/13 Page 42 of 94 Doc. Title ROSE Service Manual Check the setting of menu 6. Select the type of USB connection with “ActiveSync” mode in the settings of menu. RUU-1 7. Hold the volume down key then press power button to trigger the boot loader mode.
  • Page 43 Issued Date 2008/8/12 Revised Date 2008/11/13 Page 43 of 94 Doc. Title ROSE Service Manual RUU – 3 12. Current image version confirmation. 13. Click “Update” to proceed RUU-4 14. Double verify the ROM revision which you want to update before re-flash procedure.
  • Page 44 2008/8/12 Revised Date 2008/11/13 Page 44 of 94 Doc. Title ROSE Service Manual RUU – 6 18. You can see the update progress from your PC and in your device. RUU – 7 19. The OS upgrade is finished, click “Finish”...

  • Page 45: Rom Image Upgrade Thru Sd Card

    Issued Date 2008/8/12 Revised Date 2008/11/13 Page 45 of 94 Doc. Title ROSE Service Manual 3.2 ROM Image upgrade thru SD card Download OS Image from SDO 1. Download OS image from SDO. http://htcscm10.htc.com.tw/SDO Un-zip the image file. Format SD card and copy image file to SD card 3.
  • Page 46 Issued Date 2008/8/12 Revised Date 2008/11/13 Page 46 of 94 Doc. Title ROSE Service Manual SD Upgrade - 1 5. Turn the device power off and insert micro SD card. 6. Press and hold Volume down Power button and then release the power button first to enter Boot loader mode.

  • Page 47: Diagnostic Program

    DOC-00045381 REV. HTC Corporation Issued Date 2008/8/12 Revised Date 2008/11/13 Page 47 of 94 Doc. Title ROSE Service Manual 4. DIAGNOSTIC PROGRAM 4.1 List of Diagnostic Test Items Mode No Item Description Remark Function Test Auto Auto Regular Tests (Display, B.L, Vibrator, etc…) Display Test Color bar/R/G/B/Black/White/Gray pattern.
  • Page 48 DOC-00045381 REV. HTC Corporation Issued Date 2008/8/12 Revised Date 2008/11/13 Page 48 of 94 Doc. Title ROSE Service Manual Mode No Item Description Remark Bluetooth Test Bluetooth Function Test USB Test USB link test (Microsoft ActiveSync) Camera Test Camera Function Test...
  • Page 49 Page 49 of 94 Doc. Title ROSE Service Manual Test Procedure How to select test item: Using navigation button -"Up" or "Down" to select the test items How to execute the test program: Press “Action” button to start each of test items.
  • Page 50 2008/8/12 Revised Date 2008/11/13 Page 50 of 94 Doc. Title ROSE Service Manual ROM Checksum Test 7. Press Action key to select 8. The Rom Checksum will be displayed on the screen LED Test 9. Press Action key to select 10.
  • Page 51 Revised Date 2008/11/13 Page 51 of 94 Doc. Title ROSE Service Manual Display Test (and RED/ GREEN pattern) 11. Press Action key to select Display Test on Function test menu. 12. After the test pattern is show up, please check the pattern if any un-uniform color or chromatist.
  • Page 52 2008/8/12 Revised Date 2008/11/13 Page 52 of 94 Doc. Title ROSE Service Manual Back Light Test Press Action key to select Back Light Test on Function test menu. 17. Press Action key to switch the LCD backlight level from Level 1, Level2, and Level3.
  • Page 53 2008/8/12 Revised Date 2008/11/13 Page 53 of 94 Doc. Title ROSE Service Manual SD card R/W Test 23. Press Action key to select SD card R/W Test on Function test menu. Button Test Press Action key to select Button Test on Function test menu.
  • Page 54 2008/8/12 Revised Date 2008/11/13 Page 54 of 94 Doc. Title ROSE Service Manual Light Sensor Test Press Action key to select Light Sensor Test on Function test menu. Battery Test 28. Press Action key to select Battery Test on Function test menu.
  • Page 55 2008/8/12 Revised Date 2008/11/13 Page 55 of 94 Doc. Title ROSE Service Manual WinCE Test Bluetooth Test – 1 Select Comm Manager on the Today screen and turn on Bluetooth. Select the icon “Settings” down-right the corner of the screen and select the “Make this device….”...
  • Page 56 HTC Corporation Issued Date 2008/8/12 Revised Date 2008/11/13 Page 56 of 94 Doc. Title ROSE Service Manual USB Test Select Start->ActiveSync to do the USB link test. Camera Test Select Start->Program->Camera or Press Camera button to turn on the Camera.
  • Page 57 Issued Date 2008/8/12 Revised Date 2008/11/13 Page 57 of 94 Doc. Title ROSE Service Manual WLAN Test Select icon Comm Manager on the Today screen and turn on WLAN. Select the hot-spot/ or access point which searchable and appears on screen.
  • Page 58 REV. HTC Corporation Issued Date 2008/8/12 Revised Date 2008/11/13 Page 58 of 94 Doc. Title ROSE Service Manual Download test program from SDO (GSD-00005556) http://htcscm10.htc.com.tw/SDO Un-zip the image file. Copy “mfgtest.dll” “Audio Test.exe” to internal storage. Execute”Audio Test” program from internal storage.
  • Page 59 2008/8/12 Revised Date 2008/11/13 Page 59 of 94 Doc. Title ROSE Service Manual Connect the headset into the USB port before doing the testing Select the Headset Test then press Play button for testing Audio Test-5 10. Select the Int-Rec Test then press “Record”...

  • Page 60: Power Measurement Test

    2008/11/13 Page 60 of 94 Doc. Title ROSE Service Manual 5. Power measurement test 5.1 Main board leakage current Test Procedure This is a quick method to measure if any abnormal leakage current on main board which caused high power consumption compare to GOOD main board.
  • Page 61 2008/8/12 Revised Date 2008/11/13 Page 61 of 94 Doc. Title ROSE Service Manual C. types Jig Jig - F (3 pins-Short) Jig-F Equipment set up 1. Connect control box and jig through 3 colors cable with red, black and yellow...
  • Page 62 Issued Date 2008/8/12 Revised Date 2008/11/13 Page 62 of 94 Doc. Title ROSE Service Manual 2. Set up each button by row A~D according to product specification Following is an setting for Diamond Button set up matrix MODEL JIG TYPE...
  • Page 63 2008/8/12 Revised Date 2008/11/13 Page 63 of 94 Doc. Title ROSE Service Manual 2. Press Power button to turn on the Device 3. In “main page”, Check phone status, Click “Turn on Airplane mode” Set the unit to : * Airplane mode * Make sure all RF function is off (phone, BT, Wifi..)
  • Page 64 2008/11/13 Page 64 of 94 Doc. Title ROSE Service Manual 5. After idle current checked, Switch OFF the unit. Unit is turn off and no display to be the sleep mode (condition: Display & BL off/ KB LED off/ RF off/ WiFi off/ BT off).

  • Page 65: Battery Rundown Test Procedure

    Issued Date 2008/8/12 Revised Date 2008/11/13 Page 65 of 94 Doc. Title ROSE Service Manual 5.2 Battery rundown test procedure Test Requirement: -Windows 2000/XP -USB Cable -ActiveSync 4.2 above (WINCE 6.0 should use ActiveSync 4.5) -Master Unit -Battery in Warrantee Caution: Please charge your unit to full capacity for battery (until the green light is displayed) before doing the test.
  • Page 66 HTC Corporation Issued Date 2008/8/12 Revised Date 2008/11/13 Page 66 of 94 Doc. Title ROSE Service Manual IV. Make a folder in the device. Copy into the PowerDetect.exe folder. Battery Rundown-1 VI. Adjust the Backlight brightness into the maximum level on battery power.
  • Page 67 HTC Corporation Issued Date 2008/8/12 Revised Date 2008/11/13 Page 67 of 94 Doc. Title ROSE Service Manual VII. Disable Turn off backlight if device is not used for Turn off device if not used for on Advanced menu. HTC CONFIDENTIAL...
  • Page 68 Doc. No. DOC-00045381 REV. HTC Corporation Issued Date 2008/8/12 Revised Date 2008/11/13 Page 68 of 94 Doc. Title ROSE Service Manual Battery Rundown-3 VIII. Execute PowerDetect.exe under WinCE Battery Rundown-3 Set the Sleep as 1hour Set the Record as 2Mins...
  • Page 69 2008/8/12 Revised Date 2008/11/13 Page 69 of 94 Doc. Title ROSE Service Manual Battery Rundown-4 After running 1 hour, the test will be finished. XII. Press the Power Button to turn on the power. XIII. Click ok to quit the program.
  • Page 70 Issued Date 2008/8/12 Revised Date 2008/11/13 Page 70 of 94 Doc. Title ROSE Service Manual Battery Rundown-6 XV. Tag the log file to check the capacity. Caution: If the capacity is under 70%, Please replace a new battery. HTC CONFIDENTIAL...

  • Page 71: Cosmetic Inspection Criteria

    2008/11/13 Page 71 of 94 Doc. Title ROSE Service Manual 6. Cosmetic Inspection Criteria 6.1 Classes definition of inspective area Class A area => The front side of main unit involve all buttons and LED lens except LCD. Class B area => View of QWERTY keyboard (involve stylus).
  • Page 72 Doc. No. DOC-00045381 REV. HTC Corporation Issued Date 2008/8/12 Revised Date 2008/11/13 Page 72 of 94 Doc. Title ROSE Service Manual CLASS C CLASS D HTC CONFIDENTIAL SM-TP001-0812...

  • Page 73: Display Inspection

    Revised Date 2008/11/13 Page 73 of 94 Doc. Title ROSE Service Manual IT IS GENERIC COSMETIC INSPECTION CRITERIA FOR ALL PRODUCTS IF THERE HAVE ANY CONFLICT WITH THESE GENERIC CRITERIONS; PLEASE FOLLOW THE PRODUCT INSPECTION CRITERIA RESPECTIVELY. Description D: Diameter / L: Length / W: Width / N: Number of defects/ S: Distance from dot to dot Inspecting distance: 30 ±...

  • Page 74: Main Unit Inspection

    2008/11/13 Page 74 of 94 Doc. Title ROSE Service Manual 6.3 Main unit inspection Cosmetic inspection generic spec: 1. Exposure of substratum is not acceptable for peeling. (Area 4 is included)If not exposure of substratum, please check by SPEC of dot or scratch. (Area 4 is not included) 2.
  • Page 75 REV. HTC Corporation Issued Date 2008/8/12 Revised Date 2008/11/13 Page 75 of 94 Doc. Title ROSE Service Manual Exposure of substrate do not accept ≦ ≦ ≦ ≧ Scratch : L 7mm ,W 0.25mm ,N 3, S 10mm Class B If IR window has scratch without any effective feeling then don’t care...
  • Page 76 HTC Corporation Issued Date 2008/8/12 Revised Date 2008/11/13 Page 76 of 94 Doc. Title ROSE Service Manual Bright mark Description A c c e p t c r i t e r i a ≦ ≦ ≦ L 2.5mm,W 0.25mm,N 3 Class A ≦...

  • Page 77: Generic Troubleshooting

    2008/11/13 Page 77 of 94 Doc. Title ROSE Service Manual 7. Generic Troubleshooting 1．Main Unit Does Not Respond to Power Button (1) Connect the AC adapter, maybe the battery pack is exhaust and wait few minutes for battery recharging. (2) Check if battery installed well.
  • Page 78 2008/11/13 Page 78 of 94 Doc. Title ROSE Service Manual 3．Unusual Vertical / Horizontal lines or partial display (1) Check the connection of LCM FPC whether is properly connected. (2) Try to cold boot the unit then tries again. (3) Try to re-flash the ROM code.
  • Page 79 2008/11/13 Page 79 of 94 Doc. Title ROSE Service Manual 6．PC Connection not possible (1) If test result is NFF, it is possible caused by user connect cradle to computer before ActiveSync is installed. (2) Check whether “Connection Settings” in the MS ActiveSync is properly set.
  • Page 80 Page 80 of 94 Doc. Title ROSE Service Manual 9．Battery Pack does not recharge (1) Make sure the Battery Pack takes fully charge with AC Adapter. (2) Check whether the condition of Battery Charging status is correct. Charge should be done no more than 4 hours.
  • Page 81 2008/11/13 Page 81 of 94 Doc. Title ROSE Service Manual 12．Wireless connection (WLAN/BT) not functioning (1) Make sure the wireless environment is OK before connecting to WLAN. (2) Make sure the wireless connection setting has properly set. (3) Make a life connection with Internet or another device.

  • Page 82: Generic Labeling Plan

    HTC Corporation Issued Date 2008/8/12 Revised Date 2008/11/13 Page 82 of 94 Doc. Title ROSE Service Manual 8. Generic Labeling Plan Main unit Agency label_Rose100 The brand name is shown on bezel HTC P/N: 77H00631-00M Size: 35.50 X 49.53mm HTC CONFIDENTIAL...
  • Page 83 Doc. No. DOC-00045381 REV. HTC Corporation Issued Date 2008/8/12 Revised Date 2008/11/13 Page 83 of 94 Doc. Title ROSE Service Manual Water sensitive label HTC P/N: 77H00668-00M Qty: 1 Tamper evident label HTC P/N: 77H00460-01M Qty: 1 HTC CONFIDENTIAL SM-TP001-0812...
  • Page 84 Doc. No. DOC-00045381 REV. HTC Corporation Issued Date 2008/8/12 Revised Date 2008/11/13 Page 84 of 94 Doc. Title ROSE Service Manual HTC CONFIDENTIAL SM-TP001-0812...

  • Page 85: Generic Spare Part List And Photos

    Doc. No. DOC-00045381 REV. HTC Corporation Issued Date 2008/8/12 Revised Date 2008/11/13 Page 85 of 94 Doc. Title ROSE Service Manual 9. Generic Spare Part List and Photos 9.1 SPL for Repair HTC CONFIDENTIAL SM-TP001-0812...
  • Page 86 Doc. No. DOC-00045381 REV. HTC Corporation Issued Date 2008/8/12 Revised Date 2008/11/13 Page 86 of 94 Doc. Title ROSE Service Manual HTC CONFIDENTIAL SM-TP001-0812...
  • Page 87 Doc. No. DOC-00045381 REV. HTC Corporation Issued Date 2008/8/12 Revised Date 2008/11/13 Page 87 of 94 Doc. Title ROSE Service Manual HTC CONFIDENTIAL SM-TP001-0812...
  • Page 88 Doc. No. DOC-00045381 REV. HTC Corporation Issued Date 2008/8/12 Revised Date 2008/11/13 Page 88 of 94 Doc. Title ROSE Service Manual HTC CONFIDENTIAL SM-TP001-0812...
  • Page 89 Page 89 of 94 Doc. Title ROSE Service Manual NOTE: THE PHOTO OF SPL IS GENERIC AND FOR REFERENCE ONLY, THE COLOR AND THE APPEARANCE MAY BE DIFFERENT FROM THE SHIPPED PARTS, IF YOU WANT TO APPLY THOSE PARTS, PLEASE CONTACT YOUR SERVICE ACCOUNT MANAGER FOR MORE INFORMATION.

  • Page 90: Board Level 2.5 Repairs

    Revised Date 2008/11/13 Page 90 of 94 Doc. Title ROSE Service Manual 9.2 Board Level 2.5 Repairs Basic Repair Instructions for Component Replacement: Step 1 Place the solder-proof tape to cover the surrounding area of the components which being replaced.
  • Page 91 Doc. No. DOC-00045381 REV. HTC Corporation Issued Date 2008/8/12 Revised Date 2008/11/13 Page 91 of 94 Doc. Title ROSE Service Manual MAIN BOARD (51H40453-XXM) TOP SIDE PACON1 Description Location Remark Connector Device,60mohm,SUYIN,060062MB003GX01ZL,3P, Battery 75H00776-00M PACON1 2.75Pitch,2A,12V connector HTC CONFIDENTIAL SM-TP001-0812...
  • Page 92 Doc. No. DOC-00045381 REV. HTC Corporation Issued Date 2008/8/12 Revised Date 2008/11/13 Page 92 of 94 Doc. Title ROSE Service Manual BOTTOM SIDE PAC118 Description Location Remark Gold Cap,0.02F,300ohm,SEIKO,XH311HGII45E, 16H00019-00M PAC118 Gold Cap 60/-20degC,+/-30%,3.3V,5.8*3.8*1.45mm HTC CONFIDENTIAL SM-TP001-0812...

  • Page 93: Rf Antenna Specification

    2008/11/13 Page 93 of 94 Doc. Title ROSE Service Manual 10. RF Antenna Specification ROSE/MARIA RF Antenna SPEC Dual-Band HSDPA/UMTS 900/2100 for EU & Asia, 1700MHz for eMobile Tri-Band GSM/GPRS/EDGE (900/1800/1900MHz) EIRP & Sensitivity Test Channel EIRP Spec Cell power (dBm) Cell power Spec (dBm) -104.0...

  • Page 94: Sm-Tp001

    Doc. No. DOC-00045381 REV. HTC Corporation Issued Date 2008/8/12 Revised Date 2008/11/13 Page 94 of 94 Doc. Title ROSE Service Manual Channel UMTS Band I 9612 9750 9888 EIRP (dBm) EIRP Spec Cell power (dBm) Cell power Spec (dBm) -104.0 -104.0...
