Changing filter bag

Disconnect cleaner from electrical outlet.
Removing and
3.1
installing filter
bag
Grasp filter bag col-
lar (A) and pull collar
from tube (B).
Note: Do not clean
out old filter bag
and reuse. Discard
Removing bag used filter bag.
door Hold new filter bag
as shown. Align
To change filter
opening in filter
bag, press down at
bag with (B).
top of bag door and
Push (A) firmly
pull door forward.
onto (B).
Remove door.
Tuck in filter bag.
Secondary and final filters
3.4
A
Cleaning secondary filter
Disconnect cleaner from electrical outlet.
The secondary filter (A), located behind the
grill in the bottom of bag compartment,
protects the motor from dirt particles.
If filter becomes dirty, pull off grill and lift
out filter.
Hand wash filter in cold water with mild
detergent, then air dry.
Reposition dry filter and grill.
Should you want to replace this filter, ask for
HOOVER part No. 38765019.
Cleaning final filter
The final filter assists in the filtration pro-
cess to return clean air to the room.
To remove this filter when it becomes dirty,
open the door on the side of the cleaner.
3.2 3.3
B
A
C
Replacing bag
door
Reposition bag door
by placing tabs on
bottom of door into
opening (C).
Press top of door to
snap securely shut.
Lift out filter (B)
3.5
and hand wash it
in cold water with
mild detergent.
Let filter air dry
and reposition it
B
on the side of the
cleaner. Make sure
the green colored
side of filter faces
outward. Close door.
Should you want to replace this filter, ask for
HOOVER part No. 40110004.
Do not operate cleaner without either the
secondary or final filter in place.
Reattaching filter door
The filter door
3.6
is designed with
a "break-away"
feature which al-
lows it to snap free
if it is pushed open
too far.
To reattach, align
hinges (C) of cover
with slots on sides
of filter area.
Press door back
into place.
11
C
