  • Page 1 Durango 2 0 1 6 O W N E R ’ S M A N U A L S U P P L E M E N T Police...
  • Page 2 This manual illustrates and describes the operation of VEHICLES SOLD IN CANADA With respect to any Vehicles Sold in Canada, the name FCA features and equipment that are either standard or op- US LLC shall be deemed to be deleted and the name FCA tional on this vehicle.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS SECTION PAGE INTRODUCTION ............. . . 3 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE .

  • Page 5: Introduction

    INTRODUCTION CONTENTS INTRODUCTION ......4...
  • Page 6 4 INTRODUCTION INTRODUCTION Refer to the Police Upfitter’s Guide provided with your vehicle, prior to the addition of any aftermarket equip- This booklet is a supplement to the Owner’s Manual ment. prepared with the assistance of service and engineering specialists, and is intended to aid the operators of police Following the instructions and recommendations pro- or fleet vehicles (used in severe duty, high-mileage op- vided herein, will help assure safe and reliable operation...

  • Page 7: Things To Know Before Starting Your Vehicle

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CONTENTS DOOR LOCKS ......6 PASSIVE ENTRY SYSTEM ....9 ▫...

  • Page 8: Door Locks

    6 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE DOOR LOCKS Manual Door Locks The power door locks can be manually locked from inside the vehicle by using the door lock knob. To lock each door, push the door lock knob on each door trim panel downward.
  • Page 9 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 7 WARNING! WARNING! (Continued) • Do not leave the key fob in or near the vehicle, or • For personal security and safety in the event of an in a location accessible to children, and do not collision, lock the vehicle doors as you drive as leave the ignition of a vehicle equipped with well as when you park and leave the vehicle.

  • Page 10: Power Door Locks

    8 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Power Door Locks If the lock knob is down when the door is closed, the door will lock. Therefore, make sure the key fob is not inside The power door lock switch is located on each front door the vehicle before closing the door.

  • Page 11: Passive Entry System

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 9 • If wearing gloves on your hands, or if it has been PASSIVE ENTRY SYSTEM raining on the Passive Entry door handle, the unlock The Passive Entry system is an enhancement to the sensitivity can be affected, resulting in a slower re- vehicle’s Remote Keyless Entry (RKE) system.
  • Page 12 10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To Unlock From The Driver’s Side: NOTE: If “Unlock All Doors 1st Press” is programmed all doors will unlock when you grab hold of the driver’s With a valid Passive Entry RKE transmitter within 5 ft front door handle.

  • Page 13: Occupant Restraints

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 11 OCCUPANT RESTRAINTS WARNING! Driver/passenger air bags affect the way police equip- • Vehicles equipped with left and right Supplemen- ment can be safely mounted in police vehicles. tal Side Curtain Air Bags (SABIC) must use police Any surface that could come into contact with an air bag, cages, which have been approved by the equip- once it has been deployed, must not damage the air bag...

  • Page 14: Air Bag Deployment Zones

    12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Air Bag Deployment Zones WARNING! (Continued) There are four zones to be aware of: • Do not place objects or mount equipment in front of the air bag module cover, or in front of the seat 1.
  • Page 15 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13 Figure 1 - Driver Air Bag Deployment Zone, depicts the following. 1. Vertical Plane Passing Through Center of Steering Wheel 2. 18.5 inches (47 cm) 3. Vertical Plane Passing Through Maximum Rearward Point that the Driver Air Bag Cushion Reaches 4.
  • Page 16 14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE DRIVER AIR BAG/STEERING COLUMN DRIVER AIR BAG CUSHION POSITION SPECIFICATIONS STEERING COLUMN TILT POSITION RANGE DRIVER AIR BAG CUSHION POSITION +/– 2.7 Degrees from Steering Column Tilt DAB Diameter When 26.5 inches (67 cm) Pivot Point Deployed (Full) 21.0 Degrees from Vertical is the Nominal Position...
  • Page 17 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 15 Figure 2 - Driver Air Bag Lateral Deployment Zone, depicts the following. 1. Driver Seating Reference 2. Driver Air Bag Cushion Lateral Deployment Zone, 28 inches (71 cm) Figure 2...
  • Page 18 16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Figure 3 - Passenger Air Bag Deployment Zone, depicts the following. 1. Passenger Air Bag Cushion 2. Vertical Plane from Point of Instrument Panel 3. Passenger Air Bag Module 4. Instrument Panel 5.
  • Page 19 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 17 Figure 4 - Passenger Air Bag Lateral Deployment Zone, depicts the following. 1. 23 inches (77 mm) 2. Passenger Air Bag Cushion Deployment Zone 3. 20 inches (515 mm) 4. Reference Point Figure 4...
  • Page 20 18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Figure 5...
  • Page 21 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 19 Figure 5 - Supplemental Side Air Bag Inflatable Curtain 8. 18.01 inches (45.74 cm) Air Bag Deployment Zone, depicts the following. 9. 16.01 inches (40.67 cm) 1. Cross-Sectional Area Side View 10. B-Pillar Trim 2.
  • Page 22 20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Figure 6...
  • Page 23 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 21 Figure 6 - Supplemental Seat Mounted Side Air Bag Deployment Zone, depicts the following. 1. Front Driver’s Seat 2. 23.62 inches (60.0 cm) 3. 5.51 inches (14.0 cm) 4. 18.5 inches (47.0 cm) 5.

  • Page 25: Understanding The Features Of Your Vehicle

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS ▫ Dome Light ......24 LIGHTS ......24...
  • Page 26 24 UNDERSTANDING THE FEATURES OF YOUR VEHICLE LIGHTS Dome Light The police dome light has three positions. Position one is used for white light, and position two is used for red LED light. Always remember to return the dome light switch to the OFF (center) position when finished using to prevent discharging the vehicle battery.

  • Page 27: Understanding Your Instrument Panel

    UNDERSTANDING YOUR INSTRUMENT PANEL CONTENTS ▫ Hour Meter ......28 DRIVER INFORMATION DISPLAY (DID) ..26...
  • Page 28 26 UNDERSTANDING YOUR INSTRUMENT PANEL DRIVER INFORMATION DISPLAY (DID) This system conveniently allows the driver to select a variety of useful information by pushing the arrow The Driver Information Display (DID) features a driver- buttons located on the left side of the steering wheel. The interactive display that is located in the instrument DID Menu Items consists of the following: cluster.
  • Page 29 UNDERSTANDING YOUR INSTRUMENT PANEL 27 • UP Arrow Button The system allows the driver to select information by pushing the following buttons mounted on the steering Push and release the UP arrow button to scroll wheel: upward through the main menu. •...
  • Page 30 28 UNDERSTANDING YOUR INSTRUMENT PANEL • OK Button Push the OK button to access/select the information screens or submenu screens of a main menu item. Push and hold the OK button for two seconds to reset displayed/selected features that can be reset. Hour Meter 1.

  • Page 31: Maintaining Your Vehicle

    MAINTAINING YOUR VEHICLE CONTENTS MAINTENANCE PROCEDURES ... .30...
  • Page 32 30 MAINTAINING YOUR VEHICLE MAINTENANCE PROCEDURES Failure to maintain your vehicle properly may reduce vehicle performance and operational capabilities, ad- Police and fleet vehicles are equipped with heavy-duty versely affect the safety of you and your passengers, as parts that are designed specifically for the varying de- well as restrict your warranty coverage.

  • Page 33: Index

    INDEX...
  • Page 34 32 INDEX Door Locks .......6 Door Locks ......8 Introduction .
  • Page 35 INSTALLATION OF RADIO TRANSMITTING EQUIPMENT Special design considerations are incorporated into this The antenna cable should be as short as practical and vehicle’s electronic system to provide immunity to radio routed away from the vehicle wiring when possible. Use frequency signals. Mobile two-way radios and telephone only fully shielded coaxial cable.
  • Page 36 STICK WITH THE SPECIALISTS ® 16WD01-226-AA ©2015 FCA US LLC. All Rights Reserved. First Edition Dodge is a registered trademark of FCA US LLC. Printed in U.S.A.
