PART LIST—Model No. PETL38061
Key
Qty.
Description
No.
1
2
Handrail w/Foam Grip
2
4
3/8" x 1" Bolt
3
1
Console Housing
4
1
60" Wire Harness
5*
1
Console Assembly
6
7
Console Screw
7
2
Ground Nut
8
1
Console Cable Loom
9
1
Key/Clip
10
2
Foam Grip
11
1
Upright
12
1
Motor Swivel Bolt
13
1
Motor Mount Bracket
14
1
Motor Swivel Nut
15
2
Motor Bolt
16
1
Motor
17
2
Motor Nut
18
4
Filter Screw
19
1
Motor Tension Washer
20
1
Star Washer
21
1
Motor Tension Nut
22
2
Incline Leg Washer
23
4
Hood Anchor
24
7
Anchor Screw
25
1
Upright Pivot Nut
26
2
Upright Pivot Washer
27
1
Upright Cable Loom
28
1
3/8" x 1 1/2" Washer
29
2
Rubber Cushion
30
1
Motor/Controller Wire
31
1
Circuit Breaker
32
1
Upright Pivot Bolt
33
1
Receptical
34
2
Frame Endcap
35
13
Screw
36
2
Incline Pin
37
2
Incline Leg Cap
38
2
Incline Leg
39
1
Belt Guide
40
1
Front Roller Adjustment Bolt
41
3
Adjustment Washer
42
1
Safety Cover
43
1
Front Roller/Pulley
44
1
Walking Platform
45
1
Walking Belt
46
2
Foot Rail
47
1
Pulley/Flywheel/Fan
48
2
5/16" Flange Nut
49
2
5/16" x 2 3/4" Bolt
50
2
5/16" Washer
Specifications are subject to change without notice. See the back cover for information about ordering replace-
14
ment parts.
R0198A
Key
Qty.
Description
No.
51
1
Controller
52
1
Choke
53
13
Small Screw
54
1
4" Cable Tie
55
4
8" Cable Tie
56
1
Tie Holder
57
2
Motor Pivot Bushing
58
1
Motor Pivot Sleeve
59
1
Frame
60
2
Rear Leg Endcap
61
1
Magnet
62
1
Roller Ground Wire
63
1
Right Endcap
64
2
Wrench Clip
65
1
3/16" Allen Wrench
66
2
Rear Roller Adjustment Bolt
67
1
Left Endcap
68
1
Rear Roller
69
8
Platform Screw
70
2
Incline Leg Plug
71
1
Hood
72
1
Reed Switch Clamp
73
1
Reed Switch/Sensor Wire
74
1
Motor Belt
75
3
Cage Nut
76*
1
Motor/Pulley/Flywheel/Fan
77
1
Battery Cover
78
1
Potentiometer
79
1
Speed Control
80
2
3/8" Washer
81
1
Interface Board
82
1
Electronics Plate
83
1
Electronics Plate Grommet
84
1
Filter
85
4
Plastic Stand-Off
86
3
Plastic Washer
87
1
Filter Bracket
88
2
Ground Screw
89
2
Ground Star Washer
#
1
14" White Wire, Twisted
#
1
10" White Wire, 2 Female
#
1
8" Black Wire, 2 Female
#
1
4" Black Wire, 2 Female
#
1
8" Blue Wire, Twisted
#
3
4" Green Ground Wire
#
1
User's Manual
* Includes all parts shown in the box.
# Indicates a non-illustrated part.
9. When connecting the power cord (see HOW
TO PLUG IN THE POWER CORD on page 6),
plug the power cord directly into an earthed
circuit. When replacing the fuse, on ASTA
approved BS1362 type should be fitted to the
fuse carrier. A 13 amp fuse should be used.
No other appliance should be on the same
circuit.
10. If an extension cord is needed, use only a 14-
gauge general-purpose three cord of cable of
1,5 meters (5 feet) or less in length.
11. Never move the walking belt whilst the power
is turned off. Do not operate the treadmill if
the power cord or plug is damaged, or if the
treadmill is not working properly. (See
BEFORE YOU BEGIN on page 4 if the tread-
mill is not working properly.)
12. Keep the power cord away from heated sur-
faces.
13. Never start the treadmill whilst you are stand-
ing on the walking belt. Always hold the
handrails whilst exercising on the treadmill.
14. The treadmill is capable of high speeds.
Adjust the speed in small increments to
avoid sudden jumps in speed.
15. To reduce the possibility of the treadmill
overheating, do not operate the treadmill
continuously for longer than 1 hour.
SAVE THESE INSTRUCTIONS
WARNING:
Before beginning this or any exercise program, consult your physician. This
is especially important for persons over the age of 35 or persons with pre-existing health problems.
Read all instructions before using. ICON assumes no responsibility for personal injury or property
damage sustained by or through the use of this product.
16. The pulse sensor is not a medical device.
Various factors, including the user's
movement, may affect the accuracy of heart
rate readings. The pulse sensor is intended
only as an exercise aid in determining heart
rate trends in general.
17. Never leave the treadmill unattended whilst it
is running. Always remove the key when the
treadmill is not in use.
18. To change the incline level of the treadmill,
refer to the instructions on page 9. Do not
use the treadmill with the incline pins
removed.
19. Never drop or insert any object into any
opening.
20. Inspect and tighten all parts of the treadmill
every three months.
21. Always unplug the power cord before per-
forming the maintenance and adjustment
procedures described in this manual. Never
remove the motor hood unless instructed to
do so by an authorised service representa-
tive. Servicing other than the procedures in
this manual should be performed by an
authorised service representative only.
22. This treadmill is intended for in-home use
only. Do not use this treadmill in any com-
mercial, rental, or institutional setting.
3
