Installation & Operation
Instructions
CARRIER REFRIGERATION OPERATIONS
CHEST FREEZERS
BUNKER MODELS B5, B7,B7P, B9, B13, B15, B18
An Important Message for Installers and Operators
These instructions include information which is intended to
assure the operator of correct installation, operation and
service. Before attempting installation, adjustment or mainte-
nance, be certain of the following:
1. That you have read and fully understand the instructions.
2. That you have all tools required and are trained to use them.
3. That you have met all installation and usage restrictions and
are familiar with the functions and operation of the unit.
4. That you follow all instructions exactly as given.
All fittings, measurements, procedures and recommendations
are significant. Substitutions and approximations must be
avoided. Improper handling, maintenance, installation and
adjustment, or service attempted by anyone other than a
qualified technician, may void the future warranty claims and
cause damage to the unit and/or result in injury to the operator
and/or bystanders.
BE SURE TO INSPECT THE CABINET FOR SHIPPING DAMAGE
BEFORE AND AFTER UNCRATING IT.
REFRIGERATION OPERATIONS
707 Robins St. • P.O. Box 4000
Conway Arkansas 72032 • (501) 327-8945
Important information is contained in
these instructions which should be
retained in a convenient location for
future reference.
Record for Service
Model No.
Serial No.
Installation Date
Invoice Date
Start-up Date
Telephone for Service
Part No. 51-0177-00 Rev. 6
P/N 216774400 (0011)
Advertisement
Table of Contents
Related Manuals for Carrier B5
Summary of Contents for Carrier B5
- Page 1 Installation & Operation Instructions CARRIER REFRIGERATION OPERATIONS CHEST FREEZERS BUNKER MODELS B5, B7,B7P, B9, B13, B15, B18 Part No. 51-0177-00 Rev. 6 An Important Message for Installers and Operators These instructions include information which is intended to Important information is contained in...
- Page 2 If additional information is necessary, call Carrier Refrig- eration headquarters. Our toll free number is 1-800-558-7627. Technical assistance engineers are willing to assist you in any way possible. Office hours are from 7:30 am to 5:00 pm Central Standard Time.
-
Page 3: Important Safety Instructions
Read all instructions before using this freezer. Important Safety Instructions For Your Safety Do not store or use gasoline or other flammable vapors and liquids in the vicinity of Proper Disposal of Your this or any other appliance. Read product labels for flammability and other warnings. Refrigerator/Freezer Child Safety Risk of child entrapment. -
Page 4: Set-Up Instructions
• Inspect the freezer and packaging for damage such as a fork truck can cause, or look for bent corners from dropping the cabinet. If hidden damage is found after uncrating, immediately call the delivery carrier and request an inspection. Retain all packaging and crating materials until the inspection is complete. -
Page 5: Setting The Temperature Control
Set-Up Instructions (continued) Installation • Roll the unit to the place where it will be installed. If the floor is not flat and level, the unit may tip from side to side. If it does tip, take the time to level the unit. •... -
Page 6: Freezer Features
Freezer Features Defrost Drain The defrost drain provides a method of draining water during defrosting and cleaning. See "Defrosting" in the Care and Cleaning Section. Sliding Basket (Some Models) Makes locating and retrieving stored items easier. Helps segregate food items into groups. -
Page 7: Care And Cleaning
Care and Cleaning Between Defrostings To avoid frequent defrosting, occasionally use a plastic scraper to remove frost. Scrape with a pulling motion. Never use a metal instrument to remove frost. Defrosting It is important to defrost and clean freezer when ¼ to ½ inch of frost has accumulated. Frost may tend to accumulate faster on upper part of the freezer due to warm, moist air entering the freezer when the door is opened. -
Page 8: Replacement Parts
CARRIER REFRIGERATION OPERATIONS REPLACEMENT PARTS s t i • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •... -
Page 10: Important Safety Notice
IMPORTANT SAFETY NOTICE The information provided herein is designed to assist qualified repair personnel only. Untrained persons should not attempt to make repairs due to the possibility of electrical shock. Disconnect the power cord before servicing. ELECTRICAL CIRCUIT WIRING DIAGRAM WIRING DIAGRAM Capacitor Compressor...
