Installation, Start-Up, and Operating Instructions
NOTE: Read the entire instruction manual before starting the
installation.
This symbol → indicates a change since the last issue.
Index
SAFETY CONSIDERATIONS .....................................................1
Clearances From Combustible Materials .................................1
Dimensional Drawing ...............................................................2
ELECTROSTATIC DISCHARGE (ESD) PRECAUTIONS
PROCEDURE........................................................................2-3
INTRODUCTION ..........................................................................3
LOCATION....................................................................................3
General ......................................................................................3
Location Relative to Cooling Equipment ................................3
Hazardous Locations.................................................................3
AIR FOR COMBUSTION AND VENTILATION...................3-5
Unconfined Space .....................................................................4
Confined Space......................................................................4-5
FILTER ARRANGEMENT .......................................................5-6
LEVELING LEGS (IF REQUIRED).........................................5-6
GAS PIPING...............................................................................6-7
ELECTRICAL CONNECTIONS ..................................................7
115-v Wiring.............................................................................7
24-v Wiring...............................................................................7
Accessories................................................................................7
VENTING ......................................................................................7
START-UP, ADJUSTMENT, AND SAFETY CHECK.........8-14
General ......................................................................................8
Sequence Of Operation .......................................................9-11
Heating Mode ......................................................................9-11
Cooling Mode .........................................................................11
Continuous Blower Mode.......................................................11
Heat Pump Mode ....................................................................11
Start-Up Procedures ................................................................11
Adjustments .......................................................................11-16
Set Gas Input Rate ............................................................11-15
Set Temperature Rise..............................................................15
Set Thermostat Heat Anticipator ......................................15-16
Check Safety Controls .................................................................16
Checklist .......................................................................................16

SAFETY CONSIDERATIONS

Installing and servicing heating equipment can be hazardous due to
gas and electrical components. Only trained and qualified person-
nel should install, repair, or service heating equipment.
Untrained personnel can perform basic maintenance functions
such as cleaning and replacing air filters. All other operations must
be performed by trained service personnel. When working on
heating equipment, observe precautions in the literature, on tags,
and on labels attached to or shipped with the unit and other safety
precautions that may apply.
→
Follow all safety codes. In the United States, follow all safety
codes including the National Fuel Gas Code (NFGC) NFPA No.
54-1992/ANSI Z223.1-1992 and the Installation Standards, Warm
Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.
Book 1 4
PC 101
Tab 6a 8a
Sizes 045-155, Series 141
Catalog No. 565-980 Printed in U.S.A.
Upflow Induced-Combustion Furnaces
Page
®
Air Heating and Air Conditioning Systems (NFPA 90B)
ANSI/NFPA 90B. In Canada, refer to the current edition of the
National Standard of Canada CAN/CGA-B149.1- and .2-M95
Natural Gas and Propane Installation Codes (NSCNGPIC). Wear
safety glasses and work gloves. Have fire extinguisher available
during start-up and adjustment procedures and service calls.
Recognize safety information. This is the safety-alert symbol
When you see this symbol on the furnace and in instructions or
manuals, be alert to the potential for personal injury.
Understand the signal words DANGER, WARNING, and CAU-
TION. These words are used with the safety-alert symbol. DAN-
GER identifies the most serious hazards which will result in severe
personal injury or death. WARNING signifies a hazard which
could result in personal injury or death. CAUTION is used to
identify unsafe practices which would result in minor personal
injury or product and property damage. NOTE is used to highlight
suggestions which will result in enhanced installation, reliability,
or operation.
These instructions cover minimum requirements and conform to
existing national standards and safety codes. In some instances,
these instructions exceed certain local codes and ordinances,
especially those that may not have kept up with changing residen-
tial construction practices. We require these instructions as a
minimum for a safe installation.
Table 1-Minimum Clearances From
Combustible Materials (In.)
Sides Single-Wall Vent
Type B-1 Double-Wall Vent
Back
Plenum Top
Vent Single-Wall Vent
Type B-1 Double-Wall Vent
Front Single-Wall Vent
Type B-1 Double-Wall Vent
Service
NOTES:
1. Provide 30-in. front clearance for servicing. An open door in front of the unit
can meet this requirement.
2. A minimum clearance of 3 in. must be provided in front of the unit for
combustion air and proper operation.
Form 58WAV-7SI
WeatherMaker 8000™
ama
UNIT SIZE 045 AND 070 091-155
Pg 1 5-96 Replaces: 58WAV-6SI
58WAV
A PP R O VED
R
.
1 0
0 0
0 0
1 1
6 6
1 1
6 6
3 3
30 30
