Page 2 Job Management Guide explains the functions of the job management utilities, and how you can use them to monitor and control jobs on the Xerox EX7750. This manual is intended for a user with the necessary access privileges who monitors and manages job ﬂow, and troubleshoots problems that may arise.
Page 3 Copyright © 2004 Electronics for Imaging, Inc. All rights reserved. This product documentation is protected by copyright, and all rights are reserved. No part of it may be reproduced or transmitted in any form or by any means for any purpose without express prior written consent from Electronics for Imaging, Inc. (“EFI”), except as expressly permitted herein. Information in this document is subject to change without notice and does not represent a commitment on the part of EFI.
Page 4 FCC Information WARNING: FCC Regulations state that any unauthorized changes or modiﬁcations to this equipment not expressly approved by the manufacturer could void the user’s authority to operate this equipment. Refer to the Class Compliance sticker afﬁxed to the back of your Fiery (or, in the case of embedded systems, to the sticker afﬁxed to the print engine) to identify the appropriate classiﬁcation (A or B, below) for this product.
Page 5 CE Marking (Declaration of Conformity) This product complies with the following EU directives: 89/336/EEC, 73/23/EEC, and 93/68/EEC directives. This declaration is valid for the area of the European Union. SOFTWARE LICENSE AGREEMENT PLEASE READ THIS SOFTWARE LICENSE AGREEMENT (“LICENSE AGREEMENT”) CAREFULLY. THIS LICENSE AGREEMENT IS A LEGAL AGREEMENT BETWEEN YOU AND ELECTRONICS FOR IMAGING, INC.
Page 6 TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, EXCEPT FOR THE EXPRESS LIMITED WARRANTY SET FORTH ABOVE (“LIMITED WARRANTY”), EFI MAKES AND YOU RECEIVE NO REPRESENTATIONS OR WARRANTIES RELATING TO THE SOFTWARE, ANY PRODUCT AND/OR ANY SERVICES, WHETHER EXPRESS, IMPLIED, STATUTORY, OR IN ANY OTHER PROVISION OF THIS AGREEMENT OR ANY OTHER COMMUNICATION.
Page 7 U.S. Government Restricted Rights Use, duplication, or disclosure of the Software by the United States Government is subject to restrictions as set forth in FAR 12.212 or DFARS 227.7202-3 - 227.7202-4 and, to the extent required under U.S. federal law, the minimum restricted rights as set out in FAR 52.227-14, Restricted Rights Notice (June 1987) Alternate III(g)(3) (June 1987) or FAR 52.227-19 (June 1987).
Page 8 This page is intentionally blank.
Page 9: Table Of Contents
Contents About the Documentation Introduction About this manual Chapter 1: Connecting to the Network EX7750 on the network Stages of installation on the network Quick path to installation Connecting network cable to the EX7750 1-11 Back view of the EX7750 1-11 Ethernet connection 1-12...
Page 10 x Contents Chapter 3: Preparing for EX7750 Setup Levels of access and control EX7750 print connections Passwords WebTools Control level scenarios EX7750 system software About Setup Local Setup from the EX7750 Network server setup requirements 3-10 Ensuring the printer connection 3-10 Ensuring virus-free operation of the EX7750 on a network 3-11...
Page 11 xi Contents Color Setup options 4-50 Administrative functions in the Setup menu 4-54 Job Log Setup 4-54 Font Archiving 4-56 Exit Setup 4-58 Chapter 5: Setting up the EX7750 from a Windows Computer Accessing Setup Local Fiery Setup Remote Fiery Setup General Setup options Job Log Setup Network Setup...
Page 12 xii Contents Chapter 7: Administering the EX7750 Administrator functions Setting passwords Passwords from the Control Panel Passwords from local Setup or remote Setup Clearing the EX7750 System software Restoring backup system software Installing system software 7-10 Managing Fiery Address Books 7-13 Printing a Conﬁguration page from the Control Panel 7-17...
Page 13 After setting up the Xerox EX7750 and client workstations, individual users can print to the Xerox EX7750 as a high-performance color printer. This manual describes how to set up network servers and clients to use the Xerox EX7750 and how to install user software and set up printing from Microsoft Windows and Apple Mac OS computers.
Page 14: Xiv Introduction
xiv Introduction About this manual This manual covers the following topics: • Basic conﬁguration of the EX7750 to support printing over AppleTalk, TCP/IP, and IPX (Novell) networks • Administering network printing • Conﬁguring Novell and Microsoft Windows 2000 servers and UNIX systems to provide EX7750 printing services •...
Page 15: Chapter 1: Connecting To The Network
1-1 EX7750 on the network This chapter summarizes the stages in setting up the EX7750, and includes diagrams Chapter 1: that refer you to other chapters or other manuals for completing your installation. Connecting Check those references to ﬁnd the information you need quickly. to the Network EX7750 on the network When the EX7750 is connected to a network, it behaves as a networked PostScript...
Page 16: Stages Of Installation On The Network
1-2 Connecting to the Network These protocols are supported on Mac OS, Windows, and UNIX platforms and can run concurrently on the same cable. Workstations that use other protocols can print through a server that uses one of the protocols mentioned. The EX7750 is auto-sensing, and can handle all of these connections simultaneously.
Page 17 1-3 Stages of installation on the network • Setting up the EX7750 Conﬁgure the EX7750 for your particular printing and network environment. First read Chapter 2, and then see subsequent chapters for details. • Preparing client workstations for printing Install the ﬁles needed for printing, install additional user software, and connect the client to the EX7750 over the network.
Page 18 1-4 Connecting to the Network Summary of EX7750 network installation ONNECTION EX7750 Prepare a network node. Connect the EX7750 to the printer and the network. If you use a computer running Command WorkStation software, connect it to the network. ERVER CONFIGURATION Network server Conﬁgure UNIX, Windows 2000, and IPX (Novell) servers to specify EX7750 print queues and EX7750...
Page 19: Quick Path To Installation
1-5 Quick path to installation Quick path to installation The diagrams on the following pages show typical systems you can use to print and run Fiery software from remote workstations. Find the page with your preferred platform and network type, and then look up the setup procedures referenced in the “Key to setup”...
Page 20 1-6 Connecting to the Network Mac OS environment with AppleTalk Key to setup: 1 Mac OS computer User Software Installation Guide 2 EX7750 Setup Chapter 4 Another supported protocol EX7750 connected to printer TCP/IP (http) for WebTools AppleTalk Mac OS computer Mac OS computer Mac OS computers can print directly.
Page 21 1-7 Quick path to installation Windows computers in a Novell environment Key to setup: 1 NetWare server page 2-14 2 EX7750 Setup Chapter 4 Another supported 3 NetWare client User Software Installation Guide protocol 4 Windows computer page 2-9 EX7750 connected to printer NDPS Gateway TCP/IP (lpd) NetWare server...
Page 22 1-8 Connecting to the Network Windows 2000 server environment Key to setup: 1 Windows 2000 server page 2-3 2 EX7750 Setup Chapter 4 3 Windows client page 2-6 Another supported protocol 4 Windows 2000/XP client User Software Installation Guide Windows 2000/XP Workstation or EX7750 connected to printer Windows 2000server, acting as print server...
Page 23 1-9 Quick path to installation Windows computers using Windows printing Key to setup: 1 Windows computer User Software Installation Guide 2 EX7750 Setup Chapter 4 Another supported protocol EX7750 connected to printer TCP/IP (nbt) Windows computer Windows computer Windows computer For Windows printing Windows (SMB) printing enabled on the EX7750.
Page 24 1-10 Connecting to the Network UNIX workstations and Windows computers on a TCP/IP network Key to setup: 1 UNIX server/host page 2-16 2 EX7750 Setup Chapter 4 Another supported 3 UNIX workstation page 2-16 protocol 4 TCP/IP client User Software Installation Guide, Chapter 4 5 Windows 2000/XP client page 2-6...
Page 25: Connecting Network Cable To The Ex7750
1-11 Connecting network cable to the EX7750 Connecting network cable to the EX7750 In this section, the front view and back panel of the EX7750 are illustrated, followed by information for connecting to the Ethernet board. Turn off the EX7750 before connecting it to any network device. If the EX7750 has just ﬁnished processing, wait ﬁve seconds after the system reaches the Idle state before using the power button on the front of the EX7750 to turn it off.
Page 26: Ethernet Connection
1-12 Connecting to the Network Ethernet connection For Ethernet connections, the EX7750 supports Unshielded Twisted Pair (UTP, 4 pairs) cabling, deﬁned as Category 5 for use with 100BaseT and 1000BaseT; or as Category 3, Category 4, or Category 5 for use with 10BaseT. The cable uses an 8-pin RJ-45 connector that plugs into the RJ-45 socket on the EX7750.
Page 27: Chapter 2: Setting Up Network Servers
2-1 EX7750 on a TCP/IP network with Windows 2000/XP This chapter describes environments that typically include one or more network Chapter 2: servers—Novell NetWare servers and Windows 2000s—that share printing to the Setting up EX7750. It describes setting up servers that use IPX/SPX or TCP/IP protocols for Network Servers communicating with the EX7750.
Page 28: Tips For Experts-Windows With Tcp/Ip
2-2 Setting up Network Servers A typical system combination is: • Print server running Windows 2000; clients running Windows 2000/XP. With TCP/IP protocols loaded, you can run Fiery utilities and WebTools from a Windows computer. Tips for experts—Windows with TCP/IP Setting up printing from Windows using TCP/IP protocols is similar to setting up UNIX workstations with TCP/IP.
Page 29: Conﬁguring A Windows 2000 Server To Communicate With The Ex7750
2-3 EX7750 on a TCP/IP network with Windows 2000/XP Conﬁguring a Windows 2000 server to communicate with the EX7750 To conﬁgure a Windows 2000 server to communicate with the EX7750, follow these general steps. More detail is provided in subsequent sections in this chapter and in your Microsoft documentation.
Page 30 2-4 Setting up Network Servers EX7750 TCP/IP 2000 O ADD THE TO A NETWORK WITH A INDOWS SERVER 1. Register the IP address of the EX7750 in the host name database used by your system. For installations that do not have a network administrator or central host name database, add the EX7750 to the ﬁle on the Windows 2000 server.
Page 31 2-5 EX7750 on a TCP/IP network with Windows 2000/XP Installing the EX7750 as a shared printer The ﬁrst step in creating a printer is installing the printer driver ﬁles, which give your applications access to printer features. You can use the installation instructions in the User Software Installation Guide for every workstation that will print directly and independently to the EX7750.
Page 32 2-6 Setting up Network Servers Conﬁguring clients of a Windows 2000 server Each client of a Windows 2000 server is already using a network protocol to communicate with the server. Each client can print to the EX7750 if it has been shared by a Windows 2000 server or Windows 2000/XP clients.
Page 33 2-7 EX7750 on a TCP/IP network with Windows 2000/XP Conﬁguring Windows computers without a Windows 2000 server If your network does not have a Windows 2000 server, Windows 2000/XP workstations can still print to the EX7750. This method of printing is called Windows, or SMB printing.
Page 34: Ex7750 On A Netware Network
2-8 Setting up Network Servers EX7750 on a NetWare network The NetWise features built into the EX7750 support the following network operating environments: • NetWare—NDS (Novell Directory Services) • Servers running NetWare in bindery emulation mode The term “Netware” is used to refer to Netware 4.x, 5.x, and 6.x. For Ethernet-based networks, the IPX/SPX protocol is supported.
Page 35: Tips For Experts-Ipx Networks
2-9 EX7750 on a NetWare network Tips for experts—IPX networks Setting up the EX7750 is similar to setting up any other PostScript printer on the network. The EX7750 with IPX connections has the following characteristics: • A minimum connection to the EX7750 consists of a NetWare ﬁle server, a NetWare print server, and a NetWare queue.
Page 36: Conﬁguring A Netware Server For Printing
2-10 Setting up Network Servers You do not need to rerun Setup when you add or remove a NetWare queue; however, you should restart the EX7750 after you create or remove a queue. When the EX7750 is conﬁgured to connect to a NetWare server, it polls the NetWare server for jobs in each of its queues.
Page 37 2-11 EX7750 on a NetWare network With bindery services, you can route all EX7750 print jobs through the same NetWare ﬁle server, or you can conﬁgure more than one ﬁle server to handle EX7750 jobs. The functions you perform on the Novell server, the EX7750, and the client workstation are summarized in the following tables.
Page 38 2-12 Setting up Network Servers Conﬁguring a bindery connection In Setup from On Bindery FS On client workstation Command WorkStation In NetWare Port Setup Install user software. administration tools: Ethernet Setup For printing: Protocol Setup For each FS: Connect client to PQs that IPX/SPX Setup—select Conﬁgure PS you set up on the NetWare FS...
Page 39 2-13 EX7750 on a NetWare network In order to set up the NetWare server in bindery emulation mode for printing to the EX7750, the network administrator must do the following: • Determine the Directory Services path to the container in which the print server and the EX7750 Print queue will be created.
Page 40: Ex7750 On A Netware Network With Ndps
2-14 Setting up Network Servers • Setting up the EX7750 as a PostScript printer by installing a PostScript printer driver and the EX7750 PPD (PostScript printer description). • Adding a network port and connecting the workstation to one or more NetWare queues that have been deﬁned for the EX7750.
Page 41: Tips For Experts-Netware Networks
2-15 EX7750 on a NetWare network with NDPS Tips for experts—NetWare networks Setting up the EX7750 in an NDPS environment is similar to setting up any other PostScript printer on the network. When setting up the EX7750 in such an environment, refer to the following information: •...
Page 42: Ex7750 On A Network With Unix Workstations
2-16 Setting up Network Servers EX7750 on a network with UNIX workstations When a UNIX workstation is conﬁgured with the lpd protocol and connected to the EX7750 over a TCP/IP network, it can print directly to the EX7750. Setting up UNIX workstations requires an administrator with root privileges. After the initial conﬁguration, UNIX users simply submit print jobs to a named printer.
Page 43: Important Note About The Remote Printer Name
2-17 EX7750 on a network with UNIX workstations Important note about the remote printer name Whichever UNIX system you use, the name used for the remote printer (or in the ﬁle) in conﬁguring the EX7750 must be one of the following /etc/printcap print hold...
Page 44 2-18 Setting up Network Servers EX7750 UNIX O SET UP PRINTING ON SYSTEMS 1. Specify the appropriate settings in EX7750 Server Setup. To access EX7750 Setup, see “Accessing Setup options” on page 4-9. 2. Specify the appropriate settings in EX7750 Network Setup. Enter a valid IP address, subnet mask, and gateway address for the EX7750.
Page 45: Managing Print Jobs
2-19 EX7750 on a network with UNIX workstations EX7750 O PRINT TO THE • On a UNIX system running Solaris 8, use the lp command to send a job to the EX7750. • Windows 2000/XP users with the TCP/IP protocol loaded can send print jobs to the EX7750 from their applications or from a command prompt.
Page 46 This page is intentionally blank.
Page 47: Chapter 3: Preparing For Ex7750 Setup
3-1 Levels of access and control To prepare for printing at your site, you must do some initial EX7750 conﬁguration, Chapter 3: or Setup, to specify the network environment and the kind of printing you will do. Preparing Before you perform Setup, you must decide the levels of access you will implement for for EX7750 your site.
Page 48 3-2 Preparing for EX7750 Setup In addition, you can enable the Printed queue, which is a storage area for the most recent jobs from the Print queue. The Printed queue makes it convenient to reprint those jobs. In Setup, you can enable the Printed queue and specify the maximum number of jobs retained in the queue (see “Jobs Saved in Printed Queue 1-99 [10]”...
Page 49: Passwords
3-3 Levels of access and control Passwords You can implement passwords as a means of controlling access to EX7750 functions. The EX7750 allows you to set the following passwords in Setup: • Administrator—from the Control Panel, WebSetup, or Command WorkStation (or local Setup, if you have the Fiery Advanced Controller Interface [FACI] installed) •...
Page 50: Webtools
3-4 Preparing for EX7750 Setup Operator privileges Operator control includes control of print jobs from the job management tools, including the ability to override job settings. Guest privileges (no password) No password is needed for a user to log in as a Guest from the job management tools. A Guest can view the status of active jobs but cannot make changes to jobs or to the EX7750 state.
Page 51 3-5 Levels of access and control WebLink WebLink provides all users with a link to an address on the Internet. To change the WebLink Internet address, see “Setting the WebLink destination” on page 6-3. This function requires the Administrator password, if one has been set (see “Passwords”...
Page 52: Control Level Scenarios
3-6 Preparing for EX7750 Setup Control level scenarios Typical scenarios of access and control, ranging from minimum control to maximum control, are described in this section. Choose the scenario that best matches your site requirements, and then refer to the corresponding number in the table for guidance on how to conﬁgure your system for those requirements.
Page 53 3-7 Levels of access and control 4. An administrator and an operator; no WebTool access Only an administrator can perform Setup, calibration, and other administrator functions, and only an operator or administrator can control jobs from the job management tools; users can print to the Hold queue and Print queue, but not to the Direct connection;...
Page 54: Ex7750 System Software
3-8 Preparing for EX7750 Setup EX7750 system software The EX7750 uses Windows XP Embedded system architecture to receive and process jobs and send job data to the printer. To log on to the EX7750, enter Administrator the user name, and enter the password “ Fiery.1 ”.
Page 55: Local Setup From The Ex7750
3-9 About Setup The ﬁrst time you perform Setup, you must use the EX7750 Control Panel. Conﬁgure, at a minimum, Server Setup, Network Setup, and Printer Setup, in that sequence. After the initial Setup, you can change Setup options from the Control Panel (see “EX7750 Control Panel”...
Page 56: Network Server Setup Requirements
3-10 Preparing for EX7750 Setup Network server setup requirements For Novell and Windows 2000 (using TCP/IP) networks, you must conﬁgure the network servers for printing to the EX7750 before you conﬁgure EX7750 network settings in Setup. For chapter references to information about network server Setup, see the diagrams in Chapter To conﬁgure network settings in Setup, you must have a live network connection, so...
Page 57: Ensuring Virus-Free Operation Of The Ex7750 On A Network
3-11 About Setup EX7750 O PREPARE FOR CONFIGURATION 1. Copy a test page to verify the printer is functioning normally. 2. Turn off the printer and connect the interface cable from the printer to the EX7750. 3. To conﬁrm this connection, turn on the printer and allow it to warm up. Then turn on the EX7750, and print a Test Page from the EX7750 Control Panel.
Page 58 3-12 Preparing for EX7750 Setup EX7750 O SCAN THE FROM A INDOWS COMPUTER 1. Disable all the print connections published in Server Setup and Printer Setup. In Server Setup, set Enable Printed Queue to No. In Printer Setup, set the following: •...
Page 59: About The Ex7750 Default Password
3-13 About Setup 8. Run the program as instructed. The program scans the C:, D:, and E: drives mapped. For details, see the anti-virus software documentation. 9. Enable the appropriate print connections in Server Setup and Printer Setup. When no jobs are processing or printing, scanning is complete within 10 minutes.
Page 60 3-14 Preparing for EX7750 Setup 2. In the Windows Security dialog box, click Change Password, and then enter the following: For example, if you want to change to “Fiery.2”: For User name, Administrator Log on to (Windows 2000/XP),\\EX7750 name For Old Password, Fiery.1 For New Password, Fiery.2 For Conﬁrm New Password, Fiery.2 3.
Page 61: Chapter 4: Performing Setup From The Control Panel
4-1 EX7750 Setup from the Control Panel Setup is required the ﬁrst time the EX7750 is turned on after new system software is Chapter 4: loaded. If you do not conﬁgure a particular Setup option, the EX7750 uses default Performing settings.
Page 62 4-2 Performing Setup from the Control Panel The Control Panel on the front of the EX7750 allows you to set options and view information about jobs printed to the EX7750. It comprises the following parts: • Activity light—indicates normal or problem activity •...
Page 63: Ex7750 Control Panel
4-3 EX7750 Control Panel EX7750 Control Panel Use the EX7750 Control Panel to view status information, print special pages, and set up printing. While most elements in the Control Panel display have counterparts in Command WorkStation, you can view current functions on the Control Panel even when Command WorkStation is not connected to the server or is not running.
Page 64: Buttons
4-4 Performing Setup from the Control Panel Buttons Line selection Use these buttons to select the command displayed on the buttons corresponding line of the display window. When a button is active, a special character (>) appears in the display window next to the button.
Page 65: Display Window
4-5 EX7750 Control Panel Display window The display window provides information about the status of the EX7750, displays menu information, and allows you to view and edit information in the Setup menus. The status area at the bottom of the display window displays the screen name and highlights one of the icons to indicate what the EX7750 is doing.
Page 66 4-6 Performing Setup from the Control Panel Info Status When the EX7750 is not processing or printing a job, it displays information about the current server and software: —The EX7750 name, as it is conﬁgured in Setup. Server Name —The current status of the EX7750. The EX7750 status can be: Idle, Status Initializing, Busy, Processing, or Printing.
Page 67: Functions Menu
4-7 EX7750 Control Panel Functions menu The Functions menu provides many of the options available from Command WorkStation. Choose the following commands from this menu: Print Pages Print special pages from the EX7750. You can print the following pages from the submenu that appears: —Prints a Test Page that allows you to conﬁrm that the EX7750 is PS Test Page...
Page 68 4-8 Performing Setup from the Control Panel Suspend Printing Suspend communication between the EX7750 and the printer. Resume Printing Resume communication between the printer and the EX7750. Secure Print Allows users to control Secure Print jobs. To access Secure Print jobs, a password is required.
Page 69: Accessing Setup Options
4-9 EX7750 Control Panel Run Diagnostics This function is provided for service representatives only. For information about running diagnostics, contact your authorized service/support technician. Calibration Calibrate the EX7750 using VisualCal. If an Administrator password has been set, you must enter it to access Calibration. Accessing Setup options EX7750 O ACCESS...
Page 70: About The Control Panel Setup Interface
4-10 Performing Setup from the Control Panel About the Control Panel Setup interface When you perform Setup from the Control Panel, you can select one menu after another and enter information about your EX7750 and your network and printing environment. In each Setup screen, the last line of the display window shows the name of the current Setup menu.
Page 71: Types Of Setup Screens
4-11 EX7750 Control Panel Types of Setup screens There are two types of Setup options: Multiple choice You are given choices (for example, Yes or No, or a list questions of options from which to choose). Only one choice is displayed at a time, in highlighted text.
Page 72 4-12 Performing Setup from the Control Panel Example: Multiple choice Publish Print Queue Publish Print Queue Printer Setup Printer Setup Press the up or down When the setting you want arrow buttons to display appears, press the button the other option or options. beside OK to continue.
Page 73: Server Setup Options
4-13 Server Setup options If you make a mistake during Setup, use the Menu button to cancel without saving changes. Pressing Menu cancels what you are doing in the current screen to bring you to the next higher-level menu. You may need to press Menu more than once to return to the top level for the particular Setup in which you are working.
Page 74 4-14 Performing Setup from the Control Panel System Time Enter the correct system time. Enter the time based on the 24-hour clock in the form HH:MM (Hours:Minutes). The time appears on the Job Log. Time Zone Select a time zone in which you are located. Daylight Saving Yes/No [No] Select Yes if your location has daylight saving time changes.
Page 75 4-15 Server Setup options Enable Printed Queue Yes/No [Yes] Specify whether to enable the Printed queue, which creates a storage location on the EX7750 hard disk for recent jobs that were printed from the Print queue. Users with Administrator or Operator access to the job management tools can reprint jobs from the Printed queue without resending them to the EX7750.
Page 76: Network Setup Options
4-16 Performing Setup from the Control Panel Network Setup options When you perform network Setup, you conﬁgure the EX7750 to receive print jobs over the network systems that are used at your site. In the Setup menu, choose Network Setup, where you specify network addresses and Exit Setup Server Setup names to be used by workstations, servers, and the EX7750 when they communicate...
Page 77 4-17 Network Setup options O ACCESS ETWORK ETUP OPTIONS 1. Conﬁrm that the network cable is connected to the EX7750. During Network Setup, the EX7750 queries the network for zones, servers, and server-based queues. If you perform Network Setup without a connected and functioning network, default settings are used that may not meet your needs.
Page 78: Port Setup Options
4-18 Performing Setup from the Control Panel Port Setup options Network Setup Port Setup To conﬁgure the EX7750, choose the port type you use and enter the settings for that port. Since network setups are nested, the names of higher-level menus are shown in this chapter to the left of each menu heading.
Page 79 4-19 Network Setup options AppleTalk Zone List of zones The EX7750 searches the network for AppleTalk zones in your network segment. Scroll through the list to select the AppleTalk zone in which you want the EX7750 to appear. If your segment has only one zone, the EX7750 is assigned to that zone automatically.
Page 80 4-20 Performing Setup from the Control Panel TCP/IP Setup with Ethernet Network Setup Protocol Setup TCP/IP Setup Ethernet Setup Enable TCP/IP for Ethernet Yes/No [Yes] Select Yes if you have a TCP/IP network connected to the EX7750 over Ethernet cabling. If you are using TCP/IP for printing from Windows computers, enabling TCP/IP here also enables you to use Fiery utilities from Windows computers using TCP/IP protocols.
Page 81 4-21 Network Setup options Get Gateway Address Automatically Yes/No [Yes] Use this option to assign the gateway address automatically for printing with TCP/IP. This option appears only if you selected DHCP or BOOTP as the protocol in the previous option. IP Address [127.0.0.1] This option appears only if you answered No to Enable Auto IP Conﬁguration.
Page 82 4-22 Performing Setup from the Control Panel DNS Setup options Network Setup Protocol Setup TCP/IP Setup DNS Setup DNS Setup You can conﬁgure the EX7750 so that it can access an appropriate DNS server. With the DNS server, when connecting the Fiery utilities or WebTools from remote workstations to the EX7750, users need to remember only its Server Name, which is much easier to remember than an IP address.
Page 83 4-23 Network Setup options If you want to use sending functions, you may also need to change the WINS name server settings speciﬁed in the Windows Setup>Service Setup>Network Setup. However, setting up the WINS name server is outside the scope of this document. For more information about setting up a WINS name server, contact your network administrator.
Page 84: Service Setup Options
4-24 Performing Setup from the Control Panel Select Frame Types Exit IPX/SPX Setup Select Frame Types Enable IPX Auto Frame Type Clear Frame Types Yes/No [No] IPX/SPX Setup Specify whether the EX7750 should try to bind to all available frame types automatically.
Page 85 4-25 Network Setup options LPD Setup options Network Setup Service Setup LPD Setup Enable LPD Yes/No [Yes] Select Yes to allow lpd printing. For more information, see “Setting up the EX7750 on TCP/IP networks” on page 2-17. PServer Setup options Network Setup Service Setup PServer Setup...
Page 86 4-26 Performing Setup from the Control Panel Network Setup Service Setup PServer Setup NDS Setup Before entering NDS settings, make sure the EX7750 is connected to the network and that you have conﬁgured an NDS directory tree with a printer, print server, and one or more Print queue objects for EX7750 jobs (see “Setting up a NetWare Print queue for bindery”...
Page 87 4-27 Network Setup options Is user login needed to browse NDS tree? Yes/No [No] Select No if no password is required to browse the tree. You can proceed to navigate to the Print Server object. Select Yes if network permissions require that you log in to browse the NDS tree and see the Print Server object you want to select.
Page 88 4-28 Performing Setup from the Control Panel Enter Password Enter the login password for the NDS tree, using the up and down arrow buttons to select characters, and the left and right arrow buttons to move the cursor. Choose OK. Navigate the NDS tree to the Print Server.
Page 89 4-29 Network Setup options Server should look for print queues in: Entire NDS Tree/Specified Subtree [Entire NDS Tree] By default, the EX7750 searches the entire NDS tree for EX7750 print connections. This option lets you restrict the search for EX7750 print jobs to a subtree (the Print Queue root) in which the EX7750 print connections have been deﬁned.
Page 90 4-30 Performing Setup from the Control Panel With an object selected, choose OK to travel down the tree, or choose “..” to go up the tree. When you select an object and choose OK, that object is then displayed on the top line, and the second line lists objects contained within.
Page 91 4-31 Network Setup options Bindery Setup menu Because you can set up more than one Novell server to handle EX7750 print jobs, an Exit Bindery Setup Add File Server additional menu is displayed for this purpose. The options are: View Server List Edit Connection •...
Page 92 4-32 Performing Setup from the Control Panel Network Setup Service Setup PServer Setup Bindery Setup Add File Server This option gives you two ways to add a Novell NetWare ﬁle server. Select File Server From List/Search by Name [From List] You may select the ﬁle server from a scrollable list, or by a name search.
Page 93 4-33 Network Setup options File Server Login administrator/supervisor/Enter Login Name [supervisor] This option appears only if a password is required for login, if there is no guest account, or the guest account is restricted. Choose Enter Login Name to enter your own login name and password or log in as a guest.
Page 94 4-34 Performing Setup from the Control Panel Network Setup Service Setup PServer Setup Bindery Setup View Server List Supported servers This option allows you to view the list of ﬁle servers currently connected to the EX7750—that is, servers you have added in Bindery Setup. You are notiﬁed if there are none.
Page 95 4-35 Network Setup options Enter Your Print Server Password This option appears only if your NetWare print server is password-protected. Enter your print server password. The Bindery Setup menu is displayed again. You can edit other connections, choose another Bindery Setup option, or choose Exit Bindery Setup. Network Setup Service Setup PServer Setup...
Page 96 4-36 Performing Setup from the Control Panel Polling Interval options Network Setup Service Setup PServer Setup Polling Interval Whether you use NDS or Bindery services, choose Polling Interval from the main PServer Setup menu. If you do not reset the interval, the default value of 15 seconds is used.
Page 97 4-37 Network Setup options Use Automatic Configuration Yes/No [Yes] This option appears if you chose DHCP or BOOTP as the protocol for automatically obtaining the IP address of the EX7750. Choose Yes and the EX7750 uses a WINS name server and automatically obtains its IP address.
Page 98 4-38 Performing Setup from the Control Panel Server Comments Server comments (optional) can contain information about the printer. These comments are listed in the EX7750 Properties in Network Neighborhood and can be up to 15 characters. Set Domain Name Select from list/Enter manually [Select from list] This option provides two ways to specify the workgroup or domain in which you want the EX7750 to appear.
Page 99 4-39 Network Setup options IPP Setup Network Setup Service Setup IPP Setup Enable IPP Yes/No [Yes] Select Yes to enable printing with the Internet Printing Protocol (IPP). You must enable Web Services. For information about setting up user computers to use IPP printing, see the User Software Installation Guide.
Page 100 4-40 Performing Setup from the Control Panel E-mail Setup Network Setup Service Setup E-mail Setup Enable E-mail Services Yes/No/Restore Settings [No] This option enables the EX7750 to use e-mail as a means of communication for a variety of purposes. The EX7750 serves as a messenger between the printer and the e-mail recipient.
Page 101 4-41 Network Setup options Fiery E-mail User Name Enter the user name of the e-mail account. This is typically the part of the e-mail address that precedes the @ symbol. For example, in the address pat@test.com , the user name is You can enter a maximum of 14 characters.
Page 102 4-42 Performing Setup from the Control Panel Administrator E-mail Domain Name Enter the name of the domain in which the administrator has an account. This is typically the part of the e-mail address that follows the @ symbol. For example, in the address , the domain name is pat@test.com...
Page 103 4-43 Network Setup options SNMP Setup Network Setup Service Setup SNMP Setup Enable SNMP Yes/No [Yes] This option enables the SNMP communication over a TCP/IP or IPX connection. Selecting No disables any access to remote Setup through Command WorkStation. SNMP Read Community Name [public] This option appears if you select Yes for Enable SNMP.
Page 104: Printer Setup Options
4-44 Performing Setup from the Control Panel Network Setup Service Setup Exit Service Setup This returns you to the main Network Setup menu. Choose Exit Network Setup. Save Changes Yes/No [Yes] Select Yes to activate any changes made in Network Setup; select No to return to the main Setup menu without making any changes.
Page 105 4-45 Printer Setup options Publish Direct Connection Yes/No [Yes] This option allows users to print (or download) jobs to the EX7750 without spooling. Jobs printed to the Direct connection are not saved in the Printed queue. If you plan to download fonts to the EX7750, you must publish the Direct connection.
Page 106: Postscript Setup Options
4-46 Performing Setup from the Control Panel PostScript Setup options PS (PostScript) Setup allows you to set defaults for the EX7750. Users can override most of these defaults on a job-by-job basis. However, users printing from UNIX or DOS command lines cannot override defaults from their applications. Therefore, you must set defaults in PS Setup.
Page 107 4-47 PostScript Setup options Print to PS Error Yes/No [No] Specify whether the EX7750 should print the available portion of a print job when it encounters a PostScript error. Select Yes to print the portion of the job that was processed before the error occurred;...
Page 108: Pcl Setup Options
4-48 Performing Setup from the Control Panel PCL Setup options PCL Setup allows you to set defaults to control printer output. These defaults can be overridden by the user from within an application, but they determine how a job will be printed in the absence of other information.
Page 109 4-49 PCL Setup options Font Number 0-999 [0] Specify a font number which designates the default font for the EX7750. To determine font numbers, print the internal PCL Font List. The standard fonts are listed in order. The font numbers, however, are not displayed. Font Pitch (char/in) [10.00] When the number selected in Font Number represents a ﬁxed pitch scalable font, the...
Page 110: Color Setup Options
4-50 Performing Setup from the Control Panel Color Setup options Color Setup allows you to set defaults the EX7750 uses to control color output. Mac OS and Windows users who use the printer drivers provided on the User Software CD can override most of these defaults on a job-by-job basis. However, users printing from UNIX or DOS command lines cannot override defaults from their applications.
Page 111 4-51 Color Setup options Rendering Style Photographic/Presentation/Abs. Colorimetric/Rel. Colorimetric [Presentation] The color rendering dictionary (CRD) deﬁnes how colors are converted from the RGB color space to device CMYK. Photographic, designed for images, retains the relative balance between colors to maintain the overall appearance of the image. Presentation, designed for bright colors, produces the saturated prints needed for most business presentations, but handles photographic images the same way as the Photographic CRD.
Page 112 4-52 Performing Setup from the Control Panel RGB Separation Output/Simulation [Output] This option deﬁnes how the EX7750 processes RGB jobs. Select Output for RGB jobs that you print to the ﬁnal output device. Select Simulation to simulate an output device that is not the device to which you are printing. Use Media Defined Profiles Yes/No [Yes] Specify whether to use the Media-Deﬁned Proﬁles feature.
Page 113 4-53 Color Setup options Spot Color Matching On/Off [Off] With this option On, the EX7750 uses an internal lookup table to print the best equivalents of PANTONE colors. With this option Off, PANTONE colors are printed using the CMYK values deﬁned in the original applications. For more information, see Color Guide.
Page 114: Administrative Functions In The Setup Menu
4-54 Performing Setup from the Control Panel Administrative functions in the Setup menu The remaining choices in the Setup menu are intended to help you manage print jobs and color output but are not required for printing. • allows you to specify whether the EX7750 prints and clears its log of Job Log Setup printed jobs automatically.
Page 115 4-55 Administrative functions in the Setup menu Default values for the following options, where applicable, appear in square brackets. Auto Print Job Log Every 55 Jobs Yes/No [No] Use this option to specify whether the EX7750 prints the Job Log after every 55 jobs. Setting the Job Log for automatic printing is useful if accounting for each printed page is important at your site.
Page 116: Font Archiving
4-56 Performing Setup from the Control Panel Font Archiving This feature is available only if an external ZIP drive is installed on the EX7750. For more information, see “Installing a ZIP drive for Font Archiving” on page 7-21. You can back up and restore the EX7750 resident fonts to a ZIP disk. All fonts are backed up or restored;...
Page 117 4-57 Administrative functions in the Setup menu Label the disk [XXXXXXXX-X] Write down the disk label displayed on a label sticker and put it on the disk. You need the label information for font restoration later. When backup is complete, press OK to exit the Back up Fonts menu. Keep the disk stored for font restoration later.
Page 118: Exit Setup
4-58 Performing Setup from the Control Panel Data verified. Proceed to: Continue/Cancel [Cancel] All the fonts resident on the EX7750 are veriﬁed. The EX7750 is now ready to proceed to restore backed up fonts from the ZIP disk. Select Continue to overwrite all the fonts currently resident on the EX7750 hard disk.
Page 119: Chapter 5: Setting Up The Ex7750 From A Windows Computer
5-1 Accessing Setup After you perform initial Setup (Server, Network, and Printer Setup) from the Control Chapter 5: Panel, you can change most Setup options from a Windows computer. Setting up the EX7750 from Accessing Setup a Windows In addition to using the Control Panel, you can set up the EX7750 in two ways: locally Computer and remotely.
Page 120: Local Fiery Setup
5-2 Setting up the EX7750 from a Windows Computer Local Fiery Setup You can access EX7750 Server Setup in any of the following ways: • Right-click FieryBar on the Windows XP desktop and choose Set Up Fiery. • Right-click the Fiery icon in the Windows XP taskbar and choose Set Up Fiery. •...
Page 121: Remote Fiery Setup
5-3 Accessing Setup Remote Fiery Setup You can access remote Setup from WebTools or Command WorkStation. O ACCESS IERY ETUP OR ETUP FROM OMMAND TATION 1. To access Fiery WebSetup, start your Internet browser and enter the IP address of the EX7750.
Page 122 5-4 Setting up the EX7750 from a Windows Computer Regardless of how you access Setup remotely, the following window appears. The interface of remote Setup from Command WorkStation and Fiery WebSetup is identical.
Page 123: General Setup Options
5-5 General Setup options General Setup options You can specify EX7750 system settings that affect all users, such as the name of the EX7750, system date and time, passwords, and Job Log printing. The interface of local EX7750 Setup and remote Setup is similar. The following instructions describe setup from Command WorkStation.
Page 124 5-6 Setting up the EX7750 from a Windows Computer —Specify the system time and date, which are recorded on the Job Log. Time and Date —Specify whether to enable the Printed Queue, a storage Enable Printed Queue location on the EX7750 hard disk for recently printed jobs. You can reprint jobs from the Printed queue without resending them to the EX7750.
Page 125: Job Log Setup
5-7 General Setup options Job Log Setup —Specify whether the EX7750 prints the Job Log Auto Print Job Log every 55 Jobs after every 55 jobs. The Job Log lists the last 55 jobs processed on the EX7750, with accounting information about each one, including user name, document name, time and date printed, number of pages, and other job information.
Page 126: Network Setup
5-8 Setting up the EX7750 from a Windows Computer Network Setup Network Setup conﬁgures the EX7750 to receive print jobs over the networks used at your site. If the EX7750 is conﬁgured to enable more than one protocol, it automatically switches to the correct protocol when it receives a print job. When two network ports are enabled, print jobs can be received over all ports at the same time.
Page 127: Adapters/Ports
5-9 Network Setup Adapters/Ports In local Setup only, the installed network boards are displayed. You cannot change this information. From remote Setup, you can enable Ethernet. These options are described in the following section. Ethernet (Port Setup) —Select to connect the EX7750 to an Ethernet network. Enable Ethernet —Select an appropriate setting according to the settings of the Transmission Speed...
Page 128: Protocols
5-10 Setting up the EX7750 from a Windows Computer Protocols You can change AppleTalk, IPX/SPX, and TCP/IP protocol settings for the EX7750. These protocols work in conjunction with the Windows XP Local Area Connection Properties Control Panel. When you click the Modify or Advanced button next to the setting, the system opens the Local Area Connection Properties Control Panel, where you complete the settings.
Page 129 5-11 Network Setup O CHANGE PROTOCOL SETTINGS FROM LOCAL ETUP 1. Click Modify or Advanced next to the setting. The Windows XP Local Area Connection Properties Control Panel opens. 2. Click the General tab. 3. Select the protocol to modify. Unless you have installed additional protocols, the choices are Eﬁ...
Page 130 5-12 Setting up the EX7750 from a Windows Computer IPX/SPX Use this option to specify IPX/SPX frame types. The EX7750 supports the following Ethernet frame types for IPX/SPX: Ethernet 802.2, Ethernet 802.3, Ethernet II, and Ethernet SNAP. You can also allow the EX7750 to select the frame type automatically.
Page 131 5-13 Network Setup TCP/IP Specify TCP/IP settings. The current settings for IP address, subnet mask, and default gateway address are displayed. For information about setting up printing with TCP/IP, Chapter The EX7750 requires a unique, valid IP address. You can set a static address or specify that the EX7750 use DHCP or BOOTP to obtain IP addresses automatically.
Page 132 5-14 Setting up the EX7750 from a Windows Computer To set the subnet mask, enter one of the following values: • 255.0.0.0 if the IP address starts with a number less than 128 • if the IP address starts with a number from 128 through 191 255.255.0.0 •...
Page 133: Services
5-15 Network Setup Services You can conﬁgure the following network services: —enable or disable LPD print LPD Printing (TCP/IP)/Enable LPD Printing Service services. —specify NDS and Bindery services (see NetWare Printing (PServer)/NetWare Services “NetWare Printing (PServer) options” on page 5-16). —enable or disable SMB print Windows Print Sharing (SMB)/Windows Printing Service services.
Page 134 5-16 Setting up the EX7750 from a Windows Computer LPD Printing —Select to enable or disable LPD LPD Printing (TCP/IP)/Enable LPD Printing Service printing services. NetWare Printing (PServer) options The following procedures for setting up NetWare printing depict the windows from local Setup at the EX7750.
Page 135 5-17 Network Setup Setting up the EX7750 for NDS printing Only one NDS tree can be connected. To specify or change the NDS Tree, click Modify and specify settings in the NDS Print Server dialog box, as follows. The currently selected NDS Tree and Print Server are displayed. EX7750 S O SPECIFY THE TREE SETTING FROM LOCAL...
Page 136 5-18 Setting up the EX7750 from a Windows Computer 2. In the NDS Connection dialog box, double-click an NDS tree in the list on the left. 3. Navigate to the NDS container and click OK. If necessary, enter the password.
Page 137 5-19 Network Setup 4. Select a container from the Containers list. 5. Double-click a print server from the Select Print Server list. The full path to the print server appears. Another way to change the path is to click Edit and type the path to the print server.
Page 138 5-20 Setting up the EX7750 from a Windows Computer 6. Click OK. The Server Setup dialog box appears, displaying the path to the selected print server on the Network Setup tab.
Page 139 5-21 Network Setup EX7750 S O SPECIFY THE TREE SETTING FROM REMOTE ETUP 1. Select Enable NDS and click Change Trees. 2. In the NDS Conﬁguration window that appears, double-click an NDS tree in the Available Trees list. 3. In the Select User Login window, select Use Default User Information or enter your password, and click Next.
Page 140 5-22 Setting up the EX7750 from a Windows Computer 4. Navigate to the NDS container, select it, and click Next. If necessary, enter the password. The password must be 19 alphanumerical characters or less. If it exceeds this limit, you cannot connect to the server.
Page 141 5-23 Network Setup 5. Select Use Default Print Queue Root or navigate to the Print Queue Root and click Finish.
Page 142 5-24 Setting up the EX7750 from a Windows Computer 6. Click OK. The NDS Conﬁguration window appears, displaying information about the print server.
Page 143 5-25 Network Setup Bindery Setup From the Network Setup tab, specify Bindery services. The currently connected servers are displayed. A maximum of eight bindery servers can be connected. To add, remove, or change bindery connections, click Modify and specify settings in the Bindery Connections dialog box, as described in the following procedures.
Page 144 5-26 Setting up the EX7750 from a Windows Computer EX7750 S O ADD BINDERY CONNECTIONS FROM LOCAL ETUP 1. Click Modify in the Bindery Setup dialog box. The Bindery Connections dialog box appears. 2. Select a ﬁle server from the Select File Server list. If the File Server User Name and Password dialog box appears, enter the appropriate user name and password to log on to the selected ﬁle server.
Page 145 5-27 Network Setup 3. Select a print server from the Select Print Server list, and click Add. The name of the newly added server appears in the Connected Servers list. To add another server, repeat the preceding steps. You can connect a maximum of eight servers.
Page 146 5-28 Setting up the EX7750 from a Windows Computer EX7750 S O REMOVE BINDERY CONNECTIONS FROM LOCAL ETUP 1. Click Modify in the Bindery Setup dialog box. The Bindery Connections dialog box appears. 2. Select a server from the Connected Server list and click Remove. 3.
Page 147 5-29 Network Setup EX7750 S O ADD BINDERY CONNECTIONS FROM REMOTE ETUP 1. Select Enable PServer mode from the Service1 tab. 2. Click Bindery Setup. 3. Select a ﬁle server from the Available Servers list. If the File Server User Name and Password dialog box appears, enter the appropriate user name and password to log on to the selected ﬁle server.
Page 148 5-30 Setting up the EX7750 from a Windows Computer 4. Select a print server from the list and click Finish. If necessary, enter the appropriate password in the Print Server Password dialog box to log on to the selected ﬁle server. The name of the newly added server appears in the Selected Servers list.
Page 149 5-31 Network Setup O REMOVE BINDERY CONNECTIONS FROM REMOTE EX7750 S ETUP 1. Select Enable PServer mode from the Service1 tab. 2. Click Bindery Setup. The Novell Setup dialog box appears. 3. Make your selection in the Selected Servers list. 4.
Page 150 5-32 Setting up the EX7750 from a Windows Computer Poll Interval (local Setup) or PServer Poll Interval (remote Setup) Specify the polling interval (in seconds) for NetWare printing.
Page 151 5-33 Network Setup Windows Print Sharing with Server Message Block (SMB) For setting up the Windows printing service, text ﬁelds may include uppercase letters, numerals, spaces, and the following characters: - _ . ~ ! @ # $ % ^ & ( ) { } \ ' , " Lowercase letters are not allowed, except in the Comment ﬁeld.
Page 152 5-34 Setting up the EX7750 from a Windows Computer —Select to enable SMB Enable SMB Print Services/Enable Windows Printing Service (Server Message Block), the ﬁle and printer sharing protocol built into Windows. Enabling SMB lists the EX7750 on the network so that Windows clients can print to a particular print connection (Hold, Print, or Direct) on the EX7750 without any other networking software.
Page 153 5-35 Network Setup SNMP Setup The following options can be accessed only in local Setup. —Select to enable the SNMP communication over a TCP/IP or IPX Enable SNMP connection. Leaving this option unselected disables any access to remote Setup through Command WorkStation. —Change the SNMP Community Name (“public”...
Page 154 5-36 Setting up the EX7750 from a Windows Computer HTTP Connection Support (WWW) —Select to make the WebTools available to Enable Web server/Enable Web Services users (see “Setting up WebTools” on page 6-2). TCP/IP must already be enabled on the EX7750 and on users’ computers. A Java-enabled Web browser and a valid IP address are required for each user.
Page 155 5-37 Network Setup Port 9100 printing —Enables applications to open a TCP/IP socket to Enable Port 9100 (Print Services) the EX7750 at Port 9100 to download a print job. —Allows you to attach Port 9100 to any of the published EX7750 Port 9100 Queue print connections.
Page 156 5-38 Setting up the EX7750 from a Windows Computer E-mail Service Setup —Enabling e-mail services is required for Enable Email Services/E-mail Service Setup all e-mail client services including printing ﬁles or sending scan ﬁles through e-mail. Enabling e-mail services is also required for printing an E-mail log. —If selected, print jobs sent via e-mail are accepted.
Page 157 5-39 Network Setup —Specify the IP address of the server (SMTP) on your network Outgoing Mail Server that handles outgoing e-mail. You can enter a maximum of 64 characters. You must deﬁne both an Incoming and Outgoing mail server. If an Outgoing mail server is not deﬁned, the e-mail service assumes that the incoming and outgoing server names are the same.
Page 158 5-40 Setting up the EX7750 from a Windows Computer —Enter the name of the e-mail account. For example, Fiery E-mail Address pat@test.com You can enter a maximum of 80 characters. —Enter a password for accessing the mailbox account on the mail server. Password You can enter a maximum of 16 characters.
Page 159: Printer Setup Options
5-41 Printer Setup options Printer Setup options You can specify the following settings on the Printer Setup tab: • Printer Connections • PS (PostScript) Setup • PCL Setup • Color Setup In the following illustrations, “Device name” represents the model of the printer connected to the EX7750, which is EX7550 Printer connections...
Page 160: Ps (Postscript) Setup
5-42 Setting up the EX7750 from a Windows Computer PS (PostScript) Setup In the following illustrations, “Device name” represents the model of the printer connected to the EX7750, which is EX7550 —Specify whether to print color (CMYK) or Grayscale images to the Color Mode EX7750 by default.
Page 161 5-43 Printer Setup options —Specify whether the EX7750 should print the available portion of a Print to PS Error print job when it encounters a PostScript error. In general, this option should be No. • When you choose No, the printing of the entire job is canceled when a PostScript error occurs, but the processed portion of the job and the PostScript error information are stored on the EX7750.
Page 162: Pcl Setup
5-44 Setting up the EX7750 from a Windows Computer PCL Setup PCL options can be set only from local Setup. If you do not have the FACI option installed, change the PCL options on the EX7750 Control Panel as described in “PCL Setup options”...
Page 163 5-45 Printer Setup options —Specify a font number which designates the default font for the Font Number EX7750 from 0 though 999. To determine font numbers, print the internal PCL Font List. The standard fonts are listed in order. The font numbers, however, are not displayed. —When the number selected in Font Number represents a ﬁxed Font Pitch (char/in) pitch scalable font, the Font Pitch option is selectable.
Page 164: Color Setup
5-46 Setting up the EX7750 from a Windows Computer Color Setup Color options can be set only from local Setup. If you do not have the FACI installed, change the PCL options on the EX7750 Control Panel as described in “Color Setup options”...
Page 165 5-47 Printer Setup options —Specify the RGB source space to be applied to RGB data. RGB Source Proﬁle —Specify the Rendering Style to be applied to RGB data. Rendering Style —Specify the simulation to be applied to CMYK data. CMYK Simulation Proﬁle —Specify the simulation method to be used.
Page 166: Setting Up Printing Groups
5-48 Setting up the EX7750 from a Windows Computer Setting up printing groups The EX7750 administrator can arrange users into groups and allow members of a group to print only if they supply a password at print time. This method of printing is known as Printing Groups, or Member Printing.
Page 167 5-49 Setting up printing groups O CHANGE PRINTING GROUPS AND PASSWORDS 1. Select Printing Groups from the Command WorkStation Server menu. 2. Select the printing group name in the Printing Groups Setup dialog box, and click Modify. 3. Make the necessary changes. 4.
Page 168: Exiting Setup
5-50 Setting up the EX7750 from a Windows Computer Exiting Setup When you ﬁnish specifying Setup options in local Setup, click OK and close the Setup dialog box. You are notiﬁed that the EX7750 must be restarted for the new settings to take effect.
Page 169: Printing The Conﬁguration Page
5-51 Printing the Conﬁguration page Printing the Conﬁguration page The Conﬁguration page lists the settings in effect for the current Setup. After you have performed Setup, print a Conﬁguration page to conﬁrm your settings. The other pages you can print from Command WorkStation include the Test Page, Control Panel Map, Font List, Job Log, Color Charts, and E-mail Log.
Page 170 This page is intentionally blank.
Page 171: Chapter 6: Conﬁguring Webtools
6-1 Conﬁguring the EX7750 and clients for WebTools WebTools allow you to manage your EX7750 remotely from the Internet or from your Chapter 6: company’s intranet. From the EX7750 home page, you can select a variety of Conﬁguring functions, including Status, WebLink, WebDownloader, WebSetup, and Installer. WebTools For more information about using WebTools, see the Printing...
Page 172: Setting Up Webtools
6-2 Conﬁguring WebTools O ACCESS OOLS 1. Start your Internet browser. 2. Enter the IP address or DNS name of the EX7750. 3. Press Enter. The EX7750 home page appears. 4. Click the name of a particular WebTool. 5. Click Conﬁgure to enable speciﬁc WebTools for users. Setting up WebTools To enable network users to access and use WebTools, you must set certain EX7750 options in Network Setup and Printer Setup.
Page 173: Setting The Weblink Destination
6-3 Setting the WebLink destination Setting the WebLink destination You can change the pre-set WebLink destination; this function requires the Administrator password, if one has been set. O CHANGE THE INK DESTINATION 1. Start your Internet browser. 2. Enter the IP address or the DNS name of the EX7750. The EX7750 home page appears.
Page 174 This page is intentionally blank.
Page 175: Chapter 7: Administering The Ex7750
7-1 Administrator functions This chapter provides tips on managing EX7750 printing. Chapter 7: Administering Administrator functions the EX7750 Administration features are included with the user software and are built into the EX7750 itself. The following table describes where to ﬁnd information on these features (page references refer to this manual).
Page 176: Setting Passwords
7-2 Administering the EX7750 For these operations And these tasks Getting users started Printing to the EX7750 Printing Guide with printing Setting job-speciﬁc options Using Fiery utilities Job Management Guide Controlling the job ﬂow Using WebTools, Command WorkStation and Fiery Printing Guide utilities and for managing job priorities, tracking current Job Management Guide...
Page 177: Passwords From The Control Panel
7-3 Setting passwords Passwords from the Control Panel From the Control Panel, you can set or change only the Administrator password. For more information about Administrator access privileges, see page 3-3. For information about controlling print jobs with the job management tools, see the Job Management Guide.
Page 178: Passwords From Local Setup Or Remote Setup
7-4 Administering the EX7750 Passwords from local Setup or remote Setup You can set, change, and remove both Administrator and Operator passwords from local Setup or remote Setup (Fiery WebSetup and Command WorkStation). For more information about EX7750 passwords and the access privileges they allow, see “Passwords”...
Page 179: Clearing The Ex7750
7-5 Clearing the EX7750 O REMOVE A PASSWORD 1. Select the password you want to delete. 2. Delete the asterisks (*) in both the Enter New Password and Verify New Password ﬁelds. If you forget the Administrator password, reinstall EX7750 system software (see page 7-6).
Page 180: System Software
7-6 Administering the EX7750 System software The EX7750 ships with system software preinstalled on the HDD (hard disk drive), so you do not need to install system software to begin using the EX7750. A backup copy of the system software also resides on a separate partition on the HDD. If you need to reinstall the current version of system software in the future (for example, to restore the EX7750 to its factory default conﬁguration), you can do so either by restoring the backup copy or by using the system software CDs included in the media pack.
Page 181: Restoring Backup System Software
7-7 System software Restoring backup system software Restoring backup system software returns the system to its default conﬁguration. It is slightly faster and more convenient than reinstalling system software from the system software CDs. If restoring backup fails or you are replacing the HDD, updating to a more recent version of the system software, or changing languages, you must reinstall system software from the system software CDs.
Page 182 7-8 Administering the EX7750 6. Select Restore system from the following menu. Select Option: Restore system Press the 4th line selection button Restore/Update CD Select Option: Update system Do not use Update in this procedure Restore/Update CD Select Option: Exit Restore/Update CD 7.
Page 183 7-9 System software After you power on, the EX7750 organizes the software on the system and then reboots once (twice, if the monitor/keyboard/mouse option is enabled). Several messages display indicating that the backup software is being installed or restored. This segment takes approximately 10 minutes. Wait for the system to boot completely and the Idle screen to appear on the Control Panel.
Page 184: Installing System Software
7-10 Administering the EX7750 Installing system software The System Software CD includes the system software and fonts. Use the System Software CD when: • You replace the HDD • You update to a more recent version of the system software •...
Page 185 7-11 System software 3. Insert the appropriate language CD 1 in the DVD drive. If you installed a new HDD, you need to power on the system using the power switch on the back panel, insert CD 1, and allow the system to boot from the CD, and then proceed to step 6 on page 7-11.
Page 186 7-12 Administering the EX7750 10. At the message “Remove CD and recycle power”, remove CD 3. Then, using the power switch on the back panel, power off the system, wait 10 seconds, and then power the system back on. After you power on, the EX7750 applies the content restored from CD 3 and then reboots once more.
Page 187: Managing Fiery Address Books
7-13 Managing Fiery Address Books Managing Fiery Address Books The E-mail Service feature allows an administrator to import a list of e-mail addresses to the EX7750. This is done by sending messages to the EX7750 in e-mail form. The list will be added to the Fiery Address Books, designed for controlling user access to E-mail Services.
Page 188 7-14 Administering the EX7750 The administrator can manage the address books by sending an e-mail to the EX7750 with command codes in the subject and message ﬁelds. The EX7750 responds by e-mail to these commands with information about each request. When managing address books, see the following table.
Page 189 7-15 Managing Fiery Address Books Fiery e-mail Fiery e-mail Administrator Task Administrator message ﬁeld response subject response message subject ﬁeld ﬁeld ﬁeld To delete #DeleteAddressFrom name@domain Removed from Deleted Address 1 an address name of address book Address Book Deleted Address 2 from an “display name”...
Page 190 7-16 Administering the EX7750 EX7750 O RESTORE AN ADDRESS BOOK TO THE 1. Start your e-mail client software application. 2. Open a new message window. 3. Enter the e-mail address of your print server in the To line. 4. Enter the command of a speciﬁed address book in the Subject line. For the User, enter “#GetAddressTo User”.
Page 191: Printing A Conﬁguration Page From The Control Panel
7-17 Printing a Conﬁguration page from the Control Panel Printing a Conﬁguration page from the Control Panel The Conﬁguration page lists all the settings in effect in the current Setup. After you have ﬁnished running Setup, print a Conﬁguration page to conﬁrm your settings.
Page 192: Maintaining Optimal Ex7750 Performance
7-18 Administering the EX7750 Maintaining optimal EX7750 performance The EX7750 does not require maintenance. Beyond the obvious requirements of servicing and maintaining the printer and replenishing consumables, you can improve the overall performance of your system by doing the following: •...
Page 193: Using Fierybar
7-19 Using FieryBar Using FieryBar This section describes FieryBar, which appears at the top of the monitor screen when you power on the EX7750. You can use FieryBar to access and monitor different functions of the EX7750. Activity light Click to expand or collapse FieryBar Message area Messages When a job is processing or printing, the message area remains blue-gray and the...
Page 194: Commands
7-20 Administering the EX7750 Commands Right-clicking FieryBar allows you to access many EX7750 features. You can choose the following commands from the menu that appears: Command Starts Command WorkStation. For information about WorkStation using the features of Command WorkStation, see the Management Guide.
Page 195: Installing A Zip Drive For Font Archiving
7-21 Installing a ZIP drive for Font Archiving Installing a ZIP drive for Font Archiving To use the EX7750 Font Archiving feature, you must connect a USB compatible external ZIP drive to the EX7750. Connect the power cable to your ZIP drive, and the USB cable to your ZIP drive and to one of the USB connectors on the back panel of the EX7750.
Page 196: Restarting The Ex7750
7-22 Administering the EX7750 Restarting the EX7750 Use the following procedure to restart the EX7750, rather than using the power button on the front of the EX7750. Restart Server restarts the EX7750 system software without shutting down the EX7750 operating system. EX7750 O RESTART THE 1.
Page 197: Rebooting The Ex7750
7-23 Starting and shutting down the EX7750 Rebooting the EX7750 Use the following procedure to reboot the EX7750. Reboot System shuts down and restarts the EX7750 system software and operating system. EX7750 O REBOOT THE 1. Make sure the EX7750 is not receiving, processing, or printing a job. Make sure the status message on the Control Panel reads Idle.
Page 198: Shutting Down The Ex7750
7-24 Administering the EX7750 Shutting down the EX7750 You may need to shut down the EX7750 for service. When you do so, fonts downloaded to the hard disk are not deleted. Print jobs in the Hold and Printed queues and jobs that have been processed but not printed are not deleted and are available for printing when you restart the EX7750.
Page 199: Appendix A: Troubleshooting
A-1 Troubleshooting This chapter provides troubleshooting tips. Appendix A: Troubleshooting Troubleshooting the EX7750 Startup diagnostics are described in the Installation and Service Guide for service technicians. Contact your authorized service/support center if you see any startup error messages on Command WorkStation or if the EX7750 does not reach the Idle state. Troubleshooting during Setup from the Control Panel The following section explains some error and alert messages you may see during Setup that may not be self-explanatory.
Page 200 A-2 Troubleshooting After this Setup screen This message Means Enable NDS No NDS trees found. No NDS trees were found on the Novell network. Check to see that the frame types on the EX7750 are (Network Setup>Service properly conﬁgured. Setup >PServer Setup >NDS Setup) Select NDS Tree Warning! Selecting a new...
Page 201 A-3 Troubleshooting After this Setup screen This message Means Enter First Letters File server name not found. No ﬁle server with those letters was found when EX7750 of Server Name Try again? queried the network. Check the name of the NetWare ﬁle server, check cable connections, and make sure the (Network Setup>Service NetWare server is turned on.
Page 202 A-4 Troubleshooting If the selected NetWare ﬁle server or tree does not have a guest account, or if the guest account has expired or been disabled by the NetWare supervisor, you will be prompted to notify the IPX (Novell) administrator. In that case, there are two options: •...
Page 203 A-5 Troubleshooting Novell error Cause Suggested action or exit The server has connected to a ﬁle server, Select a different login account or print server. but is unable to log in to the ﬁle server Unable to log in The error screen exits to the File Server Login or print server because the password has to server.
Page 204: Runtime Error Messages
A-6 Troubleshooting Runtime error messages For error messages related to canceling jobs and printing, including the Disk Full message and alerts to load media, see the Job Management Guide. These messages are reported by the job management tools. You can turn on PostScript error reporting as a print option from Mac OS applications.
Page 205 A-7 Troubleshooting See the following table for the appropriate name. In this location For this item IPX/SPX networks TCP/IP networks Server Setup Server Name option Administrator Administrator page 4-13 deﬁnes name deﬁnes name Windows 2000 hosts ﬁle host name — DNS name page 2-1 (TCP/IP host name)
Page 206 A-8 Troubleshooting Cannot connect to EX7750 with Fiery utilities If users cannot connect to the EX7750, check the following: • EX7750 Setup—the appropriate network protocol must be enabled, with the correct parameters (for example, for TCP/IP, the IP address), and you must publish either the Print queue or Hold queue.
Page 207: Test E-Mail
A-9 Troubleshooting • Check the conﬁguration of the connection and modify it, if necessary, or delete the Eﬁnl.ini ﬁle and start over with the process of conﬁguring the connection as described in the User Software Installation Guide. For Windows 2000/XP, the Eﬁnl.ini ﬁle is located in \WINNT. To ﬁnd the Efnl.ini ﬁle on Mac OS X, perform a search.
Page 208 This page is intentionally blank.
Page 209 Index Index Numerics Alert Status screen 4-5 Allow Courier Substitution 1000BaseT connector 1-12 option 4-47, 5-43 100BaseT connector 1-12 AppleTalk 1-6 10BaseT connector 1-12 color server name 4-13, 5-5 8-pin RJ-45 connector 1-12 network diagram 1-6 protocol setup 4-18, 5-10 access level scenarios 3-6, 3-7 AppleTalk Setup access to network and software 3-1...
Page 210 I-2 Index Color Mode option 5-42 color server 1-11 Calibration command, from the Control back view showing connectors 1-11 Panel 4-9 Control Panel 4-2 Cancel Job display window 4-2 from the Control Panel during maintaining and improving printing 4-5 performance 7-18 from the Control Panel during naming 4-13, 5-5 RIPping 4-5...
Page 211 I-3 Index connected Novell servers, Bindery 4-34, 5-27 date, setting 4-13, 5-6 connecting Daylight Saving option 4-14 copier interface cable 3-11 Default Orientation option 4-48, 5-44 network cable 1-11 delete symbol, in Setup display 4-11 to a Bindery ﬁle server 4-32, 4-33 destination, Fiery WebLink 6-3 to multiple Bindery ﬁle servers 4-31 device...
Page 212 I-4 Index Enable E-mail Services option 4-40 Ethernet 1-12 Enable Email Services option 5-38 frame types 5-12 Enable Ethernet option 4-18, 5-9 network 2-8 Enable IPP option 4-39, 5-36 Port Setup 4-18 Enable LPD option 4-25, 5-16 Ethernet Setup from Control Panel 4-17 Enable NDS option 4-26, 5-17, 5-21 Ethernet Speed 4-18 Enable PCL option 4-48, 5-44...
Page 213 I-5 Index fonts IP address printer fonts on server 4-7 assigning automatically 4-20 printing font list 4-7 for Ethernet Setup 4-21 Form Length option 4-48, 5-44 required for TCP/IP printing 2-17 frame types supported IPP Setup 4-39 AppleTalk 4-23 IPX (Novell) 2-8 to 2-14 IPX/SPX, Ethernet 4-23, 5-12 Bindery ﬁle server, connecting 4-30 TCP/IP 4-23...
Page 214 I-6 Index NDS tree browsing 4-26, 4-27, 5-17 LCD 4-3 browsing to print queue root 4-29 LED 7-19 browsing to Print Server 4-28 line selection buttons 4-4 browsing to User Login object 4-27 local Setup password 4-27 exiting 5-50 NetWare Log Off Windows command, from Bindery and NDS on the same FieryBar 7-20...
Page 215 I-7 Index Network Setup 3-9 Point and Print Drivers option 4-37 exiting 4-17 Polling Interval from Control Panel 4-16 to 4-44 E-mail Setup 5-39 from Windows computer 5-8 to 5-37 polling interval for NetWare print part of initial Setup 5-1 jobs 4-36, 5-32 troubleshooting A-3 Polling Interval option, E-mail Setup 4-42...
Page 216 I-8 Index Printer Setup 3-9 PServer Setup 5-16 from Control Panel 4-44 options 4-25 from Windows computer 5-41 Publish Direct Connection part of initial Setup 5-1 option 4-45, 5-41 Printed queue options 5-6 Publish Hold Queue option 4-45, 5-41 printing Publish Print Queue option 4-45, 5-41 Conﬁguration page 4-7 publishing connections, overview 3-1...
Page 217 I-9 Index See also Server Setup, Network Setup, Printer Setup, PS Setup, Color Setup, safety 4-3 Job Log Setup Save Changes Setup Fiery command, from FieryBar 7-20 Color Setup, Control Panel 4-53 Setup from Control Panel Job Log Setup, Control Panel 4-55 accessing 4-2 Network Setup, Control administrative functions 4-54...
Page 218 I-10 Index system software troubleshooting description 7-6 Command WorkStation connection installing 7-10 problems A-8 restoring backup of 7-7 connection to printer fails A-6 System Time option 4-14, 5-6 Printer not found in the selection list of Fiery utilities A-8 Printer not found—TCP/IP or IPX TCP/IP networks A-6 adding server to network 2-3...
Page 219 I-11 Index warning display window breakage 4-3 Web Services Setup 4-38, 5-36 WebDownloader, see Fiery WebDownloader WebLink, see Fiery WebLink WebSetup, see Fiery WebSetup WebTools 6-1 to 6-2 enabling 4-38, 4-39, 5-36 enabling only certain WebTools 6-2 Installer 3-5 listed 3-4 setting up 6-2 Status 3-4 Windows 2000...
Page 220 This page is intentionally blank.
