SHINDAIWA OWNER'S/OPERATOR'S MANUAL
SHINDAIWA OWNER'S/OPERATOR'S MANUAL
EB633RT BLOWER
EB633RT BLOWER
WARNING!
WARNING!
Minimize the risk of injury to yourself and others!
Read this manual and familiarize yourself with the contents. Always
wear eye and hearing protection when operating this unit.
Minimize the risk of injury to yourself and others!
Read this manual and familiarize yourself with the
contents. Always wear eye and hearing protection
when operating this unit.
Part Number 82050 Rev. 6

Advertisement

Table of Contents
loading

Related Manuals for Shindaiwa EB633RT

Summary of Contents for Shindaiwa EB633RT

  • Page 1 English....1 Spanish..SP_1 French..FR_1 SHINDAIWA OWNER’S/OPERATOR’S MANUAL SHINDAIWA OWNER’S/OPERATOR’S MANUAL EB633RT BLOWER EB633RT BLOWER Minimize the risk of injury to yourself and others! Read this manual and familiarize yourself with the contents. Always wear eye and hearing protection WARNING! WARNING! when operating this unit.

  • Page 2: Table Of Contents

    Shindaiwa engines represent the leading edge of high-performance engine technology, and deliver exceptionally high power at remarkably low displacement and weight. As an owner/operator, you’ll soon discover why Shindaiwa is simply in a class by itself.

  • Page 3: Safety

    afeTy manual safeTy symbols and ImporTanT InformaTIon Throughout this manual and on the product itself, you will find safety alerts and helpful, informational messages preceded by symbols or key words. The following is an explanation of those symbols and key words and what they mean to you.
  • Page 4 To reduce the risk of serious or fatal injury, persons with pacemakers should consult with their physician and the pacemaker manufacturer before operating this machine. In the absence of such information, Shindaiwa does not recommend the use of Shindaiwa products by anyone who has a pacemaker. Vibration and Cold It is believed that a condition called Raynaud’s Phenomenon, which affects the fingers of certain individuals, may...
  • Page 5 Repetitive Stress Injuries It is believed that overusing the muscles and tendons of the fingers, hands, arms, and shoulders may cause soreness, swelling, numbness, weakness, and extreme pain in those areas. Certain repetitive hand activities may put you at a high risk for developing a Repetitive Stress Injury (RSI).

  • Page 6: Equipment

    Use only Shindaiwa attachments. Serious injury may result from the use of a non-approved attachment combination. ECHO, INC. will not be responsible for the failure of cutting devices, attachments or accessories which have not been tested and approved by Shindaiwa. Read and comply with all safety instructions listed in this manual and safety manual.

  • Page 7: Description

    Locate these safety decals on your unit. Make sure the decals are legible and that you understand and follow the instruc- tions on them. If a decal cannot be read, a new one can be ordered from your Shindaiwa dealer.

  • Page 8: Contents

    AIR CLEANER - Contains replaceable air filter element. AIR CLEANER - Contains replaceable air filter element. SPARK PLUG - Provides spark to ignite fuel mixture. SPARK PLUG - Provides spark to ignite fuel mixture. SAFETY DECAL - Lists important safety precautions. SAFETY DECAL - Lists important safety precautions.

  • Page 9: Assembly

    ssembly WARNING Never perform maintenance or assembly procedures with engine running or serious personal injury may result. InsTall blower pIpes 1. Assemble clamps (A) and (G) onto both ends of flexible pipe (B). NOTE Clamp with cable guide loop (G) fits elbow end of flexible pipe.

  • Page 10: Operation

    WARNING Diesel fuels and alternative fuels, such as E15 (15% ethanol), E85 (85% ethanol) or any fuels not meeting Shindaiwa requirements are NOT approved for use in Shindaiwa 2-stroke or hybrid 4-stroke gasoline engines. Use of diesel or alternative fuels may cause performance problems, loss of power, overheating, fuel vapor lock, and unintended machine operation, including, but not limited to, improper clutch engagement.

  • Page 11: Handling Fuel

    Handling Fuel dANGeR Fuel is VERY flammable. Use extreme care when mixing, storing or handling or serious personal injury may result. • Use an approved fuel container. • DO NOT smoke near fuel. • DO NOT allow flames or sparks near fuel. •...
  • Page 12 Filling the fuel tank 1. Place the unit on a flat, level surface. 2. Clear any dirt or other debris from around the fuel filler cap. CAUTION! Slowly remove the fuel cap only after stopping the engine. 3. Remove the fuel cap (A), and fill the fuel tank with clean, fresh fuel. Do not fill above bottom of fuel tank neck (B).

  • Page 13: Starting Cold Engine

    After use Stored fuel ages. Do not mix more fuel than you expect to use in IMPORTANT thirty (30) days, ninety (90) days when a fuel stabilizer is added. • DO NOT store a unit with fuel in its tank. Leaks can occur. Return thirty (30) days, ninety (90) days when a fuel stabilizer is added.

  • Page 14: Starting Warm Engine

    - COLD START position - to stall engine. Have your Slide stop switch (B) to Stop position. Slide stop switch (B) to Stop position. Shindaiwa dealer repair stop switch before using blower again. WarnInG WarnInG If engine does not stop when stop switch is moved to STOP position, If engine does not stop when stop switch is moved to STOP position, close choke - COLD START position - to stall engine.

  • Page 15: Operating Blower

    operaTIng blower WARNING Engine exhaust IS HOT, and contains Carbon Monoxide (CO), a poison gas. Breathing CO can cause unconscious- ness, serious injury, or death. Exhaust can cause serious burns. ALWAYS blow exhaust away from your face and body. WARNING Always wear safety glasses, hearing protection, a face filter mask and take all safety precautions or serious personal injury may result.

  • Page 16: Maintenance

    aInTenanCe WARNING Moving parts can amputate fingers or cause severe injuries. Keep hands, clothing and loose objects away from all openings. Always stop engine, disconnect spark plug, and make sure all moving parts have come to a complete stop before removing obstructions, clearing debris, or servicing unit. Wear gloves to protect hands from sharp edges and hot surfaces.

  • Page 17: Air Filter

    aIr fIlTer aIr fIlTer Level 1. Level 1. Tools required: 25 - 50mm (1 - 2 in.) cleaning brush Parts Required: Air Filter NOTE Always brush dirt and debris away from air cleaner area prior to NOTE cleaning air filter. Always brush dirt and debris away from air cleaner area prior to cleaning air filter.

  • Page 18: Spark Plug

    fuel fIlTer Level 1. Tools required: 200 - 250 mm (8 - 10 in.) length of wire with one end bent into a hook, clean rag, funnel, and an approved fuel container fuel fIlTer DANGer Level 1. Fuel is VERY flammable. Use extreme care when mixing, storing or handling.

  • Page 19: Cooling System

    CoolInG sysTem Level 2. CoolIng sysTem Tools required: 25 - 50mm (1 - 2 in.) cleaning brush, Cross Head Screwdriver Level 2. Parts Required: None, if you are careful. Parts Required: None, if you are careful. IMPORTANT To maintain proper engine operating temperatures, cooling air must IMPORTANT pass freely through the cylinder fin area.

  • Page 20: Exhaust System

    The cylinder exhaust port must be inspected and cleaned of excess carbon every 3 months or 90 hours of operation in order to main- tain this engine within the emissions durability period. Shindaiwa strongly recommends that you return your unit to your Shindaiwa dealer for this important maintenance service.

  • Page 21: Carburetor Adjustment

    (ASL) (96.0 kPa). To maintain proper engine operation and emission compliance above 1,100 feet ASL the carburetor may need to be adjusted by an authorized Shindaiwa service dealer. IMPORTANT If the engine is adjusted for operation above 1,100 feet ASL, the carburetor must be re-adjusted when operating the engine below 1,100 feet ASL, otherwise severe engine damage may result.
  • Page 22 This engine has been factory adjusted to maintain satisfactory start- ing, emission, and durability performance up to 1,000 feet above mean Level 2. sea level (MSL). To maintain proper engine operation above 1,000 feet MSL the carburetor must be adjusted by an authorized Shindaiwa service dealer. Parts required: None.

  • Page 23: Troubleshooting

    Shindaiwa dealer i l y i l y Shindaiwa dealer f f u r e l h t i c i r t l i f s t r Shindaiwa dealer t ' n i r t...

  • Page 24: Storage

    Torage WARNING During operation the muffler or catalytic muffler and surrounding cover become hot. Always keep exhaust area clear of flammable debris during transportation or when storing, otherwise serious property damage or personal injury may result. Long Term Storage (Over 30 Days) Do not store your unit for a prolonged period of time (30 days or longer) without performing protective storage mainte- nance which includes the following: 1.

  • Page 25: Specifications

    Exhaust System -------------------------------------------- Spark arrestor muffler or spark arrestor muffler with catalyst Fuel ---------------------------------------------------------- Mixed (Gasoline and Two-stroke Oil) Fuel/Oil Ratio ---------------------------------------------- 50:1 Shindaiwa Red Armor® ISO-L-EGD (ISO/CD 13738) and J.A.S.O. M345- FD, two-stroke, air-cooled engine oil. Gasoline ----------------------------------------------------- Use 89 Octane unleaded. Do not use fuel containing methyl alcohol, more than 10% ethyl alcohol or 15% MTBE.
  • Page 26 The owner shall demonstrate reasonable care and use, and follow preventative maintenance, storage, fuel and oil usage as pre- scribed in the operator’s manual. Should a product difficulty occur, you must, at your expense, deliver or ship your Shindaiwa unit to an authorized Shindaiwa servicing dealer for warranty repairs (within the applicable warranty period), and arrange for pick-up or return of your unit after the repairs have been made.

  • Page 27: Warranty Statement

    89 octane or higher. Gasohol which contains a maximum 10% ethanol (grain alcohol) or 15% MTBE (methyl/tertiary/butyl/ether) is also approved. The prescribed mixing ratio of gasoline to oil is listed on the Shindaiwa oil label and covered in your operator’s manual.
  • Page 28 noTes...

  • Page 29: Product Registration

    Thank you for choosing shindaiwa Power equipment Please go to http://www.shindaiwa-usa.com to register your new product on-line. It's FAST and EASY! NOTE: your information will never be sold or misused by ECHO, Inc. Registering your purchase enables us to contact you in the unlikely event of a service update or product recall, and verifies your ownership for warranty consideration.
  • Page 30 noTes...
  • Page 31 noTes...

  • Page 32: Servicing Information

    Service of this product during the warranty period must be performed by an Authorized SHINDAIWA Service Dealer. For the name and address of the Authorized SHINDAIWA Service Dealer nearest you, ask your retailer or call: 1-877- 986-7783. Dealer information is also available on WWW.SHINDAIWA-USA.COM. When presenting your unit for War- ranty service/repairs, proof of purchase is required.
