Hardware Description
Charge Status LEDs
Each charger channel has a row of LEDs that illuminate to indicate the microphone battery charge level:
LED
1
2
3
4
5
NCS Energy Efficient Mode
Operate the charger in a low-energy mode to reduce power consumption. In this mode, only one LED indicator illuminates
per channel after powering on.
To change to the mode:
1. Open the MXW control software to the Utility page.
2. Open the Device Properties window for the charging station.
3. Select the Energy Efficient Mode check-box.
USB Charger
The USB Charger (SBC-USB) can connect to an MXW transmitter to provide power during operation.
27
1 2 3 4 5
% Battery Charge
• Flashing: <10%
• Solid: >10%
>25%
>50%
>75%
>95%
