T-4355
Instruction Manual
Thank you for purchasing an Onkyo AM/FM Tuner.
Please read this manual thoroughly before making
connections and plugging in the unit.
Following the instructions in this manual will enable
you to obtain optimum performance and listening
enjoyment from your new Tuner.
Please retain this manual for future reference.
Contents
Introduction .................................... 2
Connections ................................. 10
Enjoying Audio Sources.............. 14
Troubleshooting ........................... 20
Specifications .............................. 21
E
n
Advertisement
Table of Contents
Related Manuals for Onkyo T-4355
Summary of Contents for Onkyo T-4355
-
Page 1: Instruction Manual
AM/FM Tuner T-4355 Instruction Manual Thank you for purchasing an Onkyo AM/FM Tuner. Please read this manual thoroughly before making connections and plugging in the unit. Following the instructions in this manual will enable you to obtain optimum performance and listening enjoyment from your new Tuner. -
Page 2: Important Safety Instructions
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR MOISTURE. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING QUALIFIED PERSONNEL. -
Page 3: Precautions
5. Never Touch this Unit with Wet Hands—Never handle this unit or its power cord while your hands are wet or damp. If water or any other liquid gets inside this unit, have it checked by your Onkyo dealer. 6. Handling Notes •... -
Page 4: Features
Indoor FM antenna AM loop antenna In catalogs and on packaging, the letter added to the end of the product name indicates the color of the T-4355. Specifications and operation are the same regardless of color. Before Using this Unit •... -
Page 5: Table Of Contents
Connecting the AM Loop Antenna...12 Connecting an Outdoor FM Antenna...13 Connecting an Outdoor AM Antenna...13 Enjoying Audio Sources Turning On the T-4355 ...14 Listening to the Radio...14 Tuning into Radio Stations Manually ...14 Presetting All Stations Automatically (Auto Preset)...15 Presetting Stations Manually ...15 Selecting Preset Stations ...16... -
Page 6: Front & Rear Panels
Front & Rear Panels Front Panel For detailed information, refer to the pages in parentheses. POWER switch (14) This switch is used to turn on/off the T-4355. DISPLAY button (18) This button is used to view various information on the display. -
Page 7: Display
(Remote Interactive) jacks can be connected to the jacks on your other Onkyo components for interactive control. To use , the T-4355 must be connected with an and an audio cable. AM ANTENNA (12) These push terminals are for connecting the sup- plied AM loop antenna or an outdoor AM antenna. -
Page 8: Remote Controller
TUNER, these buttons can be used to tune into stations. * Any remote controller for Onkyo amplifier is avail- able to control T-4355 in a condition of the tion. (On some remote controllers, some buttons shown in the figure are missing. The corresponding functions cannot be controlled by the remote controller.) -
Page 9: Using The Remote Controller
Remote Controller—Continued Using the Remote Controller The T-4355 doesn’t have its own remote controller, but it can be controlled by using the RC-627S remote con- troller that’s supplied with the Onkyo A-9355/A-9155 Integrated Amplifier. The T-4355 and A-9355/A-9155 must be connected with an cable and an audio cable for this to work. -
Page 10: Connections
, you must make an audio connection between the T-4355 and the other component. • Use only dedicated cables for • If the T-4355 is used with another Onkyo component, such as the A-9355/A-9155, refer to its instruction manual as well. RCA Audio Connection Color Coding •... -
Page 11: About The System Functions
When you select a radio preset or change the band (AM, FM), your Onkyo amplifier will automatically select the T-4355 as the input source. Remote Control Operation You can control the T-4355 by using your Onkyo ampli- fier’s remote controller. See the amplifier’s instruction manual for details. With... -
Page 12: Connecting Antennas
Attach the FM antenna, as shown. Insert the plug fully into the jack. Once your T-4355 is ready for use, you’ll need to tune into an FM radio station and adjust the posi- tion of the FM antenna to achieve the best possi- ble reception. -
Page 13: Connecting An Outdoor Fm Antenna
If circumstances demand it, use a TV/FM antenna split- ter, as shown. TV/FM antenna splitter To T-4355 Connecting an Outdoor AM Antenna If good reception cannot be achieved using the supplied AM loop antenna, an outdoor AM antenna can be used in addition to the loop antenna, as shown. -
Page 14: Turning On The T-4355
A-9355/A-9155) If you’re using the T-4355 together with the A-9355/A-9155 Onkyo amplifier, press the remote con- troller’s [ON] button to turn on the T-4355 and A-9355/A-9155. (Plug the T-4355 power cord into the A-9355/A-9155 AC OUTLET.) Memory backup... -
Page 15: Presetting All Stations Automatically (Auto Preset)
When a station is found, auto tuning stops and the lights up. Starting at the bottom of the frequency band, the T-4355 automatically tunes and stores up to 20 FM stations, then up to 10 AM stations. Note: Depending on your location, a preset may be stored with no station and you’ll hear only noise when you... -
Page 16: Selecting Preset Stations
MEM indicator The MEM indicator appears and the preset number flashes. If you don’t complete the next step within 8 sec- onds, the T-4355 will return to the pre- vious condition and the MEM indicator will disappear. Note: Be careful not to press the [MEM- ORY] button for too long because “AUTO PRESET”... -
Page 17: Naming Presets
Listening to the Radio—Continued Naming Presets Radio presets can be named for easy identification, and names may contain up to 8 characters from the follow- ing selection. _ A B C D E F G H I J K L M N O P Q R S T U V W X Y Z a b c d e f g h i j k l m n o p q r s t u v w x y z "... -
Page 18: Deleting Presets
The preset number on the display dis- appears and the preset is deleted. CLEAR Displaying Information By pressing the T-4355’s [DISPLAY] button repeatedly, you can view the tuning frequency or text (preset name or RDS). Frequency Text (preset name or RDS) Note: If the current preset doesn’t have a name, no text will be... -
Page 19: Using Rds (European Models Only)
RDS stands for Radio Data System and is a method of transmitting data in FM radio signals. Many FM sta- tions use it these days. The T-4355 supports the following types of RDS data: PS: Program Service Name When tuned to an RDS station that’s broadcasting PS information, the station’s name appears on the display. -
Page 20: Troubleshooting
Troubleshooting If you have any trouble using the T-4355, look for a solution here. If you can’t resolve the issue yourself, contact your Onkyo dealer. Power Can’t turn on the T-4355. • Make sure that the power cord is properly plugged into the wall outlet (page 14). -
Page 21: Specifications
Specifications Tuning frequency range: Usable sensitivity: SN ratio: THD (total harmonic distortion): Frequency response: Stereo separation: Tuning frequency range: Usable sensitivity: SN ratio: THD (total harmonic distortion): General Power supply: Power consumption: Dimensions (W H D): Weight: Specifications and features are subject to change without notice. 87.50–108.00 MHz Stereo: 17.2 dBf 2.0 µV (75 IHF) Mono: 11.2 dBf 1.0 µV (75 IHF) - Page 22 Memo...
