Zero Turn Radius Mowers
All models

Loose Parts

Use the chart below to verify that all parts have been shipped.
Procedure
7
8
9
Note: Determine the left and right sides of the machine from the normal operating position.
1

Checking Tire Pressure

No Parts Required
Procedure
1. Check the tire pressure in the drive tires. Proper
inflation for drive tires is 13 psi (90 kPa).
2. Adjust if necessary.
2
Fastening the Seat
No Parts Required
Procedure
1. Remove the nut and bolt from the loose end of the
lanyard.
Printed in the USA.
Description
Deflector assembly
Rod
Spring
Cotter pin
Side discharge baffle
Carriage bolt (5/16 x 3/4 inch)
Hex-head bolt (5/16 x 3/4 inch)
Lock nut (5/16 inch)
Hole cover decal
Ignition Key
Hose coupling
Operator's Manual
Engine Operator's Manual
Operator Training Material
Original Instructions (EN)
Qty.
1
1
Install the discharge deflector.
1
1
1
2
2
Convert to side discharge (optional).
4
3
1
1
1
Complete the setup.
1
1
2. Tilt seat downward and align lanyard to the hole in
the side of the seat (see Figure 1).
3. Install bolt and nut. Tighten bolt and then loosen
nut 1/4-1/2 turn so that lanyard end rotates freely.
Verify that lanyard is free to rotate on both ends so
that it pulls straight while supporting the seat..
Form No. 3360-101 Rev A
Setup Instructions
Use
All Rights Reserved
