P/N 900464-01
Rev. A 01/2016
DANGER
WARNING: No not store gasoline or other fl ammable vapors and liquids in the vicinity of this or any other
appliance. An LP-cylinder not connected for use shall not be stored in the vicinity of this or any other appliance.
WARNING: Improper installation, adjustment, alteration, service or maintenance can cause injury or
property damage. Read the installation, operating and maintenance instructions thoroughly before install-
ing or servicing this equipment.
WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could result in serious injury, death, or property damage.
- Do not store or use gasoline or other fl ammable vapors and liquids in the vicinity of this or any other appli-
ance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Leave the building immediately.
• Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fi re department.
- Installation and service must be performed by a qualifi ed installer, service agency or the gas supplier.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
PFS
®
US
Report No. 10-87
WHEN USED AS AN OUTDOOR APPLIANCE
CARBON MONOXIDE WARNING
•
This appliance can produce carbon
monoxide which has no odor.
•
Using it in an enclosed space can
kill you.
•
Never use this appliance in an en-
closed space such as a camper, tent,
car or home.
WHEN USED AS INDOOR VENTED APPLIANCE
Installation and Operation Instructions
®
Superior
Vented Gas Log and Burner Set
Models
MNF24ONE
MNF24OPE
For use with log sets
LMF24GTA/B
LMF30GTA/B
LMF36GTA/B
WARNING: For Outdoor Use Only.
DANGER
IF YOU SMELL GAS:
1. Shut off gas to appliance.
2. Extinguish any open fl ame.
3. If odor continues, keep away from the
appliance and immediately call your gas
supplier or fi re department.
MNF30ONE
MNF30OPE
LMF24MOA/B
LMF30MOA/B
LMF36MOA/B
P900464-01
Advertisement
Table of Contents
Related Manuals for Superior MNF24ONE
Summary of Contents for Superior MNF24ONE
- Page 1 Installation and Operation Instructions ® Superior Vented Gas Log and Burner Set P/N 900464-01 Rev. A 01/2016 Models MNF24ONE MNF24OPE MNF30ONE MNF30OPE For use with log sets LMF24GTA/B LMF24MOA/B ® LMF30GTA/B LMF30MOA/B LMF36GTA/B LMF36MOA/B Report No. 10-87 WHEN USED AS AN OUTDOOR APPLIANCE WARNING: For Outdoor Use Only.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety ..................2 Specifi cations ..............16 Product Identifi cation ............3 Wiring Diagram ..............17 Local Codes.................4 Troubleshooting ..............18 Unpacking................4 Accessories ...............21 Product Features ..............4 Parts ..................22 Installation ................4 Replacement Parts ............26 Operation ................14 Service Hints ..............26 Inspecting Burners.............15 Technical Service...............26 Cleaning and Maintenance ..........16 Warranty ................27 SAFETY... -
Page 3: Product Identifi Cation
SAFETY Continued 1. This appliance is only for use with the type of gas indicated 15.This appliances must not be connected to any external on the rating plate. This appliance is not convertible for use electrical source. with other gases. 16.Operating appliance above elevations of 4,500 feet may 2. -
Page 4: Local Codes
INSTALLATION LOCAL CODES Install and use appliance with care. Follow all local codes. WARNING: A qualifi ed service person must In the absence of local codes, use the latest edition of The install appliance. Follow all local codes. National Fuel Gas Code, ANSI Z223.1/NFPA 54*. *Available from: NOTICE: State or local codes may only allow American National Standards Institute, Inc. - Page 5 INSTALLATION Continued MINIMUM FIREPLACE CLEARANCE TO COMBUSTIBLE Minimum Noncombustible Material Clearances MATERIALS If Not Using Mantel Side Wall 16", Ceiling 42" NOTE: If using a mantel proceed to If Using Mantel. If not Floor 5", Front: 36" using a mantel, follow these instructions. You must have noncombustible material(s) above the fi...
- Page 6 INSTALLATION Continued MANTEL CLEARANCES NOTICE: Surface temperatures of adjacent In addition to meeting noncombustible material clearances, walls and mantels become hot during opera- you must also meet required clearances between fi replace tion. Walls and mantels above the fi rebox may opening and mantel shelf.
- Page 7 INSTALLATION Continued For Massachusetts Residents Only: Installation of this gas Chimney Height Minimum Permanent Flue Opening log set as a vented indoor appliance in the Commonwealth of Massachusetts requires the damper be permanently removed 6' to 15' 39 sq. inches or welded in the fully open position.
- Page 8 INSTALLATION Continued Masonry Screw optional equipment shutoff valve from your dealer. For propane/LP units, the installer must supply an external regulator. The external regulator will reduce incoming gas pressure. You must reduce incoming gas pressure to between 11" and 14" of water. If you do not reduce incoming gas pres- sure, appliance regulator damage could occur.
- Page 9 INSTALLATION Continued Equipment Shutoff Valve PROPANE/LP 2. Cap off open end of gas pipe where equipment shutoff With 1/8" NPT Tap* From External valve was connected. Regulator 3. Pressurize supply piping system by either opening pro- Approved Flexible (11" W.C.** pane/LP supply tank valve for propane/LP gas or opening Gas Hose (if allowed to 14"...
- Page 10 Figure 16 - Installing Right Front Log 3. Replace battery cover onto remote control. MF SERIES BURNER SYSTEM LOG COMPATIBILITY CHART Burner System Model Refractory Concrete Logs For Use With This Burner System LMF24GTA/B MNF24ONE LMF30GTA/B MNF24OPE LMF24MOA/B LMF30MOA/B MNF30ONE LMF36GTA/B MNF30OPE LMF36MOA/B SuperiorFireplaces.us.com...
- Page 11 INSTALLATION Continued Round Tube 2. Find the back left log (LMF24GTA/B or LMF24MOA/B mod- Burner els: D-060, LMF30GTA/B or LMF30MOA/B models: D-018, LMF36GTA/B or LMF36MOA/B models: D-026). See Fig- ures 17, 17A, and 17B. Figure 17A shows how the log must fi...
- Page 12 INSTALLATION Continued 3. Find the front left log (LMF24GTA/B or LMF24MOA/B mod- 4. Find the charred log (D-020). See Figures 19, 19A, and els: D-059, LMF30GTA/B or LMF30MOA/B models: D-017, 19B. The log has a slot in the bottom that fi ts over the LMF36GTA/B or LMF36MOA/B models: D-025).
- Page 13 INSTALLATION Continued Square Peg Right Split Crossover 5. Find the middle split log (LMF24GTA/B or LMF24MOA/B Log (D-022) models: D-063, LMF30GTA/B or LMF30MOA/B models: D-021, LMF36GTA/B or LMF36MOA/B models: D-028). See Figures 20 and 20A. The split side of the log faces forward.
-
Page 14: Operation
INSTALLATION OPERATION Continued FOR YOUR SAFETY Back Top Log (D-062, READ BEFORE LIGHTING D-023 or D-029) Right Split Crossover WARNING: If you do not follow these instruc- Log (D-022) tions exactly, a fi re or explosion may result causing property damage, personal injury or loss of life. -
Page 15: Inspecting Burners
OPERATION INSPECTING BURNERS Continued Check burner fl ame patterns often. IGNITER ASSEMBLY The igniter assembly is factory preset for proper ignition of Incoming the burner. Alterations may have occurred during shipping Gas Line Equipment and handling. Call a qualifi ed service person to readjust the Shutoff Valve igniter assembly if necessary. -
Page 16: Cleaning And Maintenance
SPECIFICATIONS by a qualifi ed service person. We also recommend that you keep the burner tube clean and MNF24ONE AND MNF30ONE free of dust and dirt. To clean these parts we recommend using • Rating (Variable): 29,000/40,000 Btu/Hr compressed air no greater than 30 PSI. Your local computer •... -
Page 17: Wiring Diagram
WIRING DIAGRAM Green Orange White Orange Igniter HI/LO Pilot Solenoid Black AF-4000 AF-5000MOD Main Control Module AF-4000B/P Black Orange Brown Black Black (GND) Brown Brown These wires are not used on this application Black SuperiorFireplaces.us.com 900464-01A... -
Page 18: Troubleshooting
TROUBLESHOOTING WARNING: Turn off appliance and let cool before servicing. Only a qualifi ed service person should service and repair appliance. NOTE: All troubleshooting items are listed in order of operation. OBSERVED PROBLEM POSSIBLE CAUSE REMEDY When ''ON'' button on remote con- 1. - Page 19 TROUBLESHOOTING Continued OBSERVED PROBLEM POSSIBLE CAUSE REMEDY Delayed ignition of burner 1. Manifold pressure is too low 1. Contact local natural or propane/ LP gas company 2. Burner orifi ce clogged 2. Clean burner (see Cleaning and Maintenance, Page 16) or replace burner orifi...
- Page 20 TROUBLESHOOTING Continued WARNING: If you smell gas • Shut off gas supply. • Do not try to light any appliance. • Do not touch any electrical switch; do not use any phone in your building. • Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instruc- tions.
-
Page 21: Accessories
ACCESSORIES Purchase these appliance accessories from your local dealer. DAMPER CLAMP If they can not supply these accessories, contact IHP at Su- Cat No. F1760, Model GA6080 periorFireplaces.US.com for referral information. You can For all models. Permanently opens chimney fl ue damper for also write to the address listed on the back of this manual. -
Page 22: Parts
PARTS MODELS MNF24ONE, MNF24OPE, MNF30ONE AND MNF30OPE Cat. No. Model F2123 MNF24ONE F2125 MNF24OPE F2127 MNF30ONE F2129 MNF30OPE SuperiorFireplaces.us.com 900464-01A... - Page 23 PARTS MNF24ONE, MNF24OPE, MNF30ONE AND MNF30OPE This list contains replaceable parts used in your appliance. When ordering parts, follow the instructions listed under Replace- ment Parts on Page 26 of this manual. Only kits supplied by IHP shall be used in the installation of this appliance. Use of non-approved accessory/part kit(s) can result in poor performance and safety hazards.
- Page 24 PARTS LOG SET MODELS LMF24GTA/B, LMF30GTA/B AND LMF36GTA/B This list contains replaceable parts used in your appliance. When ordering parts, follow the instructions listed under Re- placement Parts on Page 26 of this manual. LMF24MOA/B LMF30MOA/B LMF36MOA/B CAT. NO. Log Id. # CAT.
- Page 25 PARTS LOG SET MODELS LMF24MOA/B, LMF30MOA/B, AND LMF36MOA/B This list contains replaceable parts used in your appliance. When ordering parts, follow the instructions listed under Replacement Parts on Page 26 of this manual. LMF24MOA/B LMF30MOA/B LMF36MOA/B CAT. NO. LOG ID NO. CAT.
-
Page 26: Replacement Parts
REPLACEMENT PARTS See Pages 22-24 for a complete replacement parts list. Use 1. The model number of the appliance. only parts supplied from the manufacturer. 2. The serial number of the appliance. 3. The part number. Normally, all parts should be ordered through your IHP dis- 4. -
Page 27: Warranty
Brand Gas Log Set Limited Three Year Warranty THE WARRANTY Innovative Hearth Products Limited Three Year Warranty ("IHP") warrants your Superior ® brand Gas Log Set ("Product") to be free from defects in materials and workmanship at the time of manufacture. The logs and grate carry the Limited Three Year Warranty. After installation, if covered components manufactured by IHP are found to be defec- tive in materials or workmanship during the Limited Three Year Warranty period and while the Product remains at the site of the original installation, IHP will, at its option, repair or replace the covered components. - Page 28 SuperiorFireplaces.US.com Record the following important information about your appliance: Appliance model number Appliance serial number Date appliance was Installed Type of gas appliance uses Dealer name IHP reserves the right to make changes at any time, without notice, in design, materials, specifi...
