Related Manuals for Samsung MS23J5133A series

Summary of Contents for Samsung MS23J5133A series

  • Page 1 QUESTIONS OR COMMENTS COUNTRY CALL OR VISIT US ONLINE AT AUSTRIA 0800 - SAMSUNG (0800 - 7267864) www.samsung.com/at/support www.samsung.com/be/support (Dutch) BELGIUM 02-201-24-18 www.samsung.com/be_fr/support (French) DENMARK 70 70 19 70 www.samsung.com/dk/support FINLAND 030-6227 515 www.samsung.com/fi/support FRANCE 01 48 63 00 00 www.samsung.com/fr/support...

  • Page 2: Microwave Oven

    Microwave Oven User manual MS23J5133A* Please be advised that the Samsung warranty does NOT cover service calls to explain product operation, correct improper installation, or perform normal cleaning or maintenance. MS23J5133A_EU_DE68-04328C-00_EN.indd 1 2015-01-21 6:22:57...

  • Page 3: Table Of Contents

    Contents Using this user manual The following symbols are used in this User Manual: Safety instructions Important safety instructions Installation & wiring instructions Wiring instructions Cooking instructions on food packaging Cooking instructions Installation Accessories Installation site Turntable Maintenance Cleaning Replacement (repair) Care against an extended period of disuse Quick look-up guide Oven features...
  • Page 4 Setting a standing time (kitchen timer) Safety-locking your microwave oven Switching the beefer off Cookware guide Cooking guide Troubleshooting Checkpoints Information code Technical specifications English MS23J5133A_EU_DE68-04328C-00_EN.indd 3 2015-01-21 6:22:57...

  • Page 5: Using This User Manual

    Using this user manual Using this user manual You have just purchased a SAMSUNG microwave oven. Your Owner’s Instructions contains valuable information on cooking with your microwave oven: • Safety precautions • Suitable accessories and cookware • Useful cooking tips •...

  • Page 6: Safety Instructions

    Safety instructions IMPORTANT SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE. MAKE SURE THAT THESE SAFETY PRECAUTIONS ARE OBEYED AT ALL TIMES. BEFORE USING THE OVEN, CONFIRM THAT THE FOLLOWING INSTRUCTIONS ARE FOLLOWED. Microwave function only WARNING: If the door or door seals are damaged, the oven must not be operated until it has been repaired by a competent person.
  • Page 7 Safety instructions WARNING: This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
  • Page 8 Failure to maintain the oven in a clean condition could lead to deterioration of the surface that could adversely affect the life of the appliance and possibly result in a hazardous situation. The appliance is not intended for installing in road vehicles, caravans and similar vehicles etc.
  • Page 9 Safety instructions Oven function only - Optional WARNING: When the appliance is operated in the combination mode, children should only use the oven under adult supervision due to the temperatures generated. During use the appliance becomes hot. Care should be taken to avoid touching heating elements inside the oven.

  • Page 10: General Safety

    The temperature of accessible surfaces may be high when the appliance is operating. The door or the outer surface may get hot when the appliance is operating. Keep the appliance and its cord out of reach of children less than 8 years.
  • Page 11 Safety instructions Do not place the oven over a fragile object such as a sink or glass object. Do not use benzene, thinner, alcohol, steam cleaner or high pressure cleaner to clean the appliance. Ensure that the power voltage, frequency and current are the same as those of the product specifications.
  • Page 12 CAUTION Only use utensils that are suitable for use in microwave ovens; DO NOT use any metallic containers, Dinnerware with gold or silver trimmings, Skewers, forks, etc. Remove wire twist ties from paper or plastic bags. Reason: Electric arcing or sparking may occur and may damage the oven. Do not use your microwave oven to dry papers or clothes.
  • Page 13 Samsung will charge a repair fee for replacing an accessory or repairing a cosmetic defect if the damage to the unit and/or damage to or loss of the accessory was caused by the customer.

  • Page 14: Installation & Wiring Instructions

    Correct disposal of this product (waste electrical & electronic equipment) (Applicable in countries with separate collection systems) This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g. charger, headset, USB cable) should not be disposed of with other household waste at the end of their working life.

  • Page 15: Wiring Instructions

    Safety instructions WIRING INSTRUCTIONS WARNING THIS APPLIANCE MUST BE EARTHED. This appliance must be earthed. In the event of an electrical short circuit, earthing reduces the risk of electric shock providing an escape wire for the electric current. The appliance is equipped with a mains lead which includes an earth wire for connecting to the earth terminal of your mains plug.

  • Page 16: Cooking Instructions On Food Packaging

    The manufacturer of this oven will not accept any liability for damage to persons or material for non observance of these requirements. There are no user-serviceable parts inside the oven and if the mains lead of this appliance is damaged, it must only be replaced by qualified service personnel approved by the manufacturer because special tools are required.

  • Page 17: Cooking Instructions

    Safety instructions COOKING INSTRUCTIONS The IEC Power Output rating is an internationally standardised rating, so all microwave manufacturers now use the same method of measuring power output. If food packaging gives cooking instructions based on IEC Power ratings, set cooking times according to the IEC Power of your oven.

  • Page 18: Installation

    Installation Accessories Depending on the model that you have purchased, you are supplied with several accessories that can be used in a variety of ways. Roller ring, to be placed in the centre of the oven. Purpose: The roller ring supports the turntable.

  • Page 19: Installation Site

    Installation Installation site • Select a flat, level surface 20 cm 10 cm above behind approx. 85 cm above the floor. The surface must support the weight of the oven. • Secure room for ventilation, at least 10 cm from the rear 10 cm wall and both sides, and 20 cm 85 cm of...

  • Page 20: Maintenance

    Maintenance Cleaning Clean the oven regularly to prevent impurities from building up on or inside the oven. Also pay special attention to the door, door sealing, and turntable and roller ring (applicable models only). If the door won’t open or close smoothly, first check if the door seals have built up impurities.
  • Page 21 Maintenance To clean inside swing-heater models To clean the upper area of the cooking chamber, lower the top heating element by 45° as shown. This will help clean the upper area. When done, reposition the top heating element. • Do not use any abrasive CAUTION or chemical substances for •...

  • Page 22: Replacement (Repair)

    Samsung and then contact a local service centre for technical Samsung service centre. assistance.

  • Page 23: Quick Look-Up Guide

    Quick look-up guide Quick look-up guide If you want to cook some food. Place the food in the oven. Press Microwave button to start cooking. Press Up/Down button until the appropriate power level is displayed. At that time, press the Select button to set the power level.

  • Page 24: Oven Features

    Oven features Oven Ventilation holes Door Safety interlock holes Light Turntable Open door push button Display Coupler Control panel Door latches Roller ring English MS23J5133A_EU_DE68-04328C-00_EN.indd 23 2015-01-21 6:23:06...

  • Page 25: Control Panel

    Oven features Control panel Healthy Cooking Selection My Plate Button Power Defrost Button Soften/Melt Button Keep Warm Button Microwave Mode Button Memory Cook Button Deodorisation Button Kitchen Timer Button Clock Button Child Lock Button Up/Down Button (Cooking time, Weight and serving size) Select Button Stop/Energy save Button +30s Button...

  • Page 26: Oven Use

    Oven use How a microwave oven works Microwaves are high-frequency electromagnetic waves; the energy released enables food to be cooked or reheated without the foods form or colour changing. You can use your microwave oven to: • Defrost (manual & auto) •...

  • Page 27: Checking That Your Oven Is Operating Correctly

    Oven use Checking that your oven is operating correctly The following simple procedure enables you to check that your oven is working correctly at all times. Open the oven door, and place a glass of water on the turntable. Then, close the door. Press the +30s button and set the time to 4-5 minutes by pressing +30s button the appropriate number of times.

  • Page 28: Setting The Time

    Setting the time When power is supplied, “88:88” and then “12:00” is automatically displayed on the display. Please set the current time. The time can be displayed in either the 24-hour or 12-hour notation. You must set the clock: • When you first install your microwave NOTE oven Do not forget to reset the clock when you...

  • Page 29: Cooking/Reheating

    Oven use Cooking/Reheating The following procedure explains how to cook or reheat food. Open the door. Place the food in the centre IMPORTANT of the turntable. Close the door. Never ALWAYS check your cooking settings before switch the microwave oven on when it is leaving the oven unattended.

  • Page 30: Power Levels

    Power levels You can choose among the power levels below. NOTE Power level Output HIGH 800 W If you select higher power level, the cooking time must be decreased. MEDIUM HIGH 600 W MEDIUM 450 W NOTE MEDIUM LOW 300 W If you select lower power level, the cooking time must be increased.

  • Page 31: Setting The Energy Save Mode

    Oven use Stopping the cooking You can stop cooking at any time to check the food. To stop temporarily; Open the door. Result: Cooking stops. To resume cooking, close the door and press the START button again. To stop completely; Press the STOP/ECO button.

  • Page 32: Using The Healthy Cooking Features

    Using the healthy cooking features The 16 Healthy Cooking features provide pre-programmed cooking times. You do not need to set either the cooking times or the power level. NOTE Open the door. Place the food in the centre Use only recipients that are microwave-safe. of the turntable.
  • Page 33 Oven use Healthy cooking guide Vegetable/Grains Code/Food Serving Size Instructions 250 g Rinse and clean fresh broccoli and prepare florets. Put them evenly into a glass bowl with lid. Add 30 ml (2 tbsp) water Broccoli when cooking for 250 g. Put bowl in the centre of turntable. Florets Cook covered.
  • Page 34 Poultry/Seafood Code/Food Serving Size Instructions 300 g Rinse pieces and put on a ceramic plate. Cover with (2 pcs) microwave cling film. Pierce film. Put dish on turntable. Chicken Stand for 2 minutes. Breasts 300 g Rinse pieces and put on a ceramic plate. Cover with (2 pcs) microwave cling film.

  • Page 35: Using The My Plate Features

    Oven use Using the my plate features The My Plate features has two pre-programmed cooking times. You do not need to set either the cooking times or the power level. You can adjust the number of servings by Pressing Up/Down button. First, place the food in the centre of the turntable and close the door.

  • Page 36: Using The Power Defrost Features

    Using the power defrost features The Power Defrost features enable you to defrost meat, poultry, fish, bread/case. The defrost time and power level are set automatically. You simply select the programme and the weight. NOTE Open the door. Place the frozen food on a Use only containers that are microwave- ceramic in the centre of the turntable.
  • Page 37 Oven use The following table presents the various Power Defrost programmes, quantities and appropriate instructions. Remove all kind of package material before defrosting. Place meat, poultry, fish, bread/case on a ceramic plate. Code/Food Serving Size Instructions 200-1500 g Shield the edges with aluminium foil. Turn the meat over when the oven beeps.

  • Page 38: Using The Soften/Melt Features

    Using the soften/melt features The Soften/Melt features has four pre-programmed cooking times. You do not need to set either the cooking times or the power level. You can adjust the number of servings by Pressing Up/Down button. First, place the food in the centre of the turntable and close the door. Press the Soften/Melt button.

  • Page 39: Using The Keep Warm Features

    Oven use The following table presents the Soften/Melt programmes, quantities and appropriate Instructions. Those programmes are running with microwave energy only. Code/Food Serving Size Instructions 50 g Cut butter into 3 or 4 pieces and Put them on small glass bowl. Melt uncovered. Stir after cooking. Stand for Melting Butter 100 g 1-2 minutes.

  • Page 40: Using The Memory Cook Features

    Using the memory cook features If you often cook or reheat the same types of dishes, you can store the cooking times and power levels in the oven’s memory, so that you do not have to reset them each order. you can store two different setting Set your cooking programme as usual (cooking time and power level) see...

  • Page 41: Using The Deodorisation Features

    Oven use Using the deodorisation features Use this features after cooking odorous food or when there is a lot of smoke in the oven interior. First clean the oven interior. Press the Deodorisation button after you have finished cleaning and press the Start button.

  • Page 42: Safety-Locking Your Microwave Oven

    Safety-locking your microwave oven Your microwave oven is fitted with a special Child Safety programme, which enables the oven to be “locked” so that children or anyone unfamiliar with it cannot operate it accidentally. The oven can be locked at any time. Press the Child Lock button for 3 seconds.

  • Page 43: Cookware Guide

    Cookware guide Cookware guide To cook food in the microwave oven, the microwaves must be able to penetrate the food, without being reflected or absorbed by the dish used. Care must therefore be taken when choosing the cookware. If the cookware is marked microwave-safe, you do not need to worry.
  • Page 44 Cookware Microwave-safe Comments Paper • Plates, cups, napkins For short cooking times and warming. Also to ✓ absorb excess moisture. and kitchen paper • Recycled paper May cause arcing. ✗ Plastic • Containers Particularly if heat-resistant thermoplastic. ✓ Some other plastics may warp or discolour at high temperatures.

  • Page 45: Cooking Guide

    Cooking guide Cooking guide Microwaves Covering during cooking To cover the food during cooking is very Microwave energy actually penetrates food, important, as the evaporated water rises as attracted and absorbed by its water, fat and steam and contributes to cooking process. sugar content.
  • Page 46 Reheating liquids and food Use the power levels and times in this table as a guide lines for reheating. Food Serving Size Power Time (min.) Drinks (Coffee, Tea and 150 ml (1 cup) 800 W 1-1½ Water) 250 ml (1 mug) 1½-2 Instructions Pour into cup and reheat uncovered.

  • Page 47: Troubleshooting

    You may encounter a problem using the oven. In that case, first check the table below and try the suggestions. If a problem persists, or if any information code keeps appearing on the display, contact a local Samsung service centre. Checkpoints If you encounter a problem with the oven, first check the table below and try the suggestions.
  • Page 48 Problem Cause Action Power is not supplied. Make sure power is supplied. There is no power to the oven. Cooking sealed food or using a Do not use sealed containers There is a popping container with a lid may causes as they may burst during sound during popping sounds.
  • Page 49 Troubleshooting Problem Cause Action The oven may not work, too Put one cup of water in a The warm function much food is being cooked, or microwave-safe container and does not work. improper cookware is being run the microwave for 1-2 used.
  • Page 50 Problem Cause Action The power or power socket is Make sure the power and power There is electricity not properly grounded. socket are properly grounded. coming from the oven. There may be water or steam Let the oven cool and then wipe There is water in some cases depending on with a dry dish towel.
  • Page 51 Troubleshooting Problem Cause Action Turntable There is no roller ring, or the Install the roller ring and then While turning, the roller ring is not properly in try again. turntable comes out place. of place or stops turning. The roller ring is not properly Adjust the amount of food and The turn table drags in place, there is too much food,...
  • Page 52 NOTE If the above guidelines do not enable you to solve the problem, then contact your local SAMSUNG customer service centre. Please have the following information read; English MS23J5133A_EU_DE68-04328C-00_EN.indd 51 2015-01-21 6:23:16...

  • Page 53: Information Code

    The model and serial numbers, normally printed on the rear of the oven • Your warranty details A clear description of the problem • Then contact your local dealer or SAMSUNG aftersales service. Information code Check code Cause Action Clean the keys and check if there is water on the surface around key.

  • Page 54: Technical Specifications

    Technical specifications SAMSUNG strives to improve its products at all times. Both the design specifications and these user instructions are thus subject to change without notice. Model MS23J5133A* Power source 230 V ~ 50 Hz Power consumption Microwave 1150 W...
  • Page 55 Memo MS23J5133A_EU_DE68-04328C-00_EN.indd 54 2015-01-21 6:23:16...
  • Page 56 Memo MS23J5133A_EU_DE68-04328C-00_EN.indd 55 2015-01-21 6:23:16...
