Sanyo PLV-Z2 Service Manual

SERVICE MANUAL

NOTE: PLV-Z2 (Chassis No. M4K-Z201) is basically the same as original model PLV-Z2
(Chassis No. M4K-Z200).
Any information not contained in this manual will be found in the original model's
service manual SM5110585-00 issued in November 2003.
FILE WITH ORIGINAL SERVICE MANUAL SM5110585
PRODUCT CODE
112212520 PLV-Z2 (M4KAA)
112212620 PLV-Z2 (P4KAA)
112212622 PLV-Z2 (P4KCA)
Multimedia Projector
Differences ------------------------------------------------------------------------------ 2
Board (ASSY, PWB) --------------------------------------------------------------- 2
Circuit Diagram ------------------------------------------------------------------------- 2
1. Main and AV Boards (Differences) ----------------------------------------- 2
2. LED Board ----------------------------------------------------------------------- 3
3. AV Board --------------------------------------------------------------------- 4 - 5
4. Main Board (Differences) ------------------------------------------------ 6 - 7
Electrical Parts List -------------------------------------------------------------- 8 - 19
Read Description in the parts list ----------------------------------------------- 8
Assy, PWB, Main ------------------------------------------------------------ 9 - 17
Assy, PWB, AV ------------------------------------------------------------- 17 - 19
Assy, PWB, LED ----------------------------------------------------------------- 19
FILE NO.
Model No. PLV-Z2
(U.S.A., Canada, Europe
Asia, Africa, U.K. )
ORIGINAL VERSION
Chassis No. M4K-Z201
(PLV-Z2)
NOTE: Match the Chassis No. on the
unit's back cover with the Chassis
No. in the Service Manual.
If the Original Version Service
Manual Chassis No. does not
match the unit's, additional
Service Literature is required. You
must refer to "Notices" to the
Original Service Manual prior to
servicing the unit.
CONTENTS
REFERENCE NO.
Pages
SS
5110637-00
