Icom IC-7300 Service Manual page 42

[TUNER UNIT]
REF ORDER
NO. NO.
W2001* 8970024721 1.5DCOAXIAL140MM-1 C31/C31
J1001* 6510028210 SJ050010 (TMP-J01X-V6)
J1801* 6510021722 30FLT-SM2-TB (LF) (SN) (M)
J2001* 6510028210 SJ050010 (TMP-J01X-V6)
J2002* 6510028210 SJ050010 (TMP-J01X-V6)
MP1301* 8510013390 2355 MIX CASE
MP2001* 8930075430 3015 ANT SPRING Y1091
[FRONT UNIT]
REF ORDER
NO. NO.
DS1 5030004050 RFE430H-AZH-DNS-000 <TRIA>
W1** 8910000070 FFC-1008 (P0.5N6L50)
W2** 8910000070 FFC-1008 (P0.5N6L50)
W3** 8910000070 FFC-1008 (P0.5N6L50)
W4** 8900018000 OPC-1344A (P1N10L70)
EP1 0880001360 EX-2500 SENSOR
MP1 8210031701 3765 FRONT PANEL ASSEMBLY-1 (including MP2)
MP2 8930093270 3765 B-LENS
MP3 8610015840 KNOB K-300 ASSEMBLY (including MP4)
MP4 8930093260 3765 A-LENS
MP5 8610015710 KNOB K-301
MP6 8610015720 KNOB K-302
MP7 8610015730 KNOB K-303
MP8 8610015740 KNOB K-304
MP11 8010023630 3765 SUB CHASSIS Y2204
MP21 8810008661 PHBT M3 X 8 NI-ZC3
MP22 8810008661 PHBT M3 X 8 NI-ZC3
MP23 8810008661 PHBT M3 X 8 NI-ZC3
MP24 8810008631 PHBT M3 X 6 NI-ZC3
MP31 8930093290 3765 BRAKE PLATE
MP32 8930093280 3765 BRAKE BUTTON (including MP31)
MP33 8930077360 3073 BRAKE PAD
MP34 8930094550 3765 BRAKE SHEET
MP35 8610015830 KNOB N-432 ASSEMBLY (including MP42)
MP36 8610015760 KNOB N-432 COVER (TOP)
MP37 8610013880 KNOB N-379
MP38 8610011830 KNOB N301
MP39 8610013870 KNOB N-378
MP40 8610013290 KNOB N-361
MP41 8610015780 KNOB N-433
MP42 8610010040 KNOB N-239 FINGER REST
MP43 8810003560 M4 X 6 SUS
MP47 8930057950 DOUBLE SIDE TAPE (AH)
MP48 8930094510 SPONGE (NZ)
MP49 8930094520 SPONGE (OA)
MP50 8930094530 HIMELON SHEET (DM)
MP51 8930094530 HIMELON SHEET (DM)
MP52 8930094500 3765 VR SHEET
MP53 8930094540 DOUBLE SIDE TAPE (CA)
MP54 8930083180 SPONGE (LG)
MP55 8930032130 THERMAL SHEET AQ
MP56 8930094490 3765 KEY SPONGE
MP57* 8930037760 INSULATION SHEETDY
MP58 8930094650 SPONGE (OB)
MP60 8930094680 DOUBLE SIDE TAPE (CC)
MP61* 8930088580 HIMELON SHEET (DD)
MP62 8930094750 SPONGE (OF)
*: Refer to "BOARD LAYOUTS" for the location.
**: Refer to "GENERAL WIRING" for the connection
Screw abbreviations
DESCRIPTION
DESCRIPTION
A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
[DISPLAY UNIT]
REF ORDER
QTY.
NO. NO.
1
J51* 6510022692 06FLT-SM2-TB (LF) (SN) (M)
J61* 6510022692 06FLT-SM2-TB (LF) (SN) (M)
1
J71* 6510022692 06FLT-SM2-TB (LF) (SN) (M)
1
J101* 6510031070 AYF534035
1
J201* 6510018971 B4B-PH-SM4-TB (LF) (SN)
1
J301* 6510022692 06FLT-SM2-TB (LF) (SN) (M)
J401* 6510018971 B4B-PH-SM4-TB (LF) (SN)
1
J421* 6510018971 B4B-PH-SM4-TB (LF) (SN)
1
J451* 6510019971 52808-1071
J601* 6510022472 40FLT-SM2-TB (LF) (SN) (M)
S1* 2230001480 LS37J2-T
S2* 2230001480 LS37J2-T
S3* 2230001480 LS37J2-T
QTY.
S4* 2230001480 LS37J2-T
S5* 2230001480 LS37J2-T
1
S6* 2230001480 LS37J2-T
S7* 2230001480 LS37J2-T
1
S8* 2230001480 LS37J2-T
1
S9* 2230001480 LS37J2-T
1
S10* 2230001480 LS37J2-T
1
S11* 2230001480 LS37J2-T
S12* 2230001480 LS37J2-T
1
S13* 2230001480 LS37J2-T
S14* 2230001480 LS37J2-T
1
S15* 2230001480 LS37J2-T
1
S16* 2230001480 LS37J2-T
1
S17* 2230001480 LS37J2-T
1
S18* 2230001480 LS37J2-T
1
S19* 2230001480 LS37J2-T
1
S20* 2230001480 LS37J2-T
1
S21* 2230001480 LS37J2-T
1
S22* 2230001480 LS37J2-T
1
S23* 2230001480 LS37J2-T
5
S24* 2230001480 LS37J2-T
12
S25* 2230001480 LS37J2-T
2
2
MP1* 8510002280 VCOSHIELD PLATE (A) FX 15
1
1
2 [PBT UNIT]
1
1
REF ORDER
1
NO. NO.
1
J1* 6510029480 06FH-SM1-TB (LF) (SN)
1
1
S1 2250000960 TP90D96AE20-30.5F-3765
1
1
1
[VR UNIT]
1
2
REF ORDER
8
NO. NO.
3
1
J1* 6510029480 06FH-SM1-TB (LF) (SN)
1
1
1
[RIT UNIT]
4
2
REF ORDER
1
NO. NO.
1
1
J1* 6510029480 06FH-SM1-TB (LF) (SN)
1
1
S1 2250001010 TP90N00AE20-14.5F-3765A
1
[PHONE UNIT]
REF ORDER
NO. NO.
W1** 8600036920 EX2500 P01*J01MA
J1 6450001630 HSJ1406-01-050
[MIC UNIT]
REF ORDER
NO. NO.
J1 6510000191 FM214-8SS (P)-1
J2* 6510019971 52808-1071
[SD UNIT]
REF ORDER
NO. NO.
J1* 6510028980 SCDABA0500
J2* 6510031540 12FHJ-SM1-TB (LF) (SN)
6-2
DESCRIPTION QTY.
DESCRIPTION QTY.
DESCRIPTION QTY.
DESCRIPTION QTY.
DESCRIPTION QTY.
DESCRIPTION QTY.
DESCRIPTION QTY.
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
