QuickSpecs
Overview
1. Dual microphone array
2. 2.0 MP Webcam (optional)
3. Webcam Activity LED (only on models with Webcam)
4. 23-inch Full HD capable screen (with or without optical touch panel option)
5. Optical drive opening
6. Power button
7. Capacitive Controls for Brightness, Volume, Mic Mute, Speaker Mute
8 Stand(Can be configured with no stand, basic stand, or height adjustable/reclining stand)
DA - 14352 Worldwide QuickSpecs — Version 24 — 3.5.2013
HP Compaq 8300 Elite All-in-One PC
FRONT
Page 1

Advertisement

Table of Contents
loading

Related Manuals for HP Compaq 8300 Elite

Summary of Contents for HP Compaq 8300 Elite

  • Page 1 QuickSpecs HP Compaq 8300 Elite All-in-One PC Overview FRONT 1. Dual microphone array 2. 2.0 MP Webcam (optional) 3. Webcam Activity LED (only on models with Webcam) 4. 23-inch Full HD capable screen (with or without optical touch panel option) 5.
  • Page 2 QuickSpecs HP Compaq 8300 Elite All-in-One PC Overview BACK 1. Vent slots 2. Side venting 3. 6-in-1 Media Card Reader (optional) 4. (2) USB 3.0 ports 5. Mic input jack 6. Headphone jack 7. Access panel latches 8. Rear port cover REAR PORTS (BEHIND COVER) DA - 14352 Worldwide QuickSpecs —...
  • Page 3 QuickSpecs HP Compaq 8300 Elite All-in-One PC Overview 1. Security lock slot 2. Power connector 3. PS/2 mouse and keyboard connectors 4. (2) USB 2.0 ports 5. (2) USB 3.0 ports 6. DisplayPort connector 7. RJ-45 Gigabit Ethernet port 8. Stereo line out SIDE 1.
  • Page 4 TCO AiO and Edge BFR/PVC Free Arsenic Free Protected by HP Services, including standard warranties up to 5-5-5 (terms and conditions vary by country; certain restrictions and exclusions apply) Portrait orientation not recommended for Touch DA - 14352 Worldwide QuickSpecs — Version 24 — 3.5.2013...

  • Page 5: Standard Features

    QuickSpecs HP Compaq 8300 Elite All-in-One PC Standard Features OPERATING SYSTEM Preinstalled Windows 8 Pro (64-bit)*, ± Windows 8 (64-bit)*, ± Windows® 7 Ultimate (32-bit)** Windows® 7 Ultimate (64-bit)** Windows® 7 Professional (32-bit)** Windows® 7 Professional (64-bit)** Windows® 7 Professional (32-bit) (available through downgrade rights from Windows 8 Pro)***, ±...
  • Page 6 QuickSpecs HP Compaq 8300 Elite All-in-One PC Standard Features Intel® 3rd Generation Core™ i3 Processors Intel® Core™ i3-3240 3.4 GHz base frequency, 3 MB cache, 2 cores, 4 threads Intel HD Graphics 2500 Supports DDR3 memory up to 1600 MT/s data rate Intel®...
  • Page 7 QuickSpecs HP Compaq 8300 Elite All-in-One PC Standard Features INTEL VPRO TECHNOLOGY CAPABLE Intel Core i5 with vPro and Core i7 with vPro technology is a selectable feature that is available on units configured with select processors, and a preinstalled Windows operating system. It provides advances in remote manageability, security, energy efficient performance, and wireless connectivity.

  • Page 8: Wireless Display

    QuickSpecs HP Compaq 8300 Elite All-in-One PC Standard Features SMBIOS System Management BIOS, previously known as DMI BIOS, is used to store system management information GRAPHICS Integrated (depends on processor) Intel HD Graphics: Basic, 2000, 2500, or 4000 Models with Intel Core i3/i5/i7 processors include HD 2000, 2500, or 4000 graphics. Models with Pentium or Celeron processors include HD graphics.
  • Page 9 (typical) Anti-glare Default color temperature Warm (6500K) 8300 Non-touch is anti-glare NOTE: All performance specifications represent the typical specifications provided by HP's component manufacturers; actual performance may vary either higher or lower. Basic Stand: Tilt Angle -5° to +30° Rotation 360°...
  • Page 10 QuickSpecs HP Compaq 8300 Elite All-in-One PC Standard Features STORAGE 3.5" SATA Hard Drive 250 GB, 7200 rpm, SATA 6.0 Gb/s, SMART IV 500 GB, 7200 rpm, SATA 6.0 Gb/s, SMART IV 1 TB, 7200 rpm, SATA 6.0 Gb/s, SMART IV 2.5 "...
  • Page 11 QuickSpecs HP Compaq 8300 Elite All-in-One PC Standard Features NETWORKING/COMMUNICATIONS Ethernet (RJ-45) Integrated Intel 82579LM Gigabit Network Connection NOTE: The term "10/100/1000" or "Gigabit" Ethernet indicates compliance with IEEE standard 802.3ab for Gigabit Ethernet, and does not connote actual operating speed of 1 Gb/s. For high-speed transmission, connection to a Gigabit Ethernet server and network infrastructure is required.
  • Page 12 Setup support for 12 languages. Select models feature either Intel Standard Manageability or Intel Core vPro Processor Technology. Stability - HP BIOS supports the HP stable product roadmap by releasing only critical BIOS changes to the factory and advanced change notification.
  • Page 13 QuickSpecs HP Compaq 8300 Elite All-in-One PC Standard Features SECURITY USB port disable Lockable Access Panels Security Screw HP Keyed Cable Lock (optional) Common Criteria Certified, Infineon TPM SLB9635TT1.2 - 3.17 FW Intrusion Detector Wall Mountable via VESA bracket Support for Nobel Locking Plate (3rd party option)
  • Page 14 Subscriptions can be purchased for terms ranging from one to five years. Service is limited, check with Absolute for availability outside the U.S. *** Requires an Internet connection to HP web-enabled printer and HP ePrint account registration (for a list of eligible printers, supported documents and image types and other HP ePrint details, see www.hp.com/go/eprintcenter).

  • Page 15: Weights And Dimensions

    TCO AiO and Edge Qualified for Microsoft Lync BFR/ PVC Free Arsenic Free 80 PLUS® TAA compliant For accessibility information on HP products, please visit: http://www.hp.com/accessibility. WEIGHTS & DIMENSIONS Weight Product Weight Basic stand 21.7 - 25.5 lbs 9.85 - 11.55 kg Height adjustable/reclining stand 33.4 - 37.1 lbs...
  • Page 16 QuickSpecs HP Compaq 8300 Elite All-in-One PC Standard Features Without stand 15 - 18.8 lbs 6.82 - 8.52 kg Shipping Weight Pallet Basic Stand Basic Stand (18 units) 30.78 lbs 595.35 lbs 13.96 kg 270 kg Height adjustable/reclining stand Height adjustable/reclining stand (12 units) 43.81 lbs...
  • Page 17 QuickSpecs HP Compaq 8300 Elite All-in-One PC Standard Features BASIC STAND DIMENSIONS DA - 14352 Worldwide QuickSpecs — Version 24 — 3.5.2013 Page 17...
  • Page 18 QuickSpecs HP Compaq 8300 Elite All-in-One PC Standard Features HEIGHT ADJUSTABLE/RECLINING STAND DIMENSIONS TEMPERATURE, HUMIDITY, ALTITUDE Temperature Operating 50° to 95° F (10° to 35° C) Non-operating -22° to 140° F(-30° to 60° C) Relative humidity Operating 10% to 90% (non-condensing at ambient)

  • Page 19: Service And Support

    NOTE 2: On-site service may be provided pursuant to a service contract between HP and an authorized HP third- party provider, and is not available in certain countries. Global service response times are based on commercially reasonable best effort and may vary by country.

  • Page 20: Technical Specifications - Graphics

    QuickSpecs HP Compaq 8300 Elite All-in-One PC Technical Specifications – Graphics Intel HD Graphics VGA Controller Integrated DisplayPort 1.1a; integrated, multimode capable; supports HDCP and audio over DisplayPort Bus Type PCI Express x16 RAMDAC Integrated, 350 MHz Memory Intel graphics do not have dedicated memory but utilizes some of the computer's system memory The amount of memory used for graphics depending on the amount of system memory installed, BIOS settings, operating system, and system load.
  • Page 21 HP Compaq 8300 Elite All-in-One PC Technical Specifications – Graphics OpenGL 3.0 support Supported Display Resolutions and Refresh Rates NOTE: other resolutions may be available but are not recommended as they may not have been tested and qualified by HP Resolution Refresh Rates 800x600...
  • Page 22 HP Compaq 8300 Elite All-in-One PC Technical Specifications – Graphics Supported Display Resolutions and Refresh Rates NOTE: other resolutions may be available but are not recommended as they may not have been tested and qualified by HP Resolution Refresh Rates...

  • Page 23: Technical Specifications - Hard Disk And Solid State Storage

    HP Drive Lock HP Serial ATA Hard Drives offer enhanced security via a new Drive Lock. When enabled, this ATA security feature set prevents software access to user data on the drive until one or two user-defined passwords are provided.
  • Page 24 Media diameter: 3.5 in (8.89 cm) Width (nominal) Physical size: 4 in (10.2 cm) Operating Temperature 41° to 131° F (5° to 55° C) HP 500-GB 7.2K rpm SATA 6.0Gb/s 3.5” Hard Disk Drive Capacity 500,107,862,016 bytes Rotational Speed 7,200 rpm Interface Serial ATA 3.0 (6.0 Gb/s)
  • Page 25 QuickSpecs HP Compaq 8300 Elite All-in-One PC Technical Specifications – Hard Disk and Solid State Storage HP 320-GB 7.2K SATA 6.0Gb/s 2.5" Hard Disk Drive Capacity 320,072,933,376 bytes Rotational Speed 7,200 rpm Interface Serial ATA 2.0 (3.0 Gb/s) Buffer Size...
  • Page 26 UL, CSA, EN 60950-2000, CISPR Pub 22 Class B, CNS 13438, AS/NZS Regulations CISPR 22:2002 Class B, Korea KCC, CE Mark HP 128 GB Solid State Drive, documentation, 3.5-inch bay adapter bracket, Option kit contents 3.5-inch bay adapter bracket screws, SATA cable * For solid state disk drives, GB means 1 billion bytes.

  • Page 27: Technical Specifications - Removable Storage

    QuickSpecs HP Compaq 8300 Elite All-in-One PC Technical Specifications – Removable Storage HP Slim SuperMulti DVD Writer Drive Height 12.7mm height Orientation Either horizontal or vertical Interface type SATA/ATAPI Disc recording capacity Up to 8.5 GB DL or 4.7 GB standard Dimensions (W x H x D) 5.0 x 0.5 x 5.0 in (128 x 13.6 x 129 mm)
  • Page 28 QuickSpecs HP Compaq 8300 Elite All-in-One PC Technical Specifications – Removable Storage Total Drive Power < 2.5 Watt (standby mode) Line-Out 0.7 VRMS Audio output Signal-to-Noise Ratio 74 dB Channel Separation 65 dB Temperature 41° to 122° F (5° to 50° C)
  • Page 29 QuickSpecs HP Compaq 8300 Elite All-in-One PC Technical Specifications – Removable Storage DA - 14352 Worldwide QuickSpecs — Version 24 — 3.5.2013 Page 29...

  • Page 30: Memory Configurations

    System Memory Support The HP Compaq Elite 8300 Business PC supports the 2nd and 3rd generation Intel® Core™ processor families. Based on a new PC micro-architecture, the processor is designed for a two-chip platform consisting of a processor and Platform Controller Hub (PCH).

  • Page 31: Technical Specifications - Networking And Communications

    QuickSpecs HP Compaq 8300 Elite All-in-One PC Technical Specifications – Networking and Communications Intel 82579LM GbE Network Connection (integrated) Connector RJ-45 System Interface Integrated on PCA Controller Intel 82579LM GbE platform LAN connect networking controller Memory 24 KB FIFO packet buffer memory...
  • Page 32 QuickSpecs HP Compaq 8300 Elite All-in-One PC Technical Specifications – Networking and Communications Modulation Direct Sequence Spread Spectrum DBPSK, DQPSK, CCK, OFDM, BPSK, QPSK, 16-QAM, 64-QAM Security Supports 64- and 128-bit WEP, WPA, WPA2, hardware-accelerated AES (support for key sizes of 128bits), TKIP, 802.1x authentication types EAP-TLS, EAP-TTLS, PEAP, MSCHAP,...
  • Page 33 QuickSpecs HP Compaq 8300 Elite All-in-One PC Technical Specifications – Networking and Communications HP 802.11b/g/n Wireless PCIe Minicard Dimensions (L x H) 1.18 x 1.06 in (30 x 26.8 mm) Controller Ralink RT5392 System interface PCI Express x1 Network standard 802.11 b/g/n...
  • Page 34 QuickSpecs HP Compaq 8300 Elite All-in-One PC Technical Specifications – Networking and Communications Platform/WLAN Mode Power Consumption Wi-Fi Tx Mode 515 mA Rx Mode 425 mA Bluetooth Power Consumption Tx Mode 40 mA Rx Mode 38 mA Wi-Fi + Bluetooth - 165 mA...

  • Page 35: Technical Specifications - Audio

    QuickSpecs HP Compaq 8300 Elite All-in-One PC Technical Specifications – Audio IDT 92HD91Audio Type Integrated HD Stereo Codec IDT92HD91 4-channel codec Ports Line-In/Microphone input ports are 50K (nominal) at the pin Line-Out intended to drive an external 10K load (nominal) and an on board shunt resistor of...

  • Page 36: Technical Specifications - Keyboards And Pointing Devices

    QuickSpecs HP Compaq 8300 Elite All-in-One PC Technical Specifications – Keyboards and Pointing Devices HP USB Keyboard Keys 104, 105, 106, 107, 109 layout (depending upon country) Dimensions Physical characteristics 18.12 x 6.47 x 0.96 in (46.03 x 16.43 x 2.44 cm)
  • Page 37 Boost your security, simplify access procedures and reduce the costs associated with managing networks by preventing unauthorized access to your computers and networks using smartcard technology with the HP Smart Card (CCID) DA - 14352 Worldwide QuickSpecs — Version 24 — 3.5.2013...
  • Page 38 HP ProtectTools Smart Card Manager provides authentication software for the smart card. The Smart Card Reader module works with the HP ProtectTools Security Manager and enables the user to setup, use, and manage the smart card. This allows strengthened security with HP patented technology.
  • Page 39 QuickSpecs HP Compaq 8300 Elite All-in-One PC Technical Specifications – Keyboards and Pointing Devices Non-operating temperature -22° to 140° F (-30° to 60° C) Operating humidity 10% to 90% (non-condensing at ambient) Non-operating humidity 20% to 80% (non-condensing at ambient)
  • Page 40 QuickSpecs HP Compaq 8300 Elite All-in-One PC Technical Specifications – Keyboards and Pointing Devices HP USB PS/2 Washable Keyboard Keys 104 (US) Layout, 105 (EU) layout - depending upon country Dimensions 17.67x 6.62 x 1.38 in (449 x 168 x 35 mm)
  • Page 41 QuickSpecs HP Compaq 8300 Elite All-in-One PC Technical Specifications – Keyboards and Pointing Devices HP Wireless Keyboard and Mouse Dimensions (H x L x W) 1.09 x 18.1 x 6.47 in (27.87 x 460.3 x 164.3 mm Keyboard Weight – Without Two AA 1.94 lb (880 g)
  • Page 42 QuickSpecs HP Compaq 8300 Elite All-in-One PC Technical Specifications – Keyboards and Pointing Devices Weight 3.53 oz (100g; +10g/- 5 g) Operating temperature -32° to 104°F (0° to 40° C) Non-operating temperature -4° to 140°F (-20° to 60° C) Operating humidity...
  • Page 43 QuickSpecs HP Compaq 8300 Elite All-in-One PC Technical Specifications – Keyboards and Pointing Devices HP USB Mouse Dimensions 1.5 x 4.5 x 2.5 in (3.8 x 11.6 x 6.3 cm) (H x L x W) Weight 0.22 lb (0.10 kg) Cable length 70.9 in (180 cm)
  • Page 44 QuickSpecs HP Compaq 8300 Elite All-in-One PC Technical Specifications – Keyboards and Pointing Devices Mechanical Resolution 400 ± 20% DPI Tracking speed 10 in/s (25.4 cm/s) maximum Acceleration 100 in/s/s (2.54 m/s/s) Switch actuation 61 g nominal peak force Switch life...
  • Page 45 1.33 W NOTE: Energy efficiency data listed is for an ENERGY STAR® compliant product if offered within the model family . HP computers marked with the ENERGY STAR® Logo are compliant with the applicable U.S. Environmental Protection Agency (EPA) ENERGY STAR®...

  • Page 46: Environmental Data

    RoHS Directive on a worldwide basis. By July 1, 2006, RoHS substances will be virtually eliminated (virtually = to levels below legal limits) for all HP electronic products subject to the RoHS Directive, except where it is widely recognized that there is no technically feasible alternative (as indicated by an exemption under the EU RoHS Directive).
  • Page 47 To recycle your product, please go to: http://www.hp.com/go/reuse-recycle Recycling or contact your nearest HP sales office. Products returned to HP will be recycled, recovered or disposed of in a responsible manner. The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment information for each product type for use by treatment facilities.

  • Page 48: After Market Options

    QuickSpecs HP Compaq 8300 Elite All-in-One PC Options and Accessories (sold separately) AFTER MARKET OPTIONS: MEMORY Part Number HP 2GB DDR3-1600 (PC3-12800) SODIMM B4U38AA HP 4GB DDR3-1600 (PC3-12800) SODIMM B4U39AA HP 8GB DDR3-1600 (PC3-12800) SODIMM B4U40AA DATA STORAGE DRIVES AND ACCESSORIES Part Number 1 TB, 7200 rpm, SATA -6.0 Gb/s...

  • Page 49: Options And Accessories (Sold Separately)

    The warranties for HP products are set forth in the express limited warranty statements accompanying such products. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
