HP Compaq 8300 Elite Illustrated Parts & Service Map

Illustrated Parts & Service Map
HP Compaq 8300 Elite Business PC
Convertible Minitower
© 2012 Hewlett-Packard Development Company, L.P. The information con-
tained herein is subject to change without notice. HP shall not be liable for tech-
nical or editorial errors or omissions contained herein. Intel, Pentium, Intel
Inside, and the Intel logo are trademarks or registered trademarks of the Intel
Corporation and its subsidiaries in the U. S. and other countries.
Document Number 690357-002.
Key Specifications
Processor Type Intel® Core i7, i5, i3, Pentium®
RAM Type Non-ECC DDR3 PC3-12800 (1600 MHz)
Maximum RAM 32 GB
Expansion Slots •
•
•
Chipset Intel Q77 Express
Graphics Adapter Integrated Intel HD graphics
Bays •
•
•
I/O Interfaces Front: (4) USB 2.0 ports, headphone jack, microphone jack
Rear: (4) USB 3.0 ports, (2) USB 2.0 ports, DisplayPort 1.1a,
VGA video, serial port, PS/2 mouse and keyboard, RJ-45 net-
work interface, 3.5mm audio in/out jacks
Preinstalled Operating •
Systems
•
•

Spare Parts

System Unit
System Unit
1 Access panel
2 Front bezel - 8300 models
* Front bezel - 8380 models
3 Power supply, 320W, 90% efficient
* Power supply, 320W
4 Chassis
* 5.25-inch bezel blank
* 3.5-inch bezel blank
* Not shown
HP Compaq 8300 Elite, CMT Chassis
2nd Edition December 2012.
(2) PCIe-x16
(1) PCIe-x1
(3) PCI
(1) card reader
(2) external 5.25-inch
(3) internal 3.5-inch
Windows® 8
Windows 7
FreeLnx
Cables
Cables
1 Power switch/LED assembly
2 SATA optical drive power cable
3 Front USB, I/O assembly
4 SATA hard drive power cable
* SATA cable, 18 inch, 1 straight end, 1 angled end
* SATA cable, 17.7 inch, 2 straight ends
* DMS-59 to dual VGA cable
* Adapter, DisplayPort to VGA
* Adapter, DisplayPort to DVI
* Adapter, DisplayPort to HDMI
* DisplayPort cable
*Not shown
Keyboards (not illustrated)
PS/2 (standard/Windows 8)
USB (standard/Windows 8)
USB, silver/black (Windows 8)
Wireless (standard/Windows 8)
Washable (standard/Windows 8)
Smart card (standard/Windows 8)
USB, hub
Arabic
Belgian
Brazilian Portuguese
Bulgaria
Czech
Danish
Finnish
French
French Canadian
German
Greek
Hebrew
Hungarian
International
International English
Italian
Japanese
Mass Storage Devices (not illustrated)
Optical Drives
16X SATA DVD-ROM drive
16X SATA DVD±RW drive
Blu-ray BD-RW SuperMulti DL Drive
Hard Drives
1 TB, 7200 rpm SATA hard drive
500 GB, 7200 rpm SATA hard drive
250 GB, 7200 rpm SATA hard drive
256 GB Solid State Drive (SSD), self-encrypting (SED), SATA 6.0*
180 GB Solid State Drive (SSD), SATA 6.0*
646819-001
160 GB Solid State Drive (SSD), SATA 3.0*
689380-001
128 GB Solid State Drive (SSD), SATA 2.0*
689381-001
120 GB Solid State Drive (SSD), SATA 2.0*
613764-001
20 GB Solid State Drive (SSD), SATA*
613765-001
*2.5-inch solid-state drives require an adapter for installation.
not spared
570838-001
583653-001
690357-002
537745-xx1/701428-xx1
537746-xx1/701424-xx1
701429-xx1
674314-xx1/701426-xx1
613125-xx1/700510-xx1
631411-xx1/701427-xx1
631913-xx1
-17x LA Spanish
-18x Norwegian
-20x People's Republic of China
-26x Portuguese
-22x Romanian
-08x Russian
-35x Saudi Arabia
-05x Slovakian
-12x South Korea
-04x Spanish
-15x Swedish
-BBx Swiss
-21x Taiwanese
-37x Thai
-L3x Turkish
-06x U.S.
-29x U.K.
646820-001
646832-001
646821-001
646831-001
639958-001
639959-001
463023-001
603250-001
484156-001
617450-001
487562-001
-16x
-09x
-AAx
-13x
-27x
-25x
-DEx
-23x
-KDx
-07x
-10x
-11x
-ABx
-28x
-14x
-00x
-03x
581599-001
660408-001
656792-001
636930-001
636929-001
636927-001
680020-001
696622-001
646809-001
665961-001
661841-001
683305-001
page 1
