Contents vary depending on the area where you purchased this camera. Attaching the strap Pull the strap tight so that it does not come loose. Strap USB Cable Other bundled items OLYMPUS Master CD-ROM Basic Manual (this manual) Advanced Manual (CD-ROM) Warranty Card Registration Card Lithium Ion Battery...
MANUAL CONTENTS Thank you for purchasing an Olympus digital camera. Before you start to use your new camera, please read these instructions carefully to enjoy optimum performance and a longer service life. This manual explains shooting and playback basics. For details on functions, read the advanced manual.
You can even connect the FILE NAME camera directly to a TV to display pictures for your friends and family. Using the provided OLYMPUS Master software on your computer, you can enjoy editing, viewing, and printing pictures. Organize pictures...
TURNING THE CAMERA ON POWER button Battery check indicator Shooting mode 1/2000 1/2000 F2.8 F2.8 × 3264 3264 2448 2448 Battery check indicator The battery check indicator is displayed on the monitor when the camera is turned on. Lit (green) (Disappears after a while.) Ready to shoot.
TAKING A PICTURE Hold the camera securely Compose your picture Position the AF target mark on your subject. Press the zoom button to get close-up pictures of your subject. Focus on your subject Press the shutter button lightly. The green lamp lights when the focus and exposure are locked.
SETTING FREQUENTLY USED FUNCTIONS Direct buttons This camera features buttons for setting functions directly. QUICK VIEW button GUIDE button DISP button Y/S(Self-timer/Single-frame erase) button To set the flash mode Press O# repeatedly in shooting mode to set the flash mode. 1/2000 1/2000 F2.8...
SETTING FREQUENTLY USED FUNCTIONS Menus Press Z to display the top menu on the monitor. Use the menu for setting each function. To set the record mode You can change the record mode used in shooting mode. MODE MENU To set the date and time You can set the date format, year, month, and day.
PRINTING YOUR PICTURES By connecting the camera to a PictBridge-compatible printer with the USB cable, you can print out recorded pictures directly. PRINT MODE SELECT PRINT ALL PRINT MULTI PRINT ALL INDEX EXIT SELECT PRINT Prints the selected picture. ALL PRINT Prints all pictures.
ENJOYING YOUR PICTURES ON A COMPUTER The provided CD-ROM contains OLYMPUS Master software for editing and managing image files. Install the software to get the most out of your digital pictures and movies. What is OLYMPUS Master? Download images from the camera Make panoramic images Edit images (trim, resize, etc.)
Page 13
Advanced Manual “Connecting the camera to a computer” (P. 111) User Registration After installing the OLYMPUS Master software, we recommend you fill out the user registration for your camera. By making your registration, you will receive information on software and firmware...
(based on CIPA battery life measurement standards) : 8,000,000 pixels : 1/1.8" CCD (primary color filter), 8,320,000 pixels (gross) : Olympus lens 8.0 to 24.0 mm, f2.8 to 4.9 (equivalent to 38 to 114 mm on a 35mm camera) : Digital ESP metering, spot metering system : 4 to 1/2000 sec.
-20°C to 60°C (-4°F to 140°F) (storage) Humidity : 30% to 90% (operation)/10% to 90% (storage) Power supply : One Olympus lithium ion battery (LI-10B/LI-12B) or Olympus AC adapter Dimensions : 102.8 mm (W) × 57.6 mm (H) × 32.9 mm (D) (4.0 ×...
CAUTION: TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED OLYMPUS SERVICE PERSONNEL. Lightning flash with an arrowhead, enclosed in a triangle, alerts you to the presence of uninsulated voltage points inside the product which could cause a serious electrical shock.
Page 17
Location — To avoid damage to the product and prevent personal injury, never place this product on an unstable stand, tripod, bracket, table or cart. Mount only on a stable tripod, stand, or bracket. Follow the instructions that describe how to safely mount the product, and use only the mounting devices recommended by the manufacturer.
Page 18
SAFETY PRECAUTIONS Damage Requiring Service — If you notice any of the conditions described below while using a specified AC adapter, unplug it from the wall outlet and refer servicing to qualified service personnel: a) Liquid has been spilled onto the product or some other object has fallen into the product.
Page 19
(if attached). Allow the camera to sit idle for a few minutes to cool. Take the camera outdoors, away from flammable objects, and carefully remove the batteries. Never remove the batteries with bare hands, which may cause a fire or burn your hands. Contact the nearest Olympus service center immediately. SAFETY PRECAUTIONS...
Page 20
– and cause serious damage. ( Use only the AC adapter specified by Olympus. • Never use any AC adapter except one specified by Olympus. Using a different AC adapter may damage the camera or power source, or result in accidents or fire.
Page 21
DANGER • This camera uses a lithium ion battery specified by Olympus. Charge the battery with the specified charger. Do not use any other chargers. • Never heat or incinerate batteries.
Page 22
Weatherproof feature This camera is weatherproof, but it cannot be used underwater. Olympus will not assume any responsibility for malfunction of the camera caused by water getting inside as a result of misuse by the user. The camera is weatherproof and is not damaged by water spray from any direction.
Page 23
For customers in North and South America For customers in USA Declaration of Conformity Model Number : Stylus 800/µ DIGITAL 800 Trade Name : OLYMPUS Responsible Party Address : Two Corporate Center Drive, P.O. Box 9058, Melville, NY 11747-9058 U.S.A.
디지털 카메라 배터리 충전기 (LI-10C) 내용물은 카메라의 구입장소에 따라 다릅니다. 스트랩 연결하기 스트랩이 느슨해 지지 않도록 단단히 잡아 당깁니다. 스트랩 USB 케이블 기타 동봉물 OLYMPUS Master CD-ROM 기본편 (본 설명서) 고급편 (CD-ROM) 보증서 등록 카드 리튬 이온 배터리 (LI-12B) AV 케이블...
Page 25
사용 설명서 목차 저희 올림푸스 디지털 카메라를 구입해 주신데 대해 감사드립니다. 카메라를 사용하 시기 전에 본 설명서를 잘 읽으시고 최적의 기능을 즐기면서 제품을 오랫동안 사용하 시기 바랍니다. 본 설명서는 촬영과 재생의 기본에 관해서 설명합니다. 기능에 관한 상세한 내용은, 고 급편을 참조하십시오. 본 설명서를 안전한 곳에 보관하시고 계속해서 사용하시기 바 랍니다.
액세스할 수 있습니다. 앨범 기능을 사 용하여 사진을 정리합니다. 배경 음악과 함께 슬라이드 쇼를 즐길 수 있습니다. 카메라를 TV에 직접 연결 하여 친구들과 가족들에게 보여줄 수 있습니다. 동봉된 OLYMPUS Master를 사용하여 컴퓨터에서 사진을 편집, 열람, 인쇄할 수 있습니다. 사진 정리 Mon Tue Tue Wed...
카메라 켜기 POWER 버튼 배터리 확인 표시 촬영 모드 1/2000 1/2000 F2.8 F2.8 3264 3264 × 2448 2448 배터리 확인 표시 카메라를 켜면 모니터에 배터리 확인 표시가 나타납니다. 켜짐(녹색) (잠시 후 사라짐) 촬영할 준비가 되었습니다. 카메가 조작을 멈춘 경우 카메라는 배터리 전원 절약을 위해, 약 3분 동안 아무 조작도 하지 않으면 자동으로 절전 모드로...
사진 촬영 카메라 잡기 구도 잡기 피사체에 AF 타겟 표시를 맞춥니다. 줌 버튼을 누르면 근접 촬 영을 할 수 있습니다. 초점 맞추기 셔터 버튼을 가볍게 누릅니 다. 초점과 노출이 고정되면 녹 색 램프가 켜집니다. 플래시가 발광할 준비가 되 면 # 표시가 켜집니다. 촬영...
자주 사용하는 기능 설정 다이렉트 버튼 카메라에는 기능을 직접 설정할 수 있는 버튼 기능이 있습니다. QUICK VIEW 버튼 GUIDE 버튼 DISP 버튼 Y/S(셀프 타이머/한 프레임 삭제) 버튼 플래시 모드 설정 촬영 모드에서 O#를 반복적으로 눌러 플래시 모드를 설정합니다. 1/2000 1/2000 F2.8 F2.8 AUTO...
Page 32
자주 사용하는 기능 설정 메뉴 Z를 눌러 모니터에 톱 메뉴를 표시합니다. 각 기능의 설정은 메뉴를 사용 합니다. 저장 모드 설정 촬영 시 사용할 저장 모드를 변경할 수 있습니다. MODE 날짜와 시간 설정 날짜 형식, 연, 월, 일을 설정할 수 있습니다. MODE 모드...
사진 인쇄 USB 케이블을 통해 카메라를 PictBridge 호환 프린터에 연결하면 촬영한 사진을 직접 인쇄할 수 있습니다. 인쇄 선택한 사진을 인쇄합니다. 모두 인쇄 모든 사진을 인쇄합니다. 다중 인쇄 한 장의 사진을 여러 가지 레이아웃 형식으로 인쇄합니다. 모든 인덱스 모든 사진을 인덱스 형식으로 인쇄합니다. 예약...
컴퓨터에서 촬영한 사진 즐기기 동봉된 CD-ROM의 OLYMPUS Master 소프트웨어는 이미지 편집과 관리 를 위한 소프트웨어입니다. 소프트웨어를 설치하여 디지털 사진과 동영상 을 최대한 활용하십시오. OLYMPUS Master란? 카메라에서 이미지 다운로드 파노라마 이미지 제작 이미지 편집(트리밍, 크기조절 등) 달력 형식으로 이미지를 표시하여 관리...
Page 35
USB 케이블 멀티 커넥터 [PC]를 선택하고 Z를 누릅니다. g 고급편 “카메라를 컴퓨터에 연결” (P. 111) 사용자 등록 OLYMPUS Master 소프트웨어를 설치한 다음, 카메라의 사용자 등 록을 하실 것을 권합니다. 등록을 하면 Olympus의 소프트웨어와 펌 웨어 업데이트의 정보를 얻으실 수 있습니다.
Page 36
(CIPA 배터리수명측정법에 준거) : 8,000,000 픽셀 : 1/1.8" CCD (원색 컬러 필터), 8,320,000 픽셀 (총) : Olympus 렌즈 8.0 ~ 24.0 mm, f2.8 ~ 4.9 (35 mm 카메라 환산 38 ~ 114 mm 상당) : 디지털 ESP 측광, 스팟 측광 시스템...
Page 37
: 0°C ~ 40°C (조작시)/-20°C ~ 60°C (보관시) 온도 : 30% ~ 90% (작동시)/10% ~ 90% (보관시) 습도 : Olympus 리튬 이온 배터리(LI-10B/LI-12B)1개 또는 전원 공급 Olympus AC 어댑터 : 102.8 mm (W) × 57.6 mm (H) × 32.9 mm (D) 돌출부 제외...
는 약간 물기있는 천만 사용하십시오. 제품을 청소할 때는 용액, 분무식 클리너 또는 모든 형태의 유기 용제를 절대 사용하지 마십시오. 부속물 — 고객의 안전과 제품 손상 방지를 위해 Olympus에서 권장하는 액세서리 만 사용하십시오. 물과 습기 — 이 제품은 물 근처(욕조, 부엌 싱크대, 세탁용 물통, 습기가 많은 지하...
Page 39
위치 선정 — 제품 손상을 예방하고 상해를 막기 위해 제품을 불안정한 스탠드, 삼 각대, 선반, 탁자 또는 짐수레에 절대로 올려 놓지 마십시오. 안정된 삼각대, 스 탠드 또는 선반 위에만 올려 놓으십시오. 제품을 안전하게 설치하는 방법을 설 명하는 지침을 준수하고 제조업체가 권장하는 설치 장비만 사용하십시오. 전원...
Page 40
안전 주의 사항 서비스가 필요한 손상 — 지정된 AC 어댑터를 사용하는 도중 아래 설명 중 하나가 발생할 경우 콘센트에서 어댑터를 뽑고 서비스를 요청하십시오. a) 제품에 용액이 쏟아졌거나 다른 물체가 제품에 떨어졌습니다. b) 제품이 물에 노출되었습니다. c) 작동 지침을 준수하였음에도 불구하고 제품이 정상적으로 작동하지 않습니 다.
Page 41
한 화재나 감전의 위험이 있습니다. ( 카메라 내부에 물이나 이물질이 들어가지 않도록 주의하십시오. • 카메라를 실수로 물에 빠뜨렸거나 카메라에 액체를 엎지른 경우, 사용을 중 지하고 건조시킨 다음 배터리를 제거하십시오. 가까운 Olympus 서비스 센터 에 수리를 의뢰하십시오. 주의 ( 이상한 냄새, 잡음 또는 연기가 나는 경우 카메라 사용을 즉시 중지하...
Page 42
걸려서 심각한 손상의 원인이 될 수 있습니다. ( Olympus에서 지정한 AC 어댑터만 사용하십시오. • Olympus에서 지정한 AC 어댑터만 사용하십시오. 다른 AC 어댑터를 사용하 면 카메라나 전원에 손상이 가거나 사고 또는 화재가 발생할 수 있습니다. 사 용하는 어댑터가 거주 지역 또는 국가에 적합한 것인지 확인하십시오. 자세...
Page 43
다음은 배터리 누액, 과열, 연소, 폭발 또는 감전이나 화재를 방지하기 위한 중요 한 지침입니다. 위험 • 본 카메라에는 Olympus에서 지정한 리튬 이온 배터리를 사용합니다. 지정한 충 전기만 사용하여 충전하십시오. 다른 충전기는 사용하지 마십시오. • 배터리를 가열하거나 소각하지 마십시오. • 배터리를 운반하거나 보관할 때는 장신구, 핀, 단추 등의 금속 물질과 접촉하지...
Page 44
생활방수 기능 본 카메라는 생활방수 기능을 가지고 있으나 물 속에서는 사용할 수 없습 니다. Olympus는 사용자의 실수로 인해 카메라 내부에 물이 들어가 카메라가 고장난 경우 책임을 지지 않습니다. 본 카메라는 생활방수 기능을 가지고 있으며 어느 방향에서 물이 뿌려져 도 손상되지 않습니다.
Page 45
이 기기는 가정용으로 전자파 적합등록을 한 기기로서 주거지역에서는 물론 모든 지역에서 사용할 수 있습니다. * 인증내역 * 1. 기기명칭(모델명):Stylus 800/µ DIGITAL 800 2. 인증받은자의 상호:올림푸스한국(주) 3. 제조자: 등록 상표 • IBM은 International Business Machines Corporation의 등록 상표입니다. • Microsoft 및 Windows는 Microsoft Corporation의 등록 상표입니다.
