6.1 User Options

Lifting the Manual Controller from its holder will change the text display on the LCD to the manual
operating menu, as seen in Figure 6.1.
Pressing 'GO' once will take you to the next screen, 'User Preferences'. Figure 6.2.
Using the 'Up ⇑ Down ⇓' arrow keys will allow you to scroll through the menu items, as shown in
figure 6.2.
The 'GO' button is used as a means to select or confirm different menu options or settings. By
pressing the 'GO' button, it will generally select or confirm what is shown on the second line of the
LCD text message. There are several settings for which the operator can make changes to or
features to enable/disable. Pressing the 'C' button at any time during the menu selection process will
bring you back to the main menu. The following menu options are available to the user and may be
changed as desired; (not all options are available on all models)
Chapter 6
Settings and
Advanced Features
Figure 6.1
User options
User Preferences User Preferences User Preferences
Press GO Press GO Press GO
Information Information Information
Docking options Docking options Docking options
Figure 6.2
Child Guard Child Guard Child Guard
Safety Tests Safety Tests Safety Tests
Manual
Press GO Press GO Press GO
Press GO Press GO Press GO
Press GO Press GO Press GO
Press GO Press GO Press GO
(Not accessible to user (Not accessible to user
Service Service Service
Password required) Password required)
Press GO Press GO Press GO
51
