Seagate ST3000DM001 Product Manual
Desktop hdd
Hide thumbs
Also See for ST3000DM001:
- Product manual (44 pages) ,
- Product manual (44 pages) ,
- Product manual (38 pages)
Related Manuals for Seagate ST3000DM001
Summary of Contents for Seagate ST3000DM001
- Page 1 Desktop HDD Product Manual Standard models Self-Encryption models ST3000DM001 ST3000DM002 ST2000DM001 ST2000DM002 ST1500DM003 ST1000DM004 ST1000DM003 ST750DM003 ST500DM002 ST320DM000 ST250DM000 100686584, Rev. P Gen 14 - September 2015...
- Page 2 Publication number: 100686584, Rev. P September 2015 Seagate, Seagate Technology and the Spiral logo are registered trademarks of Seagate Technology LLC in the United States and/or other countries. Desktop HDD and SeaTools are either trademarks or registered trademarks of Seagate Technology LLC or one of its affiliated companies in the United States and/or other countries. All other trademarks or registered trade- marks are the property of their respective owners.
-
Page 3: Table Of Contents
Seagate® Technology Support Services ........ - Page 4 S.M.A.R.T. commands ..........36 Seagate Desktop HDD Product Manual, Rev. P...
- Page 5 Mounting dimensions (1-disk: 250GB to 1TB models) ......25 Seagate Desktop HDD Product Manual, Rev. P...
-
Page 6: Seagate® Technology Support Services
Authorized Service Centers For information regarding Warranty Support, visit: http://www.seagate.com/support/warranty-and-replacements/ For information regarding data recovery services, visit: http://www.seagate.com/services-software/seagate-recovery-services/ recover/ For Seagate OEM and Distribution partner portal, visit: http://www.seagate.com/partners For Seagate reseller portal, visit: http://www.seagate.com/partners Seagate Desktop HDD Product Manual, Rev. P... -
Page 7: Introduction
• Native Command Queuing with command ordering to increase performance in demanding applications. • Full-track multiple-sector transfer capability without local processor intervention. • Seagate AcuTrac™ servo technology delivers dependable performance, even with hard drive track widths of only 75 nanometers. -
Page 8: About The Sata Interface
SATA ports are represented to host software as a Device 0 (master) and Device 1 (slave) accessed at Note the same set of host bus addresses. A host adapter that emulates a master/slave environment manages two sets of shadow registers. This is not a typical SATA environment. Seagate Desktop HDD Product Manual, Rev. P... -
Page 9: Drive Specifications
Standby to ready (max) <17.0s <10.0s Average seek, read (typical) <8.5ms typical Average seek, write (typical) <9.5ms typical Startup current 12V 2.0A or 2.8A 2.0A Voltage tolerance (including noise) 5V: ±5% 12V: +10% / -7.5% Seagate Desktop HDD Product Manual, Rev. P... - Page 10 ** One GB equals one billion bytes and 1TB equals one trillion bytes when referring to hard drive capacity. Accessible capacity may vary depending on operating environment and formatting. * ** During periods of drive idle, some offline activity may occur according to the S.M.A.R.T. specification, which may increase acoustic and power to operational levels. Seagate Desktop HDD Product Manual, Rev. P...
- Page 11 2Hz to 22Hz: 0.25 Gs, Limited displacement 22Hz to 350Hz: 0.50 Gs 350Hz to 500Hz: 0.25 Gs Vibration, non-operating 5Hz to 22Hz: 3.0 Gs 22Hz to 350Hz: 3.0 Gs 350Hz to 500Hz: 3.0 Gs Drive acoustics, sound power Seagate Desktop HDD Product Manual, Rev. P...
-
Page 12: Formatted Capacityy
320GB 625,142,448 ST250DM000 250GB 488,397,168 *One GB equals one billion bytes and 1TB equals one trillion bytes when referring to hard drive capacity. Accessible capacity may vary depending on operating environment and formatting. Seagate Desktop HDD Product Manual, Rev. P... -
Page 13: Lba Mode
Maximum sustained data transfer rate, OD read (MB/s) 3TB, 2TB, 1.5TB, 1TB and 750GB models 500GB, 320GB, 250GB models Average data rate, read/write (MB/s) 3TB, 2TB, 1.5TB, 1TB and 750GB models 500GB, 320GB, 250GB models I/O data-transfer rate (MB/s max) Seagate Desktop HDD Product Manual, Rev. P... -
Page 14: Physical Characteristics
(such as track-to-track and average), are expected to meet the noted values. However, due to Note the manner in which these drives are formatted, benchmark tests that include command overhead or measure logical seeks may produce results that vary from these specifications. Seagate Desktop HDD Product Manual, Rev. P... -
Page 15: Start/Stop Times
Idle mode power is measured with the drive up to speed, with servo electronics active and with the heads in a random track location. • Standby mode During Standby mode, the drive accepts commands, but the drive is not spinning, and the servo and read/write elec- tronics are in power-down mode. Seagate Desktop HDD Product Manual, Rev. P... - Page 16 Sleep 0.79 0.350 0.010 *During periods of drive idle, some offline activity may occur according to the S.M.A.R.T. specification, which may increase acoustic and power to operational levels. †5W IDLE with DIPLM Enabled Seagate Desktop HDD Product Manual, Rev. P...
-
Page 17: Conducted Noise
If the standby timer reaches zero before any drive activity is required, the drive makes a transition to Standby mode. In both Idle and Standby mode, the drive accepts all com- mands and returns to Active mode when disk access is necessary. Seagate Desktop HDD Product Manual, Rev. P... -
Page 18: Environmental Specifications
–304.8m to 3048m (–1000 ft. to 10,000+ ft.) Non-operating –304.8m to 12,192m (–1000 ft. to 40,000+ ft.) Maximum storage condition not to exceed 90 days at a wetbulb temperature of 32°C (example: 34°C / 90% RH) Note Seagate Desktop HDD Product Manual, Rev. P... -
Page 19: Shock
The maximum non-operating vibration levels that the drive may experience without incurring physical damage or degradation in performance when subsequently put into operation are specified below. 5Hz to 22Hz 3.0 Gs (Limited displacement) 22Hz to 350Hz 3.0 Gs 350Hz to 500Hz 3.0 Gs Seagate Desktop HDD Product Manual, Rev. P... -
Page 20: Acoustics
Seagate follows the ECMA-74 standards for measurement and identification of PDTs. An exception to this process is the use of the absolute threshold of hearing. Seagate uses this threshold curve (originated in ISO 389-7) to discern tone audibility and to compensate for the inaudible components of sound prior to computation of tone ratios according to Annex D of the ECMA-74 standards. -
Page 21: Reliability
EN 55024. Drives are tested in representative end-user systems. Although CE-marked Seagate drives comply with the directives when used in the test systems, we cannot guarantee that all systems will comply with the directives. The drive is designed for operation inside a properly designed enclosure, with properly shielded I/O cable (if necessary) and terminators on all unused I/O ports. -
Page 22: Fcc Verification
As a subassembly, no Federal Communications Commission verification or certification of the device is required. Seagate has tested this device in enclosures as described above to ensure that the total assembly (enclosure, disk drive, motherboard, power supply, etc.) does comply with the limits for a Class B computing device, pursuant to Subpart J, Part 15 of the FCC rules. -
Page 23: Environmental Protection
The silver, copper, nickel and gold films used in Seagate products are especially sensitive to the presence of sulfide, chloride, and nitrate contaminants. Sulfur is found to be the most damaging. -
Page 24: Configuring And Mounting The Drive
For installations which require cables, users can connect the drive as illustrated in Figure 1 Attaching SATA cabling Signal connector Power connector Signal cable Power cable Each cable is keyed to ensure correct orientation. Desktop HDD drives support latching SATA connectors. Seagate Desktop HDD Product Manual, Rev. P... -
Page 25: Drive Mounting
3 MINIMUM THREAD DEPTH 0.15 MAXIMUM FASTENER PENETRATION 2x 3.750 in 95.25 mm Drawings are for mounting hole reference only. Note PCBA show in pictorial only and can vary based on specific customer configurations. Seagate Desktop HDD Product Manual, Rev. P... -
Page 26: Figure 3 Mounting Dimensions (1-Disk: 250Gb To 1Tb Models)
3 MINIMUM THREAD DEPTH 0.15 MAXIMUM FASTENER PENETRATION 2x 3.750 in 95.25 mm Drawings are for mounting hole reference only. Note PCBA show in pictorial only and can vary based on specific customer configurations. Seagate Desktop HDD Product Manual, Rev. P... -
Page 27: About (Sed) Self-Encrypting Drives
• Trusted Send • Trusted Receive These commands are used to convey the TCG protocol to and from the drive in their command payloads. Seagate Secure SEDs also support TCG Single User Mode, which can be disabled. 4.1 Data Encryption Encrypting drives use one inline encryption engine within each drive employing AES-256 algorithms in Cipher Block Chaining (CBC) mode to encrypt all data prior to being written on the media and to decrypt all data as it is read from the media. -
Page 28: Drive Locking
In addition to providing a locking mechanism to prevent unwanted firmware download attempts, the drive also only accepts download files which have been cryptographically signed by the appropriate Seagate Design Center. Three conditions must be met before the drive will allow the download operation: 1. -
Page 29: Sata Interface
There are three power pins for each voltage. One pin from each voltage is used for pre-charge when installed in a blind-mate backplane configuration. • All used voltage pins (V ) must be terminated. Seagate Desktop HDD Product Manual, Rev. P... -
Page 30: Supported Ata Commands
Read Native Max Address Extended Read Sectors Read Sectors Extended Read Sectors Without Retries Read Verify Sectors Read Verify Sectors Extended Read Verify Sectors Without Retries Recalibrate Security Disable Password Security Erase Prepare Security Erase Unit Seagate Desktop HDD Product Manual, Rev. P... - Page 31 Write DMA Extended Write DMA FUA Extended Write DMA Without Retries Write Log Extended Write Multiple Write Multiple Extended Write Multiple FUA Extended Write Sectors Write Sectors Without Retries Write Sectors Extended Write Uncorrectable Seagate Desktop HDD Product Manual, Rev. P...
-
Page 32: Identify Device Command
Number of current logical heads xxxx Number of current logical sectors per logical track xxxx 57–58 Current capacity in sectors xxxx Number of sectors transferred during a Read Multiple xxxx or Write Multiple command Seagate Desktop HDD Product Manual, Rev. P... - Page 33 Ultra DMA support and current mode (see note following this table) xx7F Security erase time 0039 Enhanced security erase time 0039 Master password revision code FFFE Hardware reset value xxxx Automatic acoustic management 8080 95–99 ATA-reserved 0000 Seagate Desktop HDD Product Manual, Rev. P...
- Page 34 SMART error login is supported. SMART self-test is supported. Media serial number is supported. Media Card Pass Through Command feature set is supported. Streaming feature set is supported. GPL feature set is supported. Seagate Desktop HDD Product Manual, Rev. P...
- Page 35 Ultra DMA mode 2 is currently active. Ultra DMA mode 3 is currently active. Ultra DMA mode 4 is currently active. Ultra DMA mode 5 is currently active. Ultra DMA mode 6 is currently active. Seagate Desktop HDD Product Manual, Rev. P...
-
Page 36: Set Features Command
Disable use of SATA features Enable read look-ahead (read cache) feature (default). Report full capacity available At power-on, or after a hardware or software reset, the Note default values of the features are as indicated above. Seagate Desktop HDD Product Manual, Rev. P... -
Page 37: Commands
S.M.A.R.T. Enable Operations S.M.A.R.T. Disable Operations S.M.A.R.T. Return Status If an appropriate code is not written to the Features Register, the command Note is aborted and 0x04 (abort) is written to the Error register. Seagate Desktop HDD Product Manual, Rev. P... -
Page 38: Publication Number: 100686584, Rev. P September
