Philips HD9040 Service Manual

Philips Consumer Lifestyle
Service Manual
PRODUCT INFORMATION
- This product meets the requirements regarding
interference suppression on radio and TV.
- After the product has been repaired, it should function
properly and has to meet the safety requirements as
officially laid down at this moment.
TECHNICAL INFORMATION
- Voltage
- Power consumption
- Power standby
- Dimensions (w x d x h)
- Length power cable
- Colour setting
- SAP coding
DISASSEMBLY- AND RE-ASSEMBLY ADVISE
- Before you start dismantling!
For your safety be sure the plug is
!
disconnected from the mains!
Published by Philips Consumer Lifestyle
10/12
: 220 - 240 V, 50 - 60 Hz
: 850 W
: 0.5 W
: 275 x 420 x 305 mm
: 1.35 Meter
: Black
: HD9040
Printed in the Netherlands
REPAIR INSTRUCTIONS
Note:
!
Be aware of the sharp edges of the appliance,
Use hand cloves to repair the appliance.
1. Remove the Lid assy (4). Use a Phillips screwdriver to
remove screw A.
2. Remove the Control panel assy (3). Remove the 2 screw
covers (12) out of the panel and use a Phillips screwdriver
to remove screws B.
(Tip: use an air pump to remove the screw covers)
3. Remove the Heating element assy (20). Remove the
5 screw covers (13) out of the cover and use a Phillips
screwdriver to remove the screws
the wires from the PCB.
(Tip: use an air pump to remove the screw covers)
4. Remove the PCB (17). Use a Phillips screwdriver to
remove screws F and disconnect the wires.
5. Remove the Motor PCB (14). Use a Phillips screwdriver
to remove screws G and disconnect the wires.
6. Remove the motor assy (15). Use a Phillips screwdriver to
remove screws H.
OPTIONAL (accessories)
- No specific issues
© Copyright reserved
Bread Maker
HD9040
C and D. Disconnect
Subject to modification
