Summary of Contents for Olevia LT32HVM Series
- Page 1 LCD Multi-Media Display LT32HVE / LT32HVM Series MK0-UM00091G000...
-
Page 2: Table Of Contents
Table of C ontents Important Information Important Safety Precautions FCC Statement Accessories Installation And Connection Guide Identifying Front Controls and Rear Inputs -Descriptions of Input Types -Connecting the TV's Power Installation Connecting to an Antenna or Video Equipment with Antenna outlet -Connecting to a VCR -Connecting to an Audio Receiver/Home Theater System Connecting to a DVD Player with A/V or S Video Cables... -
Page 3: Important Information
Import ant information Caution Risk of electronic shock Do not open To reduce the risk of electronic shock, do not remove cover (or back). No user-serviceable parts inside. Refer service to qualified Repair Technician or Repair Center. Read the following context indicated by the following symbol to the left. -
Page 4: Important Safety Precautions
Import ant safety precautions Cleaning Remember to unplug the AC cord from the AC outlet before cleaning the display unit. And do not use liquid cleaners or aerosol cleaners to clean the display. Ventilation Do not cover or block these vents and openings located on the top and back of the display. -
Page 5: Power Source
Important safety precautions Never insert objects or spill liquid into the display unit Never insert any object into the display unit through openings or spill liquid on the display unit. High voltage flows in the display unit, and inserting an object can cause electric shock and/or short internal parts. -
Page 6: Replacement Parts
Replacement parts In case the display unit needs replacement parts, make sure that the service technician uses replacement parts specified by the manufacturer, or those with the same characteristics and performance as the original parts. Use of unauthorized parts can result in fire, electric shock and/or other danger. -
Page 7: Fcc Statement
FCC Statement FCC notice This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 8: Accessories
Remote control & batteries (AAA x 2) Power cord x 1 VGA cable (D-Sub 15 male) x 1 User manual booklet x 1 LCD Multi-Media Display LT32HVE / LT32HVM Series QSG x 1 LCD Multi-Media Display Quick Start Guide LT32HVE / LT32HVM Series... -
Page 9: Optional Accessories
Accessories Optional accessories AV cable with RCA connector Wall mount set Model# WM-20D S-video cable DVI cable Audio cable with RCA connector Component cable with RCA connector Audio cable with stereo mini jack Use the proper cable for the device. ( Stereo mini jack cable ) ( Stereo mini jack to RCA cable ) -
Page 10: Front Panel
TV Installation and Connection Guide Identifying Front and Rear Panels Front Panel Turns display on/off POWER Displays the On Screen Display(OSD) MENU menu. In OSD menu, press it to return to pre-phase Source VOL- VOL+ Menu Power Adjusts Channel. In the OSD menu, / CH both keys are used to navigate within menu. -
Page 11: Identifying Front And Rear Connectors
TV Installation and Connection Guide Identifying Front and Rear Connectors Rear Panel DVI / HDCP Service Port AC IN power cord connects here. DVI/HDCP and VGA Port This display includes a DVI input that receives analog or digital video signals through the interface for the display of high quality digital video signals. -
Page 12: Descriptions Of Input Types
Descriptions of Connector Types You may find it necessary to use some of the following connector types during setup. 75-ohm coaxial cable Used for TV cable connection . S-Video Cable High quality video cable for enhanced picture quality. Audio/Video Cable Some DVD players are equipped with the following three video connectors: TV Installation and Connection Guide Video Yellow... -
Page 13: Connecting The Power Cord
TV Installation and Connection Guide Connecting the Power Cord Complete other connections prior to connecting the power cord: 1.Connect the power cord to the AC IN connector of the TV 2.Connect the other end of the power cord to the wall outlet. -
Page 14: Installation
TV Installation and Connection Guide Installation In the following pages, you will find directions on how to install your tv and choice of video equipment. Connecting to an Antenna or Video Equipment with Antenna outlet Connecting to a VCR Connecting to an Audio Receiver/Home Theater System Connecting to a DVD Player with A/V or S Video Cables Connecting to a DVD Player with Component Cables Connecting to a Satellite Receiver or Cable Box with A/V Cables... -
Page 15: Connecting To An Antenna Or Video Equipment With Antenna Outlet
TV Installation and Connection Guide Connecting to an Antenna or Video Equipment with Antenna ou tlet Disconnect all power sources before making any connection. 1.Connect a 75-ohm coaxial cable onto the ANT input on the back of the TV's right side panel. 75-ohm coaxial cable If connecting to Video Equipment with Antenna outlet 1.Using a 75-ohm coaxial cable (or choice of Antenna Cable), connect... -
Page 16: Connecting To A Vcr
Connecting to a VCR Disconnect all power sources before making any connections. Use this hookup if you subscribe to a cable TV system that does not require a cable box. 1.Using A/V cable and S-Video cables, connect the VCR's Audio and S Video OUT jacks to the TV's Audio and S-Video In jacks. -
Page 17: Connecting To An Audio Receiver/Home Theater System
TV Installation and Connection Guide Connecting to an Audio Receiver Disconnect all power sources before making any connections. 1.Using an audio cable, connect the TV's audio OUT jack to the audio receiver's audio IN or AUX IN jacks. Audio Receiver Audio cable Note: When connecting an Audio output signal, an external Audio amplifier is necessary to amplify the signal for external speakers. -
Page 18: Connecting To A Dvd Player With A/V Or S Video Cables
Connecting to a DVD Player with A/V or S Video Cables Disconnect all power sources before making any connections. Use this hookup if your DVD player does not have component (Y, Pb, Pr) jacks. Note: If your DVD player has component video output connectors, for best picture quality, use the connection described for Connecting to a DVD Player With Component Connectors.(See page.17) 1.Using an A/V cable, connect the DVD player's Audio OUT jacks to... -
Page 19: Connecting To A Dvd Player With Component Cables
TV Installation and Connection Guide Connecting to a DVD Player With Component Cables Disconnect all power sources before making any connections. Use this hookup if your DVD Player has component (Y, Pb, Pr) jacks. 1.Using a component video cable, connect the DVD Player's Y, Pb and Pr jacks to the Y, Pb and Pr jacks on the TV. -
Page 20: Connecting To A Satellite Receiver Or Cable Box With A/V Cables
Connecting to a Satellite Receiver or Cable Box with A/V Connectors Disconnect all power sources before making any connections. 1.Using Audio and S Video cables, connect the satellite receiver's Audio and S Video OUT jacks to the TV Audio and S Video IN jacks. 2.Connect a 75-ohm coaxial cable from your cable or antenna to the Satellite Receiver's or Cable Box's Ant (Antenna) jack. -
Page 21: Connecting To A Satellite Receiver Or Cable Box With Component Connectors
TV Installation and Connection Guide Connecting to a Satellite Receiver or Cable Box With Component Connectors Disconnect all power sources before making any connections. Use this hookup if your Satellite Receiver or Cable Box has component (Y, Pb, Pr) jacks. 1.Using a component video cable, connect the Satellite Receiver or Cable Boxes' Y, Pb and Pr jacks to the Y, Pb and Pr jacks on the TV. -
Page 22: Connecting To A Pc With Vga, And A Dvd Player With Dvi/Hdcp Cables
Connecting to a PC with VGA Connector Disconnect all power sources before making any connections. 1.Using a D-Sub 15 pin cable, connect the VGA output terminal of the PC to the TV's VGA signal input terminal. 2.You may need to use a Stereo mini jack to RCA L/R connectors to receive audio. -
Page 23: Other Connections
TV Installation and Connection Guide Other Connections Disconnect all power sources before making any connections. See setup instructions for: Connecting to an Audio Receiver on page 15. Speaker Outputs White Headphone Set Right Side of TV Note: When headphone is plugged in the speaker will turn into mute mode. Rear of TV Audio Output Ear Phone... -
Page 24: Remote Control Guide
Remote Control Guide Remote Function Keys & Description Regular Buttons POWER Press to turn display on/off. CH + / CH - Press to adjust channel up and channel down. NUMBER BUTTONS Press the number buttons to select channels on the display. VOL+/ VOL- Press to adjust the volume. -
Page 25: Hotkeys Tutorial
Remote Control Guide Hot Keys Tutorial The remote control contains 15 additional "Hotkeys" that represent direct access to a certain function on your TV. Hotkeys enable you to directly change the setting to your preference without having to navigate through the OSD (On Screen Display) Menu. How to use your Hot Keys HOT KEY FUNCTION TV / VIDEO Press to select a video signal from different sources (TV 1... -
Page 26: Battery Installation
Battery Installation 1.Push the tab and pull it out as illustrated below. 2.Insert two size AAA batteries (supplied) by matching the (+) and (-) on the batteries to the diagram inside the remote control's battery department. 3.Replace the cover back and make sure the cover "snaps" into the remote control. -
Page 27: Introduction
Adjusting On Screen Displays (OSD) Introduction After you have finished connecting your TV, you are now ready to choose and personalize your TV settings in the OSD (On Screen Display) menu. There are four main sections in the OSD Menu: Video Audio Miscellaneous... -
Page 28: Video Adjusting Tv Picture Settings
OSD-Video VIDEO Adjusting TV Picture Settings Advance Video Quality In this Setup Index, you can adjust the video and picture settings to suit your personal preferences. Video Settings Item Adjustment Brightness 0~100 Contrast 0~100 Saturation 0~100 0~100 Sharpness 0~100 Color temp Cool / Middle / Warm / User Red Gain 0~100... - Page 29 Adjusting On Screen Displays (OSD) Advance P Adjust icture To further adjust specific picture settings, enter this function by pressing button. Advance Picture Adjust Definition of Terms Item Status Off/Low/Middle/Strong Black Level Extender On/Off White Peak Limitator On/Off Flesh Tone On/Off Adaptive Luma Control On/Off...
-
Page 30: To Adjust Settings
OSD-Video To Adjust S ettings: Use the remote buttons to adjust each Video picture setting, as seen below: Brightness Saturation To exit, press the Button Enter To Reset Factory Settings If, at any time, you wish to go back to original factory setting, you may do so by choosing the Default setting in the OSD Picture and Audio Sections. -
Page 31: Auto Setting : Return To Default Factory Settings
Adjusting On Screen Displays (OSD) Audio Adjusting Sound Quality Audio setting Definition of Terms Item Adjustment Treble -50~50 Bass -50~50 Balance -20~20 Surround On / Off Equalizer 1 Off, Concert, Living Room, Hall, Arena, Church Equalizer 2 Off, Rock, Pop, Live, Classic, Soft Mono, Stereo, SAP Speakers... -
Page 32: Audio Adjusting Sound Quality
OSD-Audio To Adjust S ettings: Use the remote buttons to adjust each Audio sound quality, as seen below: Treble Bass Balance Surround Sound is an available option for creating a panoramic stereo audio image by producing deep and rich bass tones and clear treble tones. -
Page 33: Osd Audio Settings: Equalizer 1
OSD-Audio Adjusting On Screen Displays (OSD) OSD Audio Settings: Equalizer 1 OSD Audio Settings: Equalizer 2... -
Page 34: Mts System For Stereo Tv
OSD-Audio MTS System for Stereo TV You can enjoy stereo, bilingual and mono programs. Additionally, you can press the hotkey "MTS" until the desired sound in dication appears. Each time you press the button, the sound indication changes as follows: Mono, Sap, Stereo Definifion of Terms Sound Effect... -
Page 35: Miscellaneous Adjusting Personal Tv Settings
Adjusting On Screen Displays (OSD) MISCELLANEOUS Adjusting Personal TV Settings In this Section, you can adjust additional TV settings to your personal preference, including channel setup, choosing tuner modes, setting up timer, closed caption services, parental controls, and viewing the OSD in your preferred language. -
Page 36: Setting The Channels
OSD-Miscellaneous Setting the Channels After you finish connecting your TV, you can run Auto Scan program to setup your channels. The program will scan and preset all receivable channels automatically. To Cancel Auto Program Exit auto scan program by pressing "menu" Key. Note: The Auto Scan is set to scan cable TV channels by default. -
Page 37: Personal Channel Preferences : Channel Skip/Lock
Adjusting On Screen Displays (OSD) Watching favorite channels To watch you favorite channels after specifying your preferences, just press the Hotkey "FAVORITE" to browse through each favorite channel. Editing Channels You can also edit channels to your personal preference. Once you edit a channel, it will be skipped when surfing through TV channels. -
Page 38: Personal Channel Preferences: Channel Naming
OSD-Miscellaneous Adjusting On Screen Displays (OSD) Personal Channel Preferences: Channel Naming You can also create personal names for each channel, which will show up in the upper Right hand corner of the TV screen. To Name a Channel: 1. Enter Channel Name sub-page 2. -
Page 39: Setting Up The Tv Timer
OSD-Miscellaneous Adjusting On Screen Displays (OSD) Setting up the TV Timer To setup the time on the TV: 1.Using keys, enter in HH: MM: SS Enter the time using the number keys found on the remote. 2.press "Enter" when complete. NOTE: Clock will NOT BE affected when Factory Default settings are reset.Under Activate, "ON"... -
Page 40: Watching With Closed Caption
OSD-Miscellaneous Timer: Start Time / Stop Time You can set the TV to turn On and/or Off automatically at a predetermined time through the timer function. Use the Start Time to setup the hour and minute preferences. Your TV will automatically turn on at the set time. Use the Stop Time to setup the hour and minute preferences. -
Page 41: Tv Osd Languages
Adjusting On Screen Displays (OSD) TV OSD Languages There are nine language formats available for the OSD Menu. You may choose from the following: English, Chinese Traditional, Chinese Simplified, Deutsch, Francese, Italiano, Espanol, Portugues and Pycc Using the Parental Control Feature To block programs you feel unsuitable for your children, you need to Set the TV for desired rating systems. -
Page 42: Parental Control
OSD-Miscellaneous Parental Control 1. This function allows programs to be restricted and controlled by parents based on FCC regulation. It prevents children from watching program contents that may be prohibited by parents. 2. Restriction of programs is based on three Rating Systems: MPAA Rating, TV (Child) Rating and TV (Entire Audience) Rating. -
Page 43: Activating The Parental Control Feature
Adjusting On Screen Displays (OSD) Activating the Parental Control Feature Once you enter the highlighted section of Parental Control, you will have to enter your password. The Factory Default password is"9999". Once you enter the Parental Control Menu, you may change the password to your personal preference. -
Page 44: To Block Unrated Channels
OSD-Miscellaneous Adjusting On Screen Displays (OSD) MPAA Rating controls channels and movies that are rated from G, PG-13, R, NC-17, and X. TV Rating controls channels and movies that have been rated from TV-Y, TV Y-7, TV-G, TV-PG, TV-14, and TV-MA. To Block Unrated Channels You may choose "YES"... -
Page 45: Setting Up Parental Control Password
OSD-Miscellaneous Adjusting On Screen Displays (OSD) Setting up Parental Control Password Enter the password sub-page. Enter the current password. If this is the first time, you do not have to enter a password. You will have to enter and confirm your password before changing to a new password. -
Page 46: Factory Default Option
OSD-Miscellaneous Factory Default Option Reset Factory Settings: Initiating Factory Default will reset all OSD settings to original manufacture settings. The only items, which will remain unaffected are: Clock Auto Scan Channels Edited Channels Parental Control Password Adjusting On Screen Displays (OSD) -
Page 47: Screen Adjusting Screen Modes
Adjusting On Screen Displays (OSD) Adjusting Screen Modes There are two option in the Screen Modes, "aspect & "View." Apect will allow user to select different aspect ratios, whereas, View will all different modes of viewing 1 or 2 sources. Changing the Screen Mode You can alter the aspect ratio of a picture by choosing between these four options: Input... -
Page 48: Picture In Picture (Pip)
OSD-Screen Changing the View Modes You can select four view types of picture modes that best suits the program you are watching. You can set a different view mode for each video mode for each input and store it manually. View Modes Function Picture-in-Picture has a Main screen and small screen view... - Page 49 OSD-Screen Adjusting On Screen Displays (OSD) OSD View TV View...
-
Page 50: Pip Mode
OSD-Screen PIP mode You may adjust setting for each Picture source. Pic 1 allows for a TV, AV1, AV2 and DVI sources while Pic 2 supports all other input sources. Item Adjustment PIP Position Upper Left / Upper Right / Lower Left / Lower Right PIP-Pic1 TV1,AV1, AV2, DVI... -
Page 51: Split Screen
Adjusting On Screen Displays (OSD) Split Screen Allows you to view two separate screens simultaneously (Picture 1 and Picture 2). Press 'source' button to switch from P1 to P2 and vice versa. OSD View TV View Pic1 Pic1 OSD-Screen Pic2 Pic2... -
Page 52: Split Screen Mode
Split Screen mode You may adjust setting for each Picture source. Only Pic1 supports a TV input source, while Pic2 supports all other TV input sources. Item Adjustment Pic1 TV1, AV1, AV2, DVI Pic2 AV1, AV2, S-Video1, S-Video2, YpbPr1, YpbPr2, DVI, VGA Note: Pic 1 allows for a TV, AV1, AV2 and DVI. -
Page 53: Specifications
Specifications Specifications LT32HVE Panel Size 32" Aspect Ratio 16:9 Pixels 1366 X 768 Dynamic Contrast Ratio 1600:1 H/V(View Angle) 178 (H) / 178 (V) Gray to Gray Response Time 8 ms Video/Graphic Processing PC Compatible Frequency 30~85 KHz(H) / 50~80Hz(V) Max. - Page 54 Output Terminals LT32HVE Audio Output(Rear) Others (Voltage) Power (Power Consumption) Stand-by Dimensions (W x D x H) Carton Dimensions (W x D x H) Weight w/o stand Weight Gross Weight Dimensional drawing 25.59in 39.8in LT32HVM Output 1: Stereo Audio R/L x1 Output 1: Stereo Audio R/L x1 Output 2: Earphone x 1 Output 2: Earphone x 1...
-
Page 55: Timing Mode For Vga And Dvi
Timing Mode for VGA and DVI Resolution Vertical frequency(Hz) Source 480p YPbPr 720p 1080i 512 x 384 640 x 350 640 x 400 640x480 720 x 350 720 x 400 800 x 600 832 x 624 1024 x 768 Horizontal frequency (Khz) 59.94 31.469 33.75... - Page 56 Source Resolution Vertical frequency(Hz) 1024 x 768 1152 x 864 1152 x 870 1152 x 900 1024 x 1024 1280x 960 1280 x 720 1280 x 768 1280 x 1024 1366 x 768 1024 x 768 1280 x 720 800 x 600 1024 x 768 1280 x 768 1366 x 768...
-
Page 57: Pixels Policy
Pixels Policy Syntax's D.O.A. Policy for LCD TVs for Defective Pixels on LCD Panels (Applicable to the LCD TV sold within USA & Canada only) Syntax LCD TVs are evaluated at a distance of approximately 50 centimeters (approximately 20 inches) between the LCD panel and the eyes of the user at a 90 degrees viewing angle. -
Page 58: Glossary
Channel Favorite - Feature on the OSD for the Syntax Olevia models that allows the user to scroll through a defined list of channels that the user sets up. Channel Edit - Feature on the OSD for the Syntax Olevia models that allows the user add or delete a channel. - Page 59 DVI-I - Digital Video Interface Integrated; Cable that supports analog and digital signals; See DVI DTV - Digital Television Factory Default - Feature on the OSD for the Syntax Olevia models that resets all menu options to factory default. F-Connector - The standard connector found on video equipments that coaxial cables connect to.
- Page 60 1/60 of a second, before reassembling the even lines which results in a full picture. Antonym: Progressive Language - Feature on the OSD for the Syntax Olevia models that enables the OSD to be read in different languages.
- Page 61 Glossary Swap - Button featured on the Olevia remote. Used in the POP3 or PIP12 views to swap the sub viewable boxes with the main viewable box. Tint - Adjusts the whiteness level within the color . Similar to Hue.
