4-38 Diagnostics

ENCODER TYPE

This diagnostic indicates the encoder type:
OSD Description
Not Inst Not Installed
MPEG2 MPEG2
Other Other
Unknown Unknown

RECORD QUALITY

This diagnostic indicates the current quality setting for the encoder. This setting may change at
any time via software. RECORD QUALITY is only valid for the encoding of analog services.
OSD Description
LOW1 Video bit rate of 1 Mbps
LOW2 Video bit rate of 2 Mbps
MEDIUM1 Video bit rate of 3 Mbps
MEDIUM2 Video bit rate of 4 Mbps
HIGH1 Video bit rate of 5 Mbps
HIGH2 Video bit rate of 6 Mbps

DVR Enabled Disk Drive Information Table

This diagnostic displays the recording capacity remaining for each disk drive. Currently, only
one IDE disk drive is supported.
DISK DRIVE types are IDE (internal), 1394 or USB (external).
RECORD CAPACITY REMAINING indicates the remaining recording capacity in bytes.
If the disk drive is not enabled or configured, NOT AVAILABLE is displayed in the DVR Enabled
Disk Drive Information Table.
