Port page ..........151 Figures Using the Passport 8672ATME Module...
• Understanding of the transmission and management protocols used on your network • Experience with windowing systems or graphical user interfaces (GUIs) ® 8672ATME Module is part of the Nortel Networks Passport line of Using the Passport 8672ATME Module...
Preface Text conventions This guide uses the following text conventions: angle brackets (< >) bold Courier text braces ({}) brackets ([ ]) ellipsis points (. . . ) 209195-B Indicate that you choose the text to enter based on the description inside the brackets.
( > ) vertical line ( Related publications For more information about using a Passport 8000 Series switch, the resident CLI, or Device Manager, refer to the following publications: • Release Notes for the Passport 8000 Series Switch Release 3.2 (part number...
Page 22
Preface • Installing and Maintaining the Passport 8003 Chassis and Components (part number 313074-B Rev 00) Provides instructions for installing the Passport 8003 Chassis in an equipment rack and for installing and replacing fan trays, power supplies, modules, gigabit interface converters, and media dependent adapters. This guide describes some of the routine tasks of operating the Passport 8003 Chassis and includes technical specifications for the chassis and the modules.
Page 23
VLANs, MultiLink Trunking, OSPF, RIP, and IPX. • Network Design Guidelines for the Passport 8000 Series Switch (part number 313197-B Rev 00) Provides guidelines for using the switching and routing features of the Passport 8000 Series hardware and software in your network design.
You can purchase selected documentation sets, CDs, and technical publications through the Internet at the How to get help If you purchased a service contract for your Nortel Networks product from a distributor or authorized reseller, contact the technical support staff for that distributor or reseller for assistance.
Passport 8600 Routing Switch. (For more information on ATM, refer to the ATM Forum Web site at the http://www.atmforum.com URL.) The Passport 8672ATME Module occupies a single slot in a Passport 8600 series chassis. The module is a baseboard with room for two of the following optional Media dependent adapters (MDAs): •...
Chapter 1 About the Passport 8672ATME Module You can use up to two Passport 8672ATME Modules in one Passport 8600 series chassis. Refer to Networking Concepts for the Passport 8000 Series Switch for a thorough discussion of the complete functionality of the Passport 8000 series product line, including the Passport 8672ATME Module.
If you delete a VLAN, you delete 1483 ELANs associated with the VLAN. Virtual network router Virtual network router (VNR) refers to the routing functions between two ATM virtual/emulated networks. You can use the Passport 8672ATME Module as an IP- and IPX-optimized VNR. Traffic shaping The Passport 8672ATME Module provides per channel traffic shaping and supports unspecified bit rate (UBR) and variable bit rate (VBR).
PVCs between Centillion ATM virtual ports (VPorts) and other clients based on LLC encapsulation. The current Centillion platform only supports bridged variations of RFC 1483. The Passport 8672ATME Module supports the following types of RFC 1483 ELANs: •...
Figure 1 Passport 8672ATM module To configure and manage the Passport 8672ATME Module, connect to the console port of your switch fabric module (either the Passport 8690SF Module or the Passport 8691SF Module). For information on connecting to the console port, refer to the installation guide that came with your switch.
Figure 4 Passport 8672 ATM module with OC-12c/STM-4 MDA Online LED The front panel of the Passport 8672ATME Module has an Online LED that indicates whether or not the module has power applied and is initialized correctly. When the Passport 8672ATME Module is first inserted into the chassis, the Online LED turns amber until the board is recognized by the system and passes a power-on self-test.
Table 1 lists the Passport 8672ATME Module online LED indications. Passport 8672ATME Module Table 1 Online LED State Card is not receiving power. Amber Card is initializing or downloading. Amber Card is offline. Green Card is online. MDA LEDs Table 2 lists the MDA LED indications.
Console port of either module, refer to Getting Started with the Passport 8000 Series Switch Management Software. The Diag port on the Passport 8672ATME Module is used only by Nortel Networks personnel for debugging purposes. You can see diagnostic messages but you cannot input any text.
ATM uses dedicated media connections running in parallel, allowing simultaneous multiple connections through a single switch device at very high speeds. • PVC: Permanent virtual circuit. Dedicated connection between devices that is manually set up. acronyms,” next Using the Passport 8672ATME Module...
Page 34
Chapter 2 Passport 8672ATME Module terminology • SVC: Switched virtual circuit. On-demand connection between an ATM or frame relay source and destination that lasts for the duration of the transmission. • VC: Virtual circuit. This is a network service that provides connection-oriented service regardless of the underlying network structure.
STS-12c/STM-4 frame structures at 622 Mb/s. Concatenation refers to the fact that there is only one logical data stream (rather than supporting a channelized structure). Chapter 2 Passport 8672ATME Module terminology Using the Passport 8672ATME Module...
Chapter 3 Installing the Passport 8672ATME Module This chapter describes the procedure for installing the Passport 8672ATME Module. It covers the following topics: • “Safety and environmental • “Installing the Passport 8672ATME Module” on page 39 • “Verifying installation” on page 41 •...
Page 38
Chapter 3 Installing the Passport 8672ATME Module • When handling modules, do not touch components on the modules; always handle modules by their edges. Store unused modules in their protective packaging. Warning: Fiber optic equipment can emit laser or infrared light that can injure your eyes.
Note: Always handle an I/O module by the sides and carefully slide it out of the chassis. Place the module on a grounded work surface and in an antistatic bag for storage. Chapter 3 Installing the Passport 8672ATME Module (Figure 9059FA...
Chapter 3 Installing the Passport 8672ATME Module Handling the Passport 8672ATME Module by the sides only, carefully align it with the card guides in the chassis. Slide the module into the slot until the module connectors touch the chassis backplane...
Tighten the retaining screws Figure 9 Tightening the retainer screws You must install at least one MDA on the Passport 8672ATME Module in order to pass traffic. For instructions on installing MDAs, refer to Installing Media Dependent Adapters for the Passport 8672ATME Module.
Chapter 3 Installing the Passport 8672ATME Module Initialization When the Passport 8672ATME Module is installed into a Passport 8600 series chassis, ensure that the switch fabric module (either the Passport 8690SF or Passport 8691SF module) in the same chassis has a PCMCIA card inserted and that the PCMCIA card contains the p80t3200.dld image, which supports the...
Chapter 3 Installing the Passport 8672ATME Module After the image loads onto the Passport 8672ATME Module, it performs a series of self-diagnostic tests. If the module fails the diagnostics, the screen displays the following message: Fatal bring up error on ATM card in slot <number>.
To verify that the Passport 8672ATME Module is ready to receive and transmit traffic, check the LEDs on the module and the MDA. Once you enable the ports using the CLI or Device Manager, the online LED on the module lights steady green, and the module is ready.
Chapter 3 Installing the Passport 8672ATME Module Starting the system after a module replacement After you a replace a module on the chassis, you can expect the following results: • In a running system, when you replace an I/O module with a module of the same type, the system restores the configuration of all the ports.
Web-based management features. Port numbering You must install an MDA into the Passport 8672ATME Module in order to have connectivity. The module contains two slots for MDAs, and you can mix and match among the following MDAs, which are available in both SMF and MMF: •...
5 to 8 apply to the MDA in the right slot regardless of the actual physical number of ports. For example, a Passport 8672ATME Module in the third slot of the Passport 8600 series chassis with an OC-12c/STM-4 MDA in the left slot and an OC-3c/STM-1...
Chapter 4 Managing the Passport 8672ATME Module with Device Manager For detailed information on all aspects of installing and running Device Manager, refer to: • Getting Started with the Passport 8000 Series Switch Management Software • Configuring Switching and Routing Operations for the Passport 8000 Series Switch Using Device Manager Release 5.x.x...
Chapter 4 Managing the Passport 8672ATME Module with Device Manager Figure 11 Passport 8000 series chassis with Passport 8672ATME Module The ports on the graphical image are color-coded to provide at-a-glance port status. Table 3 Table 3 Device Manager port color codes...
Chapter 4 Managing the Passport 8672ATME Module with Device Manager Additionally, many Device Manager windows and dialog boxes contain buttons. Table 4 describes the function of these buttons. Table 4 Device Manager buttons Field Apply Refresh Close Help Insert Resize Columns Note: You must always click Apply at the bottom of the tab to implement any changes you make.
Chapter 4 Managing the Passport 8672ATME Module with Device Manager Changing default settings To change the default settings on the Passport 8000 Series switch or to perform any configuration tasks in Device Manager: On the device view, double-click on the port you want to configure.
Chapter 4 Managing the Passport 8672ATME Module with Device Manager Table 5 describes the Interface tab fields. Table 5 ATM Interface tab fields Item Description Index Unique value assigned to each interface. The value ranges between 16 and 255. Name Displays the name of this port.
Chapter 4 Managing the Passport 8672ATME Module with Device Manager Table 5 ATM Interface tab fields (continued) Item UnknownMacDiscard DirectBroadcastEnable Action Result Resetting the module To reset the module: Highlight the module. From the Device Manager menu bar, choose Edit > Card.
Chapter 4 Managing the Passport 8672ATME Module with Device Manager Figure 13 Card tab Table 6 describes the Card tab fields. Table 6 Card tab fields Field Description FrontType Card type. FrontDescription ATM. FrontAdminStatus Administrative status of the card. FrontOperStatus Operational status of the card.
Chapter 4 Managing the Passport 8672ATME Module with Device Manager Table 6 Card tab fields (continued) Field BackHWVersion BackPartNumer BackDateCode BackDeviations Click the ATM tab. The ATM tab opens Figure 14 ATM tab Click reset. Click Apply. Viewing MDA information To view information on the MDA you are using, Highlight the MDA.
Chapter 4 Managing the Passport 8672ATME Module with Device Manager Click Apply. To enable or disable a port using a shortcut menu: Right-click on the port. A shortcut menu opens. Choose Enable or Disable. Editing port parameters To view or change the general parameters of the port: On the device view, highlight a port.
Chapter 4 Managing the Passport 8672ATME Module with Device Manager Table 8 ATM tab fields (continued) Item FramingMode ClockSource LoopBackMode MacAddress Editing circuit parameters To view and configure ATM PVC parameters: On the device view, highlight a port. From the Device Manager menu bar, choose Edit > Port.
Chapter 4 Managing the Passport 8672ATME Module with Device Manager In the Vpi field, type the VPI-bit size. In the Vci field, type the VCI-bit size. Note: For <vpi.vci>, 0.0 is not supported. In the Name field, type the name of the ATM PVC.
Chapter 4 Managing the Passport 8672ATME Module with Device Manager Figure 19 ATM PVC tab with a PVC selected Click Delete. The PVC is deleted. Configuring ATM 1483 ELAN parameters To view and configure ATM 1483 ELAN parameters for the port: On the device view, highlight a port.
Chapter 4 Managing the Passport 8672ATME Module with Device Manager Table 11 describes the ATM 1483 ELA Table 11 ATM 1483 ELAN tab fields Field Description VlanId VLAN to which the ELAN belongs. ElanId Internal ID of the ELAN. NumPvcIds Number of PVCs pairs used in the ELAN.
Chapter 4 Managing the Passport 8672ATME Module with Device Manager Figure 21 Port, Insert ATM 1483 ELAN dialog box Table 12 describes the Insert ATM 1483 ELAN dialog box fields. Table 12 Port, Insert ATM 1483 ELAN dialog box fields...
Page 67
Chapter 4 Managing the Passport 8672ATME Module with Device Manager In the VlanId field, type the VLAN ID. In the PvcIds field, type the PVC ID. Note: For <vpi.vci>, 0.0 is not supported. In the ConnectType field, select the type of routing protocol: bridged, ip, or ipx.
Chapter 4 Managing the Passport 8672ATME Module with Device Manager Figure 22 Insert ATM 1483 ELAN dialog box for IP routing 10 If Ipx is selected in the ConnectType field, complete the following fields: In the IpxVlanEncapMethod, select the encapsulation method (llc, snap, ether-ii, or raw).
Chapter 4 Managing the Passport 8672ATME Module with Device Manager Figure 23 Insert ATM 1483 ELAN dialog box for IPX routing Deleting an ATM 1483 ELAN To delete an ATM 1483 ELAN: On the device view, highlight a port. From the Device Manager menu bar, choose Edit > Port.
The ATM 1483 ELAN is deleted. Configuring ATM F5-OAM End-to-End Loopback A Passport 8672ATME Module, by default, replies to ATM F5-OAM Loopback requests received. However, the transmission of F5-OAM Loopback requests and the processing of F5-OAM Loopback replies received require enabling this feature on a PVC by PVC basis.
Chapter 4 Managing the Passport 8672ATME Module with Device Manager Table 13 F5 Loopback tab field descriptions (continued) Field LbUpCount LbDownCount TrapEnable Displaying F5 Loopback statistics To display F5 Loopback statistics: From the Device Manager menu bar choose Edit > ATM.
Chapter 4 Managing the Passport 8672ATME Module with Device Manager Table 14 describes the fields in the F5 Loopback Stats tab. Table 14 F5 Loopback Stats tab fields Field VcStatus LbRequestSent LbReplyReceive LbReplySent Displaying statistics using Device Manager Statistics are not supported in Device Manager in this release. See the stats atmport command”...
Page 74
Chapter 4 Managing the Passport 8672ATME Module with Device Manager 209195-B...
Chapter 5 Managing the Passport 8672ATME Module with the CLI You can manage your Passport 8672ATME Module through the command line interface (CLI). You can also use the embedded Web-based management feature to monitor the 8672ATME Module. Refer to Chapter 4, “Managing the Passport 8672ATME Module with Device Manager”...
Chapter 5 Managing the Passport 8672ATME Module with the CLI Configuration commands This section describes the CLI configuration commands available with the Passport 8672ATME Module. There are three types of configuration commands: • “Module • “1483 ELAN statistics” on page 77 •...
Chapter 5 Managing the Passport 8672ATME Module with the CLI Table 15 config atmcard command parameters and variables Parameters and variables card-reset elan-stats <enable|disable> info 1483 ELAN statistics The 1483 ELAN statistics commands allow you to collect ELAN statistics for an ATM port.
Chapter 5 Managing the Passport 8672ATME Module with the CLI show atm elan-stats <vlan id> Use this command to display the ELAN statistics for a particular VLAN ID. If the collection of ELAN statistics is disabled, a message is printed before the ELAN statistics.
Chapter 5 Managing the Passport 8672ATME Module with the CLI Table 16 Information fields for the show atm elan-stats command (continued) Field InDiscards OutDiscards InUcastPkts OutUcastPkts InMcastPkts OutMcastPkts InBcastPkts OutBcastPkts clear atm elan-stats Use this command to clear the ELAN statistics for a particular VLAN ID. The syntax is: clear atm elan-stats <...
Chapter 5 Managing the Passport 8672ATME Module with the CLI config atm command Table 17 describes the parameters and variables for the config atm < ports > command. Table 17 config atm command parameters and variables Parameters and variables action <action choice>...
Chapter 5 Managing the Passport 8672ATME Module with the CLI Table 17 config atm command parameters and variables (continued) Parameters and variables state <enable | disable> info config atm pvc command Table 18 describes the parameters and variables for the config atm pvc command.
Chapter 5 Managing the Passport 8672ATME Module with the CLI Table 18 config atm pvc command parameters and variables (continued) delete <vpi.vci> info [<ports>] config atm pvc 1483 command Use the config atm pvc 1483 commands to configure 1483 parameters on the Passport 8672ATME Module.
Chapter 5 Managing the Passport 8672ATME Module with the CLI Table 19 config atm pvc 1483 bridged command parameters and variables (continued) remove <vid> <vpi.vci> [,<vpi.vci>]... info Table 20 describes the parameters and variables for the config atm pvc 1483 ip command.
Chapter 5 Managing the Passport 8672ATME Module with the CLI Table 21 config atm pvc 1483 ipx command parameters and variables Parameters and variables create <vid> <vpi.vci> <ipx> delete <vid> info config atm info command Figure 29 shows a sample of the output resulting from executing the command.
Chapter 5 Managing the Passport 8672ATME Module with the CLI Show commands This section discusses the CLI show commands available with the Passport 8672ATME Module. These commands allow you to view information about the module: show ports info atm all [< ports >] show ports info atm fdb show ports info atm ports [<...
Chapter 5 Managing the Passport 8672ATME Module with the CLI show ports info atm all Figure 30 Passport-8610:5/show/ports/info/atm# all ======================================================= ====================================================== PORT SCRAMBLE FRAMING MAX-BITS CLOCK DESCRIPION ENABLE --------------------------------------------------------------------- OC-12c MM enable Quad OC-3c MM enable Quad OC-3c MM enable...
Chapter 5 Managing the Passport 8672ATME Module with the CLI Table 22 describes the information fields for the show ports info atm all command. Table 22 Information fields for the show ports info atm all command Field Description PORT NUM Port number.
(FDB) for the 1483 bridged point to multi-point PVCs. The FDB stores the information that it learns in the Passport 8672ATME Module. In a point to multi-point connection, the Passport 8672ATME Module uses the FDB table to determine which PVC to use in the egress direction. The command...
Chapter 5 Managing the Passport 8672ATME Module with the CLI show ports info atm fdb Figure 31 Passport-8610:5/show/ports/info/atm# fdb ============================================================= ============================================================= PORT VLAN MAC ADDRESS --------------------------------------------------------------------- 00.00.00.00.03 Table 23 describes the information fields for the show ports info atm fdb command.
Chapter 5 Managing the Passport 8672ATME Module with the CLI Figure 32 show ports info atm ports command output Passport-8610:5/show/ports/info/atm# ports ======================================================================= ======================================================================= PORT DESCRIPION ----------------------------------------------------------------------- OC-12c MM Quad OC-3c MM enable Quad OC-3c MM enable Quad OC-3c MM enable...
Chapter 5 Managing the Passport 8672ATME Module with the CLI Table 24 Information fields for the show ports info atm ports command (continued) Field MAX-BITS VCI CLOCK SOURCE LOOPBACK MODE ADMIN STATE STATUS show ports info atm pvc command This command displays information circuits (PVCs) for the specified port or for all ports.
Chapter 5 Managing the Passport 8672ATME Module with the CLI show ports info atm 1483 command This command displays information specified port or for all ports. The command uses the syntax: show ports info atm 1483 [< ports >] Figure 34 show ports info atm 1483 command output...
Chapter 5 Managing the Passport 8672ATME Module with the CLI Table 26 Information fields for the show ports info atm 1483 command (continued) Field VLAN MAC ADDRESS LOCAL IP ADDRESS REMOTE IP ADDRESS IPX NETWORK NUMBER IPX ENCAP show ports stats atmport command...
Chapter 5 Managing the Passport 8672ATME Module with the CLI Figure 35 show ports stats atmport [<port num>] command output Passport-8606:6/show/ports/stats# atmport =========================================================================== =========================================================================== PORT CELLS CELLS --------------------------------------------------------------------------- 6744908 6744901 6744893 6744888 35314189 =========================================================================== =========================================================================== PORT IN DROP PKTS PKTS...
Chapter 5 Managing the Passport 8672ATME Module with the CLI Table 27 Information fields for the show ports stats atmport command (continued) Field OUT PKTS IN DROP PKTS OUT DROP PKTS UNKNOWN VPI/VCI CELLS Number of packets for which the vpi/vci values are...
Chapter 5 Managing the Passport 8672ATME Module with the CLI Figure 36 show ports stats atm felinecurrent command output Passport-8610:5/show/ports/stats/atm# felinecurrent ====================================================================== ATM Far End Line Current Stats ====================================================================== PORT ERRORED SECONDS COUNT (ES) ---------------------------------------------------------------------- Passport-8610:5/show/ports/stats/atm# felinecurrent Table 28 describes the information fields for the...
Chapter 5 Managing the Passport 8672ATME Module with the CLI show ports stats atm felineinterval This command displays statistics interval. You specify which interval, or span of intervals, to display for the command. The command uses the syntax: show ports stats atm felineinterval < intervalid >...
Chapter 5 Managing the Passport 8672ATME Module with the CLI Table 29 Information fields for the show ports stats atm felineinterval command (continued) Field SEVERELY ERRORED COUNT (SES) CODE VIOLATION COUNT (CV-L) UNAVAILABLE SECONDS (UAS) INTERVAL ID show ports stats atm fepathcurrent This command displays current statistics at the receiving end.
Chapter 5 Managing the Passport 8672ATME Module with the CLI Table 30 describes the information fields for the show ports fepathcurrent Table 30 Information fields for the show ports stats atm fepathcurrent command Field PORT NUM ERRORED SECONDS COUNT (ES)
Chapter 5 Managing the Passport 8672ATME Module with the CLI Figure 39 show ports stats atm fepathinterval command output Passport-8610:5/show/ports/stats/atm# fepathinterval 96 ========================================================================= ========================================================================= PORT ERRORED SECONDS COUNT (ES) ------------------------------------------------------------------------ INTERVAL ID = 96 Passport-8610:5/show/ports/stats/atm# fepathinterval 96 Table 31 describes the information fields for the show ports...
Chapter 5 Managing the Passport 8672ATME Module with the CLI show ports stats atm linecurrent This command displays current statistics uses the syntax: show ports stats atm linecurrent [< ports >] Figure 40 show ports stats atm linecurrent command output...
Chapter 5 Managing the Passport 8672ATME Module with the CLI Table 32 Information fields for the show ports stats atm linecurrent command (continued) Field SEVERELY ERRORED COUNT (SES) CODE VIOLATION COUNT (CV-P) UNAVAILABLE SECONDS (UAS) STATUS show ports stats atm lineinterval This command displays statistics interval.
Chapter 5 Managing the Passport 8672ATME Module with the CLI Table 33 describes the information fields for the show ports lineinterval Table 33 Information fields for The show ports stats atm lineinterval command Field PORT NUM ERRORED SECONDS COUNT (ES)
Chapter 5 Managing the Passport 8672ATME Module with the CLI Figure 42 show ports stats atm pathcurrent command output Passport-8610:5/show/ports/stats/atm# pathcurrent ========================================================================= ========================================================================= PORT ERRED SECS SEVERELY ERRED CODE VIOLATION COUNT (ES) COUNT (SES) ------------------------------------------------------------------------- Passport-8610:5/show/ports/stats/atm# Table 34 describes the information fields for the show ports...
Chapter 5 Managing the Passport 8672ATME Module with the CLI show ports stats atm pathinterval This command displays statistics You specify the interval or span of intervals to display. The command uses the syntax: show ports stats atm pathinterval < intervalid > [< ports >]...
Chapter 5 Managing the Passport 8672ATME Module with the CLI Table 35 Information fields for the show ports stats atm pathinterval command (continued) Field SEVERELY ERRORED COUNT (SES) CODE VIOLATION COUNT (CV-P) UNAVAILABLE SECONDS (UAS) INTERVAL ID show ports stats atm sectioncurrent...
Chapter 5 Managing the Passport 8672ATME Module with the CLI Table 36 describes the information fields for the show ports sectioncurrent Table 36 Information fields for the show ports stats atm sectioncurrent command Field PORT NUM ERRORED SECONDS COUNT (ES)
Chapter 5 Managing the Passport 8672ATME Module with the CLI Figure 45 show ports stats atm sectioninterval command output Passport-8610:5/show/ports/stats/atm# sectioninterval 96 =========================================================================== =========================================================================== PORT ERRORED SECONDS COUNT (ES) --------------------------------------------------------------------------- INTERVAL ID = 96 Passport-8610:5/show/ports/stats/atm# sectioninterval 96 Table 37 describes the information fields for the show ports...
Chapter 5 Managing the Passport 8672ATME Module with the CLI show ports stats atm sonetmediumtbl This command displays statistics command uses the syntax: show ports stats atm sonetmediumtbl Figure 46 show ports stats atm sonetmediumtbl command output Passport-8610:5/show/ports/stats/atm# sonetmediumtbl =========================================================================...
LINE TYPE CIRCUIT ID Configuring ATM F5-OAM End-to-End Loopback A Passport 8672ATME Module, by default, replies to ATM F5-OAM Loopback requests received. However, the transmission of F5-OAM Loopback requests and the processing of F5-OAM Loopback replies received require enabling this feature on a PVC by PVC basis.
Chapter 5 Managing the Passport 8672ATME Module with the CLI config atm pvc f5-oam command This CLI command enables/disables and configures the F5-OAM Loopback feature for a virtual circuit (VC). When this command is used for disabling the F5-OAM Loopback on a VC, the configuration parameters are ignored. The command uses the syntax: config atm <slot/port>...
Chapter 5 Managing the Passport 8672ATME Module with the CLI Table 39 F5-OAM Loopback parameters (continued) Configuration Default down <value> 5 responses trap <value> disabled For example, to enable F5-OAM Loopback for VPI=0 & VCI=33 in port 6 of an...
Chapter 5 Managing the Passport 8672ATME Module with the CLI Figure 47 Sample output for the show ports info atm pvc [slot/port] command As shown in Furthermore, only one PVC (3/5 0.100) is using the default F5-OAM Loopback configuration. show ports info atm f5-oam [slot/port] show ports info atm f5-oam [slot/port] F5-OAM Loopback status and statistics for a particular PVC.
Chapter 5 Managing the Passport 8672ATME Module with the CLI Table 40 defines the status and statistics in the command. [slot/port] Table 40 Status and statistic definition F5 VC Status NOT MANAGED DOWN VERIFY DOWN UP VERIFY Loopback Req Sent...
Chapter 5 Managing the Passport 8672ATME Module with the CLI Displaying packet loss counters The CLI command counters. Table 41 Table 41 Sample output for the sh ports stats interface main command Passport 8600 #5: sh ports stats interface main...
CPU for the chassis, and the other module is the standby CPU, taking over in case of failure. Note that the administrative and operational configurations of the Passport 8672ATME Module are not retained after failover. When a CPU failover occurs, all traffic on the chassis stops momentarily while the standby CPU re-initializes all input/output modules.
Chapter 6 Configuring the Passport 8672ATME Module Before you can pass traffic using the Passport 8672ATME Module with its installed MDA, you must change the clock setting. You can do this in one of two ways: • “Changing the clock setting using Device •...
Chapter 6 Configuring the Passport 8672ATME Module Figure 49 ATM tab Table 8 on page 59 To set the clock setting, in the ClockSource section, click loopTimed or freeRunning. Click Apply. Changing the clock setting using the CLI To change the clock setting using the CLI, enter: config atm <...
1483 PVC bridged across an ATM PVC network. Use a separate ATM1483 PVC for each VLAN. The VLANs may appear on the same port or on different ports of the Passport 8672ATME Modules. You cannot bridge between PVCs in the same VLAN on the same port of the Passport 8672ATME Module.
Creating a VLAN “byPort” and adding ports From the Device Manager menu bar, choose VLAN > VLANs. The VLAN dialog box opens with the Basic tab displayed Figure 51 Basic tab Chapter 6 Configuring the Passport 8672ATME Module ATM VC1 8672 ATM MDA 1...
Chapter 6 Configuring the Passport 8672ATME Module Table 43 VLAN, Insert Basic dialog box fields (continued) Field PortMembers QoSLevel Do the following: In the Id field, enter the Id number for the VLAN (an integer between 0 and 4094). b In the Name field, enter the VLAN name.
Chapter 6 Configuring the Passport 8672ATME Module Click OK. The VlanPortMembers dialog box closes and the VLAN, Insert Basic dialog is redisplayed. Click Close. Configuring an ATM 1483 PVC To configure an ATM 1483 PVC: From the Device Manager menu bar, choose Edit > ATM.
Chapter 6 Configuring the Passport 8672ATME Module h If you select vbr in the Service type field, complete these fields: In the PeakCellRate field, enter the PCR (an integer between 86 and 733490). In the SustainedCellRate field, enter the SCR (an integer between 86 and 733490).
Click Close. Bridging point-to-point traffic using an ATM 1483 PVC using the CLI To configure the Passport 8672ATME Module for ATM 1483 PVCs for VLANs bridged across an ATM PVC network, using the CLI: To create a VLAN by port, enter:...
Associating the PVCs with the same VLAN Follow the procedures outlined in page 126 to associate both PVCs with the same VLAN. The Passport 8672ATME Module directs the two ATM 1483 bridged PVCs to two different ATM ports on the other end. 209195-B ATM Switches...
To associate the two 1483 bridged PVCs with the same VLAN, enter: config atm 1/1 pvc 1483 bridged create 2 0.100, 0.101 The Passport 8672ATME Module directs the two ATM 1483 bridged PVCs to two different ATM ports on the other end. Configuring an IP routing 1483 PVC using Device Manager In the configuration shown in ATM 1483 PVC as the sole member of a VLAN configured for IP routing.
Figure 55 IP routing with ATM 1483 PVCs Passport Note: Each configured ATM 1483 PVC uses one VLAN. The Passport 8672ATME Module can be configured for a maximum of 256 VLANs per MDA and a maximum of 512 VLANs per card. This configuration requires the following procedures: •...
Chapter 6 Configuring the Passport 8672ATME Module Click IP. The IP, VLAN dialog box opens with the IP Address tab displayed (Figure 56). Figure 56 IP Address tab Table 45 describes the IP Address tab fields. IP Address tab Table 45...
Click Close. Enabling RIP routing Note: The Passport 8672ATME Module supports only RIP version 2. From the Device Manager menu bar, choose VLAN > VLANs. The VLAN dialog box opens with the Basic tab displayed Table 42 on page 122 Click one of the VLANs.
Chapter 6 Configuring the Passport 8672ATME Module Click the RIP tab. The RIP tab opens (Figure Figure 58 RIP tab Table 47 describes the RIP tab fields. Table 47 RIP tab fields Field Description Enable IP address of the VLAN.
Chapter 6 Configuring the Passport 8672ATME Module Table 47 RIP tab fields (continued) Field AutoAggregateEnable AdvertiseWhenDown Click Enable. Click Apply. The IP Address tab is redisplayed. Click Close. Enabling OSPF routing If the routing protocol is OSPF, to enable OSPF routing: From the Device Manager menu bar, choose VLAN >...
Chapter 6 Configuring the Passport 8672ATME Module Figure 59 OSPF tab Table 48 describes the OSPF tab fields. Table 48 OSPF tab fields Field Description Enable Enables or disables OSPF routing on the specified interface HelloInterval Length of time, in seconds, between the Hello packets that the router sends on the interface.
Follow the instructions there except, in the ConnectType field, select IP instead of bridged. Configuring an IP routing 1483 PVC using the CLI To configure the Passport 8672ATME Module for an ATM 1483 IP routed PVC, using the CLI: To create two VLANs by port, enter:...
Chapter 6 Configuring the Passport 8672ATME Module To add an ATM port (in this example, 1/1) and several Ethernet ports (in this example, 3/40 to 3/48) to the VLAN, enter: config vlan 2 port add 1/1 config vlan 3 port add 3/40-3/48 To configure IP addresses on both VLANs (use two different subnets), enter: config vlan 2 ip <...
Figure 60 IPX routing with ATM 1483 PVCs Passport Note: Each configured ATM 1483 PVC uses one VLAN. The Passport 8672ATME Module can be configured for a maximum of 256 VLANs per MDA and a maximum of 512 VLANs per card. This configuration requires the following procedures: •...
Chapter 6 Configuring the Passport 8672ATME Module Configuring IPX network numbers To configure the IPX network numbers for both VLANs: From the Device Manager menu bar, choose VLAN > VLANs. The VLAN dialog box opens with the Basic tab displayed Table 42 on page 122 describes the VLAN Basic tab fields.
Chapter 6 Configuring the Passport 8672ATME Module Figure 62 IPX VLAN, Insert dialog box Table 50 Table 50 IPX VLAN, Insert dialog box fields Field NetAddr Encap In the NetAddr field, configure the IPX network numbers for the VLAN. In the Encap field, click the encapsulation type.
Chapter 6 Configuring the Passport 8672ATME Module Table 52 Table 52 Circuits tab fields Field Index OperState Index VlanId NetNumber CompressedInitSent In the OperState field, enter “up” for all IPX network numbers created in this procedure. Click Apply. Click Close.
Chapter 6 Configuring the Passport 8672ATME Module Configuring an IPX routing 1483 PVC using the CLI To configure the Passport 8672ATME Module for this setup using the CLI: To create two VLANs by port, enter: config vlan 2 create byport 1...
Page 144
Chapter 6 Configuring the Passport 8672ATME Module 209195-B...
• Descriptions of the Web page layout Use the Web interface ATM folder to monitor the Passport 8672ATME Module parameters. When you access the Web interface, the System page is displayed. The ATM folder is in the navigation pane on the left of the system page (Figure 65).
LastVlanChange 209195-B Description Port type of this interface. This will be OC-3 SMF/ MMF or OC-12 SMF/MMF for a port on the Passport 8672ATME Module Value of system up time. Contact name. Port name. System location. Enables or disables traps.
Value of sysUpTime at the time the last reboot occurred. Value of sysUpTime at the time the last reboot saved configuration changes. Default runtime configuration file name. Default configuration file name. Configuration file name. 67). Using the Passport 8672ATME Module...
Chapter 7 Web Management Figure 67 PVC page Table 54 describes the fields displayed in the PVC page. Table 54 PVC page items Field Index Pvc Id Name Encapsulation Service Type Peak Cell Rate Sustained Cell Rate Max Burst Size 209195-B Description Unique value assigned to each interface.
Figure 68 1483 ELAN page, (left section) Figure 69 1483 ELAN page, (right section) Chapter 7 Web Management Figure 68 shows the left section of the page. To view Using the Passport 8672ATME Module Figure 69 shows...
Chapter 7 Web Management Table 55 describes the fields displayed in the 1483 ELAN page. 1483 ELAN Table 55 Field Index Elan Id Num Pvc Ids PvcIds Vlan Ids Connect Type Vlan Mac Address Dummy Mac Address Local Ip Address Remote Ip Address In Arp Send Enable In Arp Send Interval...
This field is read only. It takes remaining bits from NumVpiBits. For example, if NumVpiBits is 3 for OC-3c, then NumVciBits is 8. Either SMF (single-mode fiber) or MMF (multi-mode fiber). Enables or disables scrambling. Using the Passport 8672ATME Module...
Page 152
155 MBS or 622 MBS Sets the loopback mode to: • • internal • external The MAC address assigned to this VLAN (used in IP and IPX routed circuits when there is no appropriate destination MAC to use). Passport 8672ATME...
Appendix A Technical Specifications This appendix lists the technical specifications for the Passport 8672ATME Module. Environmental specifications Operating temperature: Storage temperature: Operating humidity: Storage humidity: Operating altitude Storage altitude Free fall/drop: Vibration: Shock/bump: Physical specifications Height: Width: Depth: Weight (single module):...
Page 154
Appendix A Technical Specifications Safety agency approvals Electromagnetic emissions Meets requirements of: 209195-B UL Listed (UL 1950) CUL CSA 22.2 No. 950 IEC 950/EN 60950 CE mark CB Scheme Test Report and Certification NOM (NOM-019-SCFI-1994) US: FCC, CFR 47, Part 15, Subpart B, Class A Canada: ICES-003, Issue-2, Class A Australia/New Zealand: AS/NZS 3548:1995, Class A Japan: VCCI V-3/97.04, Class A...
Appendix B Factory defaults shows the default settings on the Passport 8672ATME Module as it comes Table 57 from the factory, as well as the management tool to change parameters. Table 57 Factory default settings for the Passport 8672ATME Module...
Page 159
(MBS) 81 MBS (maximum burst size) 34 media dependent adapters (MDAs) description 29 dialog box 57 inserting 44 overview 25 port number 48 slot number 48 viewing information 56 Media Type field 151 Using the Passport 8672ATME Module Index...
Page 161
Sustained Cell Rate field 148 SustainedCellRate field 61, 62 SVC (switched virtual circuit) 34 Synchronous Digital Hierarchy (SDH) 35, 60, 80 sysContact field 146 sysDescr field 146 sysLocation field 146 sysName field 146 System page 146 Using the Passport 8672ATME Module Index...
Page 162
Index sysUpTime field 146 technical publications 24 technical specifications 153 technical support 24 technology overview 33 testing 73, 80 text conventions 20 timing 60, 80 traffic shaping 27 transmission distance 36 transmission rates 36 TrapEnable field 72 troubleshooting displaying the image filename 77 downloading the image file 44 loop-back-mode 80 maximum cabling distances 36...
