- Page 1 Getting Started with the Contivity Extranet Switch 1500 Series Part No. 306009-B Rev 00 February 2000...
-
Page 2: Restricted Rights Legend
Users must take full responsibility for their applications of any products spec- ified in this document. The information in this document is proprietary to Nortel Networks, Inc. The software described in this document is furnished under a license agreement and may only be used in ac- cordance with the terms of that license. -
Page 3: Table Of Contents
Preface Conventions ...viii Documentation ...viii Text ... ix User Interface ... ix Related Publications ... x Nortel Networks Technical Publications ... xi Nortel Networks Customer Service ...xii Chapter 1 Introducing the Contivity Extranet Switch The Switch ...1-1 Components List ...1-4... - Page 4 Managing the Switch Recommended Web Browsers ...5-1 Platforms Supported ...5-1 Browser Versions ...5-1 Display Setting ...5-1 Preparing for Configuration ...5-2 Extranet Switch Welcome Display ...5-3 Quick Start ...5-5 Guided Configuration ...5-5 Manage Extranet Switch ...5-5 Registration ...5-5 Notebook ...5-5 Logging in and Supplying a Password ...5-6...
- Page 5 Quick Start Configuration Prerequisites ...5-7 Required Environment ...5-8 Prerequisites ...5-9 Post Configuration Testing ...5-9 Configuration ...5-10 LAN/WAN Interfaces ...5-11 PPTP Users ...5-12 Administrator ...5-13 Date and Time ...5-14 Automatic Backup ...5-14 Chapter 6 Extranet Access Client Installation Windows 95 ...6-1 Windows 98 and Windows NT 4.0 ...6-3 Appendix A Specifications and Compliance...
-
Page 7: Preface
This guide takes you through the necessary tasks to get your Nortel Networks Contivity Extranet Switch 1500 • Introducing the Contivity Extranet Switch • Preparing Your Site • Assigning a System Identity • Managing the Switch • Installing the Extranet Access Client •... -
Page 8: Conventions
Conventions This guide refers to the Contivity Extranet Switch as the CES or the Switch. It assumes that you are familiar with Web browsers and their general operation. Documentation This document uses the following conventions to distinguish among notes of varying importance: Note: Take notice. -
Page 9: Text
Indicates new terms and book titles. Indicates system output, for example, prompts and system messages. Example: Set Nortel Networks Trap Monitor Filters Shows menu paths. Example: Services Available identifies the Switch services that are available. -
Page 10: Related Publications
Related Publications The following table lists the associated documentation that you will need to configure and manage your Switch and describes the document’s objectives. Related Publications Document Contivity Extranet Switch Release Notes Managing the Contivity Extranet Switch (included on the CD) -
Page 11: Nortel Networks Technical Publications
Nortel Networks Technical Publications You can print Nortel Networks technical manuals and release notes free, directly from the Internet. Go to support.baynetworks.com/library/tpubs/. Find the Nortel Networks product for which you need documentation. Then locate the specific category and model or version for your hardware or software product. Using Adobe Acrobat Reader, you can open the manuals and release notes, search for the sections you need, and print them on most standard printers. -
Page 12: Nortel Networks Customer Service
Nortel Networks Customer Service If you purchased a service contract for your Nortel Networks product from a distributor or authorized reseller, contact the technical support staff for that distributor or reseller for assistance. If you purchased a Nortel Networks service program, contact one of the following... -
Page 13: Introducing The Contivity Extranet Switch
The Nortel Networks Contivity Extranet Switch 1500 Series provides scalable, secure, manageable extranet access for up to 100 simultaneous users across the Public Data Network (PDN). The Contivity Extranet Switch 1500 Series consists of the 1500, 1510, 1520, and 1530 models. - Page 14 Server Intranet Figure 1-1. The Switch provides more security than traditional remote access schemes due to the combination of authorization, authentication, privacy, and access control on a per user basis. Additionally, the IPsec protocol and related Internet Security Association & Key Management Protocol (ISAKMP) and the Oakley key establishment protocol support further enhance the security offering.
- Page 15 The Switch offers RADIUS accounting support and extensive logging, including events, system, configuration, and security logs. Figure 1-2 shows a front view of the Switch. Figure 1-2. The Switch, Front View The Extranet Switch 1500 Series must be placed only in a horizontal position.
-
Page 16: Components List
The following table lists all of the components and accessories of the Switch. Examine the product packaging to be sure that you have all the necessary components. Note that the Extranet Switch 1500 Series has no user-serviceable components. Description Extranet Switch 1500 Series... -
Page 17: Preparing Your Site
This chapter provides information that you should read before you begin cabling and configuring the Contivity Extranet Switch 1500 Series. This information includes selecting an appropriate site, safety guidelines, information on the power cord, voltage settings, and external vent cooling and airflow recommendations. -
Page 18: Safety Guidelines
CAUTION: Make sure that the power service connection is through an Before you connect the power cord to the back panel of the Switch, ensure that the voltage selector switch is correctly set to the appropriate AC line source voltage. -
Page 19: External Vent Cooling And Airflow
The Switch has external vents for cooling and air flow on: • The chassis bezel • The back panel • On each of the side panels Keep the side vents clear of obstruction to ensure proper cooling of the Switch. -
Page 21: Cabling The Switch
Serial interface • LEDs For the Contivity Extranet Switch 1500 Series: • The 1500 and 1510 support connections to LAN interfaces • The 1520 supports connections to Single V.35 interfaces • The 1530 supports connections to T1 CSU/DSU interfaces Additionally, this chapter cites the LAN/WAN pinouts and the Switch’s LED descriptions. -
Page 22: Connecting The Cables
Figure 3-1. Connecting the Cables You must connect your cables as follows: • Connect the power cord to the back of the Switch and to the electrical outlet. WARNING: Connect the LAN and serial port cables before you plug the •... -
Page 23: Power Cord Requirements
CAUTION: You should protect your Switch by plugging it into a surge The power cord must be rated for the available AC voltage, and it must have a current rating which is at least 125 percent of the Switch's current rating. See the “Physical, Electrical” specifications on page A-1. -
Page 24: Lan Interface Connections
LAN Interface Connections The LAN interface is available for the Contivity Extranet Switch 1500 and 1510. There is at least one LAN interface connection, which provides a connection to the Web for management. 100BASE-TX connections require Category 5, twisted-pair wire. The 100BASE-TX specification supports 100 Mb/s transmission over two pairs of Category 5 twisted-pair Ethernet wiring;... -
Page 25: Single V.35 Wan Interface (Optional)
Single V.35 WAN Interface (Optional) The Single V.35 WAN connector is located on a PCI card that offers a separate DB26S connector that provides the signals needed to interface to V.35 equipment. Included in the accessory box is a cable that maps the DB26S signals to a standard V.35 connector. - Page 26 The following notes apply to the Single V.35 WAN Interface: • You will need a DSU/CSU (digital service unit/channel service unit) between the WAN connection and the Switch. • At each end, Cable shield and connector shell must connect respectively to pin A of 34-pin connector and pin 1 of the standard 28-pin connector.
-
Page 27: T1 Csu/Dsu Wan Interface (Optional)
T1 CSU/DSU WAN Interface (Optional) The T1 CSU/DSU WAN interface is available for the Contivity Extranet Switch 1530. The T1 CSU/DSU WAN crossover cable crosses the blue pair with the orange pair. This is different from the commonly available crossover cable, which crosses the green pair with the orange pair. -
Page 28: Serial Interface Cable (Optional)
Nortel Networks recommends that you use the IP Address Configuration Utility diskette for easy initial IP address configuration (refer to page 4-3 for details). However, Nortel Networks ships a serial cable with the Switch. Optionally, you can use the Serial Interface to provide the Switch with a Management IP Address, subnet mask, and default gateway address (refer to page 4-2 for details). -
Page 29: Understanding The Leds
The Power LED is green when the power is on; if it is flashing, there is a hardware failure and you should contact Nortel Networks. The Hard Disk LED is green, and when it flashes the Switch is either reading or writing to the disk. - Page 30 Figure 3-4 shows the Single V.35 LEDs. Look at the condition of the LEDs, then examine the corresponding LED tables to better understand the indications. LE D 4, R ed LED 3, G reen Figure 3-4. Table 3-5. LED1 LED2 LED3 LED4 3-10...
- Page 31 Figure 3-5 shows the T1 CSU/DSU LEDs. Look at the condition of the LEDs, then examine the corresponding LED tables to better understand the indications. LE D 4, R ed LED 2, Blue LED 1, Yellow LED 3, G reen Figure 3-5.
- Page 32 Figure 3-6 shows the PCI card 10/100BASE-TX LAN LEDs for the Contivity Extranet Switch 1510. This does not apply to the 1520 or 1530. Look at the condition of the LEDs, then examine the corresponding LED table to better understand the indications.
-
Page 33: Assigning A System Identity
IP address, subnet mask, and default gateway (optional). To configure the Switch from the serial interface configuration menu, you must first connect the serial interface cable to the Switch. Then you can use a terminal emulation application to enter the Management IP address, subnet mask, and default gateway (optional). -
Page 34: Startup Configuration Requirements
Enter a Management IP address for the system. You need this address to manage all system services, such as HTTP, FTP, and SNMP. This address must be accessible from one of the Switch's private physical interfaces. Therefore, the Management IP address must map to the same network as one of the private interfaces. -
Page 35: Ip Address Configuration Utility
The program ExtNetIP.exe is on a diskette labeled IP Address Configuration Utility that accompanies the Switch. You can copy the utility to your hard disk and execute it from there, or you can load it from the diskette drive. The ExtNetIP.exe program launches the IP Address Configuration Utility, which allows you to assign a Management IP address and subnet mask to the Switch. - Page 36 The following display appears while the program searches for an unconfigured Switch. Figure 4-1. The program automatically enters the Serial Number for the first available Switch into the table of Contivity Switches. Figure 4-2. Serial Number Search Display IP Address Configuration Utility Display...
- Page 37 Switch serial numbers. To verify the switches that have been discovered, you can refer to the serial number on the bar code on the bottom of the Switch. The serial number on the back of the Switch is that of the motherboard manufacturer.
-
Page 38: Serial Interface Configuration
Serial Interface Configuration Use the IP Address Configuration Utility (see to page 4-3) to configure the Switch with its initial IP address configuration. Alternatively, you can use the serial interface configuration menu to access the Switch from the serial interface of your PC. Typically the serial interface configuration procedure is only necessary in a system recovery situation. -
Page 39: Procedure
A Controlled Crash forces the Switch into a hard crash state, which creates a core dump file that Nortel Networks Customer Support can analyze to help diagnose problems, such as the Switch is hung or it does not respond to PINGs. - Page 40 Welcome to the Nortel Networks Extranet Switch Copyright 1998 and 1999, Nortel Networks Date: Unit Serial Number: Please enter the administrator's username: admin Please enter the administrator's password: setup 1) Management IP Address* 2) IP Subnet Mask 3) Gateway IP Address*...
-
Page 41: Managing The Switch
This chapter describes the recommended Web browsers, the default login, and passwords that you need to access the Nortel Networks Extranet Switch, and the Quick Start Configuration. Recommended Web Browsers Nortel Networks Extranet Manager uses Java, JavaScript, and HTML features. -
Page 42: Preparing For Configuration
Client dial-in. Prepare the clients for the type of tunneling protocol they plan to use. The PPTP client application is available for Windows 95 on the Nortel Networks CD, and it comes with the Windows 98 and Windows NT operating systems. Nortel Networks also provides the IPsec client on the Nortel Networks CD. -
Page 43: Extranet Switch Welcome Display
The alternatives you have when first configuring your Switch are shown in Table 5-1. Nortel Networks recommends that you begin with the Quick Start or the Guided Configuration. Once you are familiar with the Switch’s navigation menu and capabilities, then you can select Manage Extranet Switch. - Page 44 Getting Started with the Contivity Extranet Switch 1500 Series Figure 5-1. Switch Welcome Display...
-
Page 45: Quick Start
Quick Start or Guided Configuration for your first configuration. Registration Click to register the Switch with Nortel Networks. This only take a few minutes and gives you access to the latest software and technical tips. Your Switch requires Internet access in order to register. -
Page 46: Logging In And Supplying A Password
Logging in and Supplying a Password Start up a Web browser and enter your Switch's Management IP Address. Select an option in the navigational menu and submenu. When you are prompted for the Login and Password, enter the system default Login and Password in lowercase... -
Page 47: Quick Start Configuration Prerequisites
Managing the Switch Quick Start Configuration Prerequisites This screen acts as a checklist for you to prepare for the Quick Start configuration. Assembling the information beforehand, and verifying that you can establish a PPTP Client session, makes Quick Start easy. -
Page 48: Required Environment
Point-to-Point Tunnel Protocol (PPTP) tunnel access method PPTP is a tunneling protocol supported by Nortel Networks, Microsoft, and other vendors. The PPTP client is available for Windows 95 on the Nortel Networks CD and comes with Windows 98 and Windows NT 4.0 and later operating systems. -
Page 49: Prerequisites
To test your configuration, verify that a PPTP remote user can dial in from an external system. Refer to the Contivity Extranet Switch Administrator's Guide, the Switch’s online help, and the Microsoft PPTP documentation for additional information. Management IP Address for the Switch... -
Page 50: Configuration
Configuration This screen allows you to add a LAN port IP Address and Subnet Mask, establish the tunnel as Private (your private LAN) or Public (public data networks), and configure up to three PPTP Users and an Administrator with User IDs and Passwords. You can also set the system's date and time. The following figure show partial displays of the Quick Start Configuration screen. -
Page 51: Lan/Wan Interfaces
Lists the Management IP Address, LAN/WAN port, and LAN card. IP Address Enter an IP address for each interface on the Switch, including the LAN port. The Switch uses these IP addresses for tunnel creation. The IP Address consists of 32 bits, which are written as four octets in dotted-decimal format as follows: 192.168.34.21... -
Page 52: Pptp Users
A host can send only enough packets to a Public interface to establish a tunnel connection. If the tunnel is not established before the preset maximum-number-of packets-allowed counter is reached, then the Switch discards the packets from that host. Private Indicates that this interface is attached to the Private network and that it can accept non-tunneled networking protocols such as TCP/IP, FTP, and HTTP. -
Page 53: Administrator
UID to access the serial port. There can be only one Primary Administrator. User ID Enter an appropriate User ID for the Primary Administrator. This UID has the privileges to modify and view all controls in the Switch. Password Enter a user Password for the Primary Administrator. -
Page 54: Date And Time
Date and Time Date Enter the current month, day, and year (mm/dd/yyyy). Time Enter the current hour, minute, and seconds (hh:mm:ss) as displayed by a 24-hour clock (00:00:00 to 23:59:59). Automatic Backup The Automatic Backup screen under the Manage configuration option allows you to configure regular intervals when your system files are saved to designated host backup file servers. -
Page 55: Extranet Access Client Installation
To install the Nortel Networks Extranet Access Client onto a Windows 95 PC, you must copy and load the four files that are on the Nortel Networks Extranet CD in the Client folder onto your hard drive. International software users must go to the Microsoft Web site (http://support.microsoft.com/support) to... - Page 56 Remove button. This forces the Network Neighborhood to use NetBIOS over TCP/IP, which is compatible with the Extranet Switch. Under the Identity tab, configure the Workgroup to be the same as your company’s internal workgroup. For example, “Nortelnetworks.”...
-
Page 57: Windows 98 And Windows Nt 4.0
Windows 98 and Windows NT 4.0 To install the Nortel Networks Extranet Access Client onto a Windows 98 PC or Windows NT 4.0 workstation, you must copy the Extranet Access Client (Eac_20d.exe) that is on the Contivity Extranet Switch CD in the Client folder onto your hard drive. -
Page 59: Specifications And Compliance
Relative Humidity: 10%-90% non-condensing Declaration of the Manufacturer or Importer Nortel Networks hereby certifies that this product is in compliance with EU EMC Directive 89/336/EEC, using standards EN55022 Class B and EN50082-1, and the Low Voltage Directive 73/23/EEC via standard EN60950. -
Page 60: Safety Compliance
Safety Compliance USA: UL 1950, 3rd Edition Canada: UL certified to CSA C22.2 No. 950-95 for Canada Europe: TUV to EN60950 2nd Edition, with amendments International: NEMKO to IEC950 (A1 + A2 + A3) Electromagnetic Compatibility (EMC) USA: FCC CFR 47 Part 15, Tested Class B Canada: IC ICES-003 Class B Europe: EN55022, Class B EN 61000-3-2, 95... -
Page 61: Appendix B Special Notices
Inc. reserves the right to make changes to the products described in this document without notice. Nortel Networks, Inc. does not assume any liability that may occur due to the use or application of the product(s) or circuit layout(s) described herein. -
Page 62: Ec Declaration Of Conformity
EN 55 022 Statement This is to certify that the Nortel Networks Contivity Extranet Switch 1500 Series is shielded against the generation of radio interference in accordance with the application of Council Directive 89/336/ EEC, Article 4a. -
Page 63: Canadian Department Of Communications Radio Interference Regulations
Canadian Department of Communications Radio Interference Regulations This digital apparatus, the Contivity Extranet Switch 1500 Series, does not exceed the Class A limits for radio-noise emissions from digital apparatus as set out in the Radio Interference Regulations of the Canadian Department of Communications. - Page 64 Software is first shipped to Licensee. If any item of Software fails to so function during its warranty period, as the sole remedy Nortel Networks will at its discretion provide a suitable fix, patch, or workaround for the problem that may be included in a future Software release.
