Model No. NTCW90907.0
Serial No.
Write the serial number in the
space above for reference.
Serial Number Decal
(under frame)
QUESTIONS?
As a manufacturer, we are commit-
ted to providing complete customer
satisfaction. If you have questions,
or if parts are damaged or missing,
PLEASE DO NOT CONTACT THE
STORE; please contact Customer
Care.
IMPORTANT: You must note the
product model number and serial
number (see the drawing above)
before contacting us:
CALL TOLL-FREE:
1-888-825-2588
Mon.–Fri. 6 a.m.–6 p.m. MST
Sat. 8 a.m.–4 p.m. MST
ON THE WEB:
www.nordictrackservice.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.
USER'S MANUAL
Visit our website at
www.nordictrack.com
new products, prizes,
fitness tips, and much more!
Advertisement
Table of Contents
Related Manuals for NordicTrack NTCW90907.0
Summary of Contents for NordicTrack NTCW90907.0
- Page 1 Model No. NTCW90907.0 Serial No. Write the serial number in the space above for reference. Serial Number Decal (under frame) QUESTIONS? As a manufacturer, we are commit- ted to providing complete customer satisfaction. If you have questions, or if parts are damaged or missing, PLEASE DO NOT CONTACT THE STORE;...
-
Page 2: Table Of Contents
Apply the decal in the location shown. Note: The decal may not be shown at actual size. NordicTrack is a registered trademark of ICON IP, Inc. -
Page 3: Important Precautions
IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read all important precautions and instructions in this manual and all warnings on your elliptical exerciser before using your elliptical exerciser. ICON assumes no responsibility for personal injury or property damage sustained by or through the use of this product. -
Page 4: Before You Begin
BEFORE YOU BEGIN Thank you for selecting the new NordicTrack A.C.T. elliptical exerciser. The A.C.T. elliptical exercis- er provides a wide array of features designed to make your workouts at home more effective and enjoyable. For your benefit, read this manual carefully before you use the elliptical exerciser. -
Page 5: Assembly
ASSEMBLY Assembly requires two persons. Place all parts of the elliptical exerciser in a cleared area and remove the packing materials. Do not dispose of the packing materials until assembly is completed. In addition to the included hex keys, assembly requires a Phillips screwdriver wrench , and a rubber mallet As you assemble the elliptical exerciser, use the drawings below to identify small parts. - Page 6 To make assembly easier, read the information on page 5 before you begin assembling the elliptical exerciser. Remove the four screws and the four shipping brackets attached to the Frame (1). Discard the screws and the shipping brackets. Then, tighten four Leveling Feet (52) into the underside of the Frame (1).
- Page 7 3. Identify the Left and Right Upright Covers (20, 21), which are marked with “L” and “R” stickers, and orient them as shown. Attach the Left and Right Upright Covers (20, 21) around the Upright (2) with four M4 x 30mm Screws (74).
- Page 8 5. Identify the Right Pedal Arm (15), which is marked with an “R” sticker. Attach a Pedal (9) to the Right Pedal Arm with four M6 x 13mm Patch Screws (78). Attach the other Pedal to the Left Pedal Arm (not shown) in the same way.
- Page 9 7. Apply a small amount of grease to the axle of the left Pedal Arm Bracket (43). Attach the left Pedal Leg (8) to the left Pedal Arm Bracket with two M8 x 45mm Button Bolts (70) and two M8 Nylon Locknuts (63).
- Page 10 10. Slide the Lower Handlebar Cover (94) into the slots in the underside of the Console (3). Attach the Lower Handlebar Cover to the Handlebar (90) with two M4 x 16mm Screws (67). 11. Attach the Upper Handlebar Cover (93) to the Handlebar (90) with an M4 x 16mm Screw (67).
- Page 11 12. Identify the Left Handrail (4), which is marked with an “L” on the underside. Then, identify the Right Handrail (5), which is marked with an “R” on the underside. Orient the Left and Right Handrails as shown. Slide the Left Rail Cover (6) onto the Left Handrail (4).
- Page 12 14. Attach the Right Handrail (5) to the Frame (1) with three M10 x 19mm Patch Screws (61) and three M10 Split Washers (79). Press the posts on the Right Rail Cover (7) into the holes in the Frame (1). Attach the Left Handrail (4) and the Left Rail Cover (6) in the same way.
-
Page 13: How To Use The Elliptical Exerciser
HOW TO USE THE ELLIPTICAL EXERCISER HOW TO PLUG IN THE POWER SUPPLY Plug one end of the included power supply into the jack on the front of the elliptical exerciser. Plug the other end of the power supply into an appropriate out- let that is properly installed in accordance with all local codes and ordinances. - Page 14 HOW TO EXERCISE ON THE ELLIPTICAL EXERCISER Handlebars To mount the elliptical exerciser, hold the handlebars and step onto the pedal that is in the lower position. Then, step onto the other pedal. Push the pedals until they begin to move with a continuous motion. Note: The pedals can turn in either direction.
- Page 15 CONSOLE DIAGRAM FEATURES OF THE CONSOLE The advanced console offers an array of features designed to make your workouts more effective and enjoyable. When you select the manual mode of the console, you can change the resistance of the pedals with the touch of a button.
- Page 16 HOW TO USE THE MANUAL MODE 1. Press any button on the console or begin ped- aling to turn on the console. When you turn on the console, the display will light. A tone will then sound and the console will be ready for use.
- Page 17 5. Measure your heart rate if desired. If there are sheets of clear plastic on the metal contacts on the handgrip pulse sensor, remove the plas- tic. In addition, make sure that your hands are clean. To measure your heart rate, hold the handgrip pulse sensor with your palms resting against the metal contacts.
- Page 18 HOW TO USE A PRESET WORKOUT 1. Press any button on the console or begin ped- aling to turn on the console. When you turn on the console, the display will light. A tone will then sound and the console will be ready for use.
- Page 19 4. Follow your progress with the display. During the workout, the display will show the work- out profile, the time remaining in the workout, and the distance you have pedaled. To view the profile, your pedaling pace, and the distance you have pedaled, press the Display but- ton.
-
Page 20: Maintenance And Troubleshooting
MAINTENANCE AND TROUBLESHOOTING Inspect and tighten all parts of the elliptical exerciser regularly. Replace any worn parts immediately. To clean the elliptical exerciser, use a damp cloth and a small amount of mild soap. IMPORTANT: To avoid damage to the console, keep liquids away from the console and keep the console out of direct sunlight. -
Page 21: Exercise Guidelines
EXERCISE GUIDELINES WARNING: Before beginning this or any exercise program, consult your physician. This is especially important for persons over the age of 35 or persons with pre-existing health problems. The pulse sensor is not a medical device. Various factors may affect the accuracy of heart rate readings. - Page 22 SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretch—never bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. Allow your back and shoulders to relax as you reach down toward your toes as far as possible.
- Page 23 NOTES...
-
Page 24: Part List
PART LIST—Model No. NTCW90907.0 Key No. Qty. Description Frame Upright Console Left Handrail Right Handrail Left Rail Cover Right Rail Cover Pedal Leg Pedal Left Handlebar Right Handlebar Left Handlebar Leg Right Handlebar Leg Left Pedal Arm Right Pedal Arm... -
Page 25: Exploded Drawing
EXPLODED DRAWING A—Model No. NTCW90907.0 R0108A... - Page 26 EXPLODED DRAWING B—Model No. NTCW90907.0 R0108A...
- Page 27 EXPLODED DRAWING C—Model No. NTCW90907.0 R0108A...
-
Page 28: Ordering Replacement Parts
ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
