  • Page 1 EEDEN09-100 technical data RZQ100-140BW1 Split Sky Air...
  • Page 2 “ The present publication is drawn up by way of information only Het ISO14001 assures an effective ufacturer of air conditioning equip- and does not constitute an offer binding upon Daikin Europe N.V.. environmental management system in order to ment, compressors and refrige- Daikin Europe N.V.
  • Page 3 EEDEN09-100 technical data RZQ100-140BW1 Split Sky Air...

  • Page 4: Table Of Contents

    • Outdoor Units • R-410A • RZQ100-140B8W1B TABLE OF CONTENTS RZQ100-140B8W1B Features ............. 5 Specifications .

  • Page 5: Features

    This innovative Daikin unit provides a more comfortable environment and offers great savings in energy • Daikin outdoor units are neat and sturdy and can be mounted easily consumption to shop and office owners. on a roof or terrace or simply placed against an outside wall.

  • Page 6: Specifications

    • Outdoor Units • R-410A • RZQ100-140B8W1B Specifications 2-1 NOMINAL CAPACITY AND NOMINAL INPUT RZQ100B8W1B RZQ125B8W1B RZQ140B8W1B For combination indoor Indoor Units FCQ100C7VEB FCQ125C7VEB FCQ140C7VEB units + outdoor units Cooling capacity Standard 10.0 12.50 14.00 Heating capacity Standard 11.20 14.00 16.00...

  • Page 7: Technical Specifications

    • Outdoor Units • R-410A • RZQ100-140B8W1B Specifications 2-1 NOMINAL CAPACITY AND NOMINAL INPUT RZQ100B8W1B RZQ125B8W1B RZQ140B8W1B For combination Nominal 4.12 3.54 indoor units + outdoor Nominal 4.43 3.92 units Energy Label Cooling Heating Annual energy consumption 1,220 1,770 2-2 TECHNICAL SPECIFICATIONS...

  • Page 8: Electrical Specifications

    • Outdoor Units • R-410A • RZQ100-140B8W1B Specifications 2-2 TECHNICAL SPECIFICATIONS RZQ100B8W1B RZQ125B8W1B RZQ140B8W1B Refrigerant Type R-410A Charge 4.30 4.30 4.30 Control Expansion valve (electronic type) Nr of Circuits Refrigerant Oil Type Daphne FVC68D Charged Volume Piping connections Liquid (OD)

  • Page 9: Electrical Data

    • Outdoor Units • R-410A • RZQ100-140B8W1B Electrical data RZQ-BW1 Unit combination Power supply Comp. Indoor unit Outdoor unit Hz-volts Vol t age range MCA TOCA MFA MSC 3D048638C NOTES SYMBOLS 1 RLA is based on the following conditions: : Min. Circuit Amps (A) Power supply: 50Hz 230V TOCA : Total Over Current Amps (A)
  • Page 10 • Outdoor Units • R-410A • RZQ100-140B8W1B Electrical data RZQ-BW1 Unit combination Power supply Comp. Indoor unit Outdoor unit Hz-volts Vol t age range MCA TOCA MFA MSC 3D048638C SYMBOLS NOTES 1 RLA is based on the following conditions: : Min. Circuit Amps (A) Power supply: 50Hz 230V Heating TOCA...

  • Page 11: Options

    Options RZQ-B8 Kit name RZQ71D7V1B RZQ100D7V1B RZQ125D7V1B RZQ140D7V1B Name of option RZQS71D7V1B RZQS100D7V1B RZQS125D7V1B RZQS140D7V1B RZQ100B8W1B RZQ125B8W1B RZQ140B8W1B Central drain plug EKDK04 Twin KHRQ22M20TA (KHRQ58T): see note Triple KHRQ127H (KHRQ58H): see note Refrigerant branch piping KHRQ22M20TA (KHRQ58T): see note Double-twin...

  • Page 12: Capacity Tables

    Thin cassette 2x2 cassette New Duct (medium ESP) Ceiling suspended 4way ceiling Wall mounted High ESP Duct Floor standing Model name RZQ71D7V1B RZQ100D7V1B RZQ100B8W1B RZQ125D7V1B RZQ125B8W1B RZQ140D7V1B RZQ140B8W1B Sky-air HH Cassette Thin cassette 2x2 cassette New Duct (medium ESP) Ceiling suspended...

  • Page 13: Cooling Capacity Tables

    • Outdoor Units • R-410A • RZQ100-140B8W1B Capacity tables 5 - 2 Cooling capacity tables RZQ100B (Pair + Twin / triple) Cooling Capacity range Rated point Cooling Capacity (kW) Cooling Indoor Outdoor temperature (°C DB) °C °C (kW) (kW) ( - ) (kW) (kW) ( - )
  • Page 14 • Outdoor Units • R-410A • RZQ100-140B8W1B Capacity tables 5 - 2 Cooling capacity tables RZQ125B (Pair + Twin / triple / double twin) Cooling Capacity range Rated point Cooling Capacity (kW) Cooling Indoor Outdoor temperature (°C DB) °C °C (kW) (kW) ( - )
  • Page 15 • Outdoor Units • R-410A • RZQ100-140B8W1B Capacity tables 5 - 2 Cooling capacity tables RZQ140B (Pair + Twin / triple / double twin) Cooling Capacity range Rated point Cooling Capacity (kW) Cooling Indoor Outdoor temperature (°C DB) °C °C (kW) (kW) ( - )
  • Page 16 • Outdoor Units • R-410A • RZQ100-140B8W1B Capacity tables 5 - 2 Cooling capacity tables RZQ140BW1 (Pair) Cooling Cooling capacity (Rated point) Capacity range Cooling capacity 400V [50Hz] I n door Outdoor temp. (°CDB) (°C) (°C) (kW) (kW) (kW) (kW) (kW) (kW) (kW)
  • Page 17 • Outdoor Units • R-410A • RZQ100-140B8W1B Capacity tables 5 - 2 Cooling capacity tables RZQ-B/C Capacity in function of field piping length for non-inverter Capacity (%) Field piping length (m) 3TW26062-1 Cooling Heating • Split Sky Air • Outdoor Units...

  • Page 18: Heating Capacity Tables

    • Outdoor Units • R-410A • RZQ100-140B8W1B Capacity tables 5 - 3 Heating capacity tables RZQ100B (Pair + Twin / triple) Heating Capacity range Rated point Heating Capacity (kW) Heating Indoor Outdoor temperature (°C WB) °C (kW) ( - ) (kW) ( - ) (kW)
  • Page 19 • Outdoor Units • R-410A • RZQ100-140B8W1B Capacity tables 5 - 3 Heating capacity tables RZQ125B (Pair + Twin / triple / double twin) Heating Capacity range Rated point Heating Capacity (kW) Heating Indoor Outdoor temperature (°C WB) °C (kW) ( - ) (kW) ( - )
  • Page 20 • Outdoor Units • R-410A • RZQ100-140B8W1B Capacity tables 5 - 3 Heating capacity tables RZQ140B (Pair + Twin / triple / double twin) Heating Capacity range Rated point Heating Capacity (kW) Heating Indoor Outdoor temperature (°C WB) °C (kW) ( - ) (kW) ( - )
  • Page 21 • Outdoor Units • R-410A • RZQ100-140B8W1B Capacity tables 5 - 3 Heating capacity tables RZQ140BW1 (Pair) Heating Heating capacity (Rated point) Capacity range Heating capacity 400V [50Hz] I n door Outdoor temp. (°CWB) −15 −10 −5 (°C) (kW) (kW) (kW) (kW) (kW)

  • Page 22: Dimensional Drawing & Centre Of Gravity

    • Outdoor Units • R-410A • RZQ100-140B8W1B Dimensional drawing & centre of gravity 6 - 1 Dimensional drawing unit (mm) RZQ100-125-140BW1 Hole for anchor bolt 4-M12 Gas pipe connection J15.9 flare Liquid pipe connection - J9.5 flare Service port (in the unit) (2x) Grounding terminal M5 (in switch box) Refrigerant piping intake Power supply wiring intake (knock hole J34)

  • Page 23: Centre Of Gravity

    • Outdoor Units • R-410A • RZQ100-140B8W1B Dimensional drawing & centre of gravity 6 - 2 Centre of gravity RZQ-BW1 4TW26079-3 • Split Sky Air • Outdoor Units...

  • Page 24: Piping Diagram

    • Outdoor Units • R-410A • RZQ100-140B8W1B Piping diagram RZQ100-125-140BW1(Pair) One way valve One way One way valve valve Heat exchanger Filter One way One way valve valve Capillary Solenoid tube valve Capillary Electronic expansion tube valve Receiver Strainer Capillary tube Service port 5/16″...

  • Page 25: 7 Piping Diagram

    • Outdoor Units • R-410A • RZQ100-140B8W1B Piping diagram RZQ100-125-140BW1(Triple) Indoor unit Heat exchanger One way valve One way One way valve valve Stop valve Filter Heat exchanger (with service port 5/16’ flare) One way One way valve valve Field piping Capillary Solenoid tube...

  • Page 26: Wiring Diagram

    • Outdoor Units • R-410A • RZQ100-140B8W1B Wiring diagram 8 - 1 Wiring diagram RZQ100-125-140BW1 Indoor Outdoor : Live : Neutral : Field wiring : Protective earth (screw) : Wire clamp : Terminal : Connector : Relay connector Colours BLK: Black / ORG: Orange / BLU: Blue / WHT: White / RED: Red / YLW:Yellow / BRN: Brown / GRN: Green NOTES:...

  • Page 27: Sound Data

    • Outdoor Units • R-410A • RZQ100-140B8W1B Sound data 9 - 1 Sound pressure spectrum RZQ100BW1 - Cooling RZQ100BW1 - Heating 3TW26747-1 Octave band center frequency (Hz) 3TW26747-2 Octave band center frequency (Hz) NOTES NOTES Data is valid at free field condition Data is valid at free field condition Data is valid at nominal conditions.
  • Page 28 • Outdoor Units • R-410A • RZQ100-140B8W1B Sound data 9 - 1 Sound pressure spectrum RZQ140BW1 - Cooling RZQ140BW1 - Heating 3TW26787-1 Octave band center frequency (Hz) 3TW26787-2 Octave band center frequency (Hz) NOTES NOTES Data is valid at free field condition Data is valid at free field condition Data is valid at nominal conditions.

  • Page 29: Sound Power Spectrum

    • Outdoor Units • R-410A • RZQ100-140B8W1B Sound data 9 - 2 Sound power spectrum RZQ125BW1 - Cooling RZQ100BW1 - Cooling 3TW26747-3 Octave band center frequency (Hz) 3TW26757-3 Octave band center frequency (Hz) NOTES NOTES Data is valid at free field condition Data is valid at free field condition Data is valid at nominal conditions.

  • Page 30: Installation

    • Outdoor Units • R-410A • RZQ100-140B8W1B Installation 10 - 1 Installation method RZQ100-125-140BW1 A. Non stacked installation Legend Suction side obstacle Discharge side obstacle Left side obstacle Right side obstacle Top side obstacle Obstacle is present In these cases, close the bottom of the installation frame to prevent discharged air from being bypassed.

  • Page 31: Operation Range

    • Outdoor Units • R-410A • RZQ100-140B8W1B Operation range RZQ-B (Cooling) (Heating) Indoor temp. (°CWB) Indoor temp. (°CDB) NOTE Depending on operation and istallation conditions. The indoor unit can change over to freeze-up operation (indoor de-icing) To reduce the freeze-up operation (indoor de-icing) frequency it is recommended to install the outdoor unit in a location not exposed to wind. 3TW26733-1B •...
