TECHNICAL & SERVICE MANUAL
OUTDOOR UNIT: SAP-CMRV1923GJ
DC INVERTER MULTI-SYSTEM AIR CONDITIONER
2-room multi Outdoor unit
SAP -CMRV1923GJ
3-room multi Outdoor unit
SAP – CMRV2433GJ
SAP-CMRV2433GJ
Capacity
Outdoor Model No.
5.6 kW
SAP -CMRV1923GJ-C
6.8 kW
SAP -CMRV2433GJ-C
Revised Edition
Destination: General area (50Hz)
Product Code No.
1 852 084 45
1 852 084 46
< Combined Indoor Units >
Concealed duct type
Wall mounted type
SAP-DMRV93GJ
SAP-KMRV93GJ
SAP-DMRV123GJ
SAP-KMRV123GJ
SAP-DMRV183GJ
SAP-KMRV183GJ
NOTE
1. How these units may be combined is given in
the Unit Combination Tables in the Appendix.
2. Be sure to operate the air conditioning
system only when 2 or more indoor units
have been installed. If operated with only a
single unit installed, the returning fluid to the
compressor may cause a malfunction.
IMPORTANT
These air conditioners employ
new refrigerant R410A.
Pay special attention when servicing
the unit.
REVISION NO.
NOV.2003
Europe (50Hz)
Singapore (50Hz)
General area (60Hz)
SM
700540-02
W
Advertisement
Table of Contents
Related Manuals for Sanyo SAP-CMRV1923GJ
Summary of Contents for Sanyo SAP-CMRV1923GJ
- Page 1 TECHNICAL & SERVICE MANUAL Revised Edition NOV.2003 OUTDOOR UNIT: SAP-CMRV1923GJ Destination: General area (50Hz) SAP-CMRV2433GJ Europe (50Hz) Singapore (50Hz) General area (60Hz) DC INVERTER MULTI-SYSTEM AIR CONDITIONER Capacity Outdoor Model No. Product Code No. 5.6 kW SAP -CMRV1923GJ-C 1 852 084 45 6.8 kW...
-
Page 2: Please Read Before Starting
Important! When Transporting Be careful when picking up and moving the indoor and Please Read Before Starting outdoor units. Get a partner to help, and bend your knees when lifting to reduce strain on your back. Sharp This air conditioning system meets strict safety and edges or thin aluminum fins on the air conditioner can operating standards. -
Page 3: Table Of Contents
Table of Contents Page 1. OPERATING RANGE ..........................1 2. SPECIFICATIONS 2-1. Unit Specifications .......................... 2 2-2. Major Component Specifications....................4 2-3. Other Component Specifications....................6 3. DIMENSIONAL DATA..........................7 4. REFRIGERANT FLOW DIAGRAM ......................9 5. PERFORMANCE DATA 5-1. Performance Charts (2-room multi) ....................11 5-2. -
Page 4: Operating Range
1. OPERATING RANGE Temperature Indoor Air Intake Temp. Outdoor Air Intake Temp. Maximum 32°C DB / 23°C W.B. 43°C D.B. Cooling Minimum 19°C DB / 14°C W.B. 19°C D.B. -
Page 5: Specifications
2. SPECIFICATIONS 2-1. Unit Specifications Outdoor Unit SAP – CMRV1923GJ Type 2-room multi outdoor unit Number of connectable indoor units Maximum capacity of connected indoor u Maximum capacity of operating indoor units Power Source 220–240V ~ 50Hz 220V ~ 60Hz Voltage rating 230 V 220 V... - Page 6 Outdoor Unit SAP – CMRV2433GJ Type 3-room multi outdoor unit Number of connectable indoor units Maximum capacity of connected indoor u 11.4 Maximum capacity of operating indoor units 11.4 Power Source 220–240V ~ 50Hz 220V ~ 60Hz Voltage rating 230 V 220 V Performance Cooling...
-
Page 7: Major Component Specifications
2-2. Major Component Specifications 2-2-1. Outdoor Unit Outdoor Unit SAP – CMRV1923GJ Control PCB / HIC PCB / Filter PCB POW-CM5A1-C-T / CR-HIC30A2-C-T / POW-CM5B1-C-T Compressor Type DC Twin Rotary (Hermetic) Compressor model C-7RVN153H0W 80851080 Compressor oil … Amount FVC68S … 650 Ω... - Page 8 Outdoor Unit SAP – CMRV2433GJ Control PCB / HIC PCB / Filler PCB POW-CM5A1-C-T / CR-HIC30A2-C-T / POW-CM5B1-C-T Compressor Type DC Twin Rotary (Hermetic) Compressor model C-7RVN153H0W 80851080 Compressor oil … Amount FVC68S … 650 Ω Coil resistance (Ambient temp. 25°C) R –...
-
Page 9: Other Component Specifications
2-3. Other Component Specifications Outdoor Unit SAP – CMRV1923GJ SAP – CMRV2433GJ • Compressor temp sensor 10 20 30 40 50 60 70 80 90 Temperature (°C) • Outdoor air temp sensor • Narrow tube sensor • Wide tube sensor Temperature (°C) -
Page 10: Dimensional Data
3. DIMENSIONAL DATA Outdoor Unit SAP – CMRV1923GJ AIR INTAKE Drain hole AIR INTAKE AIR DISCHARGE AIR INTAKE Narrow tube service valve ø6.35 (1/4") Wide tube service valve ø9.52 (3/8") Unit: mm... - Page 11 Outdoor Unit SAP – CMRV2423GJ AIR INTAKE Drain hole AIR INTAKE AIR DISCHARGE AIR INTAKE Narrow tube service valve ø6.35 (1/4") Wide tube service valve ø9.52 (3/8") unit: mm...
-
Page 12: Refrigerant Flow Diagram
4. REFRIGERANT FLOW DIAGRAM Outdoor Unit SAP – CMRV1923GJ 2-Room Multi Refrigerant Tubing System Diagram Unit: mm Se v ce valve e c a lec c Se v ce valve valve lec c e valve S a e Insulation of Refrigerant Tubing Insulation IMPORTANT Thickness:... - Page 13 Outdoor Unit SAP – CMRV2423GJ 3-Room Multi Refrigerant Tubing System Diagram Unit: mm d tu Outd r u t a u u at r a u u at r du at r Insulation of Refrigerant Tubing Insulation IMPORTANT Thickness: Thickness: Because capillary tubing is used in the outdoor unit, both the Min.
-
Page 14: Performance Data
5. PERFORMANCE DATA 5-1. Performance charts Outdoor Unit SAP – CMRV1923GJ Outdoor Unit SAP – CMRV1923GJ SAP – KMRV93GJ × × 1 SAP – KMRV123GJ × × 1 Indoor Unit Indoor Unit • Cooling Characteristics • Cooling Characteristics (1) Low pressure performance chart (1) Low pressure performance chart (RH: 46%, Indoor fan speed: High fan) (RH: 46%, Indoor fan speed: High fan) - Page 15 Outdoor Unit SAP – CMRV1923GJ SAP – KMRV183GJ × × 1 Indoor Unit • Cooling Characteristics (1) Low pressure performance chart (RH: 46%, Indoor fan speed: High fan) (50/60Hz, 220V) Lo fan Hi fan Outdoor air temperature (°C) (2) Operating current performance chart (RH: 46%, Indoor fan speed: High fan) (50/60Hz, 220V) Lo fan...
-
Page 16: Performance Charts (3-Room Multi)
5-2. Performance charts (2-room multi) Outdoor Unit SAP – CMRV2433GJ Outdoor Unit SAP – CMRV2433GJ SAP – KMRV93GJ × × 1 SAP – KMRV123GJ × × 1 Indoor Unit Indoor Unit • Cooling Characteristics • Cooling Characteristics (1) Low pressure performance chart (1) Low pressure performance chart (RH: 46%, Indoor fan speed: High fan) (RH: 46%, Indoor fan speed: High fan) - Page 17 Outdoor Unit SAP – CMRV2433GJ SAP – KMRV183GJ × × 1 Indoor Unit • Cooling Characteristics (1) Low pressure performance chart (RH: 46%, Indoor fan speed: High fan) (50/60Hz, 220V) Lo fan Hi fan Outdoor air temperature (°C) (2) Operating current performance chart (RH: 46%, Indoor fan speed: High fan) (50/60Hz, 220V) Lo fan...
-
Page 18: Electrical Data
6. ELECTRICAL DATA 6-1. Electric Wiring Diagrams Outdoor Unit SAP – CMRV1923GJ Electric Wiring Diagram for 2-room multi outdoor unit (CMRV1923GJ) Before replacing PCBs, turn off the power and check that all CAUTION lamps on the PCB are off before starting work. Electric shock will occur if work is performed while the lamps are lit. - Page 19 Outdoor Unit SAP – CMRV2433GJ Electric Wiring Diagram for 3-room multi outdoor unit (CMRV2433GJ) Before replacing PCBs, turn off the power and check that all CAUTION lamps on the PCB are off before starting work. Electric shock will occur if work is performed while the lamps are lit. Electric Shock...
-
Page 20: Installation Instructions
7. INSTALLATION INSTRUCTIONS Installation Site Selection 7-1. Indoor Unit To prevent abnormal heat generation and the WARNING possibility of fire, do not place obstacles, enclosures and grilles in front of or surrounding the air conditioner in a way that may block air flow. AVOID: direct sunlight. - Page 21 (1) Connecting indoor unit types (93 – 183) for CMRV1923GJ 12 7 a 17 Flar 12 7 Flar 12 7 f r c g ub 12 7 al ar d ff r 12 7 al ar Fig. 2a 12 types) type) (Less than 17 m) Fig.
-
Page 22: Outdoor Unit
7-2. Outdoor Unit Exhaust fan AVOID: Hot air Heat source heat sources, exhaust fans, etc. (Fig. 3) damp, humid or uneven locations. Outdoor unit choose a place as cool as possible. choose a place that is well ventilated. Fig. 3 allow enough room around the unit for air intake/ exhaust and possible maintenance. -
Page 23: Diagram Of Outdoor Unit Installation
7-3. Diagram of Outdoor Unit Installation Never install only a single indoor unit. Be sure to connect indoor and outdoor units only in combinations that are listed in the catalog or in the combination table that was provided with the indoor unit. -
Page 24: Recommended Wire Length And Diameter
7-4. Recommended Wire Length and Diameter Regulations on wiring diameter differ from locality to locality. For field wiring requirements, please refer to your local electrical codes. Carefully observe these regulations when carrying out the installation. Table 2 shows maximum wire lengths for control line and power line and fuse or circuit capacity. -
Page 25: Current Control
8-1. Current Control 8- . Low Start Current The operating current may rise as a result of causes Operation starts at 10 Hz, and the start current is less than including increasing heating or cooling loads or the normal operating current. This prevents the flickering of decreases in power voltage. -
Page 26: Troubleshooting
9. TROUBLESHOOTING Both the indoor unit and outdoor unit include electronic control circuits. Be sure to pay attention to the following before inspecting or repairing the outdoor-side electronic circuits. High-capacity electrolytic capacitors are used inside the outdoor unit controller (inverter). They retain an electrical charge (charging voltage DC 311 V) even after the power is turned OFF, and some time is required for the charge to dissipate. -
Page 27: Outdoor Unit Trouble Diagnostics
9-1. Outdoor Unit Trouble Diagnostics If a protective device has activated or there is a sensor failure in the outdoor unit, the 6 error monitor lamps on the outdoor control circuit board will indicate the nature of the trouble. rror contents rror contents ompressor dischar e temperature sensor data failure... -
Page 28: Checking The Outdoor System
9- . Checking the Outdoor System 9- -1. Checking the outdoor unit Contro Check items (unit operation) • Apply 220 V AC between terminals 1 and 2 on the • red on the control circuit board must outdoor unit 3P terminal block. illuminate. -
Page 29: Unit Problems And Inspection Points
9-3. Unit Problems and Inspection Points Indoor nit tdoor nit t ers Problems Inspection points el - ia nostics c ec 1 Indoor controller control nit Indoor an motor oom temperat re sensor eat e c an er temperat re sensor Inter- nit cable itc circ it board tdoor control... - Page 30 9-3-1. Outdoor control circuit board Refer to 9-2-1. Checking the outdoor unit. Do not remove or insert the outdoor control circuit board connector when power is being supplied to it. (The controller will be damaged.) 9-3- . a ur nt oint ( lack) (Red) elow...
- Page 31 9-3-7. Electric expansion valve When replacing the electric expansion valve and coil, be sure to attach the connectors in the correct positions. Labels are applied to the valve body and coil, corresponding to the connector colors, to identify them. se a tester to eas re t e volta e 1 When the power is turned , the needle will move from...
-
Page 32: Explanation Of Functions
9-4. Explanation of Functions... - Page 33 The ON/OFF operation tton on the re ote in te e en a ter the rea er i t rne ON ontro er i pre e 1 e o i t i in rea e Ne operatin o e i eter ine a e on the te perat re on ition at the ti e the...
- Page 34 operation tton on t e re ote in te e en a ter t e rea er i t rne ontro er i pre e er o o er a in te 1 e o er o o er a in te er o in te...
-
Page 35: Refrigerant R410A: Special Precautions When Servicing Unit
10. REFRIGERANT R410A: SPECIAL PRECAUTIONS WHEN SERVICING UNIT 10-1. Characteristics of New Refrigerant R410A 10-1-1. What is New Refrigerant R410A? R410A is a new refrigerant that contains two types of pseudo-non-azeotropic refrigerant mixture. Its refrigeration capacity and energy efficiency are about the same level as the conventional refrigerant, R22. 10-1-2. - Page 36 Tubing precautions Refrigerant R410A is more easily affected by dust or moisture compared with R22, thus be sure to temporarily cover the ends of the tubing with caps or tape prior to installation. Never use 0.7mm-thick copper tubing or tubing which is less than 0.8mm in thickness, since air conditioners with R410A are subject to higher pressure than those using R22 and R407C.
-
Page 37: Tools Specifically For R410A
10-3. Tools Specifically for R410A For servicing, use the following tools for R410A Tool Distinction Tool Name Gauge manifold Charging hose Gas leak detector Refrigerant cylinder Charging cylinder Refrigerant recovery unit Vacuum pump with anti-reverse flow (*1) Tools specifically for R410A (Solenoid valve-installed type, which prevents oil from flowing back into the unit when the power is off, is recommended.) Vacuum pump (*2) …... -
Page 38: In Case Of Compressor Malfunction
10-5. In Case of Compressor Malfunction Should the compressor malfunction, be sure to make the switch to a replacement CAUTION compressor as quickly as possible. Use only the tools indicated exclusively for R410A. See “10-3. Tools Specifically for R410A.” 10-5-1. Procedure for replacing compressor (1) Recovering refrigerant Any remaining refrigerant inside the unit should not be released to the atmosphere, but recovered using the... - Page 39 (5) Recharging Configuration and characteristics of cylinders Valve Be sure to charge the specified amount of refrigerant in liquid state using the service port of the wide tube service valve. The proper amount is listed on the unit's nameplate. When the entire amount cannot be charged all at once, charge gradually while operating the unit in Cooling Operation.
-
Page 40: In Case Refrigerant Is Leaking
10-6. In Case Refrigerant is Leaking Never attempt to charge additional refrigerant when refrigerant has been leaking CAUTION from the unit. Follow the procedure described below to locate points of leaks and carry out repairs, then recharge the refrigerant. (1) Detecting Leaks Use the detector for R410A to locate refrigerant leak (1) Detect leaks points. - Page 41 (6) Recharging Configuration and characteristics of cylinders Valve Be sure to charge the specified amount of refrigerant in liquid state using the service port of the wide tube service valve. The proper amount is listed on the unit's nameplate. When the entire amount cannot be charged all at once, charge gradually while operating the unit in Cooling Operation.
-
Page 42: Charging Additional Refrigerant
10-7. Charging Additional Refrigerant 10-7-1. When Tubes are Extended Observe the proper amount of refrigerant as stated in this service manual or the installation manual that came with the indoor unit. Charge additional refrigerant in liquid state only. Never charge additional refrigerant if refrigerant is leaking from the unit. Follow CAUTION instructions given in “10-6. -
Page 43: Appendix
APPENDIX UNIT COMBINATION TABLES NOTE Be sure to operate the air conditioning system only when 2 or more indoor units have been installed. If operated with only a single unit installed, the returning fluid to the compressor may cause a malfunction. - Page 44 2-Room Outdoor Unit Combination Table Outdoor Unit SAP – CMRV1923GJ NOTE 2.8: SAP-#MRV93GJ 3.6: SAP-#MRV123GJ 5.0: SAP-#MRV183GJ Single-room operation Single-room operation Indoor Unit Capacity (kW) Indoor Unit Indoor unit Combination Conbination Room A Room B Room C Total Performance Power Input (W) Current (A) Min.
- Page 45 3-Room Outdoor Unit Combination Table Outdoor Unit SAP – CMRV2433GJ NOTE 2.8: SAP-#MRV93GJ 3.6: SAP-#MRV123GJ 5.0: SAP-#MRV183GJ Single-room operation Single-room operation Indoor Unit Capacity (kW) Indoor Unit Indoor unit Combination Conbination Room A Room B Room C Total Performance Power Input (W) Current (A) Min.
- Page 46 SANYO Electric Co., Ltd. Osaka, Japan 700540 MAY/2003 Printed in Japan...
