DISASSEMBLY- AND RE-ASSEMBLY ADVISE FC9228 - To open the appliance, first remove the filter cover Further disassembly advise for the hinge: (item 33). - First remove the 2 screws (A) underneath the handle to - Then remove the hinge; remove the hinge back (item 2)
PARTS LIST FC9228 Service code Description Service code Description 4322 009 09660 Handle assy Emperor red 4322 000 38790 Silencer 4 wall backpanel 4322 005 20500 Hinge back Emperor red 4322 003 25460 S-Class h. sealing 4322 005 20530 User Panel PR RMC assy...
