- Page 1 GN600 Series Gigabit PCI Adapter User’s Guide Version 1.0 April 2003...
-
Page 2: Interference Statements And Warnings
Interference Statements and Warnings FCC Interference Statement This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operations. -
Page 3: Zyxel Limited Warranty
ZyXEL Limited Warranty ZyXEL warrants to the original end user (purchaser) that this product is free from any defects in materials or workmanship for a period of up to two (2) years from the date of purchase. During the warranty period and upon proof of purchase, should the product have indications of failure due to faulty workmanship and/or materials, ZyXEL will, at its discretion, repair or replace the defective products or components without charge for either parts or labor... -
Page 5: Package Contents
Package Contents One GN600 series Gigabit PCI Adapter One 3.5” Installation Disk This User’s Guide WoL cable A. Hardware Installation Follow the steps below to install the adapter. Save your work and close all programs. Disconnect the computer power cord from the power source. -
Page 6: Hardware Connection
Connecting WoL Cable (Optional) This is an optional function. Proceed with the installation if your computer supports Wake On LAN and that you wish to use this function. Refer to your motherboard user’s guide for more information. Follow the steps in the Hardware Installation section to turn off the computer and make sure the adapter is fully seated in the PCI slot. -
Page 7: Driver Installation
COLOR STATUS DESCRIPTION Green The port is operating at 100Mbps. The port is operating at 10Mbps when the 1000 LED is also off. 1000 Green The port is operating at 1000Mbps. The port is operating at 10Mbps when the 100 LED is also off. FDX/COL Green The port is operating in full-duplex mode. -
Page 8: Troubleshooting
Troubleshooting PROBLEM CORRECTIVE ACTION Windows does Turn off the computer and make sure the adapter’s not auto-detect contacts are fully seated in the slot and secured to the the adapter. computer with a bracket screw. Perform a hardware scan by clicking Start, Settings, Control Panel and double-clicking Add/Remove Hardware.
