- Page 1 TFX2 Service Information Service Information Laney Classic British Amplification Newlyn Road, Cradley Heath, West Midlands. B64 6B£ www.laney.co.uk...
- Page 2 150K SM SW2C 100N 50VSM 4P2WPSPB DRIVE 1 SWITCH CLEANFXFET DRIVEFXFET +15V Drive 2 Active FXRETURN2 NOTE: TFX2 - FIT U1+R1. MISS OUT LN1+LN2 FXRETURN1 LED3MMRHB CD4069UBE NOTE: TFX3 - FIT LN1+LN2, MISS OUT U1+R1 FXSEND 22KSM 3K3SM LED7 CD4069UBE...
- Page 3 120V = 5600-2066B Lines are on a seperate -30V -30V2 Crack-off pcb 47U 50V 15V ZD1.3W Fitted on TFX2 model only HD10W.5 Flame proof resister Must only be replaced with same type and rating Title Revision History TFX1/TFX2 OUTPUT PCB Indi cates safety critical component C17 Added.
- Page 4 DRIVEFXFET FXRETURN2 FXRETURN1 22KB6S CLEAN FX LEVEL FXSEND HD10WLSJ DRIVE FX LEVEL 22KB6S BRKT2 BR16BU Title Revision History TFX2 FX Control Board R3/R4 FROM 100K TO 10K Size Number Revision 9392 Industries 9392_4.Sch Date: 05/09/2003 Sheet of Rich Thompson File: D:\9392_4\9392_4.Sch...
- Page 5 PIGGY BACK PUSH SWITCH 3.0000 005503 7.5mm ROUND BLACK BUTTON 4.0000 009390 TFX2/TFX3 PREAMP PCB ISSUE 3 1.0000 007986 9392 TFX2 FX CONTROL PCB ASSY 1.0000 003022 3mm GREEN LED 2.0000 004061 6mm 22K LIN POT 2.0000 005036 6 WAY LOCKING HEADER 2.0000...
- Page 6 005134 680R 2W5 WIREWOUND RESISTOR 1.0000 005135 65MM HEATSINK FINNED EXTRUSION 1.0000 005686 4.8MM TERMINAL SPADE 5.0000 009389 TFX1/TFX2 OUTPUT PCB ISSUE 3 1.0000 007991 9394 TFX2/TFX3 TUBE PCB ASSY 1.0000 001000 470K .25W RESISTOR 2.0000 001003 1K .25W RESISTOR 1.0000...
- Page 7 25mm X 25mm PAR 0.8000 10314 18mm MDF 0.1000 10308 GREY FRONTFRET 0.2000 10328 REPTILE BLACK 0.7000 10479 TFX2 CARTON 1.0000 10423 TF200 INSERT 30550 1.0000 10600 32/18 STAPLE 12.0000 10622 POLY. BAG 48(0) X 48 1.0000 10629 MASKING TAPE 1.5"...
