INTRODUCTION

This service manual describes the latest technical information
for the IC-M73, IC-M73EURO VHF MARINE TRANSCEiVER,
at the time of publication.
MODEL VERSION
USA
EXP
IC-M73
USA-10
EXP-10
EUR-01
EUR
UK
FRG
HOL
AUS
IC-M73EURO
EUR-11
EUR-10
UK-10
FRG-10
HOL-10
AUS-10

ORDERING PARTS

Be sure to include the following four points when ordering
replacement parts:
1. 10-digit Icom part number
2. Component name
3. Equipment model name and unit name
4. Quantity required
<ORDER EXAMPLE>
1110003491 S.IC TA31136FNG IC-M73 MAIN UNIT
8820001210 Screw 2438 screw
Addresses are provided on the inside back cover for your
convenience.
Icom, Icom Inc. and the Icom logo are registered trademarks of Icom Incorporated (Japan) in Japan, the United States, the
United Kingdom, Germany, France, Spain, Russia and/or other countries.
FLEXIBLE
AC ADAPTER
ANTENNA
BC-123SA
BC-123SE
FA-S64V
BC-123SA
BC-123SE FA-S59V
–
FA-S64V
BC-123SE
BC-123SV
FA-S59V
BC-123SE
–
FA-S64V
BC-123SE
BC-123SV
5 pieces
IC-M73 Top cover 10 pieces

CAUTION

NEVER connect the transceiver to an AC outlet or to a DC
power supply that uses more than the specifi ed voltage. This
will ruin the transceiver.
DO NOT reverse the polarities of the power supply when con-
necting the transceiver.
DO NOT apply an RF signal of more than 20 dBm (100 mW) to
the antenna connector. This could damage the transceiver's
front-end.
To upgrade quality, any electrical or mechanical parts
and internal circuits are subject to change without notice
or obligation.

REPAIR NOTES

1. Make sure that the problem is internal before dis-assem-
bling the transceiver.
2. DO NOT open the transceiver until the transceiver is dis-
connected from its power source.
3. DO NOT force any of the variable components. Turn them
slowly and smoothly.
4. DO NOT short any circuits or electronic parts. An insulated
tuning tool MUST be used for all adjustments.
5. DO NOT keep power ON for a long time when the trans-
ceiver is defective.
6. DO NOT transmit power into a Standard Signal Generator
or a Sweep Generator.
7. ALWAYS connect a 30 dB to 40 dB attenuator between the
transceiver and a Deviation Meter or Spectrum Analyzer,
when using such test equipment.
8. READ the instructions of the test equipment thoroughly
before connecting it to the transceiver.
(IC-M73EURO)
