SLV-SE35/SE50/SE60/SE70/SE80/SX60/SX70/SX80
SERVICE MANUAL
j
G
S MECHANISM
Refer to the SERVICE MANUAL of VHS
MECHANICAL ADJUSTMENT
MECHANICAL ADJUSTMENTS. (9-921-647-11)
System
Channel coverage
B MODEL
SECAM(L)
VHF F2 to F10
UHF F21 to F69
CATV B to Q
HYPER S21 to S41
B/AE1/AE2/NP/NP1/NP2/VC/VC1/VC2
MODEL
PAL(B/G):
VHF E2 to E12
VHF Italian channels A to H
UHF E21 to E69
CATV S01 to S05,S1 to S20
HYPER S21 to S41
EE,EG,EN MODEL
PAL(B/G,D/K)
VHF E2 to E12,R1 to R12
UHF E21 to E69,R21 to R69
CATV S1 to S41,S01 to S05
SE70EX MODEL
PAL (I)
VHFIA to IJ,SA10 to SA13
UHF B21 to B69
CATV S01 to S05,S1 to S20
HYPER S21 to S41
SE70UX/SE80UX MODEL
PAL (I)
UHF B21 to B69(SE70UX)
UHF E21 to E69(SE80UX)
MICROFILM
RMT-V256A/V257B/V259/V259A/V259B/V259C
Photo: SLV-SE80
RMT-V259B
for
SPECIFICATIONS
RF output signal
UHF channels 21 to 69
Aerial out
75-ohm asymmetrical aerial socket
Inputs and outputs
LINE-1
(TV)
21-pin
Video input: pin 20
Audio input: pins 2 and 6
Video output: pin 19
Audio output: pins 1 and 3
SE50/SE70EE/EG/EN/SE80/SX70EN/
SX80VC MODEL
LINE-2 IN
VIDEO IN, phono jack (1)
Input signal: 1 Vp-p,
75 ohms, unbalanced,sync negative
AUDIO IN, phono jack (2)(EXCEPT SE50)
AUDIO IN, phono jack (1)(SE50 MODEL)
Input level: 327 mVrms
Input impedance : more than 47 kilohms
EXCEPT AE1/AE2/EE/SE35
LINE-2 IN(SE60NP/SE70B/EX/NP1/NP2/
UX/VC1/VC2/SX70B/VC/SX60)
LINE-3 IN(SE50EG/SE70EG/EN/SE80/
SX70EN/SX80)
21-pin
Video input: pin 20
Audio input: pins 2 and 6
SLV-SE70VC1/SE70VC2/SE80VC1/
SLV-SE60NP/SE70NP1/SE70NP2/
East European Model
SLV-SE35EG/SE50EG/SE70EG/SE80EG
EXCEPT
SE35/SE50/SE60/SE70EE/
SE80EG/SX60
AUDIO OUT
Phono jack (2)
Rated output
level: 327 mVrms
Load impedance: 47 kilohms
Output impedance: less than 10 kilohms
SE50EE/SE70EE/SE80EG MODEL
LINE-2 OUT
AUDIO OUT,Phono jack(2)
Rated output level:327mVrms
Load impedance:47 kilohms
Output impedance:less than 10 kilohms
VIDEO OUT,Phono jack(1)
Rated output level:327mVrms
Load impedance:47 kilohms
Output impedance:less than 10 kilohms
General
Power requirements
220 - 240 V AC, 50 Hz
Power consumption
22 W
Operating temperature
5°C to 40°C
Storage temperatur
-20°C to 60°C
VIDEO CASSETTE RECORDER
AEP Model
SLV-SE60AE1/SE60AE2
UK Model
SLV-SE70UX/SE80UX
E Model
SLV-SE70EN/SE80EN/SX70EN
French Model
SLV-SE70B/SE80B/SX70B
German Model
SE80VC2/SX70VC/SX80VC
Spanish Model
SE80NP/SX60NP
SLV-SE50EE/SE70EE
Greek Model
Irish Model
SLV-SE70EX
Dimensions
EXCEPT SE80B/NP/UX/VC1/VC2/SX80
Approx. 430 x 100 x 314 mm
(Approx. 17 x 4 x 12 3/8inches) (w/h/d)
SE80B/NP/UX/VC1/VC2/SX80 MODEL
Approx. 430 x 100 x 317 mm
(Approx. 17 x 4 x 12 1/2inches) (w/h/d)
including projecting parts and controls
Mass
SE50/SE70EE/EG/EN/SE80/SX70EN/SX80
MODEL
Approx. 4.6 kg
(Approx. 10 lb 2 oz)
EXCEPT SE50/SE70EE/EG/EN/SE80/SX70EN/
SX80
Approx. 4.5 kg
(Approx. 9 lb 15 oz)
Supplied accessories
Remote commander (1)
R6 (size AA) batteries (2)
Aerial cable (1)
EURO-AV cable (1)
AC Plug adaptor(1)
Audio cable(1)
Design and specifications are subject to change
without notice.
Advertisement
Table of Contents
Related Manuals for Sony SLV-SE35
Summary of Contents for Sony SLV-SE35
- Page 1 SLV-SE35/SE50/SE60/SE70/SE80/SX60/SX70/SX80 RMT-V256A/V257B/V259/V259A/V259B/V259C SERVICE MANUAL AEP Model SLV-SE60AE1/SE60AE2 UK Model SLV-SE70UX/SE80UX E Model SLV-SE70EN/SE80EN/SX70EN French Model SLV-SE70B/SE80B/SX70B German Model SLV-SE70VC1/SE70VC2/SE80VC1/ SE80VC2/SX70VC/SX80VC Spanish Model Photo: SLV-SE80 RMT-V259B SLV-SE60NP/SE70NP1/SE70NP2/ SE80NP/SX60NP East European Model SLV-SE50EE/SE70EE Greek Model SLV-SE35EG/SE50EG/SE70EG/SE80EG Irish Model S MECHANISM SLV-SE70EX Refer to the SERVICE MANUAL of VHS MECHANICAL ADJUSTMENT MECHANICAL ADJUSTMENTS.
- Page 2 SLV-SE35/SE50/SE60/SE70/SE80/SX60/SX70/SX80 For schematic diagram MA-339 (1/7) (REC/PB AMP) SCHEMATIC DIAGRAM • Refer to page 4-5 for printed wiring board. — Ref. No. MA-339 Board:1,000 Series — • Refer to page 4-2 for waveforms. CUTTING PICTURE, R349 SOUND 4700 Q340 PDTC144EK-115...
- Page 3 SLV-SE35/SE50/SE60/SE70/SE80/SX60/SX70/SX80 For schematic diagram MA-339 (2/7) (VIDEO/NORMAL AUDIO) SCHEMATIC DIAGRAM • Refer to page 4-5 for printed wiring board. — Ref. No. MA-339 Board:1,000 Series — • Refer to page 4-2 for waveforms. 0.022µ Note : Note : The components identified by Les composants identifiés par...
-
Page 4: Servo/System Control
SLV-SE35/SE50/SE60/SE70/SE80/SX60/SX70/SX80 For schematic diagram MA-339 (3/7) (SERVO/SYSTEM CONTROL) SCHEMATIC DIAGRAM • Refer to page 4-5 for printed wiring board. — Ref. No. MA-339 Board:1,000 Series — • Refer to page 4-2 for waveforms. Note : Note : The components identified by Les composants identifiés par... - Page 5 SLV-SE35/SE50/SE60/SE70/SE80/SX60/SX70/SX80 For schematic diagram MA-339 (4/7) (AFM AUDIO) SCHEMATIC DIAGRAM • Refer to page 4-5 for printed wiring board. — Ref. No. MA-339 Board:1,000 Series — SE35,SE50 SE50 MODEL MODEL EXCEPT SE50:EG 11.7 11.7 11.7 11.9 11.7 11.7 11.7 11.8...
- Page 6 SLV-SE35/SE50/SE60/SE70/SE80/SX60/SX70/SX80 For schematic diagram MA-339 (5/7) (TUNER) SCHEMATIC DIAGRAM • Refer to page 4-5 for printed wiring board. — Ref. No. MA-339 Board:1,000 Series — Note : Note : The components identified by Les composants identifiés par mark ! or dotted line with mark une marque ! sont critiques ! are critical for safety.
- Page 7 SLV-SE35/SE50/SE60/SE70/SE80/SX60/SX70/SX80 For schematic diagram MA-339 (6/7) (INPUT/OUTPUT) SCHEMATIC DIAGRAM • Refer to page 4-5 for printed wiring board. — Ref. No. MA-339 Board:1,000 Series — D576 MTZJ-13 SE50:EG MODEL D514 MTZJ-13 INPUT/OUTPUT 4-18 4-17 MA-339 (6/7)
- Page 8 SLV-SE35/SE50/SE60/SE70/SE80/SX60/SX70/SX80 For schematic diagram MA-339 (7/7) (POWER SUPPLY) SCHEMATIC DIAGRAM • Refer to page 4-5 for printed wiring board. — Ref. No. MA-339 Board:1,000 Series — AE1,AE2,EE,SE35 MODEL AE1,AE2,EE,SE35 MODEL Note : Note : The components identified by Les composants identifiés par...
-
Page 9: Mode Control
SLV-SE35/SE50/SE60/SE70/SE80/SX60/SX70/SX80 For schematic diagram FR-152 (MODE CONTROL)/ KK-17 (TIMER)/ DM-82 (OPERATION SWITCHES)/SU-5 (SURROUND) SCHEMATIC DIAGRAM • Refer to page 4-2 for waveforms. — Ref. No. FR-152 Board:2,000 Series/KK-17 Board:3,000 Series/DM-82 Board:4,000 Series/SU-5 Board: 5,000 Series — MODE CONTROL TIMER OPERATION SWITCHES... -
Page 10: Power Block
SLV-SE35/SE50/SE60/SE70/SE80/SX60/SX70/SX80 POWER BLOCK SRV878EK (SWITCHING REGURATOR) SCHEMATIC DIAGRAM — Ref. No. SRV878 Board:9,000 Series — POWER BLOCK (SRV878EK) SUB BOARD MAIN BOARD T151 POWER CN151 TRANSFORMER D251 R154 C152 R251 AU02Z 100K 2W 0.01 / 400 R151 D101-104 150K 1N4005... -
Page 11: Secam Video Signal Processor
SLV-SE35/SE50/SE60/SE70/SE80/SX60/SX70/SX80 SE-77(SECAM VIDEO SIGNAL PROCESSOR) SCHEMATIC DIAGRAM — Ref. No. SE-77 Board:1,000 Series — SECAM VIDEO SIGNAL PROCESSOR 4-29 4-30 SE-77...
