Introduction Thank you for choosing this Sony product. Before operating the TV, please read this manual thoroughly and retain it for future reference. For KDL-70X4500 Users Refer to “KDL-70X4500 Start-up Guide” for details about the installation. Trademark information HDMI, the HDMI logo and High-...
Table of Contents Start-up Guide Safety Information ..........................9 Precautions .............................11 Remote and TV Controls/Indicators ....................12 Watching TV Watching TV ............................16 Using the Digital Electronic Programme Guide (EPG) (for digital channels only) ....18 Using the Favourite List ........................19 Using Optional Equipment Connecting Optional Equipment ....................20 Viewing Pictures from a Connected Equipment ................23 Playing back Photo/Music via USB ....................24...
Start-up Guide 1: Checking the accessories 2: Attaching the stand (for KDL-46X4500/40X4500) AC power cord* (1) Stand (1) and screws (4) (KDL-46X4500/40X4500 only) Remote RMF-GD001 (1) Size AA batteries (R6 type) (2) * Do not remove the ferrite cores. To replace the speaker grille (for KDL- 55X4500/46X4500/40X4500) The speaker grille unit can be replaced with others that are sold separately.
Page 5
3: Connecting an antenna/ 4: Preventing the TV from cable/VCR toppling over Connecting an antenna/cable Antenna cable (not supplied) Antenna cable (not supplied) Connecting an antenna/cable and VCR Install a wood screw (4 mm in diameter, not supplied) in the TV stand. Install a machine screw (M6 ×...
Page 6
5: Bundling the cables 6: Performing the initial set-up KDL-40X4500 KDL-46X4500 KDL-55X4500 Push and lift the cover to open. Press and hold RETURN while holding • Do not bundle the AC power cord together with down TV on the remote.
Page 7
Select “Home” for the best TV settings to use the TV in the home. Make sure that the antenna is connected. The TV starts searching for all available digital channels. Do not press any buttons on the TV or remote while proceeding. •...
Page 8
Adjusting the viewing angle Detaching the Table-Top of the TV (for KDL-55X4500/ Stand from the TV 46X4500/40X4500) • Remove the screws guided by the arrow marks This TV can be adjusted within the angles of the TV. shown below. • Do not remove the Table-Top Stand for any reason other than listed below.
Leave space around the TV set as shown below. falling down and cause personal injury or damage to the TV. s It is strongly recommended that you use a Sony wall-mount s Only qualified service personnel should carry out wall bracket in order to provide adequate air-circulation.
Page 10
Ask your dealer or Sony service centre to have it checked by – Disconnect the AC power cord from the AC power outlet before qualified service personnel.
Precautions Viewing the TV s View the TV in moderate light, as viewing the TV in poor light or during long period of time, strains your eyes. s When using headphones, adjust the volume so as to avoid excessive levels, as hearing damage may result. LCD Screen s Although the LCD screen is made with high-precision technology and 99.99% or more of the pixels are effective,...
Remote and TV Controls/Indicators Remote and TV controls The supplied remote does not function until you register it to the • To register the remote to the TV for the first time, follow the steps in “6: Performing the initial set-up” on page 6. •...
Page 13
(Twin Displays two pictures simultaneously (page 24). Picture/PIP) (Subtitle Press to change the subtitle language (page 45) (in setting) digital mode only). (Info/ In digital mode: Displays details of the current and Text reveal) next programme one by one. In analogue mode: Displays information. Press once to display the current channel number and Wide Mode.
Page 14
• If you turn the TV off, Theatre Mode is also turned off. • “Control for HDMI” (BRAVIA Sync) is only available with the connected Sony equipment that has the BRAVIA Sync or BRAVIA Theatre Sync logo or is compatible with control for HDMI.
Indicators Indicator Description 1 Light sensor Do not put anything over the sensor, doing so may affect its function. (page 43) 2 " (Power) Lights up in green when the TV is on. 3 1 (Standby) Lights up in red when the TV is in standby mode. (Picture Off/ Lights up in green when you select “Picture Off”...
Watching TV Press the number buttons or PROG +/– to Watching TV select a TV channel. To select channel numbers 10 and above using the number buttons, enter the next digit quickly. To select a digital programme using the Digital Electronic Programme Guide (EPG), see page 18.
Page 17
To change the Wide Mode manually Press repeatedly to select the desired Wide Mode. Wide Zoom* Enlarges the centre portion of the picture. The left and right edges of the picture are stretched to fill the 16:9 screen. Normal Displays the 4:3 picture in its original size.
Using the Digital Electronic Programme Guide (EPG) (for digital channels only) In digital mode, press GUIDE. Perform the desired operation as shown in the following table or displayed on the screen. Digital Electronic Programme Guide (EPG) Do this View a programme Press F/f/G/g to select a programme, then press Press GUIDE.
Using the Favourite List Analogue Favourites The Favourite feature lets you select programmes from a list of up to 16 favourite channels that you specify. In analogue mode, press Perform the desired operation as shown in the following table or displayed on the screen.
Using Optional Equipment Connecting Optional Equipment You can connect a wide range of optional equipment to your TV. Broadband router Camcorder Audio system DVD player PC (HDMI-output) Blu-ray disc player DIGITAL MEDIA PORT adaptor Digital still camera Camcorder For service use only USB storage media Camcorder...
Page 21
• The connected equipment is not powered when the TV is turned off or in standby mode. 5 USB You can enjoy photo/music files stored in a Sony digital still camera or camcorder through a USB cable or USB storage device on your TV (page 24).
Page 22
Connect to Input symbol on Description screen Use to record the analogue video and sound from TV to a DVD recorder or VCR. To turn off the sound of the TV speakers, set “Speaker” to “Audio System” (page 41). If you connect a mono equipment, connect to the L jack •...
Viewing Pictures from a • Depending on the “Skip Inputs” setting (page 42), some input sources may appear in the list. If you Connected Equipment have set an input source to “Skip”, that input Turn on the connected equipment, then press source does not appear regardless of whether the equipment is connected.
TV programme) on the screen You can enjoy photo/music files stored in a simultaneously. Sony digital still camera or camcorder through Connect an optional equipment or PC a USB cable or USB storage device on your (page 20), and make sure that images from the equipment or PC appear on the screen.
Page 25
The data on the USB device may be damaged. Picture Frame Allows you to select a • Sony will not be held liable for any damage to, or Image photograph to be loss of, data on the recording media due to a displayed as a picture Frame.
• Adjusts the volume (2 +/–) and mutes the sound (%) of a connected audio system. • You can operate the connected Sony equipment that has the BRAVIA Sync logo by the TV remote by pressing: – N/x/X/m/M to operate the connected equipment directly.
To connect the equipment that is Operating Optional compatible with control for HDMI Equipment Using the TV Connect the compatible equipment and the TV with an HDMI cable. When connecting an Remote audio system, be sure to also connect the DIGITAL AUDIO OUT (OPTICAL) jack of Buttons for using optional the TV and the audio system using an optical...
Press The selected function button flashes Programming the remote twice. This remote is preset to operate Sony TVs, and If the selected function button flashes five most Sony Blu-ray disc players, DVD players, times, repeat from step 1. DVD/HDD recorders, and audio systems Turn on your equipment and check that (Home Theatre, etc.).
Page 29
Code SONY 0219 – 0221 VCRs Manufacturer Code SONY 1001 – 1011 DAV Home Theatre System Manufacturer Code SONY (DAV) 4501 – 4506 AV receivers Manufacturer Code SONY 4001, 4002, 4056, 4057, 4085 Digital terrestrial receivers Manufacturer Code SONY 3101...
Using Home Network Features With this TV, you can enjoy contents stored in Enjoying Photo/Music Files DLNA-compatible devices on the home network. via the Network Devices that store and provide contents, such You can enjoy photo/music files on the server as photo/music files, are called “server”.
Page 31
To enjoy photographs and music on the (Music) Available OPTIONS TV screen by operating devices Option Description – Renderer Sound See page 37. Renderer is a feature for playing photo files and music files stored in network devices Surround See page 38. (digital still cameras, mobile phones, etc.) on Add to Slideshow Registers the...
Checking the Network Adjusting the Server Connection Display Settings Enter the respective (alphanumeric) values for You can select home network servers to be your router. The items that need to be set may displayed on the Home Menu. Up to 10 servers differ, depending on the Internet service can be displayed on the Home Menu provider or the router.
Page 33
If you cannot connect to your home network The TV can check if the server is being correctly recognised. Press HOME. Press G/g to select “Settings”. Press F/f to select “Network Settings”, then press Select “Server Diagnostics”, then press Select “Yes”, then press The server diagnostic starts.
Using Menu Functions Navigating through TV Home Menu on XMB™ The XMB™ (XrossMediaBar) is a menu of BRAVIA features and input sources displayed on the TV screen. The XMB™ is an easy way to select programming and adjust settings on your BRAVIA TV. Press HOME to display the XMB™.
TV Settings Menu BRAVIA Tips Introduces how to enjoy the TV. Clock/Timers Sleep Timer Sets the TV to automatically switch to standby mode after a certain amount of time. When “Sleep Timer” is activated, the (Timer) indicator on the TV front panel lights up in orange.
Page 36
Custom Allows you to store your preferred settings. Photo-Vivid For viewing photographs. Enhances picture contrast and sharpness. Photo-Standard For viewing photographs. Provides the optimum picture quality for viewing in the home. Photo-Original For viewing photographs. Represents the picture quality used when imaging developed photographs.
Page 37
Black Corrector Enhances black areas of the picture for stronger contrast. Adv. Contrast Automatically adjusts “Backlight” and “Picture” to the most Enhancer suitable settings judging from the brightness of the screen. This setting is especially effective for dark images scenes, and will increase the contrast distinction of the darker picture scenes.
Page 38
Surround Live Sports Delivers surround effects that make you feel like you are watching a live sports contest. Music Hall Delivers surround effects that make you feel like you are surrounded by sound as in a music hall. Cinema Delivers surround effects just like the high-grade audio systems found in movie theatres.
Display Area Adjusts the picture display area. Auto Automatically switches to the most appropriate display area. Full Pixel Displays pictures in their original size when parts of the picture are cut off. Displays pictures in their original size. Normal Displays pictures in their recommended size. -1/-2 Enlarges the picture so that the edges are outside the visible display area.
Page 40
Sets the image quality setting most suited to the input source (video or photograph data). Video-A Sets suitable image quality, depending on the input source, video data or photograph data when directly connecting Sony HDMI output-capable equipment that supports “Video-A” mode. Video Produces suitable image quality for moving pictures.
Audio Settings Speaker TV Speaker Turns on and outputs the TV’s sound from the TV speakers. Audio System Turns off the TV speakers and outputs the TV’s sound from external audio equipment connected to the audio output jacks on the TV. You can also turn on the connected equipment that is compatible with control for HDMI, after making the appropriate settings of control for HDMI.
Page 42
HDMI. When set to “On”, the following functions are available. If the specific Sony equipment that is compatible with control for HDMI is connected, this setting is applied to the connected equipment automatically when the “Control for HDMI”...
Page 43
• Do not put anything over the sensor, doing so may affect its function. See page 15 to check the position of the sensor. Logo Illumination Lights up and turns off the Sony logo on the front of the TV. Panel Key Constantly lights up the touch sensors on the front of the TV.
Page 44
Programme Labels Assigns a channel name of your choice, up to five letters or numbers. The name appears briefly on the screen when you select the channel. Press F/f to select the channel you want to name, then press Press F/f to select the desired letter or number (“_” for a blank space), then press g.
Page 45
Skip Skips unused analogue channels when you press PROG +/– to select channels. To select channels you have programmed to skip, use the corresponding number buttons. Improves the picture quality of the channel (noisy picture) when the broadcast signal is very weak. If you cannot see any improvement in the picture quality even if you set to “On”, set this option to “Off”...
Page 46
Optical Out Sets the audio signal that is output from the DIGITAL AUDIO OUT (OPTICAL) jack of the TV. Set to “Auto”, when connecting equipment compatible with Dolby Digital. Set to “PCM”, when connecting equipment not compatible with Dolby Digital. Radio Display Displays the screen wallpaper when you listen to a radio broadcast.
Network Settings Network IP Address DHCP Automatically acquires the network Settings settings through the Dynamic Host Configuration Protocol server function of the router or Internet service provider. Manual Allows you to set the network settings according to your network environment. Test Diagnoses whether the network is correctly connected.
TV’s weight. Be sure to entrust the attachment of these products to the wall to Sony dealers or licensed contractors and pay adequate attention to safety during the installation. Sony is not liable for any damage or injury caused by mishandling or improper...
KDL-55X4500 1,486 KDL-46X4500 1,259 KDL-40X4500 1,128 Figures in the above table may differ slightly depending on the installation. WARNING The wall that the TV will be installed on should be capable of supporting a weight of at least four times that of the TV.
Page 50
SU-WL500 SU-WL50B SU-WL500 SU-WL50B KDL-55X4500 d, g d, i KDL-46X4500/KDL-40X4500 SU-WL500: Screw location Hook location When installing the Mounting Hook on the TV. When installing the TV onto the Base Bracket. * Hook location “c” cannot be used for the models.
Specifications Model name KDL-40X4500 KDL-46X4500 KDL-55X4500 KDL-70X4500 System Panel system LCD (Liquid Crystal Display) Panel TV system Analogue: B/G, I, D/K, M Digital: GB20600-2006 Colour/video system Analogue: PAL, PAL60 (only video input), SECAM, NTSC3.58, NTSC4.43 (only video input) Digital: MPEG-2 MP@ML/HL, H.264/MPEG-4 AVC MP/HP@L4...
Page 52
Model name KDL-40X4500 KDL-46X4500 KDL-55X4500 KDL-70X4500 Dimensions with Table-Top 1,128 × 655 × 279 mm 1,259 × 737 × 315 mm 1,486 × 855 × 356 mm 1,850 × 1,065 × 401 mm (Approx.) Stand (w × h × d) without Table-Top 1,128 ×...
For example, the indicator may flash three times, go off for two seconds, then flash again three times. Press 1 on the TV to turn it off, disconnect the AC power cord, and inform your dealer or Sony service centre of how the indicator flashes (number of flashes).
Page 54
Condition Explanation/Solution No picture from the connected • Turn the connected equipment on. equipment appears on the • Check the cable connection. screen. • Press to display the list of inputs, then select the desired input. • Correctly insert the memory card or other storage device in the digital still camera.
Page 55
Condition Explanation/Solution Home Network Connection diagnostic results Check Connections indicate a failure. • Use a straight cable for the LAN cable. • Check if the cable is connected firmly. • Check the connection between the TV and the router. • Once server settings are changed, turn the TV off and on by pressing 1 The server cannot be found, a list cannot be retrieved, and on the TV.
Page 56
“Speaker” menu (page 41). Not all channels are tuned for • Check the support website for cable provide information. cable. http://www.sony-asia.com/bravia/flash.html The speaker grille has come • To attach the speaker grille, first turn off the TV, then unplug the AC off.
Page 58
Adobe 是 Adobe Systems Incorporated 在美國和 / 或其他國家的註冊商標或商 標。 在 Dolby Laboratories 的授權下製 造。杜比、 「Dolby」與雙 D 記號是 Dolby Laboratories 的商標。 “BRAVIA”和 是 Sony Corporation 的商標。 “XMB”和“xross media bar”是 Sony Corporation 和 Sony Computer Entertainment Inc. 的商標。 螢幕顯示上使用的字體由 DynaComware 獨家開發。 本電視設計在香港使用,只保 證能在香港使用。...
為了避免火災、觸電或損壞及 / 或受傷等危險,請遵照下列 指示來安裝和使用電視機。 安裝 務必要抓握住面板的底部,而不是透明的部分、喇叭或喇叭 s 應將電視機安裝在易於插拔的 AC 電源插座附近。 的格柵部分。不要擠壓面板的喇叭格柵部分。 s 將電視機擺在平穩的水平表面上,以防止傾倒而造成人員 的傷害或者損及電視機。 s 僅可由合格的維修人員執行掛壁安裝。 通風 s 為了安全起見,強烈建議您使用 Sony 配件,包括: s 切勿遮擋通風孔或將任何物體插入機殼內。 KDL-55X4500/46X4500/40X4500: s 如下圖所示,在電視機周圍保留通風空間。 壁掛式支架 SU-WL500/WL50B s 強烈建議您使用 Sony 掛壁式支架以確保足夠的空氣流通。 s 將掛勾安裝於電視機上時,務必要使用隨附於壁掛式支架 安裝在牆壁上 的螺絲。隨附螺絲的設計從掛勾安裝表面量起的長度是 8 mm 至 12 mm。...
Page 66
AC 電源線 對於兒童 為了避免火災、觸電或損壞及 / 或受傷等危險,請遵照下列 s 請勿讓兒童爬上電視機。 指示來處理 AC 電源線和插座: s 將體積小的配件放在兒童拿不到的地方,以便不會被兒童 誤吞。 請僅使用 Sony 隨附的 AC 電源線,不要使用其它品牌的電 源線。 將插頭完全插入 AC 電源插座。 如果出現下列問題… 僅可在 220-240 V AC 電源上使用電視機。 如果出現以下任何問題,請立刻關閉電視機並拔下 AC 電源 連接訊號線時,為了安全起見請務必拔下 AC 電源線,以 線。 免被訊號線絆到腳。 請咨詢您的經銷商或 Sony 服務中心以交由合格的服務人員進...
使用選用的設備 連接選用的設備 您可以將各種選用的設備連接到電視上去。 寬頻路由器 攝影機 音響系統 DVD 播放機 PC (HDMI 輸出) Blu-ray 光碟播放機 DIGITAL MEDIA PORT 轉接器 數位相機 攝影機 僅供修理人 員使用 USB 儲存媒體 攝影機 耳機 有數位輸入的家庭劇院系統 有色差訊號輸出的 DVD 播放機 視訊遊戲設備 DVD 播放機 DVD 錄影機 高傳真音響設備 錄影機 錄影機...
Page 77
音訊輸出插孔連接到 HDMI IN 1 插孔中的音訊輸入插 孔。 • HDMI 插孔只支援下列視訊輸入:480i、480p、576i、 576p、720p、1080i、1080p 和 1080/24p。 • 務必只使用經過認可、有 HDMI 標誌的 HDMI 訊號線。建 議使用 Sony HDMI 訊號線 (高速型) 。 • 連接與 HDMI 控制相容的音響系統時,務必也要將其連 接到 DIGITAL AUDIO OUT (OPTICAL) 插孔。 3 PC IN (RGB) 使用有鐵氧體磁蕊的 PC 訊號線是絕對必要的。...
若要同時觀賞兩個畫面 經由 USB 播放相片 / 音樂 - 雙重畫面 / 子母畫面功能 (子母畫面) 您可以在螢幕上同時觀賞兩個畫面 (外部 您可以經由 USB 訊號線或 USB 儲存裝置在 或 PC 輸入和電視節目) 。 電視上享受儲存在 Sony 數位相機或攝影機 連接選用的設備或 PC (20 頁) ,並確認來 中的相片 / 音樂檔案。 自該設備或 PC 的影像有出現在螢幕上。 將支援的 USB 裝置連接到電視機。 您每按一下...
Page 84
選單。 TOP MENU 回到步驟 1。 按 。 為遙控器編碼 選定的功能按鈕會閃爍兩次。 本遙控器預設用來操作 Sony 電視機、大部 如果選定的功能按鈕閃爍五次,請再 分 Sony Blu-ray 光碟播放機、DVD 播放 從步驟 1 開始進行。 機、DVD/HDD 錄影機和音響系統 (家庭劇 打開您的設備,檢查下列主要功能是 院等) 。 否能夠使用。 若要控制這種 Sony Blu-ray 光碟播放機、 DVD 播放機和 DVD/HDD 錄影機,請按下列 對於 Blu-ray 光碟播放機、DVD 播放機...
Page 85
0207, 0222 DVD/HDD 錄影機 廠牌 代碼 SONY 0219 - 0221 錄影機 廠牌 代碼 SONY 1001 - 1011 DAV 家庭劇院系統 廠牌 代碼 SONY (DAV) 4501 - 4506 AV 接收機 廠牌 代碼 SONY 4001, 4002, 4056, 4057, 4085 數位地面波接收機 廠牌 代碼 SONY 3101...
Page 112
Instructions on “Installing the Wall-Mount Bracket” are not supplied in the form of a separate leaflet with this TV. These installation instructions are included within this TV’s instructions manual. 本電視並未以附頁的方式提供關於 “安裝壁掛式支架”的說明。 這些安裝說明包含在本電視的使用說明書中。 Customer Support: 顧客支援: 4-116-768-11(1) Printed in Japan...
