Craftsman 247.29934 Operator's Manual

Hide thumbs Also See for 247.29934:

Advertisement

Quick Links

Download this manual See also: Operator's Manual
Operator's Manual
208cc Engine
Front Tine Tiller
Model No. 247.29934
CAUTION: Before using
this product, read this
manual and follow all
safety rules and operating
instructions.
Sears Brands Management Corporation, Hoffman Estates, IL 60179, U.S.A.
®
Visit our web site: www.craftsman.com
• SAFETY
• ASSEMBLY
• OPERATION
• MAINTENANCE
• PARTS LIST
• ESPAÑOL
FORM NO. 769-05511A
12/02/2009

Advertisement

loading

Related Manuals for Craftsman 247.29934

Summary of Contents for Craftsman 247.29934

  • Page 1 CAUTION: Before using • MAINTENANCE this product, read this • PARTS LIST manual and follow all • ESPAÑOL safety rules and operating instructions. Sears Brands Management Corporation, Hoffman Estates, IL 60179, U.S.A. Visit our web site: www.craftsman.com FORM NO. 769-05511A 12/02/2009...

  • Page 2: Parts List

    PARTS LIST Craftsman Tiller — Model No. 247.29934...
  • Page 3 PARTS LIST craftsman Tiller — Model no. 247.29934 Ref. No. Part No. Description Ref. No. Part No. Description 720-0274 Grip, Handle 686-0081A-0637 Wheel Bracket Assembly 731-06253A Handle Cover 911-0415 Clevis Pin, .375 x 1.75 931-1645A Clutch Bail Holder 714-04043 Bow Tie Cotter Pin 936-0140 Flat Washer, .385 x .62 x .063...
  • Page 4 PARTS LIST craftsman Tiller — Model no. 247.29934 39 31...
  • Page 5 PARTS LIST craftsman Tiller — Model no. 247.29934 Ref. No. Part No. Description Ref. No. Part No. Description 710-3005 Hex Head Screw, 3/8-16 x 1.25 986-0091 Chain Case Assembly 711-1036A Hex Nut, 5/16-18 642-0002-0637 Inner Tine Assembly, RH 712-0266A Jamlock Nut, 3/8-16...
  • Page 6 PARTS LIST craftsman engine Model ZS170-V0a for Model 247.29934 23 23...
  • Page 7 PARTS LIST craftsman engine Model ZS170-V0a for Model 247.29934 Ref. Part No. Description Ref. Part No. Description 951-11012 Bolt 710-04932 Bolt 951-11054A Valve Cover 951-11577 O-Ring 731-07059 Breather Hose 951-11578 Oil Seal 726-04101 Breather Hose Clamp 736-04440 Oil Drain Plug Washer...
  • Page 8 PARTS LIST craftsman engine Model ZS170-V0a for Model 247.29934 Ref. Part No. Description Qty. Ref. Part No. Description Qty. — 951-10798A Short Block — — 951-10799 Cylinder Head Assembly — 951-11565 Valve Cover Gasket 951-11565 Valve Cover Gasket — Exhaust Pipe Gasket...
  • Page 9 PARTS LIST craftsman engine Model ZS170-V0a for Model 247.29934 Ref. Part No. Description Qty. Ref. Part No. Description Qty. 951-10797 Carburetor Assembly — — 951-10647 Valve Kit — 951-11177 Choke Control Lever — Exhaust Valve — Choke Shaft — Intake Valve —...
  • Page 10 Parts List craftsman Tiller Model no. 247.29934 777D14195 777I23174 777I23259 777S33498 777D14194 777D13770 777D14196 777S33382 777I20358 777I22502...
