Specifications
Monitor
Specifications
LCD Module
Viewable Image Size:
Native Resolution (Pixel Count):
Input Signal
Display Colors
Synchronization
Range
Viewing Angle
Image Formation Time
Resolutions Supported
Active Display Area Landscape : Horiz. :
Power Supply
Current Rating
Dimensions
Height Adjustment:
Weight
Environmental Considerations
Operating Temperature:
Storage Temperature:
*1 Interpolated Resolutions: When resolutions are shown that are lower than the pixel count of the LCD module, text may appear different.
This is normal and necessary for all current flat panel technologies when displaying non-native resolutions full screen. In flat panel technolo-
gies, each dot on the screen is actually one pixel, so to expand resolutions to full screen, an interpolation of the resolution must be done.
NOTE: Technical specifications are subject to change without notice.
MultiSync
LCD1990FXp
Diagonal: 19,0 inch
19,0 inch
1280x1024
Video: ANALOG 0.7 Vp-p/75 Ohms
Sync: Separate sync. TTL Level Positive/Negative
Composite sync. Positive/Negative
Sync on Green (Video 0.7Vp-p and Sync Negative 0.3V p-p)
16,777,216
Horizontal: 31.5 kHz to 81.1 kHz
Vertical: 56.0 Hz to 75.0 Hz
Left/Right: ± 89˚ (CR>10)
Up/Down: ± 89˚ (CR>10)
25ms (Typ.)
720 x 400*1 at 70 Hz to 75 Hz
640 x 480*1 at 60 Hz to 75 Hz
800 x 600*1 at 56 Hz to 75 Hz
832 x 624*1 at 75 Hz
1024 x 768*1 at 60 Hz to 75 Hz
1152 x 870*1 at 75 Hz
1280 x 1024 at 60 Hz to 75 Hz ................ display performance.
376 mm/14.8 inches
Vert. : 301 mm/11.9 inches
Portrait : Horiz. : 301 mm/11.9 inches
Vert. : 376 mm/14.8 inches
100 - 240 V ~ 50/60 Hz
1.0 – 0.5A
Landscape: 392.2 mm (W) x 408.9-558.9 mm (H) x 247.3 mm (D)
15.4 inches (W) x 16.1-22.0 inches (H) x 9.7 inches (D)
Portrait: 326.7 mm (W) x 441.6-591.6 mm (H) x 247.3 mm (D)
12.9 inches (W) x 17.4-23.3 inches (H) x 9.7 inches (D)
150 mm / 5.9 inches
8.0 kg
17.6 lbs
5°C to 35°C/41°F to 95°F
Humidity: 30% to 80%
Altitude: 0 to 10,000 Feet
-10°C to 60°C/14°F to 140°F
Humidity: 10% to 85%
Altitude: 0 to 40,000 Feet
®
Active matrix; thin film transistor (TFT)
liquid crystal display(LCD); 0.294 mm dot
pitch; 250cd/m
technology; 1500:1 contrast ratio, typical
Digital Input: DVI
Dependant on display card used.
Automatically
Automatically
Some systems may not support
all modes listed.
NEC DISPLAY SOLUTIONS cites
recommended resolution at 60Hz for optimal
26
Notes
white luminance; XtraView+™
