NEC MultiSync LCD1990FXp User Manual page 19

Advanced OSM Controls
Tag 3 H. POSITION
(Analog input only)
V. POSITION
(Analog input only)
H. SIZE
(Analog input only)
FINE
(Analog input only)
VIDEO EQ
(Analog input only)
SYNC THRESHOLD
(Analog input only)
Tag 4 COLOR CONTROL
Sets Horizontal Image Position within the display area of the
LCD. Press "Left" or "Right" to adjust.
Sets Vertical Image Position within the display area of the LCD.
Press "Left" or "Right" to adjust.
Increases or decreases the horizontal (or vertical) size.
If the "Auto Adjust function" does not give a satisfactory picture,
further tuning can be performed manually using the "H. Size (or
V. Size)" function (dot clock).
To manually adjust the monitor, a Moiré test pattern should be
used.
This function may alter the width of the picture. Use Left/Right
Menu to center the image on the screen.
(see page 11).
If the "Auto Adjust" and the "H.Size" functions do not give a
satisfactory picture, further tuning can be performed using the
"Fine" function. Increasing or decreasing this setting improves
focus, clarity and image stability.
(see page 11)
Optimize the shape (Tailing) of RED, GREEN and BLUE signal.
Level:0-7
Adjusts the slice level of a synchronization signal.Adjusts the
sensitivity of the separate or composite input signals. Try this
option if the FINE adjustment does not successfully eliminate the
noise.
AccuColor Control Systems: Six color presets select the desired
color setting (sRGB and NATIVE color presets are standard and
cannot be changed).
R,G,B: Increases or decreases Red, Green or Blue color de-
pending upon which is selected.
NATIVE: Original color presented by the LCD panel that is
unadjustable.
sRGB: sRGB mode dramatically improves the color fidelity in
the desktop environment by a single standard RGB color space.
With this color supported environment, the operator could
easily and confidently communicate color without further color
management overhead in the most common situations.
17
– continued
