Advanced OSD

<How to use the advanced menu>
• When OSD is off, push the "RESET" and "EXIT" button at the same time.
• You will see the Advanced menu.
This menu is larger than the normal OSD.
<How to exit the advanced menu>
• Push the "EXIT" button.
To make an adjustment, ensure that the tag is highlighted, then press "SELECT".
To move to another tag, press "EXIT", then press "Left" or "Right" to highlight another tag.
Tag1 Luminance
Auto Contrast
(Analog input only)
Auto Black Level
(Analog input only)
AMBIENT LIGHT
COMP.
Black Level main
(Analog input only)
Black Level R/G/B
(Analog input only)
Tag2 R-H.position
(Analog input only)
G-H.position
(Analog input only)
B-H.position
(Analog input only)
R-FINE
(Analog input only)
G-FINE
(Analog input only)
B-FINE
(Analog input only)
R-SHARPNESS
(Analog input only)
G-SHARPNESS
(Analog input only)
B-SHARPNESS
(Analog input only)
DVI Long Cable
(Digital input only)
Adjusts the overall image and screen background luminance.
Press "Left" or "Right" to adjust.
When LUMINANCE is adjusting, a numerical value blinks.
Adjusts the image displayed for non-standard video inputs. Press "SELECT" to adjust.
Any adjustment requires the image to have white portions.
Automatically adjusts the black level. Any adjustment requires the image to have black
portions. Press "SELECT" to activate Auto Adjust.
Luminance setting depends on ambient light compensation.
OFF: No ambient light compensation.
1: Compensation only active during calibrations.
2: Compensation always active.
Allows you to manually adjust the black level. Press "Left" or "Right" to adjust.
Allows you to manually adjust the R/G/B black with independent controls.
Adjusts the position of the red component of the image. Press "Left" or "Right" to adjust.
Adjusts the position of the green component of the image. Press "Left" or "Right" to adjust.
Adjusts the position of the blue component of the image. Press "Left" or "Right" to adjust.
Adjusts the "FINE" setting of the RED component of the image.
Press "Left" or "Right" to adjust.
Adjusts the "FINE" setting of the GREEN component of the image.
Press "Left" or "Right" to adjust.
Adjusts the "FINE" setting of the BLUE component of the image.
Press "Left" or "Right" to adjust.
Adjusts the sharpness of the red component of the image. Press "Left" or "Right" to adjust.
Adjusts the sharpness of the green component of the image.
Press "Left" or "Right" to adjust.
Adjusts the sharpness of the blue component of the image.
Press "Left" or "Right" to adjust.
Compensates for image degradation caused by using a long DVI cable.
There are 4 possible settings, with "0" being the lowest level of compensation and
"3" being the highest level. The default setting is "1".
English-15
