Parts List - Craftsman 315.HD3000 Repair Sheet

CRAFTSMAN 1/2 in. HAMMER DRILL – MODEL NUMBER 315.HD3000
The model number will be found on a label attached to the motor housing. Always mention the model number in all correspondence regarding your
DRILL or when ordering repair parts.
KEY PART
NO. NUMBER
1 039453001013
2 039171001002
3 039171001015
4 039171001014
5 039453001008
6 039453001009
Not Shown:
990000686
3-11-14
(Rev:01)
NOTE: The assembly shown represents an important part of the double insulated system. To avoid the possibility of alteration or damage to the
System, service should be performed by your nearest Sears repair center. Contact your nearest Sears retail store for service center information.

PARTS LIST

DESCRIPTION
Auxiliary Handle Assembly ................................................................................................1
Depth Stop Rod ................................................................................................................1
Chuck Key Strap ...............................................................................................................1
Chuck Key .........................................................................................................................1
Logo Label ........................................................................................................................1
Data Label .........................................................................................................................1
Operator's Manual
3
QTY
