N150RD / N151RD

Advertisement

Table of Contents
loading

Related Manuals for Clevo N150RD

Summary of Contents for Clevo N150RD

  • Page 1 N150RD / N151RD...
  • Page 3 Preface Notebook Computer N150RD / N151RD Service Manual...
  • Page 4 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven- dor.
  • Page 5 This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and inspection of personal computers. It is organized to allow you to look up basic information for servicing and/or upgrading components of the N150RD / N151RD series notebook PC.
  • Page 6 Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock and injury to per- sons when using any electrical equipment: 1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.

  • Page 7: Instructions For Care And Operation

    Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...

  • Page 8: Power Safety

    Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag- netic fields. These can hinder proper performance and damage your data. Take care when using peripheral devices. Use only approved brands of Unplug the power cord before peripherals.

  • Page 9: Battery Precautions

    Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.

  • Page 10: System Startup

    Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on CD/DVD This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC. System Startup 1.

  • Page 11: Table Of Contents

    Preface Contents Introduction ..........1-1 Bottom ................... A-4 Main Board ................... A-5 Overview ..................1-1 HDD ....................A-6 Specifications ..................1-2 2nd HDD ..................A-7 External Locator - Top View with LCD Panel Open ......1-4 LCD ....................A-8 External Locator - Front & Right Side Views .........1-5 DVD ....................
  • Page 12 Preface PCH 1/9 ..................B-24 Front LED Board ................B-56 PCH 2/9 ..................B-25 Click / Finger Con Board ..............B-57 PCH 3/9 ..................B-26 Fingerprint Board ................B-58 PCH 4/9 ..................B-27 N150 LID, PWR SW Board ............B-59 PCH 5/9 ..................B-28 N170 LID, PWR SW Board ............B-60 PCH 6/9 ..................

  • Page 13: Introduction

    Chapter 1: Introduction Overview This manual covers the information you need to service or upgrade the N150RD / N151RD series notebook computer. Information about operating the computer (e.g. getting started, and the Setup utility) is in the User’s Manual. Information about dri-vers (e.g.

  • Page 14: Specifications

    Introduction Specifications Processor Options Video Adapter Intel® Core™ i7 Processor Intel® Integrated GPU and NVIDIA® Discrete GPU i7-6700HQ (2.60GHz) Supports Microsoft Hybrid Graphics 8MB Smart Cache, 14nm, DDR3L-1600MHz, TDP 45W  Intel Integrated GPU Intel® Core™ i5 Processor Latest Specification Information Intel®...
  • Page 15 Introduction Keyboard Communication Full-size Winkey Illuminated White-LED Keyboard (with Built-In Gigabit Ethernet LAN numeric keypad) 2.0M FHD PC Camera Module Pointing Device (Factory Option) M.2 3G or 4G Module WLAN/ Bluetooth M.2 Modules: Built-in Touchpad (Factory Option) Intel® Wireless-AC 8260 Wireless LAN Interface (802.11ac) + Bluetooth 4.1 (Factory Option) Intel®...

  • Page 16: External Locator - Top View With Lcd Panel Open

    Introduction External Locator - Top View with LCD Panel Open Figure 1 Top View 1. PC Camera 2. *PC Camera LED *When the PC camera is in use, the LED will be illuminated. 3. Microphone 4. LCD 5. Speakers 6. Power Button 7.

  • Page 17: External Locator - Front & Right Side Views

    Introduction External Locator - Front & Right Side Views Figure 2 Front View 1. LED Indicators FRONT VIEW Figure 3 Right Side View 1. USIM Card RIGHT SIDE VIEW Reader (for 3G/ 4G USIM Cards) 2. Multi-in-1 Card Reader 3. USB 3.0 Port 4.

  • Page 18: External Locator - Left Side & Rear View

    Introduction External Locator - Left Side & Rear View Figure 4 Left Side View 1. Security Lock Slot 2. USB 3.0 Ports 3. S/PDIF-Out Jack LEFT SIDE VIEW 4. Microphone-In Jack 5. Headphone-Out Jack 6. Optical Device Drive Bay 7. Emergency Eject Hole Figure 5 REAR VIEW...

  • Page 19: External Locator - Bottom View

    Introduction External Locator - Bottom View Figure 6 Bottom View 1. Vent 2. Battery  Overheating To prevent your com- puter from overhea- ting, make sure no- thing blocks any vent while the computer is in use. External Locator - Bottom View 1 - 7...

  • Page 20: Mainboard Overview - Top (Key Parts)

    Introduction Mainboard Overview - Top (Key Parts) Figure 7 Mainboard Top Key Parts 1. KBC-ITE IT8587 1 - 8 Mainboard Overview - Top (Key Parts)

  • Page 21: Mainboard Overview - Bottom (Key Parts)

    Introduction Mainboard Overview - Bottom (Key Parts) Figure 8 Mainboard Bottom Key Parts 1. CMOS Battery 2. Mini-Card Connector (M.2 PCIE/SATA SSD Module) 3. Mini-Card Connector (M.2 3G/SATA Module) 4. Mini-Card Connector (WLAN Module) 5. GPU-GTX960M 6. CPU 7. Memory Slots DDR3L SO-DIMM Mainboard Overview - Bottom (Key Parts) 1 - 9...

  • Page 22: Mainboard Overview - Top (Connectors)

    Introduction Mainboard Overview - Top (Connectors) Figure 9 Mainboard Top Connectors 1. DC-In Jack 2. Mini Display Port 3. HDMI-Out Port 4. USB Port 3.0 Connector 5. Audio Board Connector 6. Finger Print Connector 7. TP Connector 8. LED Board Connector 9.

  • Page 23: Mainboard Overview - Bottom (Connectors)

    Introduction Mainboard Overview - Bottom (Connectors) Figure 10 Mainboard Bottom Connectors 1. CCD Connector 2. Battery Connector 3. Fan Connector Mainboard Overview - Bottom (Connectors) 1 - 11...
  • Page 24 Introduction 1 - 12...

  • Page 25: Disassembly

    Chapter 2: Disassembly Overview This chapter provides step-by-step instructions for disassembling the N150RD / N151RD series notebook’s parts and subsystems. When it comes to reassembly, reverse the procedures (unless otherwise indicated). We suggest you completely review any procedure before you take the computer apart.

  • Page 26: Maintenance Tools

    Disassembly NOTE: All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •...

  • Page 27: Maintenance Precautions

    Disassembly Maintenance Precautions  The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Warning 1. Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other Before you undertake components could be damaged.

  • Page 28: Disassembly Steps

    Disassembly Disassembly Steps The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM THE DISASSEMBLY STEPS IN THE ORDER INDICATED. To remove the Battery: To remove the 3G Module: 1. Remove the battery page 2 - 5 1.

  • Page 29: Removing The Battery

    Disassembly Removing the Battery Figure 1 Battery Removal 1. Turn the computer off, and turn it over. 2. Locate the battery and remove screws (Figure 1a). a. Remove the screws. 3. Carefully lift the battery up in the direction of the arrow (Figure 1b b.

  • Page 30: Removing The Hard Disk Drive

    Disassembly Removing the Hard Disk Drive Figure 2 The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 9.5mm HDD Assembly or 7mm (h). Follow your operating system’s installation instructions, and install all necessary drivers and utilities (as Removal outlined in Chapter 4 of the User’s Manual) when setting up a new hard disk.
  • Page 31 Disassembly 5. Remove screws from the HDD assembly (Figure 3c). Figure 3 6. Lift the hard disk at a 45 degrees angle and slide it out in the direction of arrow (Figure 4d HDD Assembly 7. Remove the hard disk assembly out of the bay (Figure 4e Removal (cont’d.)
  • Page 32 Disassembly 8. Remove screws from the hard disk assembly (Figure 4f Figure 4 9. Separate the hard disk from the bracket and mylar cover (Figure 4g HDD Assembly 10. Reverse the process to install a new hard disk (do not forget to insert the mylar cover between the bracket and Removal (cont’d.) hard disk as shown before replacing the screws).
  • Page 33 Disassembly Hard Disk Size Note (Foam Rubber Insert) Note that the hard disks pictured on these pages are all 9.5mm(H) hard disk drives. In some cases 7mm(H) hard disk drives will be installed. Also pay attention on the alignment of the hard disk and bracket when tightening the screws. For more information contact your distributor/supplier, and bear in mind your warranty terms.

  • Page 34: Removing The Optical (Cd/Dvd) Device

    Disassembly Removing the Optical (CD/DVD) Device Figure 6 Optical Device 1. Turn off the computer, remove the battery (page 2 - 5), and bottom case (page 2 - Removal 2. Carefully push out the optical device out of the bay in the direction of the arrow (Figure 6a 3.

  • Page 35: Removing The Keyboard

    Disassembly Removing the Keyboard Figure 7 Keyboard Removal 1. Turn off the computer, remove the battery (page 2 - 5), and bottom case (page 2 - 2. Open it up with the LCD on a flat surface before pressing at points &...

  • Page 36: Removing The System Memory (Ram)

    Disassembly Removing the System Memory (RAM) Figure 8 RAM Module The computer has two memory sockets for 204 pin Small Outline Dual In-line Memory Modules (SO-DIMM) supporting Removal DDR3L up to 1600 MHz. The main memory can be expanded up to 16GB. The total memory size is automatically de- tected by the POST routine once you turn on your computer.

  • Page 37: Removing The M.2 Ssd Module

    Disassembly Removing the M.2 SSD Module Figure 9 M.2 SSD Module 1. Turn off the computer, remove the battery (page 2 - 5), and bottom case (page 2 - Removal 2. The M.2 SSD module will be visible at point on the mainboard (Figure 9a).

  • Page 38: Removing The Wireless Lan Module

    Disassembly Removing the Wireless LAN Module Figure 10 Wireless LAN 1. Turn off the computer, remove the battery (page 2 - 5), keyboard (page 2 - 11) and bottom case (page 2 - Module Removal 2. The Wireless LAN module will be visible at point on the mainboard (Figure 10a).

  • Page 39: Wireless Lan, Combo, 3G & Lte Module Cables

    Disassembly Wireless LAN, Combo, 3G & LTE Module Cables Note that the cables for connecting to the antennae on WLAN, WLAN & Bluetooth Combo, 3G and LTE modules are not labelled. The cables/covers (each cable will have either a black or transparent cable cover) are color coded for iden- tification as outlined in the table below.

  • Page 40: Removing The 3G/4G Module

    Disassembly Removing the 3G/4G Module Figure 11 3G/4G Module 3G/4G Module Removal Procedure Removal 1. Turn off the computer, remove the battery (page 2 - 5), and bottom case (page 2 - 2. Locate the module, it is visible at point Figure 11a a.

  • Page 41: Part Lists

    Appendix A:Part Lists This appendix breaks down the N150RD / N151RD series notebook’s construction into a series of illustrations. The com- ponent part numbers are indicated in the tables opposite the drawings. Note: This section indicates the manufacturer’s part numbers. Your organization may use a different system, so be sure to cross-check any relevant documentation.

  • Page 42: Part List Illustration Location

    Part List Illustration Location The following table indicates where to find the appropriate part list illustration. Table A - 1 Part List Illustration Part Location page A - 3 Bottom page A - 4 page A - 5 Main Board page A - 6 page A - 7 2nd HDD...

  • Page 43: Top

    Figure A - 1 Top A - 3...

  • Page 44: Bottom

    Bottom Figure A - 2 Bottom A - 4 Bottom...

  • Page 45: Main Board

    Main Board Figure A - 3 Main Board Main Board A - 5...

  • Page 46: Hdd

    Figure A - 4 A - 6 HDD...

  • Page 47: 2Nd Hdd

    2nd HDD Figure A - 5 2nd HDD 2nd HDD A - 7...

  • Page 48: Lcd

    Figure A - 6 A - 8 LCD...

  • Page 49: Dvd

    Figure A - 7 DVD A - 9...

  • Page 50: Dummy Odd

    Dummy ODD Figure A - 8 Dummy ODD A - 10 Dummy ODD...

  • Page 51: Schematic Diagrams

    Schematic Diagrams Appendix B: Schematic Diagrams This appendix has circuit diagrams of the N150RD / N151RD notebook’s PCB’s. The following table indicates where to find the appropriate schematic diagram. Diagram - Page Diagram - Page Diagram - Page Table B - 1...

  • Page 52: System Block Diagram

    Schematic Diagrams System Block Diagram N15xRD/N170RD System Block Diagram N1550SD, N157 5V,3V,5VS,3VS, 3.3VA K/B LED,PWR B'd SHEET 40 6-71-N1557-D03 SHEET 53 VDD3,VDD5 AUDIO BOARD SHEET 41 6-71-N15R8-D01 SHEET 54 2 VIA:3"~8" Nvidia 4 VIA:3"~9" DRAM POWER MINI DP PS8625 2 vias 2"~10" H-processor FRONT LED B'd SHEET 14...

  • Page 53: Processor 1/7

    Schematic Diagrams Processor 1/7 Processor 1/7 ( DMI,PEG) U137C SKYLAKE_HALO D02 0626 BGA1440 PEG_TX_0 C924 0.22u_10V_X5R_04 [18] PEG_RX0 PEG_RXP[0] PEG_TXP[0] PEG_TX0 [18] CPU HOLD PEG_TX#_0 C925 0.22u_10V_X5R_04 [18] PEG_RX#0 PEG_RXN[0] PEG_TXN[0] PEG_TX#0 [18] PEG_TX_1 C926 0.22u_10V_X5R_04 [18] PEG_RX1 PEG_RXP[1] PEG_TXP[1] PEG_TX1 [18] PEG_TX#_1...

  • Page 54: Processor 2/7

    Schematic Diagrams Processor 2/7 Processor 2/7 ( DDI, eDP ) SKYLAKE_HALO U137D BGA1440 DDI1_TXP[0] EDP_TXP[0] EDP_TXP_0 [11] DDI1_TXN[0] EDP_TXN[0] EDP_TXN_0 [11] EDP TO LVDS IC EDP_TXP_1 [11] DDI1_TXP[1] EDP_TXP[1] DDI1_TXN[1] EDP_TXN[1] EDP_TXN_1 [11] DDI1_TXP[2] EDP_TXN[2] DP_TXN2 [12] DDI1_TXN[2] EDP_TXP[2] DP_TXP2 [12] EDP TO EDP CON DP_TXN3...

  • Page 55: Processor 3/7

    Schematic Diagrams Processor 3/7 Processor 3/7 (DDR3L) SKYLAKE_HALO SKYLAKE_HALO U137A U137B M_A_DQ[63:0] [10] M_B_DQ[63:0] BGA1440 BGA1440 M_A_DQ0 M_B_DQ0 BT11 M_A_CLK_DDR0 M_B_CLK_DDR0 [10] DDR0_DQ[0] DDR0_CKP[0] DDR1_DQ[0]/DDR0_DQ[16] DDR1_CKP[0] M_A_DQ1 M_B_DQ1 BR11 M_A_CLK_DDR#0 M_B_CLK_DDR#0 [10] DDR0_DQ[1] DDR0_CKN[0] DDR1_DQ[1]/DDR0_DQ[17] DDR1_CKN[0] M_A_DQ2 M_B_DQ2 M_A_CLK_DDR#1 M_B_CLK_DDR#1 [10] DDR0_DQ[2] DDR0_CKN[1]...

  • Page 56: Processor 4/7

    Schematic Diagrams Processor 4/7 Processor 4/7 ( CLK/JTAG/MISC ) NEAR CPU 1.0V_VCCST VCCIO SKYLAKE_HALO R1346 U137E CFG9 *1K_04 BGA1440 BN25 R1347 R1348 CFG0 R1349 *1K_04 [28] PCH_CPU_BCLK_R_DP BCLKP CFG[0] BN27 CFG1 R1350 *1K_04 100_04 56.2_1%_04 [28] PCH_CPU_BCLK_R_DN BCLKN CFG[1] BN26 CFG2 R1351 *1K_04...

  • Page 57: Processor 5/7

    Schematic Diagrams Processor 5/7 Processor 5/7 ( POWER1 ) VCORE VCORE PLACE CAPS AT BOARD EDGE +VCCEDRAM CPU_TOP_VCCCORE VCORE SKYLAKE_HALO U137G SKYLAKE_HALO D02 0701 U137J BGA1440 BGA1440 AA13 C1732 C1731 C962 C969 C970 C963 AA31 BJ17 VCCOPC AA32 BJ19 VCCOPC AA33 BJ20 VCCOPC...

  • Page 58: Processor 6/7

    Schematic Diagrams Processor 6/7 Processor 6/7 ( POWER2,RSVD ) PLACE CAP BACKSIDE VCCSA VCCVDDQ_CLK 1.0V_VCCSFR 1.0V_VCCST VDDQ SKYLAKE_HALO 11.1A U137I C1089 C1090 C1091 BGA1440 VCCSA VDDQ AE12 U137K SKYLAKE_HALO VCCSA VDDQ VCCSA VDDQ BGA1440 VCCSA VDDQ BM33 VCCSA VDDQ RSVD_TP RSVD_TP BL33 VCCSA...

  • Page 59: Processor 7/7

    Schematic Diagrams Processor 7/7 Processor 7/7 ( POWER3,GND ) VCCGT U137M SKYLAKE_HALO +VCCGTU VCCGT VCCGT SKYLAKE_HALO BGA1440 U137N AK30 AK29 BGA1440 U137F SKYLAKE_HALO SKYLAKE_HALO U137H SKYLAKE_HALO U137L AJ29 VCCGT AJ38 AJ30 BGA1440 BGA1440 BG34 BGA1440 AF29 VCCGT BA38 AJ37 VCCGT AV29 AJ31 VCCGTX...

  • Page 60: Ddr3 So-Dimm A_0

    Schematic Diagrams DDR3 SO-DIMM A_0 SO-DIMM A_0 JDIMM1A M_A_A[15:0] M_A_DQ[63:0] M_A_A0 M_A_DQ0 JDIMM1B M_A_A1 M_A_DQ1 M_A_A2 M_A_DQ2 VDDQ M_A_A3 M_A_DQ3 M_A_A4 M_A_DQ4 M_A_A5 M_A_DQ5 VDD1 VSS16 M_A_A6 M_A_DQ6 VDD2 VSS17 M_A_A7 M_A_DQ7 VDD3 VSS18 M_A_A8 M_A_DQ8 VDD4 VSS19 M_A_A9 M_A_DQ9 VDD5 VSS20 M_A_A10...

  • Page 61: Ddr3 So-Dimm B_0

    Schematic Diagrams DDR3 SO-DIMM B_0 SO-DIMM B_0 JDIMM2B VDDQ JDIMM2A M_B_B[15:0] M_B_DQ[63:0] M_B_B0 M_B_DQ0 M_B_B1 M_B_DQ1 VDD1 VSS16 M_B_B2 M_B_DQ2 VDD2 VSS17 M_B_B3 M_B_DQ3 VDD3 VSS18 M_B_B4 M_B_DQ4 VDD4 VSS19 M_B_B5 M_B_DQ5 VDD5 VSS20 M_B_B6 M_B_DQ6 VDD6 VSS21 M_B_B7 M_B_DQ7 VDD7 VSS22 M_B_B8...

  • Page 62: Ps8625

    Schematic Diagrams PS8625 PS8625 VDDIO VDDIO 3.3VS VDDIO VDDIO 3.3VS VDDIOX *HCB1005KF-121T20 *HCB1005KF-121T20 R1944 R1945 C1776 C1775 *10K_04 *10K_04 C1778 C1777 C1779 PS8625_PD# RST# *0.47u_10V_Y5V_04 C1780 *0.1u_10V_X7R_04 *4.7u_6.3V_X5R_06 Single link (Odd) LVDS PIN13/14 C1781 C1782 PIN38 LVDS-L0N [12] *1u_6.3V_X5R_04 *2.2u_6.3V_X5R_04 LVDS-L0P [12] LVDS-L1N...

  • Page 63: Panel, Bkl Control

    Schematic Diagrams Panel, BKL Control PANEL POWER PANEL CONNECTOR (For coaxial cable) PLVDD M: uP7553 ---- 6-02-07553-9C0 PLVDD S: AP2821KTR-G1 6-02-02821-9C0 3.3VS >80 mil J_LCD1 VOUT NEAR PIN4,5 3.3VS C342 C827 R171 C349 C365 1u_6.3V_X5R_04 *1u_6.3V_X5R_04 10u_6.3V_X5R_06 *100K_04 1u_6.3V_X5R_04 PANEL_VCC_EN uP7553 R180 0_04...

  • Page 64: Rtd2168

    Schematic Diagrams RTD2168 CRT_5VS RB551V-30S2 6-20-14X50-015 / 6-20-14X90-015 J_CRT1 R1872 R134 D5112-15F-111B 2.2K_04 2.2K_04 DAC_RED *20mil_short_04 FCM1005MF-600T01 FRED DAC_GREEN *20mil_short_04 FCM1005MF-600T01 FGRN DAC_BLUE FBLUE *20mil_short_04 FCM1005MF-600T01 C1744 C1659 C1741 C1742 C1743 C1740 C1734 C1735 C1736 6-13-36R01-28C VGA_SDA R1877 R1873 R1878 VGA_HSYNC R1879 36_1%_04...

  • Page 65: Mini Dp Port

    Schematic Diagrams MIni DP Port Sheet 14 of 62 Mini DP Port MIni DP Port B - 15...

  • Page 66: Vga Frame Buffer Interface

    Schematic Diagrams VGA Frame Buffer Interface Frame Buffer Interface Description Term The total trace length measured from GPU ball to capacitor is Under GPU no more than 150 mil The total trace length measured from GPU ball to capacitor is no Near GPU BGA_0908_P080_P085_P100_290X290 more than 850 mil...

  • Page 67: Vga Frame Buffer A

    Schematic Diagrams VGA Frame Buffer A U31B INS284406750 BGA170 COMMON [15,17] FBA_CMD[31:0] FBA_CMD12 FBA_CMD15 [15] FBA_CLK0 FBA_CMD5 [15] FBA_CLK0# FBA_CMD0 [15] FBA_D[31:0] FBA_CMD8 U31D U31A FBA_CMD10 A0_A10 INS284406670 INS284406830 FBA_CMD11 BGA170 BGA170 A1_A9 COMMON COMMON FBA_CMD2 A2_BA0 FBA_CMD1 NORMAL NORMAL A3_BA3 FBA_CMD3 A4_BA2...

  • Page 68: Vga Frame Buffer A

    Schematic Diagrams VGA Frame Buffer A U30B INS284412453 BGA170_MIRR COMMON [15,16] FBA_CMD[31:0] FBA_CMD28 FBA_CMD31 [15] FBA_CLK1 FBA_CMD21 [15] FBA_CLK1# FBA_CMD16 [15] FBA_D[63:32] FBA_CMD24 U30D U30A INS284412315 INS284412235 FBA_CMD26 BGA170_MIRR BGA170_MIRR A0_A10 FBA_CMD27 COMMON COMMON A1_A9 FBA_CMD18 MIRRORED MIRRORED A2_BA0 FBA_CMD17 A3_BA3 FBA_CMD19 A4_BA2...

  • Page 69: Vga Pci-E Interface

    Schematic Diagrams VGA PCI-E Interface 3V3_AON R188 N16x 2.0 R411 10K_04 R174 R176 MTN7002ZHS3 N14x 1.0 BGA_0908_P080_P085_P100_290X290 PEX_CLKREQ# N16x 2.0 [28] PEG_CLKREQ# COMMON 1/19 PCI_EXPRESS R407 PEX_VDD R176 0_04 SNN_PEXWAKE AJ11 *100K_04 [21] GPU_PEX_RST# PEX_WAKE [27,51] DGPU_PWRGD AG19 PEX_IOVDD R174 *0_04 AJ12 AG21...

  • Page 70: Vga Frame Buffer B

    Schematic Diagrams VGA Frame Buffer B U33B INS284417806 BGA170 COMMON [15,20] FBB_CMD[31:0] FBB_CMD12 FBB_CMD15 [15] FBB_CLK0 FBB_CMD5 [15] FBB_CLK0# FBB_CMD0 [15] FBB_D[31:0] FBB_CMD8 U33D U33A FBB_CMD10 A0_A10 INS284418019 INS284418467 FBB_CMD11 BGA170 BGA170 A1_A9 COMMON COMMON FBB_CMD2 A2_BA0 FBB_CMD1 NORMAL NORMAL A3_BA3 FBB_CMD3 A4_BA2...

  • Page 71: Vga Frame Buffer B

    Schematic Diagrams VGA Frame Buffer B U32B INS284424754 BGA170_MIRR COMMON [15,19] FBB_CMD[31:0] FBB_CMD28 FBB_CMD31 [15] FBB_CLK1 FBB_CMD21 [15] FBB_CLK1# FBB_CMD16 [15] FBB_D[63:32] FBB_CMD24 U32A U32D INS284423878 FBB_CMD26 BGA170_MIRR A0_A10 INS284423719 FBB_CMD27 BGA170_MIRR COMMON A1_A9 COMMON FBB_CMD18 A2_BA0 MIRRORED FBB_CMD17 A3_BA3 MIRRORED FBB_CMD19 A4_BA2...

  • Page 72: Vga I/O

    Schematic Diagrams VGA I/O BGA_0908_P080_P085_P100_290X290 BGA_0908_P080_P085_P100_290X290 COMMON COMMON BGA_0908_P080_P085_P100_290X290 7/19 IFPC 9/19 IFPEF COMMON L68 NV 180 @100MHz(ESR=0.2 ) 8/19 IFPD ALL PINS NC FOR GF117 ALL PINS NC FOR GF117 6-19-31001-005 (120 500mA) ALL PINS NC FOR GF117 R1978 1K_1%_04 IFPC_RSET IFPC_RSET...

  • Page 73: Vga Nvvdd Decoupling

    Schematic Diagrams VGA NVVDD Decoupling NVVDD C253 C273 C206 C262 BGA_0908_P080_P085_P100_290X290 BGA_0908_P080_P085_P100_290X290 BGA_0908_P080_P085_P100_290X290 NVVDD BGA_0908_P080_P085_P100_290X290 *1000p_50V_X7R_04 COMMON COMMON COMMON COMMON 1u_6.3V_X5R_04 1u_6.3V_X5R_04 1u_6.3V_X5R_04 10/19 XVDD 16/19 GND_1/2 17/19 GND_2/2 14/19 NVVDD AM25 AA17 AA12 CONFIGURABLE AA18 AN10 AA14 POWER AA20 AN13 AA16 CHANNELS...

  • Page 74: Pch 1/9

    Schematic Diagrams PCH 1/9 BOOT HALT JTAG ODT ESPI FLASH SHARING MODE MASTER ATTACHED FLASH SHARING:LOW ENABLE:LOW DISABLE:LOW SLAVE ATTACEHD FLASH SHARING:HIGH (INTERNAL WEAK PU) (INTERNAL WEAK PU) (INTERNAL WEAK PD) SPT-H_PCH U138A 3.3VA SPI_3.3V SPI_3.3V R1930 *0_04 BD17 BB27 [35,39] LAN_WAKEUP# PLT_RST#...

  • Page 75: Pch 5/9

    Schematic Diagrams PCH 2/9 USB 3.0 MAPING USB2.0 USB 3.0 P1 USB 2.0 P1 AUDIO USB3 AJ_USB2 USB 3.0 P2 USB 2.0 P2 J_USB2 PORT2 USB 3.0 P3 USB 2.0 P3 J_USB1 PORT3 USB 3.0 P5 USB 2.0 P9 AUDIO USB3.0 AJ_USB1 USB 2.0 P6 USB 3.0 P8 NGFF 4G...

  • Page 76: Pch 6/9

    Schematic Diagrams PCH 3/9 BIOS RECOVERY PCH_RSVD MFG_MODE ENABLE :LOW 3.3VS 3.3VS 3.3VS R1644 R1653 R1647 *10K_04 10K_04 10K_04 MFG_MODE BIOS_REC PCH_RSVD SPT-H_PCH R1654 R1652 U138C *0_04 *10K_04 [32] CL_CLK1 CL_CLK PCIE9_RXN/SATA0A_RXN PCIE_RXN9_SATA0A_RXN_SSD [33] [32] CL_DATA1 CL_DATA CLINK PCIE_RXP9_SATA0A_RXP_SSD [33] PCIE9_RXP/SATA0A_RXP [32] CL_RST#1...

  • Page 77: Pch 9/9

    Schematic Diagrams PCH 4/9 SPT-H_PCH U138D VDD3 *RB751S-40C2 R1939 33_04 HDA_BITCLK_R BB17 ISH_GP_6_R [37] HDA_BITCLK HDA_BCLK GPP_A12/BMBUSY#/ISH_GP6/SX_EXIT_HOLDOFF# AW22 R1941 33_04 HDA_RST#_R PM_CLKRUN# close to PCH PM_CLKRUN# [38] [37] HDA_RST# HDA_RST# GPP_A8/CLKRUN# [37] HDA_SDIN0 HDA_SDI0 AR15 R2006 1.5K_1%_04 R2007 45.3K_1%_04 HDA_SDI1 GPD11/LANPHYPC R2020 33_04...
  • Page 78 Schematic Diagrams PCH 5/9 3.3VS HDMI_CTRLCLK R2015 2.2K_04 HDMI_CTRLDATA R2016 2.2K_04 VGA_CTRLCLK R1753 2.2K_04 VGA_CTRLDATA R1754 2.2K_04 DGPU_RST#_PCH R1751 *10K_04 *10K_04 GPU_EVENT# R1740 10K_8P4R_04 DGPU_SELECT# VGA_HPD R384 100K_04 [13] VGA_HPD DGPU_PRSNT# HDMI_HPD R385 100K_04 U138E [36] HDMI_HPD SB_KBCRST# SERIRQ SPT-H_PCH VGA_CTRLCLK R2097 *0_04...
  • Page 79 Schematic Diagrams PCH 6/9 C1390 6-22-24R00-1B9 22p_50V_NPO_04 6-22-24R00-1BA D02 0714 FSX3M R1760 D02 0714 1M_1%_04 C1392 22p_50V_NPO_04 FSX3M_24MHZ SPT-H_PCH U138G RTC (10M OHM RES): DO NOT CHANGE TO 0402 AR17 GPP_A16/CLKOUT_48 PCH_XDP_CLK_DN CLKOUT_ITPXDP CPU_24MHZ_R_DP PCH_XDP_CLK_DP CLKOUT_CPUNSSC_P CLKOUT_ITPXDP_P CPU_24MHZ_R_DN CLKOUT_CPUNSSC PCH_CPU_PCIBCLK_R_DN 100 MHz CLKOUT_CPUPCIBCLK 100 MHz...
  • Page 80 Schematic Diagrams PCH 7/9 R1773 *20mil_Short-p VDD1.0 R1788 *20mil_Short-p VDD3 SPT-H_PCH VDD1.0 +VCCPRIM_1P0 U138H DEFAULT SHORT 3.3VA +VCCPRIM_1P0 2.899A AA23 eSPI:1.8V VCCPRIM_1P0 LPC:3.3V AA26 R2031 *20mil_Short-p 3.3VA VCCPRIM_1P0 PJ71 AA28 AL22 0.0908A +VCCFHV_2P8 VCCPRIM_1P0 VCCPRIM_1P0 AC23 C1393 VCCPRIM_1P0 R2032 *20mil_Short-p AC26 BA24 0.195A...
  • Page 81 H_TRST# (INTERNAL WEAK PD) CPU_TRST# PCH_2_CPU_TRIGGER_R R1806 30.1_1%_04 RSVD PCH_TRIGOUT PCH_2_CPU_TRIGGER 3.3VA RSVD PCH_TRIGIN CPU_2_PCH_TRIGGER BOARD_ID N150RD,N155RD:0 R1800 N170RD:1 HM170 10 OF 12 REV = 1.3 *4.7K_04 3.3VS Sheet 30 of 62 D02 0818 LPSS_GSPI1_MOSI R1802 R2095 N170RD PCH 8/9...
  • Page 82 Schematic Diagrams PCH 9/9 U138I SPT-H_PCH U138L SPT-H_PCH AC18 AB11 AN10 BE14 AB14 BE18 AE29 AB31 BE23 AB32 BE28 AE42 AB38 BE32 AF18 BE37 AF20 BE40 AF21 AF23 AC20 AF25 AC21 AF26 AC25 AF28 AC29 AF29 AC45 AG11 AG13 AD11 AG31 AD14 AG32...

  • Page 83: Wlan, 4G, Fan, Audio Con

    Schematic Diagrams WLAN, 4G, Fan, Audio Con NGFF B KEY 3G_PWR_EN 4G POWER 3G_3.3V CURRENT2A ,DON'T DROP BELOW 3.135V 3G_3.3V 80 mils >120 mil >120 mil J_3G1 C736 220u_6.3V_6.3*6.3*4.2 R622 3.3V *100_04 0.3A C532 0.1u_10V_X5R_04 CONFIG_2 3.3V4 C594 C748 GND10 3.3V3 C537 0.1u_10V_X5R_04...

  • Page 84: Ccd, M-Key, Click Conn

    Schematic Diagrams CCD, M-Key, Click Conn CCD+ DIGITAL MIC CLICK CONN M: uP7553 ---- 6-02-07553-9C0 AP2821KTR-G1 6-02-02821-9C0 3.3VS CCD_PW R J_LED2 40 mil LED_HDD# VOUT AIRPLAN_LED# [39] C714 LED_BAT_FULL [39] C724 LED_BAT_CHG [39] 1u_6.3V_X5R_04 2.2u_6.3V_X5R_04 LED_PW R [39] LED_ACIN [39] uP7553 LED_NUM# [38,39]...

  • Page 85: Usb 3.0, Usb Charger

    Schematic Diagrams USB 3.0, USB Charger USB POWER SWITCH REAR J_USB1 value 22u_6.3V_X5R_08 USBVCC3.0_3 6-20-B4A30-009 N150 default 22u_6.3V_X5R_08 93-0022-02 0.1u_10V_X5R_04 6-20-B4A10-009 USBVCC3.0_3 C606 0.1u_10V_X7R_04 USB3_TX3_P_L USB3_TX3_P_R N157 [27] USB3_TX3_P 93-0022-03 100 mil U140 100 mil C607 0.1u_10V_X7R_04 USB3_TX3_N_L USB3_TX3_N_R [27] USB3_TX3_N J_USB1 VOUT...

  • Page 86: Lan Rtl8411B, Card Reader

    Schematic Diagrams LAN RTL8411B, Card Reader LAN (RTL8411B) 6 IN 1 SOCKET - MMC / RSMMC RSET R605 2.49K_1%_04 D02 0714 R562 *28mil_short_06 - SD / mini SD / SDHC / SDXC R589 *1K_04 XTAL2 VDD10 (>20mil) J_CARD_REV1 R587 *10K_04 AVDD33 R601 1M_04...

  • Page 87: Hdmi, Ps8407A

    Schematic Diagrams HDMI, PS8407A HDMI CONNECTOR ( W/ HDMI Repeater) HDMI_5VS For ESD HDMI_5VS 2.2K_04 2.2K_04 J_HDMI1 100 mil 100 mil *BAV99 *BAV99 *BAV99 VOUT C598 C604 HDMI_SCL-C 22u_6.3V_X5R_08 22u_6.3V_X5R_08 HDMI_HPD-C HOT PLUG DETECT HDMI_SDA-C [14,40,42] SUSB DDC/CEC GND HDMI_SDA-C HDMI_HPD-C SY6288D20AAC HDMI_SCL-C...

  • Page 88: Audio Codec Alc269

    Schematic Diagrams Audio Codec ALC269 EMI Require CODEC (ALC269 VC2) R2008 *20mil_short_04 R284 *20mil_short_04 PVDD1_2 R2009 HCB1005KF-121T20 C519 0.1u_10V_X5R_04 DVDD_IO C548 C563 C828 1M_04 C1828 C518 0.1u_10V_X5R_04 HP_JSGND_EN [32] R300 *20mil_short_04 10u_6.3V_X5R_06 0.1u_10V_X5R_04 10u_6.3V_X5R_06 0.1u_10V_X5R_04 3.3VS_AUD C531 C529 AUDG R2026 1M_04 10u_6.3V_X5R_06 0.1u_10V_X5R_04...

  • Page 89: Hdd, Tpm, Kb Led, Pwr Con, T/P

    M_BTN# [40] LID_SW # [12,39] LED_NUM# [33,39] 5VS_KB VOUT C785 LED_CAP# [33,39] VSET C1698 *50501-0060N-001 50501-0060N-001 LED_SCROLL# [33,39] FOR N170RD FOR N150RD 0.1u_10V_X5R_04 NCT3940S-A 88486-0801 0.01u_50V_X7R_04 *V15AVLC0402 KBLIGHT_ADJ [39] D02 0703 3.3VS M-MARK M-MARK M-MARK M-MARK C111D111N C126D126N C111D111N C126D126N...

  • Page 90: Kbc-Ite It8587

    0.1u_10V_X5R_04 *0.1u_10V_X5R_04 *0.1u_10V_X5R_04 U23B J_KB1 C588 [26] SUSACK#_EC GPJ0/TACH2 5VT/SSCE0#/GPG2 GPJ4/DAC4/DCD0# HCB1005KF-121T20 0.1u_10V_X5R_04 KBC_AGND [32] VGA_FAN GPJ5/DAC5/RIG0# EC_VCC 3.3VS N150RD 3G_DET# N170RD [38] KBLIGHT_ADJ 3G_DET# [32] GPJ2/DAC2//TACH0B KSO16/SMOSI/GPC3 EMI solution KSO17/SMISO/GPC5 WLAN_EN [32] J_KB1 J_KB2 [26] ME_WE GPI2/ADC2 U23A *85208-24051...

  • Page 91: System Power

    Schematic Diagrams System Power DD_ON# VDD3 3.3VA R263 SUSB 10K_04 VDD3 DD_ON# DD_ON# [34,42] 3.3VA 1.5A C494 R192 U143 1.5A *0.1u_16V_Y5V_04 100K_04 VDD3 [34,39,41] DD_ON VOUT MTN7002ZHS3 VIN/SS C1797 C1798 R271 SUSB SUSB [14,36,42] BIOS+EC setup *1u_6.3V_X5R_04 0.1u_10V_X5R_04 100K_04 G0, S5, S4:low uP7553 R1935 C1704...

  • Page 92: Vdd3, Vdd5

    Schematic Diagrams VDD3, VDD5 VDD3/VDD5 VREF PR201 *20mil_short_04 PR194 *0_04 PC172 1u_6.3V_X5R_04 PR191 PR204 EN_3V EN_5V PC166 140K_1%_04 100K_1%_04 PC175 1000p_50V_X7R_04 1000p_50V_X7R_04 VREG3 PC160 PC165 VDD3_5_POK [43] VDD5 PR205 *10K_04 4.7u_25V_X5R_08 1u_6.3V_X5R_04 PC1164 C776 VDD3 SYS5V LDO3 PC163 PC161 PC162 PC164 0.1u_10V_X5R_04 PC174...

  • Page 93: Dram Power

    Schematic Diagrams DRAM Power 1.35V/0.675VS PQ38 MDU1516 PC154 PC138 PC137 PC155 ULTRASO-8 PC142 VDDQ_VTT RB0540S2 G5616 *15u_25V_6.3*4.4 Z3709 VDDQ_R PC53 PC48 0.1u_10V_X5R_04 DEFAULT SHORT VLDOIN VBST 10u_6.3V_X5R_06 PR67 DEFAULT SHORT Z3701 Z3710 Z3718 VDDQ_VTT DRVH VDDQ PL11 VDDQ_R 0_04 PJ11 *OPEN-2mm 1.0UH_10*10*4.5 PR75...

  • Page 94: Power 1.0V, Vccio

    Schematic Diagrams Power 1.0V, VCCIO For CV test D02 0708 VDD1.0 R1892 100K_04 PR188 820K_1%_06 VDD3 PJ27 *CV-40mil PC186 PC1155 PC1154 VDD1.0_EN [41] VDD3_5_POK PJ24 PU16 INS297446954 MLP08 PR187 PC179 COMMON 0_06 0.1u_10V_X7R_04 R2025 0_04 [26,39,40,41] EC_SLP_SUS# EN_PSV V1.0A VDD1.0 G5602_5V PL20 DEFAULT SHORT...

  • Page 95: Dx_Vccstg/Vccsfr_Oc

    Schematic Diagrams 1.0DX_VCCSTG/VCCSFR_OC NOTE: 1.0DX_VCCSTG Ton need <65us DEFAULT SHORT 1.0DX_VCCSTG VCCSFR_OC DEFAULT SHORT M5938 TURON-ON TIME=60us 1.0DX_VCCSTG VDD1.0 VCCSFR_OC U131 VDDQ PJ59 *OPEN_1A U132 PJ65 *OPEN_1A VOUT C1423 C1421 C1420 C1422 VOUT C1527 C1526 C1524 C1525 VOUT VOUT VOUT R1625 VOUT VDD3...

  • Page 96: Vcore, Vccsa

    Schematic Diagrams VCore, VCCSA ,QWHO 6.</$.( ,093 32:(5 &.7   3+$6( VCORE_PROG 3.3VS 3.3VS 1.0V_VCCST CONFIGURATION PR233 PR234 PR375 1K_1%_04 PR236 13K_1%_04 PR235 100K_04 2.2_06 PR237 PR238 PR239 PC236 10K_1%_04 1u_6.3V_X5R_04 PC238 PC237 0.01u_50V_X7R_04 PC240 PC239 100_04 45.3_1%_04 *45.3_1%_04 PUT CLOSE PU19 4.7u_6.3V_X5R_06...

  • Page 97: Vcore & Vccsa Output Stage

    Schematic Diagrams VCore & VCCSA Output Stage DEFAULT SHORT VCCVIN VCORE & VCCSA OUTPUT STAGE PJ68 PC346 PC345 PC349 PC1173 D02 0717 PR396 PC344 PC120 PC131 2.2_06 PR395 2.2_06 0.22u_16V_X7R_06 PU59 NCP81151MNTBG PR390 2.2_1%_06 INS297454682 PR392 10K_06 INS297454650 MLP08 [45] PWM11 MLP08 COMMON...

  • Page 98: Vccgt

    Schematic Diagrams VCCGT ,QWHO 6.</$.( ,093 32:(5 &.7   3+$6( 3.3VS 3.3VS 1.0V_VCCST PR308 PR382 1K_1%_04 PR310 PR309 100K_1%_04 10K_1%_04 2.2_06 PR311 PR312 PR313 PC293 1u_6.3V_X5R_04 PC294 PC295 PUT CLOSE 0.01u_50V_X7R_04 *100_04 *45.3_1%_04 *45.3_1%_04 PC297 4.7u_6.3V_X5R_06 PC296 PU23 TO PWM 0.1u_16V_X7R_04 *0.1u_16V_X7R_04 NCP81203PMNTXG...

  • Page 99: Vccgt Output Stage

    Schematic Diagrams VCCGT Output Stage DEFAULT SHORT VGTVIN PJ70 PC1139 PC1145 PC1176 PC1125 INS297456482 1.05mohm PR411 PR409 MLP08 COMMON 2.2_06 2.2_06 PL16 PU63 0.22u_16V_X7R_06 CMME063T-R15MS0R907 NCP81151MNTBG PR413 VCCGT 2.2_1%_06 PCB Footprint = BCIHP0735A PC1120 PC1121 EEFSX0 D471E4 *EEFSX0 D471E4 PR412 COMMON COMMON [47]...

  • Page 100: Nvvdd

    Schematic Diagrams NVVDD DEFAULT SHORT VGA__NVVDD 3.3VS 3.3VS [39] GPIO6_VBOOT_ADJ PJ25 NVVDD_PSI [21] VTT_SELECT VTT VR Output Voltages *5mm 1.1 V PR91 PR92 high (V1.1S_VTT) 1.05 V PR93 *1K_04 PR90 *0_04 FOR C.V *1K_04 UP1462_REFIN 3V3_MAIN_EN [21,50] 3V3_MAIN_EN 0_04 PR96 0_04 PJ14 *CV-40mil...

  • Page 101: V3_Aon, 3V3_Run, Pex_Vdd

    Schematic Diagrams 3V3_AON, 3V3_RUN, PEX_VDD PEX_VDD PC41 PC44 PR53 PR61 22u_6.3V_X5R_08 10_06 0.1u_10V_X7R_04 10K_1%_04 INS294584007 APW8805 DFN10 COMMON PS6_BOOT_PEXVDD PEX_VDD PR181 10K_04 PR52 *160K_04 3V3_RUN PGOOD [51] PEX_VDD_PWRGD OpenVReg DEFAULT SHORT PR177 15K_04 PS3_1V05_EN *0.01u_16V_X7R_04 3V3_RUN EN/FS 0.400 BOOT/NC 3V3_MAIN_EN PR178 *0_04 BCIHP0412-R47M...

  • Page 102: Fbvddq

    Schematic Diagrams FBVDDQ *CV-40mil 3.3V PR163 *100K_04 PR165 820K_1%_06 3.3V PR157 *10mil_short PR207 PC113 PC104 PC111 PC106 [50] PEX_VDD_PW RGD PR160 GC6 2.0 3.3V PQ31 *10mil_short MDU1516 PR162 *0_04 ULTRASO-8 [49,50] GPU_PW ROK PR158 *10mil_short PR161 PC112 [21,27] GC6_FB_EN 1.35VS 0_06 0.1u_10V_X7R_04 EN_PSV...

  • Page 103: Ac-In, Charger

    Schematic Diagrams AC-In, Charger PR428 PC1167 SMART CHARGER V_BAT PR427 PQ16 PC1166 20K_04 PC1163 EMB20P03V D02 0707 EML1 PQ47 HCB2012KF-800T80 EMB20P03V PQ44 EMB20P03V J_DC_JACK1 EML2 HCB2012KF-800T80 PD23 PC74 PRS3 4.7UH_6.8*7.3*3 PRS4 PC1159 PC1172 PR136 0.01_1%_32 0.01_1%_32 TDC-099DHSR2-L-005-J 470K_04 FMS3004-AS-H PR73 PD24 PQ18 PR126...

  • Page 104: N155, N157 Kb Led, Pwr Board

    Schematic Diagrams N155, N157 KB LED, PWR Board K/B LED PWR LED K_3.3VS K_3.3VS K_3.3VS K_3.3VS White LED White LED White LED NUM LOCK CAPS LOCK SCROLL 1K_04 1K_04 1K_04 1K_04 LOCK LED KD_NUM KD_CAP KD_SCRL RY-SP190DBW71-5A RY-SP190DBW71-5A KD_NUM1 RY-SP190DBW71-5A KD_CAP1 RY-SP190DBW71-5A KD_SCRL1...

  • Page 105: Audio Board

    Schematic Diagrams Audio Board A_3.3V A_5V AUSBVCC3.0_1 A_3.3V A_3.3V 100 mil 100 mil AR12 *4.7K_04 AR13 *0_04 VOUT AR14 *4.7K_04 AR15 *0_04 AR16 AR17 AR18 *4.7K_04 AR19 *0_04 AC11 *4.7K_04 *4.7K_04 AC32 AC36 AC33 AC13 10u_10V_Y5V_08 AI2C_SCK_P5 AR20 *4.7K_04 AR21 *2K_1%_04 *0.01u_16V_X7R_04 *0.1u_10V_X7R_04...

  • Page 106: Front Led Board

    Schematic Diagrams Front LED Board LED BOARD LD_ACIN1 FSL-3227110WA-A4T5NYTLD AIRPLANE HDD LED L_LED_ACIN 2.2K_04 L_3.3VS L_3.3VS L_LED_PWR 2.2K_04 20141211 BCN LGND AC IN/POWER ON LED 6-52-57301-023 6-52-57301-023 2.2K_04 2.2K_04 6-52-55002-040 6-52-57301-023 LD_AIR1 LD_AIR2 LD_HDD1 LD_HDD2 LD_BAT1 FSL-3227110WA-A4T5NYTLD RY-SP190DBW71-5A RY-SP190DBW71-5A RY-SP190DBW71-5A RY-SP190DBW71-5A FOR 150 Sheet 55 of 62...

  • Page 107: Click / Finger Con Board

    Schematic Diagrams Click / Finger Con Board 0420 connect to TP(100*55) connect to button module TJ_TP1 TJ_TPBTN1 H6_0D3_7 H6_0D3_7 T_TP_BTN_L T_TP_BTN_L T_TP_BTN_R T_TP_BTN_R FP226H-004S10M 85201-04L PCB Footprint = 85201-0405L-1 TGND TGND TGND TGND TUSB_PN10 TUSB_PN10_R TUSB_PP10 TUSB_PP10_R TJ_FPB1 Sheet 56 of 62 TGND TGND T2.5V...

  • Page 108: Fingerprint Board

    Schematic Diagrams Fingerprint Board NOTE: MODE MODE=HIGH (NC) , USB MODE MODE=LOW , SPI MODE EGND MODE FUSB_PP F3.3V AVDD FUSB_PN F2.5V F2.5V DVDD FMOSI F3.3V F3.3V VDDIO UVDD FMCLK FLED1 FLED1 FMCS FMCS FLED2 LED1 SPI_CS Sheet 57 of 62 FMISO FDISCON FMOSI...

  • Page 109: N150 Lid, Pwr Sw Board

    Schematic Diagrams N150 LID, PWR SW Board N150 LID/ PWR SW BOARD S_VDD3 100K_04 0.01A S_LID_SW # MH248-ALFA-ESO *1u_10V_Y5V_06 0.1u_16V_Y5V_04 *100p_50V_NPO_04 6-02-00248-LC2 6-02-03661-LC1 Sheet 58 of 62 SGND SGND SGND S_3.3VS N150SD SGND SJ_SW 1 S_VDD3 N150 LID, PWR SW S_3.3VS SGND S_PW RBTN#...

  • Page 110: N170 Lid, Pwr Sw Board

    Schematic Diagrams N170 LID, PWR SW Board N170 LID/ PWR SW BOARD C_VDD3 100K_04 0.01A C_LID_SW# MH248-ALFA-ESO *1u_10V_Y5V_06 0.1u_16V_Y5V_04 *100p_50V_NPO_04 6-02-00248-LC2 6-02-03661-LC1 Sheet 59 of 62 CGND CGND CGND C_3.3VS CGND CJ_SW2 C_VDD3 N170 LID, PWR SW C_3.3VS CGND C_PWRBTN# C_LID_SW# Board 1K_04...

  • Page 111: N170 Odd Ext. Board

    Schematic Diagrams N170 ODD Ext. Board ODD TRANSFER BOARD QJ_ODD1 QJ_ODD2 Q_SATA_TXP1 Q_SATA_TXN1 Q_SATA_RXN1 Q_SATA_RXP1 QGND QGND Sheet 60 of 62 Q_ODD_DETECT# Q_5VS Q_5VS N170 ODD Ext. Q_SATA_ODD_DA# Board C18609-11305-L C185J9-11308-L GND1~2=QGND QGND QGND 6-21-14020-013 6-21-13800-013 MTH6_0D2_3 MTH6_0D2_3 *0_04 *0_04 QGND QGND *0_04...

  • Page 112: Power Sequence

    Schematic Diagrams Power Sequence N15/170RD PWR SEQ BIOS:1.05.E2A , EC:1.05.E4 Warm reset ref to H_PDG ver 1.2, P467 G3 to S0 G3 status S4_STATE# 47.252ms, min 9ms (tPCH01:VCC_RTC 90% to RTC_RST# Vih (VCC_RTC*75%)) VCC_RTC 236.5us, min 210us (tPCH22) 73us, min 60us (tPCH23) RTC_RST# PLT_RST# 6.7ms, 1~10ms (tPCH21)

  • Page 113: Option Bom

    Schematic Diagrams Option BOM LVDS N150 default N157 R240 0_04 R1950 0_04 R312 0_04 R237 0_04 R1951 0_04 R1966 0_04 J_KB2 J_KB1 KB_CON J_USB2 6-21-B4A60-009 R224 0_04 R1952 0_04 R326 10_06 J_LEDKB2 J_LEDKB1 6-21-B4A20-009 AJ_USB1 R220 0_04 R1953 0_04 R329 0_04 C19009-90905-L C19009-10939...
  • Page 114 Schematic Diagrams B - 64...

  • Page 115: Updating The Flash Rom Bios

    Download the BIOS computer model. 1. Go to www.clevo.com.tw and point to E-Services and click E-Channel. Note that BIOS versions 2. Use your user ID and password to access the appropriate download area (BIOS), and download the latest BIOS files...

  • Page 116: Use The Flash Tools To Update The Bios

    BIOS Update Use the flash tools to update the BIOS 1. Make sure you are not loading any memory management programs such as HIMEM by holding the F8 key as you see the message “EFI Shell”. You will then be prompted to give “Y” or “N” responses to the programs being loaded by EFI Shell.

This manual is also suitable for:

N151rd

Table of Contents
