SPLIT TYPE

ROOM AIR CONDITIONER

WALL MOUNTED TYPE

Indoor unit

ASYG09LTCB
C ONT EN T S
SPECIFICATIONS. . . . . . . . . . . . . . . . . . .
DIMENSIONS . . . . . . . . . . . . . . . . . . . . . .
REFRIGERANT SYSTEM DIAGRAM. . . .
CIRCUIT DIAGRAM . . . . . . . . . . . . . . . . .
INDOOR PCB CIRCUIT DIAGRAM . . . . .
OUTDOOR PCB CIRCUIT DIAGRAM . . .
ERROR DETECTION . . . . . . . . . . . . . . .
PARTS (INDOOR UNIT) . . . . . . . . . . . . .
PARTS (OUTDOOR UNIT) . . . . . . . . . . .
ACCESSORIES . . . . . . . . . . . . . . . . . . .

Outdoor unit

AOYG09LTCN
1
2
3
4
5
9
11
13
18
21

Advertisement

Table of Contents
loading

Summary of Contents for Fujitsu ASYG09LTCB

  • Page 1: Room Air Conditioner

    ROOM AIR CONDITIONER WALL MOUNTED TYPE Indoor unit Outdoor unit ASYG09LTCB AOYG09LTCN C ONT EN T S SPECIFICATIONS....DIMENSIONS ..... .
  • Page 2 SP E C I F IC A T IO N S ELECTRICAL DATA NOISE LEVEL High speed TYPE Cool & heat inverter 42 dB INDOOR INDOOR UNIT ASYG09LTCB Medium speed 36 dB UNIT Low speed OUTDOOR UNIT AOYG09LTCN 32 dB Cooling...
  • Page 3 D I M E N S I ON S unit : mm INDOOR UNIT Drain hose length 600 mm Drain pipe diameter Inside : 14.2 mm Outside : 16.2 mm OUTDOOR UNIT 2011.09.12...
  • Page 4: Refrigerant System Diagram

    R EF R IG E RA NT S Y S T EM D IA GRAM Heat exchanger (indoor unit) 2-way valve 3-way valve Muffler Strainer 4-way valve Expansion valve Heat exchanger (outdoor unit) Strainer Refrigerant direction Cooling Heating Refrigerant pipe diameter Liquid : 1/4"...
  • Page 8 INDOOR UNIT INDICATOR PCB ASSEMBLY K10CX-1000HSE-D0 CN201 8 - JB / PL I D204 L=250 #26 / 1061 UDZS6.2B D201 SLR-343ECT <GREEN> D205 UDZS6.2B D202 SL I-343DCT <ORANGE> SW201 D206 KSHC611BT UDZS6.2B D203 SLR-343ECT <GREEN> R202 <1/4W> C203 C204 <F> I C201 GP1UM271R R201...
  • Page 12: Error Detection

    Indoor unit display ERRO R DET E C TIO N INDOOR UNIT REMOTE CONTROL If you use a wireless remote control, the lamp on the photo detector unit will output error codes by way of blinking patterns. If you use a wired remote control, error codes OPERATION indicator lamp (green) will appear on the remote control display.
  • Page 13 OUTDOOR UNIT ERROR Discharge temperature abnormal 5.0 second on / 5.0 second off DC fan abnormal 2.0 second on / 2.0 second off CT abnormal 0.5 second on / 0.5 second off IPM overcurrent protection 0.1 second on / 0.1 second off Thermistor abnormal 0.1 second on / 2.0 second off Compressor location abnormal...
  • Page 14 P AR T S INDOOR UNIT Ref. Description Part number Bracket Panel 9318913002 Wire Cover 9318911008 Wire Shield 9318919004 Under Cover 9318879001 Louver (Upper) 9318880007 Louver (Lower) 9318881004 Air Clean Filter Assy 9317250009 Remote Control 9319207001 Remote Control Holder 9318912005 2011.09.13...
  • Page 15: Front Panel

    INDOOR UNIT Front panel Ref. Description Part number Front Panel Total Assy 9319348148 Air Filter 9318883008 Intake Grille Assy 9319351155 Front Panel 9318876000 Front Panel Cover T 9318909005 Display Plate Holder L 9318894004 Display Plate Holder R 9318895001 Display Plate R 9318893007 Arm Cover 9318900002...
  • Page 16 INDOOR UNIT Evaporator Ref. Description Part number Evaporator Total Assy 9319327006 Joint Pipe Assy 9319322001 Joint Pipe Holder 9318901009 Base 9318874006 Filter Guide 9318887006 Evaporator Holder L 9318875003 Air Seal 9319295008 2011.03.08...
  • Page 17: Control Box

    INDOOR UNIT Control box Ref. Description Part number Ref. Description Part number Cover Shield A 9318916003 Gear B 9319294001 Control Box 9318882001 Panel Gear 9319293004 43 Box Shield Assy 9319344003 Gear Case 9318903003 Controller PCB Assy 9708713052 Switch Case 9319332000 Terminal 9900638009 Grille Key Top...
  • Page 18 INDOOR UNIT Casing assy Ref. Description Part number Ref. Description Part number Fan Motor 9602947003 Pipe Bracket 9318889000 Crossflow Fan Assy 9319361000 Panel Cover 9319296005 Bearing C Assy 9306628017 Louver Holder 9318886009 Casing Assy 9319342009 R and L Louver 9318885002 Casing 9318873009 Motor Step...
  • Page 19 Ref. Description Part number 1 Front Panel Assy 9317760041 2 Emblem 9319151007 Cabinet Left Assy 9318247008 4 Top Panel Assy 9317761017 5 Protective Net 9318635003 6 Thermistor Holder 9313954031 Switch Cover A Assy 9317795005 8 Switch Cover B 9317582001 9 Grip 9317588003 10 Cabinet Right Assy 9317759007...
  • Page 20 OUTDOOR UNIT Ref. Description Part number Condenser Total Assy 9332359005 Compressor Assy 9317619004 2 way Valve Assy 9332371000 3 way Valve Sub Assy 9317109000 4 way Valve Assy 9332365009 Solenoid 9970110047 Pulse Motor Valve Assy 9332368000 Expansion Valve Coil 9970095030 2011.09.14...
  • Page 21 OUTDOOR UNIT Ref. Description Part number 31 Sealed Panel 9309913011 Controller PCB Assy 9708753164 33 PCB Holder 9313074029 Inverter Case Assy 9315690081 35 Terminal Bracket 9315233073 36 Terminal 6P 9900435028 -- Outdoor Thermistor 9900544010 -- Thermistor Assy 9900614003 2011.09.14...
  • Page 22 A C CES SO RI E S INDOOR UNIT Name and Shape Part number Bracket panel 9318913002 Remote control 9319207001 Remote control holder 9318912005 Battery (penlight) 0600185046 Cloth tape 9308117007 Tapping screw (big) 4 x 25) 0700076046 Tapping screw (small) 3 x 12) 0700019036 Air cleaning filter...
  • Page 23 1109G3963...
